Transactions

1
Transactions
2
Definition

• Transaction a collection of operations
  performing a single logical function
• written in high-level language (C, Java, SQL)
• delimited by BEGIN TRANSCATION and END
  TRANSACTION
• ACID properties

3
ACID

• Atomicity all operations in the transaction are
  executed properly or none
• both UPDATE operations need to be performed
• Consistency the execution of a single
  transaction preserves the consistency of the
  database
• the sum of balances should remain unchanged after
  execution
• Isolation each transaction is unaware of other
  transactions executed concurrently
• Ti finished before Tj started
• Durability changes the transaction have
  performed persist in the database
• recovery

4
Transaction States

• active initial state, transaction stays in this
  state while executing
• partially committed after the final operation
  has been performed
• failed when normal execution cannot proceed
• aborted transaction has been rolled back
  restoring into prior state
• committed successful completion

5
Abstraction of transaction

• a sequence of read and write operations
• T1 r1(balanceA), w1(balanceA), r1(balanceB),
  w1(balanceB)
• other operations
• ci commit everything done
• ai abort and roll back

6
Recovery
7
Example

• T1 r1(balanceA), w1(balanceA), r1(balanceB),
  w1(balanceB)

8
Failure Classification

• Transaction failure
• logical error
• e.g. bad input
• system error
• e.g. deadlock
• System crash
• e.g. bug
• Disk failure

9
Recovery algorithms

• ensure there is enough information to allow
  recovery from failure
• actions taken after failure to ensure
  consistency, atomicity and durability
• examples
• dirty pages not written to disk when failure
  occurs
• need to reexecute operation REDO
• partial writes have been performed
• need to UNDO operations

10
Log-based Recovery

• Record modification in log
• stored in disk
• sequence of log records
• transaction identifier
• data-item identifier
• old value
• new value
• ltTi startgt
• ltTi abortgt
• ltTi commitgt
• ltTi, Item, OldValue, NewValuegt

11
Example

• For each transaction and each write operation
  write log records to disk
• ltT1 startgt
• ltT1, balanceA, 1000, 900gt
• ltT1, balanceB, 900, 1000gt
• ltT1 commitgt
• Problems?

12
Write-ahead logging

• disk access for each write
• high overhead
• use buffer
• but log records might be lost!
• log records stored in stable storage (e.g RAID)
• write-ahead logging
• before data are changed log records are created
• if transaction commits, flush log to disc

13
Recovery procedure (1/2)

• Scan back through the log
• collect set of committed transactions C
• UNDO any transaction not in C
• Scan forward through the log
• REDO any transaction in C

14
Log Exercise

• Perform recovery from the current to the
  recovered state
• ltT4 startgt
• ltT1 startgt
• ltT1, balance56, 94340.45, 84340.95gt
• ltT2 startgt
• ltT2, balance34, 10900.67, 8900.67gt
• ltT2, balance67, 34005.00, 36005.25gt
• ltT7 startgt
• ltT2 commitgt
• ltT1, balance34, 8900.67, 18900.67gt
• ltT7, balance67, 36005.25, 37005.25gt
• ltT7 abortgt
• ltT4 commitgt

15
Recovery procedure (2/2)

• Any problems?
• need to read complete log
• time consuming
• unnecessary (when most of the REDO operations
  have already been written onto disk)
• Use checkpoints
• write all log records to stable storage
• write all dirty pages to disk
• store log record ltcheckpoint Lgt to stable storage
• L list of active transactions
• Recovery needed up to checkpoint
• faster
• shorter log
• updates are suspended

16
Checkpoint

• scan backwards until checkpoint
• collect set of committed transactions C
• the records of each transaction in L which is not
  in C must be UNDOne
• UNDO any transaction not in C (all its
  operations)
• REDO each record of transaction in C

17
Fuzzy Checkpoint

• checkpoint can be slow if many pages to write
• everything suspended
• fuzzy checkpoint
• permit updates after ltcheckpointgt has been
  written before modified pages written to disk
• incomplete checkpoints
• last-checkpoint record
• keep a list of modified pages
• update last-checkpoint when all modified pages
  have been written to disk

18
Concurrency
19
Concurrent Execution

• improved throughput
• number of transactions executed in given time
• improved resource utilization
• reduced waiting time
• dont need to wait behind long transactions
• transaction histories interleave
• what happens when transactions access common
  items?
• preserve isolation (ACID)

20
Examples

• H1 r1(b56), w1(b56), r1(b34), w1(b34), c1
• H2 r2(b34), w2(b34), r2(b67), w2(b67), c2
• Possible concurrent executions
• order preserved
• Hx r2(b34), r1(b56), w1(b56), r1(b34), w1(b34),
  c1,w2(b34), r2(b67), w2(b67), c2
• Hy r2(b34), w2(b34), r1(b56), w1(b56), r1(b34),
  w1(b34), c1, r2(b67), w2(b67), c2

21
Restrictions in transactions

• Example
• H r1(a), w1(a), r2(a), c2,r1(b), fail
• Whats the problem here?
• non-recoverable history
• recoverable histories
• transaction does not commit until all
  transactions it has read from have committed
• Rolling back
• H r1(a), w1(b), w1(a), r2(a), w2(a), r2(a), a1
• problem?
• cascadeless history
• transactions reads only from committed
  transactions

22
More Examples and Problems
transfer(From, To, Amount)
T1 transfer(56, 34, 10000)
T2 transfer(34, 67, 2000)
23
Anomaly 1 Lost Update
T1 transfer(56, 34, 10000)
T2 transfer(34, 67, 2000)
H2
H1
r1(b56), w1(b56), r1(b34), w1(b34), c1
r2(b34), w2(b34), r2(b67), w2(b67), c2
Hx
r2(b34,18900.67), r1(b56 ,84340.45), w1(b56
,74340.45), r1(b34 ,18900.67), w1(b34
,28900.67), c1,w2(b34 ,16900.67),
r2(b67,34005.00), w2(b67 ,36005.00), c2
24
Concurrency anomalies

• Must ensure that concurrent execution is free of
  anomalies
• e.g. lost update, inconsistent analysis, dirty
  writes, etc.
• use a serial history
• no interleaving!

25
Serialization

• Isolation (ACID) each transaction is unaware of
  other transactions executed concurrently
• Ti finished before Tj started
• Serial history all operations of a given
  transaction appear together, one after the other
• Hz r2(b34), w2(b34), r2(b67), w2(b67),
  c2,r1(b56), w1(b56), r1(b34), w1(b34), c1
• T2,T1
• All histories equivalent to a serial history are
  also accepted (and they are free of concurrency
  anomalies)
• serializable histories

26
When are two histories equivalent?

• equivalence
• view equivalence
• conflict equivalence
• view equivalence
• database ends in the same state
• writes and reads are performed in the same order
  in the two histories
• there have the same final writes
• but, difficult to test at run time
• conflict equivalence
• two operations conflict if they belong to
  different transactions and one of them is a write
• two histories are conflict equivalent if the
  order of the conflicting operations is the same
• conflict serializable
• a history is conflict serializable if it is
  conflict equivalent with a serial history

27
Conflict serializable history
r2(b34), w2(b34), r2(b67), w2(b67), c2, r1(b56),
w1(b56), r1(b34), w1(b34), c1,
28
Identifying conflict serializability

• For history H, create precedence graph Gh
• a node for each transaction in H
• a directed edge for each pair OP1, OP2 of
  conflicting operations
• OP1 appears before OP2 in H
• H is conflict serializable if
• no cycles in Gh

29
Example

• H r1(a), w1(a), r1(b), r2(b), w2(b), w1(b)
• Not conflict serializable

T1
T2
30
Serializability Exercise

• Are the following histories conflict-serializable?

• Hx r2(b34), r1(b56), w1(b56), r1(b34), w1(b34),
  c1,w2(b34), r2(b67), w2(b67), c2
• Hy r2(b34), w2(b34), r1(b56), w1(b56), r1(b34),
  w1(b34), c1, r2(b67), w2(b67), c2
• Hz r1(a), w1(a), w3(b), w3(c), r2(c), r1(a),
  w1(b), w2(b)
• which are their equivalent serial histories (if
  they have one)?

31
Concurrency control protocols
32
So far

• Transactions
• Recoverable histories
• H r1(a), w1(a), r2(a), w2(a), c2,r1(b), fail
• recovery procedures
• Concurrency
• Hx r2(b34), r1(b56), w1(b56), r1(b34), w1(b34),
  c1,w2(b34), r2(b67), w2(b67), c2
• serializable histories
• desirable
• cascadeless histories

33
Concurrency control protocol

• protocols that schedule operations (r,w) so that
  transactions executing concurrently generate only
  serializable histories
• lock-based protocols
• using locks to protect items
• timestamp-based protocols
• transactions are assigned a timestamp (unique
  identifier)

34
Lock-based Protocols (1/2)

• l(item) . op(item) u(item)
• lock manager
• if Ti requests for an item already locked by Tj
  then Ti goes into wait queue
• binary lock lock - unlock
• T1 l1(a), r1(a), u1(a), l1(b), r1(b), b ab,
  w1(b), u1(b)
• T2 l2(b), r2(b), u2(b), l2(a), r2(a), a ab,
  w2(a), u2(a)
• concurrently l1(a), r1(a), u1(a), l2(b), r2(b),
  u2(b),
• l2(a), r2(a), a ab, w2(a), u2(a), l1(b),
  r1(b), b ab,
• w1(b), u1(b)
• initially, a5, b10
• T1,T2 b15, a20
• T2,T1 a15, b35
• concurrently a15, b15, not serializable

35
Lock-based Protocols (2/2)

• batch locking
• acquire all locks at start time
• release all locks at commit/abort time
• example
• l(b56),l(b34),r1(b56), w1(b56), r1(b34), w1(b34),
  c1,u(b34), u(b56)
• does this guarantee serializability,recoverability
  ? problems?

36
Two-Phase Locking (1/2)

• read locks rl(item) ru(item)
• shared
• write locks wl(item) wu(item)
• exclusive
• downgrade from wl to rl
• upgrade from rl to wl
• two phases
• growing phase
• shrinking phase
• once a lock released,
• no more locks acquired

37
Two-Phase Locking (2/2)

• does 2PL guarantee serializability,
  recoverability?
• but
• T1 wl1(a), w1(a), wl1(b), w1(b), wu1(b), wu1(a)
• T2 wl2(b), w2(b), wl2(a), w2(a), wu2(a), wu2(b)
• concurrently wl1(a), w1(a), wl2(b), w2(b),
  deadlock
• T1 waits for lock on b
• T2 waits for lock on a
• 2PL susceptible to deadlocks
• waits-for graph

38
Variants of 2PL

• basic 2PL
• serializable
• not recoverable
• deadlocks
• conservative 2PL
• serializable
• not recoverable
• no deadlocks
• strict 2PL
• serializable
• recoverable
• deadlocks

39
Preventing deadlocks

• conservative 2PL
• using timestamps
• timestamp TS(Ti) for transaction Ti
• unique identifier for each transaction
• monotonically increasing
• if Ti started before Tj TS(Ti) lt TS(Tj)
• Ti waits for lock on item X that Tj holds
• wait-die if TS(Ti) lt TS(Tj) Ti waits
• else Ti aborts and restarts with the same
  timestamp
• wound-wait if TS(Ti) lt TS(Tj) Tj aborted and
  restarted with same timestamp
• else Ti waits
• deadlock-free why?

40
Deadlock Detection

• construct wait-for graphs
• deadlock when cycle
• select victim transaction
• expensive in space and time
• timeouts
• if waiting exceeds specified timeout, abort

41
Livelocks

• deadlock preventions
• transactions aborted based on timestamp
• deadlock detection
• transactions aborted to break waits-for cycle
• transactions are assigned a priority
• priority increased with time
• abort transactions with less priority

42
Timestamp-based protocols (1/2)

• concurrency control
• timestamp ordering
• history equivalent to the serial order
  corresponding to timestamps
• for each item accessed by conflicting operation
  doesnt violate serializability order
• read_TS(item)
• write_TS(item)
• basic timestamp ordering
• TS(T) lt read_TS(item), write_TS(item)
• T aborted

43
Timestamp-based protocols (2/2)

• T1 r1(a), w1(a)
• T2 w2(a)
• concurrently
• r1(a),
• read_TS(a) 1
• w2(a),
• TS(T2) 2 gt read_TS(a) 1
• write_TS(a) 2
• w1(a)
• TS(T1) 1 lt write_TS(a) 2
• T1 aborted
• but, w1(a) doesnt neet to be executed
• if T issues a write(X), and write_TS(X) gt TS(T),
  ignore write
• Thomas Write rule

44
Delete and Insert operations

• what are the conflicts when delete and insert
  operations are also examined?
• how should the locking protocols be adapted?
• how about timestamp ordering?
