CS204 : Advanced C Prog' Threads

1
CS-204 Advanced C Prog.Threads
2
Motivation

• You are assigned to implement a web server which
  will handle multiple user connections at the same
  time,
• You do not know in advance how many users will
  connect to your web server
• You do not know how the interaction will be
  between your server and the user (some users just
  connect to your server but do not interact with
  it)
• You need to share the CPU time equally between
  the connections (your clients)
• You can not block one user to get an interaction
  request from another

3
Motivation

• You are implementing a 3D multiplayer game, and
  you need to be responsive to each player. How can
  you do this ? While waiting for the first
  players input, how can you let the second player
  to do something ?
• Or you are implementing an image processor which
  has a GUI, and your program uses a heavy-weight
  function which takes a considerable amount of
  time to return, how can you redraw the GUI and
  handle user interactions while this function does
  its job ?

4
Motivation

• Basically, when you are doing something that
  blocks the CPU, you will need threads (which will
  manage the CPU usage among multiple requests)
• Similarly, if you have a big job, multiple
  processors
• it would be easier to divide a heavy job into
  smaller ones and let each processor do some
  portion of it and then combine the result.

5
General Description

• Thread is a unit of execution that accomplishes a
  task
• A thread belongs to a process. It can not live on
  its own.
• Each process has at least one running thread
  (primary).
• Thread ? Task
• Read numbers from a file
• Display graphical user interface
• Do mathematical calculations
• ...
• At each instant, the CPU is addressing only one
  thread, but by rotating among threads, it gives
  the feeling that each thread is handled
  simultaneously

6
Thread vs. Process

• Both threads and processes are methods of
  parallelizing an application.
• However, processes are independent execution
  units that contain their own state information,
  use their own address spaces, and only interact
  with each other via interprocess communication
  mechanisms.
• By contrast, a thread is a coding construct. A
  single process might contain multiple threads
  all threads within a process share the same state
  and same memory space, and can communicate with
  each other directly, because they share the same
  variables

7
Thread vs. Process

• Per Process Items
• Address Space
• Global Variables
• Open Files
• Child Processes
• Signals
• Accounting Info.

• Per Thread Items
• Program Counter
• Registers
• Stack
• Thread State
• Signals

8
Thread vs. Process

• Each process provides the resources needed to
  execute a program. A process has,
• A virtual address space,
• Executable code,
• Open handles to system objects,
• A unique process identifier,
• Environment variables,
• A priority class,
• And at least one thread of execution.
• Each process is started with a single thread,
  often called the primary thread, but can create
  additional threads from any of its threads.

9
Thread vs. Process

• A thread is the entity within a process that can
  be scheduled for execution.
• All threads of a process share its virtual
  address space and system resources.
• Each thread maintains
• Exception handlers,
• A scheduling priority,
• Thread local storage,
• A unique thread identifier,
• And a set of structures the system will use to
  save the thread context until it is scheduled
  (thread's set of machine registers, the kernel
  stack, a thread environment block, and a user
  stack in the address space of the thread's
  process)

10
Process Spawning

• We saw that processes can be spawned (executed)
  to parallelize the application, Win32 and MFC
  provides proper methods and functions to
  accomplish this
• CreateProcess
• ShellExecute
• Demo code ...
• But what happens if we want to do communication
  and share data between processes ? Why ?
• IPC (Inter Process Communication)
• Sockets, Pipes, Shared Memory
• What about management of the processes ?
• Killed by the system or killed by the user

11
Single vs. Multi Threads
12
Threads

• Todays many operating systems (Windows, Linux,
  BSD, Solaris) support the multi-threading on
  various levels
• Kernel Level
• User Level
• Hybrid
• We will cover user level threads

13
Threads in Windows (MFC)

• Thread Operations
• Creating Threads
• Suspending/Resuming Threads
• Terminating/Exiting Threads
• Synchronizing Execution of Multiple Threads

14
Threads in MFC

• MFC distinguishes two types of threads
• User-interface threads and worker threads.
• User-interface threads are commonly used to
  handle user input and respond to events and
  messages generated by the user.
• Worker threads are commonly used to complete
  tasks, such as recalculation, heavy-weight
  functions that do not require user input.

15
Worker Threads

• A worker thread is commonly used to handle
  background tasks that the user should not have to
  wait for to continue using your application.
• Tasks such as
• Heavy-weight mathematical calculations
• Background printing
• Creating a worker thread is a relatively simple.
  Only two steps are required to get your thread
  running
• Implementing the controlling function
• Starting the thread.

16
Controlling Function

• The controlling function defines the thread. When
  this function is entered, the thread starts, and
  when it exits, the thread terminates. This
  function should have the following prototype
• UINT AnyControllingFunction ( LPVOID pParam )

17
SOME TYPES DEFINED IN WIN API

• typedef int BOOL
• typedef unsigned int UINT
• typedef int INT
• typedef char CHAR
• typedef unsigned char BYTE
• typedef void VOID
• typedef float FLOAT
• typedef FLOAT PFLOAT //pointer to
  float
• typedef void LPVOID //pointer to void
• typedef CHAR LPSTR
• typedef const CHAR LPCSTR
• typedef void PVOID
• typedef PVOID HANDLE
• typedef HANDLE HINSTANCE
• typedef HANDLE HLOCAL
• typedef char PSTR
• ...

18
Controlling Function

• UINT AnyControllingFunction ( LPVOID pParam )
• The parameter is a single value.
• It was passed to the constructor when the thread
  object was created.
• The controlling function can interpret this value
  in any manner it chooses. It can be treated as
• A scalar value
• A pointer to a structure containing multiple
  parameters
• It can be ignored.
• If the parameter refers to a structure, the
  structure can be used not only to pass data from
  the caller to the thread, but also to pass data
  back from the thread to the caller.

19
Starting Worker Threads

• You can derive a class if you need a special
  version of CWinThread, but it is not required for
  most simple worker threads. You can use
  CWinThread without modification
• To start your worker thread call,
• AfxBeginThread with providing the following
  information
• The address of the controlling function
• The parameter to be passed to the controlling
  function
• pNewObject new MyObject
• AfxBeginThread(MyControlFunc, pNewObject)

CWinThread AfxBeginThread( AFX_THREADPROC
pfnThreadProc, LPVOID pParam, int nPriority
THREAD_PRIORITY_NORMAL, UINT nStackSize
0, DWORD dwCreateFlags 0,
LPSECURITY_ATTRIBUTES lpSecurityAttrs NULL )
20
Worker Thread Example

• include "stdafx.h"
• include ltiostreamgt
• using stdcout
• using stdendl
• UINT MyThreadFunc1 (LPVOID param)
• while (true)
• cout ltlt "Worker with no param" ltlt endl
• Sleep (500)
• return 0
• UINT MyThreadFunc2 (LPVOID param)
• int incoming (int) param
• while (true)

21
Worker Thread Example

• int main()
• int parameter 1000
• AfxBeginThread (MyThreadFunc1, NULL)
• AfxBeginThread (MyThreadFunc2, parameter)
• WaitForSingleObject(GetCurrentThread(),
  INFINITE)
• return 0

22
Suspending and Resuming Thread Execution

• Suspending a thread blocks the execution of the
  thread, when it is resumed it starts the
  execution from the point it is suspended
• AfxBeginThread returns a pointer to CWinThread
  object, we can use that pointer to suspend and
  resume the thread
• CWinThread curThread AfxBeginThread
  (MyThreadFunc, NULL)
• .....
• curThread-gtSuspendThread()
• ....
• curThread-gtResumeThread()
• Sleep suspends the execution of the thread for a
  given amount of time
• Sleep (100) // Suspends 100 milliseconds

23
User Interface Threads

• User-interface threads have a message pump and
  process messages received from the system,
• If we do not need to process any system messages
  worker threads are fine
• Just implement a controlling function
• And pass that function to AfxBeginThread
• But if we need to process system messages such
  as,
• User inputs
• User interactions
• Other OS messages (data on socket, and etc.)
• We need to use User Interface Threads

24
User Interface Threads

• For GUI applications the main thread of execution
  is provided by an object derived from CWinApp.
  CWinApp is derived from CWinThread.
• Additional CWinThread objects allow multiple
  threads within a given application,
• Basically our GUI applications are derived from
  CWinApp which constructs the primary thread of
  our application
• class CThreadDemoApp public CWinApp
• .....

25
User Interface Threads

• In order to implement a multithreaded application
  we need to implement a class (or classes) which
  will derive from CWinThread
• class CSocketThread public CWinThread
• .....
• We need to override the following methods
• virtual BOOL InitInstance( )
• Override to perform thread instance
  initialization.
• virtual int ExitInstance( )
• Override to clean up when your thread terminates.

• virtual int Run( )
• Controlling function for threads with a message
  pump. Override to customize the default message
  loop.

26
User Interface Threads

• To create the thread we will use CreateThread
  method. This comes for free when we derive from
  CWinThread class.
• When CreateThread is called from our application,
  CWinThread will call our derived InitInstance
  method and will leave the execution to our
  derived Run method

27
CWinThread Demo

• class CSocketThread public CWinThread
• public
• CSocketThread(int pSocketId)m_SocketId(pSocketId
  )
• virtual int Run()
• virtual int ExitInstance()
• virtual BOOL InitInstance()
• private
• int m_SocketId

28
CWinThread Demo

• ...
• int CSocketThreadRun()
• while (true)
• cout ltlt "Thread with Socket Id" ltlt m_SocketId
  ltlt endl
• Sleep (1000)
• return 0
• ...
• int main()
• CSocketThread firstThread(10)
• CSocketThread secondThread(20)
• firstThread.CreateThread()

29
Thread Synchronization

• Until now, we created threads and let them run.
  They do not share anything.
• But suppose, you have a global data and some of
  the threads are reading that data and some of
  them are writing into it.
• What happens when they access it at the same time
  ?
• Hint what happened when both threads accessed the
  command line window to print out some info ?
• (Undesirable and unpredictable results)

30
Thread Synchronization

• Synchronizing resource access between threads is
  a common problem when writing multithreaded
  applications.
• Having two or more threads simultaneously access
  the same data can lead to undesirable and
  unpredictable results.
• For example, one thread could be updating the
  contents of a structure while another thread is
  reading the contents of the same structure. It is
  unknown what data the reading thread will
  receive the old data, the newly written data, or
  possibly a mixture of both.
• MFC provides a number of synchronization and
  synchronization access classes to aid in solving
  this problem.

31
Thread Synchronization

• Mutexes, Locks, Semaphores, and CriticalSections
  are used to prevent the data
• CMutex
• CSingleLock, CMultipleLock
• CSemaphore
• CCriticalSection
• Basic idea here is to give the access of the data
  to only one thread at a time (which is also
  called thread-safe)
• We will cover only one method shown above
  (CMutex)
• The details of the MFC synchronization classes
  can be found on MSDN, but difference is the
  low-level structs used by MFC library (Faster or
  Slower thread context switches)

32
Thread Synchronization Demo

• class CSynchThread public CWinThread
• public
• CSynchThread(CMutex pLock, int pSocketId)
• ...
• private
• int m_SocketId
• CMutex m_Lock
• ...
• CSynchThreadCSynchThread(CMutex pLock, int
  pSocketId)
• m_SocketId(pSocketId), m_Lock(pLock)

33
Thread Synchronization Demo

• int CSynchThreadRun()
• while (true)
• m_Lock-gtLock()
• cout ltlt "Thread with Socket Id" ltlt m_SocketId
  ltlt endl
• m_Lock-gtUnlock()
• Sleep (1000)
• return 0
• int main()
• CMutex mutex new CMutex()
• CSynchThread firstThread(mutex, 10)
• CSynchThread secondThread(mutex, 20)
• firstThread.CreateThread()

34
What can go wrong ?

• Debugging a multi-threaded application needs much
  more effort.
• Too many switches between threads degrades the
  performance
• Programmer needs to pay attention to problems
  such as,
• Synchronization, Deadlocks, Starvation, and Race
  Conditions
• Most of the data types and classes available for
  use are not thread safe

35
Deadlocks

• Deadlocks occur when two or more threads (or
  processes) wait for each other to release a
  resource or waiting for resources in a circular
  chain,
• Thread -1 Thread-2
• LockResource(A) LockResource(A)
• DoActionOn(A) DoActionOn(A)
• ReleaseResource(A) //Forgetting to release

36
Deadlocks

• Waiting for resources in circular chain,
• Resources (A and B)
• Threads (T1 and T2)

Resource-A is assigned to T2 and T2 waits for
Resource-B to accomplish its job and release
resources Resource-B is assigned to T1 and T1
waits for Resource-A to accomplish its job and
release resources
A
B

• There are algorithms to detect, avoid and prevent
  deadlocks (Will be mentioned in OS Course)

37
Starvation

• Starvation (or Resource Starvation)
• From two or more of the threads, one thread is
  scheduled more often to execute but others are
  not
• Faulty scheduling
• One of the threads is unwilling to give up the
  resources for which the other threads are waiting
• Famous Dining Philosophers Problem

38
Race Conditions

• Race conditions arise when separate processes or
  threads depend on some shared state.
• Example
• Let us assume that two threads T1 and T2 each
  want to increment the value of a global integer
  by one.
• Integer i 0
• T1 reads the value of i from memory into a
  register 0
• T1 increments the value of i in the register
  (register contents) 1 1
• T1 stores the value of the register in memory 1

• T2 reads the value of i from memory into a
  register 1
• T2 increments the value of i in the register
  (register contents) 1 2
• T2 stores the value of the register in memory 2

• Integer i 2
• In the case shown above, the final value of i is
  2, as expected.
• However, if the two threads run simultaneously
  without locking or synchronization, the outcome
  of the operation could be wrong.

39
Race Conditions

• Integer i 0
• T1 reads the value of i from memory into a
  register 0
• T2 reads the value of i from memory into a
  register 0
• T1 increments the value of i in the register
  (register contents) 1 1
• T2 increments the value of i in the register
  (register contents) 1 1
• T1 stores the value of the register in memory 1

• T2 stores the value of the register in memory 1

• Integer i 1
• The final value of i is 1 instead of the expected
  result of 2.
• This occurs because the increment operations of
  the second case are non-atomic. Atomic operations
  are those that cannot be interrupted while
  accessing some resource, such as a memory
  location.

40
Threads for Windows

• MFC Threads are not the only solution for
  threading on Windows,
• POSIX Threads (or PThreads) Library
• http//sourceware.org/pthreads-win32/
• OpenThreads Library
• http//openthreads.sourceforge.net/
• Win32 Threads
• http//msdn2.microsoft.com/en-us/library/
