Title: Trish Yaxley, LVT


1
Technician's Guide to Nursing Care for Patients
with Cardiac Emergencies
Trish Yaxley, LVT Puget Sound Veterinary
Referral Center, PLLC 27th January 2008
2
Definitions
  • Afterload
  • Cardiac output CO SV x HR
  • Cardiogenic shock
  • Contractility
  • Preload
  • Stroke Volume

3
Definitions Continued
  • Arterial pressure
  • Bradycardia
  • Tachycardia
  • Diastolic BP
  • Systolic BP
  • Hyper/Hypotension
  • Mean arterial pressure
    (SBP(2xDBP))/3

4
Definitions continued
  • Pleural effusion
  • Pulmonary edema
  • Tamponade
  • Syncope

5
Normal Cardiac Physiology
  • Blood enters the heart via the vena cava
  • Vena cava empties into the right atrium
  • Right atrium empties into right ventricle via the
    tricuspid valve
  • RV pumps blood via pulmonary artery to lungs

6
Normal Cardiac Physiology
  • Blood returns from lungs via pulmonary vein and
    empties into the left atrium
  • Left atrium empties into left ventricle via the
    mitral valve
  • Blood is pumped into circulation via the aorta
  • Coronary arteries are fed from the aorta,
    ensuring the most oxygen rich blood for the heart
    muscle

7
Cardiac Conduction
  • Heart muscles shorten with electrical stimulation
  • Sinoatrial node starts conduction and goes on
    following path atrioventicular node, bundle of
    his, bundle branches, and ending in Purkinje
    fibers.

8
Receptors
  • Receptors in the heart Beta (1)
  • Receptors in blood vessels Alpha (1), Alpha
    (2), Beta (2) (also located in bronchi), and
    Muscarinic

9
Pathophysiology
  • Heart failure develops when chronic conditions
    cause the heart to work harder to pump blood
    continuously
  • Mechanisms that make the heart pump harder
    include hypertension and increased blood volume

10
Pathophysiology Ctd.
  • The heart responds to the stress of having to
    pump harder by increasing the size of heart
    cells, called hypertrophy
  • These muscle fibers will stretch to accommodate
    increased blood pressure and volume until they
    can no longer snap back effectively

11
Pathophysiology Ctd.
  • When the heart muscle is stretched too far it is
    unable to pump as strong as it used to and blood
    backs up in peripheral circulation and in the
    lungs causing edema and pulmonary edema.
  • Other results include poor peripheral perfusion
    and systemic hypotension

12
Goals
  • By the time signs and symptoms are noticed, the
    disease has usually progressed to a point where
    the prognosis is poor.
  • The goal of treatment is to control edema and
    manage blood pressure

13
Normal Sinus Rhythm
  • Characteristics Normal heart rate, with P, Q,
    R, S, and T waves all present.

14
Atrial Fibrillation
  • The atria are quivering because of a failure in
    conduction. There is no clear P wave and the
    base line is wavy because of irritable foci.
    There is an irregular heart rate.

15
VPC or Ventricular beats
  • Caused by irritable foci in the ventricles, these
    beats originate in the ventricles. They are
    large irregular complexes without P waves. The
    heart rate will be irregular. When there are
    more than one foci the VPCs will look different.

16
Ventricular Tachycardia
  • Many VPCs in a row without any atrial conduction.
    By definition, greater than 6 ventricular beats
    in a row is considered ventricular tachycardia.
    Treatment is commenced when the heart rate is
    sustained at a high rate and the patient becomes
    symptomatic. Treatment includes oxygen and
    anti-arrhythmic drugs.

17
Ventricular Fibrillation
  • The ventricle is quivering and no longer
    effectively pumping. This is considered a
    shockable rhythm, and will most likely be fatal
    if not treated as such. Other treatments include
    oxygen administration and anti-arrhythmic drugs.

18
X-Rays
19
Pulse Oximetry
  • Good to have baseline if patient tolerates. Best
    readings come from tongue, however ears and
    between the pads can also bring adequate
    readings.
  • Provides a measurement of how well the animal is
    perfusing and how well gas is being exchanged in
    the lungs.

20
Blood Pressure
21
Blood Pressure
  • It is very important to get a baseline if the
    patient is stable enough.
  • Heart rate means very little without a blood
    pressure, especially in a patient with
    cardiovascular compromise.
  • It may be easier to obtain a blood pressure on a
    front limb because it is closer to the heart.
  • Other ways to assess blood pressure include
    pulses, MM color, and CRT.

22
Signs and Symptoms of Hypotension
  • Pale mucous membranes
  • Cold extremities
  • Decreased level of consciousness
  • Shallow rapid breathing
  • Fatigue
  • Thirst
  • Fainting
  • Nausea

23
Signs and Symptoms of Hypertension
  • May not be as noticeable as hypotensive signs
  • Ocular changes
  • Seizures
  • Collapse
  • Abnormal behavior

24
CVP
25
CVP
  • Predictor of volume load.
  • Patient has central line that is in right atria
  • Line is connected to a monitoring device that
    measures pressures in cm of water.
  • Goal for treatment of heart failure is to lower
    CVP by 4-5 cm of water.
  • Most important thing about CVP is to keep the set
    up in the same position because CVPs are about
    trends

26
Labs
  • Increased BUN, Creatinine, and possibly liver
    values.
  • Hyponatremia, hypokalemia
  • Anemia
  • Hyperthyroidism? Hypothyroidism?
  • Hyperglycemia

27
Assessment Signs and Symptoms
28
JVD
  • Jugular venous distentionUsually noted in right
    sided heart failure

29
Dyspnea
  • Note rate and involvement of chest and abdomen
    and the character of the respirations.
  • Shallow rapid breathing is Kussmauls
    respirationsassociated with metabolic acidosis.
  • Deep breathing with alternating periods of
    apnea-Cheyne-Stokes respirations-end stage
    manifestation.

30
Bloody Sputum
  • Pink frothy sputum is common with patients who
    have severe pulmonary edema

31
Color
  • Remember to assess baseline.
  • Note changes with treatment and oxygen.
  • Tongue color often changes first.
  • Other areas to assess include eyes.

32
Lung Sounds
  • Need to assess often.
  • Crackles most often assessed with patients who
    have pulmonary edema.
  • Wheezes, harshness, stridor.

33
Heart Sounds
  • Murmurs
  • Gallops
  • Arrhythmias
  • May not be present, however not a rule out for
    heart disease especially with cats.

34
Cough
  • History of cough especially at night or with
    exertion
  • Accompanied with bloody sputum??

35
Exercise Intollerance
  • Noted in history-for how long?
  • How much stress can the patient handle?

36
Anorexia
  • Manifestation of decreased cardiac output.
  • May also note nausea and vomiting.

37
Ascites
  • Related to right sided heart failure.
  • Can put pressure on the diaphragm causing
    increased dyspnea.

38
Thromboembolsim
  • The 5 Ps
  • Pain
  • Paresis
  • Pallor
  • Pulselessness
  • Poikilothermy

39
Signs and Symptoms of Hypokalemia
  • Risk great with use of loop diuretics
  • Mental disturbances
  • Cardiac dysrhythmias (flattened T wave)
  • Rapid, weak pulses
  • Decreased BP
  • Weakness
  • Paralysis
  • Muscle pain
  • CatsVentroflexion of the neck

40
Signs and Symptoms of Hyponatremia
  • Nausea
  • Vomiting
  • Diarrhea
  • Abdominal cramping
  • Muscle tremors
  • Twitching
  • Weakness
  • Confusion
  • Seizures
  • Coma

41
Signs and Symptoms of Respiratory Alkalosis
  • Early manifestation of heart failure.
  • Patient will try to hyperventilate to facilitate
    gas exchange and gain more oxygen
  • Confusion
  • Syncope
  • Tachypnea

42
Signs and Symptoms of Metabolic Acidosis
  • Late manifestation of heart failure.
  • Decreased peripheral perfusion causes a build up
    of lactic acid causing MA.
  • Nausea
  • Vomiting
  • General malaise
  • Kussmauls respirations

43
Interventions
44
AVOID STRESS!!!
45
Oxygen
  • Cage or oxygen mask is preferred, some doctors
    prefer nasal oxygen.
  • Flow by oxygen can be used if mask oxygen is too
    stressful while treating pets.

46
Positioning
  • Position sternally
  • Important to prop sternally because it is the
    position that facilitates oxygenation and allows
    the patient maximal inflation of lungs.

47
IV Catheter
  • Do as soon as patient is stable enough.
  • Provide oxygen!!
  • Use a moderate sized catheter.
  • Use cephalic when able (easy access).
  • Jugular catheter to monitor CVPs when indicated.

48
Intravenous Fluids
  • Indications Cardiogenic shock, dehydration,
    drug induced hypotension, renal failure,
    hypokalemia, anorexia, vomiting, concurrent
    metabolic or infectious disease, need of a
    vehicle for constant rate of infusion

49
Special Monitoring of IVF
  • Body weight q12h
  • MMs (note dependence on O2)
  • Pulse rate and quality
  • RR and effort
  • LUNG SOUNDS
  • HEART SOUNDS
  • Rate and volume
  • Urine output (1-2 ml/kg/hr)
  • Blood pressure
  • CVP

50
DRUGS
  • Important to understand drugs action, the reason
    for administration, and side effects.
  • What do you need to know before administering the
    medication??
  • Actions can work against you..

51
Furosemide
  • Works directly on kidneys to decrease the
    resorption of sodium and chloride and
    subsequently decreasing blood volume.
  • Reduction of volume reduction in BP.
  • Baseline BP or pulses and CRT if patient is not
    stable.
  • Always provide water
  • May not work well if patient has kidney
    dysfunction
  • Lose potassium!!!

52
Thiazide Diuretics
  • Not used often in veterinary medicine
  • Prevents the reabsorption of sodium and chloride
    (and thus water) back to peripheral circulation.
  • Lowers BP and Potassium, so...

53
ACE Inhibitors
  • Review Renin-Angiotensin-Aldosterone.
  • ACE Inhibitors prevent the conversion of
    angiotensin I to II
  • Causes vasodilation and decreased BP
  • ENALAPRIL, benazapril
  • So..

54
Beta Blockers
  • Block effects on beta adrenergic receptors
  • Review Beta (1) receptors increase HR (AV
    conduction), beta (2) receptors dilate smooth
    muscle and bronchial tree
  • Older drugs arent selective for (1) so they can
    cause vasoconstriction and bronchoconstriction
  • Propranolol stablizes membranesanti-arrhythmic
  • Know HR, BP, Hx of airway dz???

55
Calcium Channel Blockers
  • Stop the slow calcium channels in the heart and
    to a greater degree in peripheral vasculature.
  • Effect Vasodilation and decreased HR, decreased
    afterload.
  • Know BP, HR.
  • NORVASC, DILTIAZEM

56
Pimobendan
  • New drug
  • Increases both contractility and as vasodilator
    effects
  • Increases calcium sensitivity in the cardiac
    contractility apparatus and inhibiting
    phosphodiesterase.
  • Effect venous and arterial vasodialation and
    decreased HR.
  • Know BP and HR.

57
Digoxin
  • Positive Ionotrope
  • Increases contractility of the heart
  • May also have diuretic effects
  • Has anti-arrhythmic effects
  • Major side effects Bradycardia and Hypokalemia
  • Need to monitor serum levels

58
Dobutamine
  • Beta (1) agonist
  • Structurally similar to dopamine
  • Positive Ionotropic agent
  • Effect Increased stroke volume and cardiac
    output
  • BP and HR increase slightly
  • Used short term to treat to restore arterial
    blood pressure, CO, and perfusion with patients
    in cardiogenic shock
  • Continuously monitor HR and BP

59
Dopamine
  • A catecholemine (neurotransmitter like
    epinephrine)
  • At low doses it dilates renal arteries as well as
    mesentaric, coronary and intracerebral beds
    (promotes perfusion)
  • Higher doses used for shock and works by
    vasoconstriction (opposite of low dose)
  • Nursing actions include BP monitoring and urine
    output
  • New studies out saying that cats dopamine
    receptors are not as effective making dobutamine
    the drug of choice for cats

60
Nitroglycerin
  • Vasodilator, especially of coronary arteries.
  • Used in severe cases of CHFlowers BP
  • Nursing actions BP, watch for signs and
    symptoms of hypotension.
  • Often administered on the skin of the abdomen or
    chest, cover with tape so that no one touches
  • Wear gloves and use the ruler provided when
    applying to prevent overdosing patient.
  • If any gets on your handswash right away!!

61
Nitroprusside
  • Relaxes smooth muscle and causes vasodilation
  • IV drip medication
  • Need to cover bag and line
  • Can cause severe hypotensionCONSTANT BP
    MONITORING!!!
  • Can give drip in very small amounts of fluid

62
Aspirin
  • Platelet aggregation inhibitor.
  • Used in patients who have coagulopathies and are
    throwing clots.
  • Aspirin works by inhibiting prostaglandins COX-1
    and 2.
  • This causes good effects of not sticky platelets,
    and pain/fever reductionsas well as bad effects
    of inhibiting the GI protective factors that
    these prostaglandins are responsible for.
  • Note platelet counts before adminsitering

63
Amiodarone
  • Anti-arrhythmic drug
  • Used when a patients ventricular tachycardia is
    refractory to other treatment such as oxygen,
    lidocaine, and propranolol
  • Need to monitor heart rate and rhythm as well as
    BP

64
Lidocaine
  • Anti-arrhythmic
  • Generally first line for control of V-Tach.
  • Monitor ECG and BP continuously if administering
    in CRI

65
Atropine
  • Usually associated with CPR/crashing animals
  • Used sometimes with bradyacardia and heart blocks
  • Action Blocks cholinergic (parasympathetic)
    receptors and increases heart rate.
  • Also associated with drying secretions, and
    decreased GI motilitybe sure that your patient
    doesnt have an obstruction!
  • Important to give adequate doselow doses can
    actually perpetuate bradycardia
  • Nursing actions include ECG and BP monitoring

66
Other Medication Notes
  • Avoid Ketamine with heart patients
  • Butorphanol and Buprenorphine are both fairly
    safe and effective to help calm anxious patients
    and provide pain relief. Cats could especially
    benefit from these medications
Write a Comment
User Comments (0)
About PowerShow.com
