Course Matters

1
Course Matters
2
Recent Papers

• from journals

3
Good PostersBad Posters
4
Improving I/O Performance of Intermediate
Multimedia Storage Node

• Pal Halvorsen
• Thomas Plagemann
• Vera Goebel
• Multimedia Systems 03

5
Problem

• Improve the performance of I/O in integrated
  multimedia storage node
• 3 areas of improvement are identified
• reduce memory copy
• checksum computation
• FEC computation

6
Reduce Memory Copy

• File system maintain pointer to an area in memory
• Communication system maintain pointer to same
  area in memory
• Memory copy avoided!

7
Network Level Framing

• Packet payloads are stored with checksum
• When packets are retrieved for sending,
  destination address in header is updated
• Checksum is updated with new destination
• No need to recompute checksum for payload

8
Integrated Error Management

• Data are stored on RAID-4 (single parity checks)
• Use the same error correcting code for RAID and
  packets
• Avoid multiple computation of error correcting
  code

9
Experiment Memory Copy

• Read 28662512B file 38 times in a loop
• The time to transmit data through the storage
  node is reduced by 45-50 when there is no CPU
  load, and by 70-73 when CPU load is high

10
Experiment Network Level Framing

• Transmit 255MB file
• Time to calculate checksum is reduced by 95-99
• Time spent in kernel is reduced by 51-61

11
Experiment Integrated Error Management

• With encoding FEC, the maximum throughput is
  22-24 Mbps.
• Without encoding FEC, the maximum throughput is
  1Gbps

12
Lets try again..
13
Improving I/O Performance of Intermediate Media
Storage Node

• Pal Halvorsen
• Thomas Plagemann
• Vera Goebel

14
Contributions

• Improve performance by
• reducing memory copy
• reducing checksum computation
• reducing ECC computation

15
Reduce Memory Copy

• One shared copy of data for different OS
  component

Memory
Network System
File System
data
16
Network Level Framing
store payload with payloads checksum
1
3
update header and checksum
2
read payload with checksum

• Reduce time to packetize data and compute
  checksum for data

17
Integrated Error Management
reuse RAID ECC as ECC packet
RAID
ECC
data
data
data
ECC

• Avoid multiple computation of error correcting
  code

18
Results Zero Copy
19
Results Network Level Framing
Accumulated UDP Protocol Execution Time for
sending 225MB file
20
Results Integrated Error Management
With ECC Encoding Without ECC Encoding
22-24 Mbps 1 Gbps
Maximum Throughput with/without Encoding
using Cauchy-based Reed Solomon Erasure Code
21
Ad Hoc Networks

• Session 1

22
Mobile Ad Hoc Network
Radio
Router
Host
23
Animation

• http//www-i4.informatik.rwth-aachen.de/mesut/man
  et/manet_en.html

24
Mobile Ad Hoc Network
25
Examples

• Battlefield
• Highway
• Disaster Zone

26
Challenges

• All the difficulties of wireless LAN
• Plus
• Nodes can move
• Connections can go up/down
• No fix route

27
Two Papers

• IEEE JSAC
• Special Issues in Wireless Multimedia
• Baochun Li from U. of Toronto
• Shiwen Mao from Polytechnic U.

28
NonStop Continuous Streaming Service on MANET

• Baochun Li
• IEEE JSAC 2004

29
Streaming over MANET
30
Network Partition Problem
31
Only Solution ..

• Predict Partition
• Replicate Service

32
Partition Prediction
33
Network Partition Problem
34
How to Predict Partition?

• given velocity of each node
• cluster nodes into mobile groups
• find mean group velocity

35
Clustering Algorithm
36
Clustering Algorithm
37
Clustering Algorithm
38
Clustering Algorithm
39
Choosing Server
?
40
How to Choose Server?

• find stable group
• choose server within stable group with the most
  similar velocity

41
Stable Group
probability
A
B
distance
mean lt radio range and variance is not too large
42
Stable Group
B
A
C
H
D
G
E
F
43
Stable Group
BCD are in my group
AGH are in my group
B
A
C
H
D
G
E
F
44
Stable Group
BCDGH are in my group
ABDGH are in my group
B
A
C
H
D
G
E
F
45
How to Choose Server?

• find stable group
• choose server within stable group with the most
  similar velocity

46
Summary

• Server construct mobile group by clustering nodes
  using velocity
• Use mean mobile group velocity to predict network
  partition
• Replicate service before partition to ensure
  continuous service

47
Summary

• Node construct stable group by comparing distance
  over time
• Choose server within stable group with most
  similar velocity

48
Multipath Transport and Multistream Coding for
MANET

• Shiwen Mao et. al.
• IEEE JSAC

49
Single Path Transport
50
Multipath Transport
51
Multipath Transport
52
Video Coding 1 of 3
I
P
P
P
P
P
P
P
Typical Frame Dependency
53
Video Coding 1 of 3
I
P
P
P
I
P
P
P
Multistream Coding
54
Dynamic Reference Frame

• Choose last received frame as reference

believed to be received
55
Predict Network States
GOOD )
NACK
ACK
BAD (
56
Example
ACK0
ACK2
ACK4
ACK6
0
2
4
6
8
10
1
3
5
7
9
NACK1
NACK3
NACK5
ACK7
57
Video Coding 2 of 3
I
P
P
P
Enhancement Layer
I
P
P
P
Base Layer
58
Video Coding 2 of 3
BL
S
D
EL
59
Video Coding 2 of 3
NACK
NACK
60
Video Coding 2 of 3
S
D
BL
61
Video Coding 3 of 3

• Multiple Description Coding

62
MDMC

• MDMC

63
Example of MDMC
359
363
370
7
Typical Reference Frame
64
Example of MDMC
359
363
370
MDMC Reference Frame
65
Example of MDMC
359
363
9
66
Example of MDMC
359
?
9
67
Example of MDMC
361
359
363
370
9
68
Example of MDMC
359
?
9,2
69
Comparisons
Reference Frame LayeredCoding MDMC
Feedback
Buffer
Decoding Delay
70
Improving Multicast

• Session 2

71
Organizing Multicast Receivers

• Brian Neil Levine
• Sanjoy Paul
• JJ Garcia-Luna-Aceves
• Multimedia Systems 03

72
Retransmission in Mcast
73
Idea

• Ask a neighbour for a missing packet

74
Helper Tree
75
Pick Helper By Hop
76
Pick Helper by Hop

• Not entirely accurate
• Need to consider latency, link condition etc.

77
Pick Neighbour By Latency
78
Pick Helper by Latency

• How to measure latency?
• unicast?
• multicast?
• shared-tree? per-source tree?

79
Ideal Location of Helper

• share a common path, and is closer to source
  (acceptable)

80
Idea

• Suppose node A and B know their path back to the
  source, then they can deduce if A is acceptable
  to help B

81
MTrace
D
F
A
B
C
H
G
I
E
82
ERS
my path is ABCDF
D
F
A
B
C
H
G
I
E
83
ERS
D
F
A
B
C
H
G
I
E
84
Respond if

• acceptable
• not too many helpee

85
Picking Helper

• packet loss measurement

10
30
86
Maintenance

• Periodic refresh states (soft-states)
• Periodic repeat procedure

87
Summary

• Organized receivers based on common path
• Enable peer-to-peer retransmission

88
THE END
