Servosystem Selection

• Servo generally is used as a synonymous of
  brushless.
• Brushless motors are generally defined in terms
  of torque, not power, since the torque is
  available from zero to nominal speed, while P C
  w

Velocity
Torque
servo
servo
Induction vector controlled
Induction vector controlled
induction V/F cost.
induction V/F cost.
time
velocity
3
Motion Transmission

• 1) Gearboxes
• Moment of inertia
• to the motor shaft
• J1 (n1/n2)2 J2
• Jtot Jmot J1

4
Motion Transmission (contd)

• 2) Belt
• J m r2 m (v/w) 2
• 3) Screw
• J m (s/(2p))2

5
Motors poles number

• Brushless can technically be built with any pole
  pair number.
• A high pole pair number generally
• gives high torques.
• The limit given by permanent
• magnets distance on the rotor and
• from the diameter of the motor.

AHR190J8 rotor with NdFeBo magnets
6
Motors Basic Equations
Speed rad/s

• Electrical Equations
• e fcem Kt w V
• C Kt I Nm
• Mechanical Equations
• P dE/dt C w w dE/dq Nm/s W
• C J dw/dt Nm

Current A
Energy JNmWs
Angle rad
7
Field-weakening (Deflussaggio)

• Increasing velocity the DC bus limit is reached
• (e fcem Kt w).
• For increasing furthermore the speed it is
  necessary to lower the statoric flux with 1/w
• (and doing so also Kt will be lowered and so also
  C Kt Iq).
• (The effect can be obtained changing the phase of
  is beyond p/2 with respect to the rotor position
  the current thus staying maximum and thus
  avoiding quantization effects due to small
  digital vectors).
• We thus have P C w cost.

8
Field Weakening (contd)
Torque
fcem e
velocity w
9
Torque characteristics of the different motor
types
DC brush motor
Torque
Torque
Peak torque
Universal Motors (motori serie)
Nominal torque
Nominal Work area
Velocity
Field weakening
Velocity
10
Torque characteristics of the different motor
types (contd)
Stepper motor
Torque
pull-out torque
Max speed possible to put as set point at speed
zero
Resonance zone
Nominal Work area
Load inertia
Velocity (steps frequency)
pull-in rate
11
Torque characteristics of the different motor
types (contd)
Pull-out torque
AC induction motor
Torque
Torque
Unstable zone
brake
const. power with Is max
Torque follows pull-out torque
const. torque
Nominal Work area
w
1/w
s 1
s 0
1/ w2
generator
w
B prop. to V/f cost.
V cost.
12
Torque characteristics of the different motor
types (contd)
AC brushless motor
Torque
Peak torque
Nominal torque
Nominal Work area
Field weakening
Velocity
13
Formulas Summary

• Rotational Case
• E C Da P Dt NmWsAm2T
• P dE/dt C w w dE/dq Nm/s
• C F leverage J dw/dt Nm
• F I L B l B F/ A N T
• F LI MMF/R MMFNI wb A

Linear Case E F Ds P Dt JNm P dE/dt
F v N m/s F m a NKgm/s2
14
Rewinding (Riavvolgimento cave statoriche)

• For increasing Kt with the same motor is
  sufficient to rewind stator slots with smaller
  section cable so to make more windings
• Kt F Srot N / A will be thus increased.
• With the same motor, I will thus have more torque
  C Kt I with the same current I,
• But with a smaller max. speed since e Kt w

prop. to N I a little bigger due to Better slot
filling
It increases proportionally to number of windings
15
Shannon Sampling Theorem
16
Servo digital control loop

• sampling time (tempo di campionamento) to avoid
  z-transform analysis (that would mean to work at
  the control system limits) it is necessary to
  sample 5-10 times faster than Shannon theorem
  says.
• Generally we have
• Load Response Bandwidth 10-50Hz
• SampleUpdate Rate gt 1KHz

17
Servo digital control loop (contd)

• lag error, following error
• (Errore di inseguimento) each control block
  introduces a delay (integral action plays an
  important role in this respect) that leads to a
  lag error naturally different from zero. To
  minimize it the feed-forward could be useful it
  bypasses closed loops regulating blocks (and thus
  it does not load the integral actions). The
  feed-forward action it is dependent from
  velocity, inertia, acceleration, viscous
  friction, that thus have to be known with good
  accuracy.

18
DC Motors (motori in continua o motori a
spazzole o motori a collettore)

• Simple drive electronics
• Cheap
• Possible problems with commutator and brushes

19
Ironless Motors(DC motor)
(With integrated gear)
20
Ironless Motors(brushless)
21
AC induction motors (a induzione o in alternata
o a gabbia di scoiattolo)

• Frequency-controlled asynchronous (induction)
  motors are mostly used for simple drive
  functions, without feed-back. For example to
  regulate the speed. The motor is a squirrel-cage
  asynchronous motor, and the control unit a
  frequency converter.
• The squirrel-cage asynchronous motor is the
  absolutely most commonly used AC induction motor
• it is CHEAP,
• it is VERY RELIABLE,
• it is a STANDARD PRODUCT within the IEC std.

22
AC induction motors (contd)
230VAC
230VAC
Squirrel Cage (gabbia di scoiattolo)
D-Connection (Connessione a triangolo)
Y-Connection (Connessione a stella)
23
AC induction motors (contd)

• The synchronous speed is the rotation speed of
  the magnetic field, generated in the field
  windings when supplied with a three-phase AC
  voltage
• The actual, true, speed of the rotor is
  determined also by how great a load the motor is
  driving. This speed is called the asynchronous
  speed, and the difference between the two is
  termed slip (scorrimento).

24
AC induction motors (contd)

• Note that the AC induction motor (asynchronous)
  has always a physiological slip (in speed), while
  the AC brushless motor (synchronous) has always a
  physiological lag error (in position).
• From a construction point of view the stator of
  an AC induction motor and the one of an AC
  brushless are quite similar (both has a winding
  lay-out so to obtain a single sinusoidal rotating
  field from 3 sinusoidal pulsating fields).
• Often an AC brushless drive can also control
  (with Vector Control techniquies) an induction
  motor.

25
Steppers(motori passo o passo-passo)

• 2 phases,
• 4 poles
• 6 rotor teeth

• Small loads
• No feed-back
• Cheap

2 phases, 8 poles 50 rotor teeth
26
Steppers

• Half Stepping
• 4 poles 6 teeth 24 steps

1-phase-ON (FullStep) 4 poles 6 teeth / 2 12
steps
27
Distribuzione del campo magnetico al traferro di
un motore passo-passo
28
Steppers Motor Types

• Variable Reluctance (iron teeth)
• Permanent Magnets (PM teeth)
• Hybrid (rotor iron teeth misaligned axially,
• PM inside the rotor with N-S axially spaced)
• Direct Drive Variable Reluctance (ring-like
  rotor, double face stator)
• Multi-Stack (rotor divided axially in 3 parts
  with teeth misalingned of 1/3 stator also
  divided in 3 parts each energized in sequence
  only 1/3 of Fe used at the same time)

29
