Software Testing and Reliability Robustness Testing

1
Software Testing and ReliabilityRobustness
Testing

• Aditya P. Mathur
• Purdue University
• May 19-23, 2003
• _at_ Guidant Corporation
• Minneapolis/St Paul, MN

Last update April 17, 2003
2
Learning objectives

• What is robustness testing?

• How to perform robustness testing? (The ballista
  test methodolgy.)

• Results from the Ballista test methodology.

3
References

• The Ballista Software Robustness Testing Service,
  John P. DeVale, Philip J. Koopman, and David J.
  Guttendorf, Testing Computer Software, June 1999.
  http//www.ices.cmu.edu/ballista

• Robustness Testing of the Microsoft Win32 API,
  Charles P. Shelton, Philip J. Koopman, and Koby
  DeVale, Proceedings of the International
  Conference on Dependable Systems, June 25-28,
  2000, IEEE Press.

4
Robustness Review

• Robustness is the degree to which a software
  component functions correctly in the presence of
  exceptional inputs or stressful environmental
  conditions.

• Robustness testing

• Clues come from requirements. The goal is to test
  a program under scenarios not stipulated in the
  requirements.

5
Failures due to Lack of Robustness

• Apollo 11 Lunar Module experienced three
  computer crashes and reboots during powered lunar
  descent due to exceptional sensor and equipment
  settings.

• Ariane 5 rocket Flight had to be aborted shortly
  after liftoff due to an unhandled exceptional
  error condition.

• Others We observe program crashes almost daily!
  Often these are due to erroneous or non-handling
  of exceptional conditions.

6
Programming error or Requirements error?

• Often, program crashes, or hangs, occur due to
  the incorrect handling of an exceptional
  condition.

• The input that causes the mishandled exception
  condition to arise might arise due to an error in
  the requirements, or in the design, or in the
  code. However, for a user it is simply a defect
  in the application that leads to a failure.

• The impact of an application crash could be
  inconvenience caused to its user or as extreme as
  to a cause a catastrophe.

7
Why lack of robustness ?

• Specifications are often incomplete. This may
  lead to an implementation that does not handle
  cases left unspecified.

• Resource constraints often leave code segments
  untested for extreme or unexpected values.

• Example atoi(NULL) ---gt segmentation fault?

• Why would any one invoke atoi() with a NULL
  parameter?

What form of black- and white- box testing are
needed to detect hidden sources of exceptional
conditions?
8
Robustness, functionality, and operational
profiles

• Most development organizations plan for
  functional testing. Often, various types of
  black-box testing techniques are used.

• Justification of functional testing is relatively
  straightforward by invoking the unhappy
  customer scenario.

• But functional testing is unlikely to lead to the
  test of exceptional conditions.

• Tests based on well-derived operational profiles
  are also unlikely to test for exceptional
  conditions for the obvious reason that the
  operational profile merely prioritizes
  functionality.

9
Off-the-shelf components and robustness

• Often one composes an application with one or
  more components acquired from a different vendor
  and integrating these with code developed
  in-house.

• The code and other related documents for
  off-the-shelf component might not be available
  thus making code-based testing impossible.

• Hence the need for a methodology for robustness
  testing that does not require access to the
  source code of the components under test.

10
The Ballista Approach to Robustness Testing

• Often one composes an application with one or
  more components acquired from a different vendor
  and integrating these with code developed
  in-house.

• The code and other related documents for
  off-the-shelf component might not be available
  thus making code-based testing impossible.

• Hence the need for a methodology for robustness
  testing that does not require access to the
  source code of the components under test.

11
The Ballista Testing Methodology

• Based on combinational generation of tests that
  consist of valid and invalid values of parameters.

• For each test case a module under test (MuT) is
  called once to check if it is robust to that
  input.

• Parameter values are drawn from a pool of valid
  and invalid values for a set of data types.

• Functionality of MuT is not a concern.

• Of concern is whether or not MuT crashes or hangs
  for the test case.

12
Test Cases from Ballista

• Each test case is of the form MuT, param_value1,
  param_value2, param_valueN and corresponds to
  the procedure call MuT (param_value1,
  param_value2, param_valueN)

13
Test Cases from Ballista Example
inttrap(double a, double b, intN)
All combinations are generated.
14
Scalability of Ballista Tests

• Scalability Growth in the number of test cases
  is linear, or sub-linear, in the number of
  modules tested.

• Scalability achieved by

• constraining specifications to dont crash and
  dont hang,

• base the test cases on the exceptional values of
  data types, and

• reuse of test cases amongst modules that have
  interfaces with matching parameters.

• Example 233 functions and system calls in Posix
  API with real-time extensions required defining
  only 20 data types.

15
Organization of Test Values

• Each data type is treated as a module and fits
  into a hierarchical object oriented class
  structure. Thus, all values (test cases) of a
  parent type are inherited by the child.

16
Generation of Test Values

• Each test value is associated with up to three
  code segments.

• The first code segment creates an instance of a
  data type with specific properties.

• The optional second code segment modifies the
  effects of the constructor such nas deleting a
  file while returning a file handle!

• The optional third code segment deletes or frees
  system resources that might be reserved by other
  constructors such as deleting a file or freeing
  system memory.

17
Phantom Parameters

• How to handle modules that have no parameters and
  might input from file(s) and/or system state?.

• Set up a dummy module that sets up system state
  and/or files to be used by the MuT and then
  invoke the MuT.

• Ballista allows the specification of phantom
  parameters during parameter set up. Ballista
  invokes constructor/destructor pairs for these
  parameters but does not actually pass them to the
  MuT.

• For example, for a file input, a phantom
  parameter is defined to create a file. If this
  file is accessed via, say, a central registry,
  then phantom parameter can appropriately register
  the file object.

18
Failure Types

• Catastrophic failure corrupts the state of the OS
  and generally leads to a restart of the machine.

• Restart failure causes a process to hang
  requiring a kill signal for its termination after
  an application-dependent time interval.

• Abort failure causes abnormal termination of the
  process such as a core dump.

• Silent failure causes return of a value with no
  indication of an error when an exceptional value
  is input, such as returning a value for log (0).
  Might require manual analysis.

• Hindering failure is characterized by the MuT
  returning an error code that incorrectly
  describes the exception that led to the error.
  Might require manual analysis.

19
Test Results Sample

• For 233 function calls across 15 different POSIX
  compliant OS, normalized failure rates were found
  to be 9.99 to 22.69.

• Code that produces catastrophic failure on Win
  95, 98, and CE

GetThreadContext(GetCurrentThread(),NULL)

• Overall robustness failure ratesNumber of failed
  tests/total tests

Sample
Windows NT Varies from 6.2-51 (No
catastrophic failures)
Windows 2000 Varies from 7.4-48.9 (No
catastrophic failures)
Windows CE Varies from 6.7-33.4 (excluding
catastrophic failures)
20
Ballista WEB Server
21
Summary

• What is robustness?

• A robustnes testing methodology

• Sample robustness failure rates of a few
  operating systems
