1Characterization Techniques
2Transmission Electron Microscopy (TEM)
illumination device
condensing lens
specimen
objective lens
projection lens
viewing plane
3TEM Formation of the Image
Contrast comes from diffraction atomic number
Z contrast sample thickness
4TEM sample preparation
no stain sample must have inherent contrast and
beam resistance negative stain heavy metal
non-selectively coats sample resulting in high Z
contrast positive stain heavy metal selectively
coats sample resulting in high Z
contrast vitreous ice cryo-TEM aqueous sample
are rapidly frozen protecting the organic
material. Allows for viewing native conditions
5High resolution TEM image (twin boundary)
5 Ã…2
6PTA negative staining agent for TEM
PTA phosphotungstic acid H3PW12O40
7TEM image of T4 bacteriophage (negatively stained
with PTA)
8Uranyl acetate negative staining agent for TEM
(UO2(CH3COO)2)22H2O
9TEM image of earthworm hemoglobin (negatively
stained with UA)
10(No Transcript)
11Negative vs Positive staining in TEM
12Microphase separation of block copolymers in
solid state
13Organization of gold particles by block copolymer
lamellar structure
annealing
14TEM transmission electron microscopy
Pros Can visualize structures down about
2Ã…. Excellent lateral resolution. Can be
used in combination with spectroscopic
techniques such as EELS and XPS. Can acquire
diffraction pattern and image from the same
sample. Cons Electron beam may be
destructive to organic assemblies. Purely
organic samples often need to be
stained. Expensive instrumentation
(gt2M) Difficult technique to learn. 2D
projection of 3D objects. difficult sample
preparation
15Scanning Electron Microscopy (SEM)
16SEM images
Molybdenum trioxide crystals
Radiolarian (magnification X 750)
17SEM images of graphite polyhedral crystals
Gogotsi et al. Science 2000, 290, 317
18SEM image of white blood cell with HIV budding
from the cell surface
19SPM Scanning Probe Microscopy
Includes AFM Atomic Force Microscopy STM
Scanning Tunneling Microscopy In some cases can
image individual molecules - Ã… level
resolution Fraught with peril - many artifacts
are possible! Some limitations on the types of
samples that may be imaged. Relatively
inexpensive (50K-200K) easy to learn
difficult to master
20AFM Atomic Force Microscopy
21AFM Tips
Typical radius of curvature is 10-15 nm
22Atomic Force Microscopy (AFM)
AFM instrument maintains constant force between
the tip and the surface.
(FS) Force Sensor - The force sensor measures the
force between the probe and the sample by
monitoring the deflection of a cantilever.
(ZP) Z piezoelectric Ceramic - Moves the force
sensor in the vertical direction to the surface
as the probe is scanned with the X and Y
piezoelectric transducers.
(FCU) Feedback control unit - The feedback
control unit takes in the signal from the light
lever force sensor and outputs the voltage that
drives the Z piezoelectric ceramic. This voltage
refers to the voltage that is required to
maintain a constant deflection of the cantilever
while scanning.
23AFM images of graft copolymers (bottle-brushes)
24AFM images of graft copolymers (bottle-brushes)
25STM Scanning Tunneling Microscopy
Same general concept as AFM in that you raster
a tip over the surface of a sample to image
it. Method of imaging is based on the
tunneling current formed between platinum tip and
the sample. Sample should be at least
minimally conductive Extremely high resolution
images are attainable
26Scanning Tunneling Microscopy (STM)
1 - piezo-electric tube
2 - sharp metallic tip (probe)
3 conducting surface (specimen)
- STM measures tunneling current between 2 and 3
(tip-surface distance 3Ã…)
- Tunneling current strongly (exponentially)
depends on tip-surface distance - That dependence provides an extremely high
resolution (as low as 0.01 Ã…)
27High resolution STM images
Misfit dislocation loop at the Au/Ni
(111) Interface (45x50 Ã…2)
Palladium nanocrystal on Al2O3 (50x50 Ã…)
28High resolution STM image of CNT
29STM images of individual atoms
30Moving and Assembling Individual Atoms
