A NEW CONCEPT IN DATA CENTERS

1
A NEW CONCEPT IN DATA CENTERS
Data Center In A Row

2
Data Center In A Row

• Modular Integrated Solutions, Inc.

3
Data Center In A Row

• Modular Integrated Solutions, Inc.

4
Data Center In A Row

• Data Center In A Row (DCR) Is A Closed
  Architecture Complete Data Center Consisting Of
• Base Modules Thermally And Acoustically
  Insulated
• Base Rack For Power Distribution, Monitoring
  Systems, Fire Suppression And Surge Suppression
• 42u Nema 12X Enclosed Racks
• Return Air Modules
• Back Up Cooling Fans 2800 CFM

• Modular Integrated Solutions, Inc.

5
Base Rack Module

• Each Base Rack Module Is Provided With An
  Adjustable Damper Adjustment Is Determined By
  Automatic Monitoring Of Discharge Air From Each
  Respective Cabinet This monitoring system is
  web capable
• Upon Loss Of Primary Cooling System, The DCR Is
  Provided With An Atmospheric Dampers That Opens
  When The Thermostatically Controlled Emergency
  Exhaust Fans Operate
• Each Base Rack Module Is Provided With Cable
  Access Door In Rear
• Additional Base Rack Modules Can Be Added As
  Needs Dictate

RACK MODULE WITH ADJUSTABLE AIR VOLUME DAMPER

• Modular Integrated Solutions, Inc.

6
Base Rack Module

• The rear side of each Base Rack Module Is
  Provided With A Removable Access door allowing
  for routing Power and Communications Cables

• Modular Integrated Solutions, Inc.

7
UPS Systems

• UPS Options Available
• 10 Kva 1 Phase 6u Rack Mounted UPS N, N1 2 N
• 10- 30 Kva 3 Phase UPS N, N1, 2 N
• Remote UPS Systems
• Individual UPSes for Each Rack

• Modular Integrated Solutions, Inc.

8
Closed Architecture Quiet Operation

• Sound Levels
• 70 dBA _at_ 3
• 67 dBA _at_ 5

• Modular Integrated Solutions, Inc.

9

Cooling System

• 18 kW Cooling Systems Available In

• Air Cooled
• Water Cooled
• Glycol Cooled
• Chilled Water
• Additional Modules Can Be Added For Capacity Or
  N1 Redundancy

• Modular Integrated Solutions, Inc.

10

Sealed Cabinets

• Standard 42u Nema 12X Enclosed Racks Are
  Provided With Base System 47u Available
• Rack Measures 23.5W X 43.3D X 77 H - Other
  Depths, Heights And Widths Available
• Base System Consists Of 3 Cabinets With Option
  For Additional Cabinets - Present Or Future
• Doors Available In Clear Glass, Smoked Glass Or
  Solid

• Modular Integrated Solutions, Inc.

11
Return Air Modules

RETURN AIR MODULE

• Return Air (R/A) Modules Provide For Heated Air
  From Each Rack To Return To Cooling System
• Emergency Exhaust Fans Are Mounted On Top Of R/A
  Modules To Provide Emergency Ventilation On Loss
  Of Primary Cooling
• Communications Cables Are Routed Through Sealed
  Channels
• R/A Modules Are Thermally And Acoustically
  Insulated

• Modular Integrated Solutions, Inc.

12
Back Up Cooling Fans

• Modular Integrated Solutions, Inc.

13
Monitoring

• Standard Monitoring
• Leaving Air Each Rack
• Surge Suppression
• Fire Panel
• AC Network Interface
• UPS Network Interface
• Optional Monitoring
• Branch Circuit Amperage
• Total Circuit Amperage per
• Amperage per cabinet
• Graphic Packages
• Network Management Systems

• Modular Integrated Solutions, Inc.

14
Distribution and Fire Detection/ Suppression
Module

• This Module Mounts On Front Of Cooling Module
  And Includes
• Utility Power Distribution
• UPS Power Distribution (For Remote UPS)
• Fire Detection
• Fire Suppression
• Power Monitoring UPS, Utility And Branch
  Circuits
• Environmental Monitoring, Including Rack
  Discharge Temperatures And Cooling System Status
  And Operation

• Modular Integrated Solutions, Inc.

15
Fike Fire Detection Suppression System
The Data Center In A Row is provided with Fike
SHP PRO Fire Detection System. This system can be
configured to meet all local codes The fire
suppression in the DCR is accomplished Utilizing
Fire Suppression Agent HFC-125. As the DCR is a
closed sealed architecture, the Quantity of
HFC-125 needed is reduced as it is only required
with in the cabinets. Total room flooding is not
required.

• Modular Integrated Solutions, Inc.

16
Power Supply Options
The DCR can be provided with A Pin and Sleeve
Electrical Connection This option will allow the
user to depreciate the system over five
years Additionally, if the user is a tenant, the
DCR can be removed and relocated as It would not
be considered a Leasehold Improvement

• Modular Integrated Solutions, Inc.

17
Top Cable Pass Thru
Various Cable Pass thrus Are available to meet
any requirements

• Modular Integrated Solutions, Inc.

18
DCR Configurations
3-5 CABINETS
N 1 COOLING
MODULES

6 10 CABINETS WITH N1 COOLING
MODULES

• Modular Integrated Solutions, Inc.

19
Data Center In A Row

• Modular Integrated Solutions, Inc.

20
Features

• Closed Architecture Providing Dedicated Energy
  Efficient Environmental Control
• Expandable, Modular Components
• Fire Detection/Suppression At Affordable Cost
• Dedicated Air Distribution To Each Cabinet
• 24x7 Monitoring Options Available
• Numerous Rack Configurations Available
• Adaptable UPS And Cooling Solutions
• Lowest Cooling Cost per kW In The Industry

• Modular Integrated Solutions, Inc.

21
Benefits

• Sealed Self Contained Moisture Proof System
• Adaptable, Expandable Modular System
• With Optional Quick Connects, System Can Be
  Re-locatable, Not Considered A Fixed Asset
• Can Be Depreciated Over 5 Years
• Leasing Plans Available
• Secure Enclosures
• Employees Not Exposed To Fire Suppression Gas In
  Event Of Discharge
• Quite, Clean, Secure Operating Environment

• Modular Integrated Solutions, Inc.

22
Data Center In A Row
- Scalable - Quiet - Back up cooling - Fire
Protection - Secure

• Thank You Comprehensive

Modular Integrated Solutions, Inc.
