Title: MAEviz Feature Highlights


1
  • Software Team
  • Shawn Hampton
  • Chris Navarro
  • Jong Sung Lee
  • Nathan Tolbert
  • MAE Center PI
  • Amr Elnashai
  • MAEviz PI
  • Bill Spencer
  • Co-PI
  • Jim Myers

http//maeviz.ncsa.uiuc.edu
2
Presentation Overview
  • MAEviz
  • What is MAEviz?
  • Motivations and Benefits
  • Design Model
  • Analyses
  • Result Views
  • Demonstration
  • Strengthen Shelby County hospitals to meet goal
  • Education Application examples
  • Conclusions
  • Contact/Additional Information

3
What is MAEviz?
  • A state-of-the-art extensible environment that
    integrates spatial information (buildings,
    bridges, demographic data), data (tables, math
    functions, etc), and visual information to
    perform risk assessment, analysis and data
    exploration.
  • Integration point for MAE Center Research
  • Simcity for Earthquakes

4
Hazards Affecting Underground Pipelines
  • Ground Shaking (acceleration, velocity)
  • Landslides (displacement)
  • Liquefaction (displacement)
  • Settlement/heaving (displacement)
  • Fault Crossings (displacement)

5
Pipe Network Damage in Earthquakes
  • 1994 Northridge Earthquake Combined water and
    gas main break on Balboa Boulevard

6
Pipe Network Damage in Earthquakes
  • Kobe earthquake 1995 Fire following gas pipe
    rupture
  • Note alignment of fire with roads

7
MAEviz Benefits
  • MAEviz is a tool to coordinate pre-event planning
    and mitigation, response, and recovery, and
    post-event deployment of resources
  • Provides a framework to add new data and
    algorithms or update existing data and algorithms
  • Connects the latest research and practices to
    emergency managers and decision-makers
  • MAEviz is a practical application with a modern
    intuitive interface and multiple data views
  • MAEviz provides a mechanism to analyze What if
    scenarios
  • MAEviz is Open Source and incorporates the latest
    industry standards (OSGi, OGC, etc)

8
MAEviz Quick View
2D 3D Views
Data Catalog
Main Window
Style Editor
Synchronized Data Views
Result Charting
Scenario Browser
9
A Community-Supported Extensible Solution
  • Open source, extensible software platform using
    Eclipse Rich Client Platform
  • Development costs can be shared by different
    communities
  • RCP supports the core user interface
    functionality of window and widget management in
    a robust cross-platform package
  • An extensible, semantic-aware analysis engine
    provides the ability to include and deploy
    science models from anywhere
  • Geographic information system (GIS) capabilities
    provided by the open source GeoTools
  • Structured to support all natural and
    human-generated hazards and risk analysis

10
What Can MAEviz Do?
  • Charting and Reporting
  • Default detailed and synopsis reports for every
    analysis
  • Visual editor for creating and sharing new
    reports
  • Advanced Visualization
  • 2D and 3D supported
  • Selection and highlighting
  • GIS Functionality
  • Querying and filtering
  • Internationalization
  • U.S. English, Turkish and Indonesian
  • Local and Remote Execution of Analysis Workflows
  • 40 Analyses in 7 categories
  • Bridges
  • Buildings
  • Lifelines
  • Decision Support
  • Hazard
  • Socioeconomics
  • GIS
  • User extensible intelligent default parameters

11
Building and Bridge Analyses
  • Building
  • Structural and Non-Structural Damage
  • Direct Economic Damage
  • Repair Cost
  • Retrofit Cost Estimation
  • Bridge
  • Structural Damage
  • Functionality
  • Repair Cost
  • Retrofit Cost Estimation

12
Decision Support GIS Analyses
  • Decision Support
  • Equivalent Cost Analysis
  • Multi Attribute Utility Analysis
  • Network Based Seismic Retrofit Analysis
  • Static Traffic Model
  • Dynamic Traffic Modeling via Vista
  • GIS
  • Aggregation, Append, Comparison, Intersection,
    Join
  • Raster Slope

13
Hazard, Lifeline Socioeconomic
  • Hazard
  • Probabilistic and scenario earthquakes
  • Liquefaction
  • Lifeline
  • Gas, water, electric facilities and networks
  • Network Interdependencies
  • Socioeconomic
  • Household and Population Dislocation
  • Business Content Loss, Interruption Loss,
    Inventory Loss
  • Fiscal Impact
  • Shelter Needs Supply Requirements
  • Social Vulnerability
  • Temporary Housing

14
MAEviz - Analysis View
  • Easy to understand the analysis workflow
  • User configurable analysis defaults
  • Users can run multiple analyses simultaneously

15
Reporting Tools
Report MAEviz generates the report for shelter
needs and supplies (in PDF format)
Supplies for 1, 3, and 7 Day Planning
16
Saved Scenarios and Analysis Templates
  • Scenarios are saved locally with relevant data
    and user inputs
  • Scenarios can be published and shared
  • Individual analyses are saved with all parameters
    allowing the user to change one parameter, re-run
    and compare results

17
Demonstration
  • Scenario A City Planner in Shelby County,
    Tennessee has a budget of 25 Million dollars to
    strengthen area hospitals against a magnitude 7.9
    earthquake. Help the city planner determine
    which hospitals should be retrofitted to give an
    overall utility of gt80 and give the greatest
    reduction in injuries and deaths.
  • Create a scenario
  • Load Hospital data for Shelby County
  • Create Scenario Earthquake and generate
    structural and non-structural damage prediction
  • Estimate Retrofit Costs
  • Estimate Utility if we retrofit nothing
  • Generate Damage predictions for retrofits
  • Generate change in Utility for retrofit options
  • Design Retrofit Scheme

18
Results
  • As-Built Utility 0.68 0M in Upgrades
  • 6 Deaths
  • 33 Injuries
  • Low Code 34M in Upgrades
  • 2 deaths
  • 15 injuries
  • Moderate Code 124M in Upgrades
  • 1 deaths
  • 7 injuries
  • High Code 258M in Upgrades
  • 0 deaths
  • 4 injuries
  • Retrofit Strategy Utility 0.85, 24.7M in
    Upgrades
  • 3 deaths
  • 20 injuries

19
Education Examples
  • Similar to our demonstration, plan for a
    magnitude 7.9 Earthquake in your area. Given 10
    Million in play money, design a retrofit strategy
    for your neighborhood to reduce life loss /
    economic loss the most
  • Determine which structures in your area would be
    suitable for short term shelter given a magnitude
    7.0 earthquake. How many people are displaced
    that will require short term shelter and how much
    food, water, etc is required for a 1, 3 and 7 day
    planning period?

20
Education Examples (2)
  • Given a scientific workflow (e.g. scenario
    earthquake simulation analysis), publish as a web
    application with open variables for students to
    investigate their effects
  • e.g. How does magnitude, depth, soil type and
    elevation effect the amount of ground shaking

21
Conclusion
  • MAEviz is a next-generation collaborative
    environment to link research and engineering to
    decision makers
  • MAEviz represents new era of analysis and risk
    assessment tools that can be used in pre and post
    disaster planning
  • MAEviz can aid students in understanding the
    social and economic consequences of natural
    disasters
  • Tutorials and the MAEviz software can be
    downloaded at http//rcp.ncsa.uiuc.edu/maeviz

22
Contact Information
  • MAEviz Website
  • http//maeviz.ncsa.uiuc.edu
  • MAE Center Website
  • http//mae.cee.uiuc.edu
  • http//mae.cee.uiuc.edu/K-12/index.html
  • USGS Website
  • http//education.usgs.gov
  • Jim Myers
  • jimmyers_at_ncsa.uiuc.edu
  • Shawn Hampton
  • shawn_at_ncsa.uiuc.edu

23
  • Questions?
