3D Video Surveillance with Augmented Virtual Environments

1
3D Video Surveillance withAugmented Virtual
Environments

• Ismail Oner Sebe, Jinhui Hu,
• Suya You, Ulrich Neumann
• Integrated Media Systems Center
• University of Southern California

2
Problem Statement

• Imagine dozens of video/data streams from people,
  UAVs, and robot sensors distributed and moving
  through a scene
• Problem visualization as separate
  streams/images provides no integration of
  information, no high-level scene comprehension,
  and obstructs collaboration

3
A Simple Example USC Campus
1
2
Visualization as separate streams provides no
integration of information, no high-level scene
comprehension, and obstructs collaboration
3
4
Motivation

• Current Surveillance Monitoring Center
• Overwhelmed with data fusion and comprehension of
  multiple image streams.
• Limited number of displays
• Waste of Resources

• Better Surveillance System
• Better understanding of streams
• Better use of resources
• Additional capabilities tracking, statistics

USC Public Security Surveillance Center
5
Outline

• Augmented Virtual Environment (AVE)
• Surveillance with AVE
• Dynamic Object Detection
• Visualization
• Conclusion and Future work

6
AVE Fusion of 2D Video/Image 3D Model

• VE captures only a snapshot of the real world,
  therefore lacks any representation of dynamic
  events and activities occurring in the scene
• AVE Approach uses sensor models and 3D models
  of the scene to integrate dynamic video/image
  data from different sources

• Visualize all data in a single context to
  maximize collaboration and comprehension of the
  big-picture
• Address dynamic visualization and change
  detection

7
AVE vs. Others

• Augmented Virtual Environment 1
• Fusion of dynamic imagery with 3D models in a
  real-time display to help observers comprehend
  multiple streams of temporal data and imagery
  from arbitrary views of the scene
• Related Work
• Distributed Interactive Video Array (DIVA) at
  UCSD 2
• VideoFlashlight at Sarnoff Corporation 3
• Video Surveillance and Monitoring (VSAM) at CMU
  4

1 Neumann U., You S., Hu J., Jiang B., and Lee
J. Augmented Virtual Environments (AVE) Dynamic
Fusion of Imagery and 3D Models VR03, March
2003 2 Hall B. Trivedi M. A novel graphical
interface and context aware map for incident
detection and monitoring, 9th World Congress on
Intelligent Transport Systems, October, 2002. 3
Kumar R. Sawhney H.S. Guo Y. Hsu S. Samarasekera
. 3D manipulation of motion imagery, ICIP2000,
September 2000 4 T. Kanade, R. Collins, A.
Lipton, P. Burt and L. Wixson, Advances in
cooperative multi-sensor video surveillance,
Proc. of DARPA Image Understanding Workshop, Vol.
1, pp. 3-24, 1998
8
AVE System Components

• Accurate 3D models
• Scene model as substrate
• Accurate 3D sensor models
• Sensor calibration tracking
• Image analysis
• detection tracking of moving objects (people,
  vehicles) and pseudo-models
• Dynamic visualization
• Data fusion video projection

9
AVE Requires a 3D Scene Model (Substrate)

• Approach
• Model reconstruction
• Input LiDAR point cloud
• Output 3D mesh model
• Automated
• Building extraction
• Vegetation remove
• Building detection
• Model fitting
• Semi-automated

3D model of USC campus
10
AVE Requires Sensor Models (Tracking)

• Tracking is the key
• Need accurate tracking information for image
  projection and fusion
• (where am I, where am I looking?)
• 6DOF measurement
• High precision

• Approach
• Combines geometric and intensity constraints to
  establish accurate 2D-3D correspondence
• Hybrid GPS/Vision/Vision tracking strategy
• An Extended Kalman Filter framework

11
AVE Requires Image/Video Texture Projection
Video Texture Mapping

• Update sensor pose and image to paint the
  scene each frame
• Compute texture transformation during rendering
  of each frame
• Dynamic control during visualization session to
  reflect most recent information
• Supports up to 4 real-time video streams
• Real-time rendering - graphics HW produces
  28fps on dual 2G PC - 1280x1024 screen

12
Dynamic Event Analysis Modeling

• Video analysis
• Segmenting and tracking moving objects (people,
  vehicle) in the scene
• Event modeling
• Creating pseudo-3D animated model
• Improving visualization situational awareness

13
Tracking and Modeling Approach

• Object detection
• Background subtraction
• A variable-length time average background model
• Morphological Filtering
• Object tracking
• SSD correlation matching
• Object modeling
• Dynamic polygon model
• 3D parameters (position, orientation and size)

14
Tracking and Modeling Results

• Tracking in 2D and modeling in pseudo 3D

15
Integrated AVE Environment

• An integrated visualization environment built in
  the IMSC laboratory
• 8x10 foot acrylic back-projection screen
  (Panowall) with stereo glasses interface
• Christie Mirage 2000 stereo cinema projector with
  HD SDI
• 3rdTech ceiling tracker
• A dual 2G CPU Computer (DELL) with Nvidia Quadro
  FX 400 graphics card
• Supports multiple DV video sources (lt4) in
  real-time (28pfs)

16
DEMO
17
Future Work

• Texture Management - texture retention,
  progressive refinement
• System Architecture - scalable video streams and
• Dynamic modeling - detection, tracking, and
  modeling of moving objects

18
Conclusion

• A novel visualization system for video
  surveillance based on tracking and 3D display of
  moving objects in an Augmented Virtual
  Environment (AVE) is presented
• Adaptive background-subtraction method combined
  with a pseudo-tracking algorithm for dynamic
  object detection
• Visualization of the dynamic objects in the AVE
  system
• Fusion of all the video, image and 3D models

19
Acknowledgement

• Integrated Media Systems Center, USC
• NIMA
• MURI team Avideh Zakhor (UC Berkeley), Suresh
  Lodha (UC Santa Cruz), Bill Ribarsky (Georgia
  Tech), and Pramod Varshney (Syracuse)
