Infiniband

1
Infiniband

• Bart Taylor

2
What it is
InfiniBand Architecture defines a new
interconnect technology for servers that changes
the way data centers will be built, deployed and
managed. By creating a centralized I/O fabric,
InfiniBand Architecture enables greater server
performance and design density while creating
data center solutions that offer greater
reliability and performance scalability.
InfiniBand technology is based upon a
channel-based switched fabric point-to-point
architecture. --www.infinibandta.org
3
History

• Infiniband is the result of a merger of two
  competing designs for an inexpensive high-speed
  network.
• Future I/O combined with Next Generation I/O form
  what we know as Infiniband.
• Future I/O was being developed by Compaq, IBM,
  and HP
• Next Generation I/O was being developed by Intel,
  Microsoft, and Sun Microsystems
• Infiniband Trade Association maintains the
  specification

4
The Basic Idea

• High speed, low latency data transport
• Bidirectional serial bus
• Switched fabric topology
• Several devices communicate at once
• Data transferred in packets that together form
  messages
• Messages are direct memory access, channel
  send/receive, or mulitcast
• Host Channnel Adapters (HCAs) are deployed on PCI
  cards

5
Main Features

• Low Latency Messaging lt 6 microseconds
• Highly Scalable Tens of thousands of nodes
• Bandwidth 3 levels of link performance
• 2.5 Gbps
• 10 Gbps
• 30 Gbps
• Allows multiple fabrics on a single cable
• Up to 8 virtual lanes per link
• No interdependency between different traffic flows

6
Physical Devices

• Standard copper cabling
• Max distance of 17 meters
• Fiber-optic cabling
• Max distance of 10 kilometers
• Host Channnel Adapters on PCI cards
• PCI, PCI-X, PCI-Express
• InfiniBand Switches
• 10Gbps non-blocking, per port
• Easily cascadable

7
Host Channel Adapters

• Standard PCI
• 133 MBps
• PCI 2.2 - 533 MBps
• PCI-X
• 1066 MBps
• PCI-X 2 - 2133 MBps
• PCI-Express
• x1 5Gbps
• x4 20Gbps
• x8 40Gbps
• x16 80Gbps

8
DAFS

• Direct Access File System
• Protocol for file storage and access
• Data transferred as logical files, not physical
  storage blocks
• Transferred directly from storage to client
• Bypasses CPU and Kernel
• Provides RDMA functionality
• Uses the Virtual Interface (VI) architecture
• Developed by Microsoft, Intel, and Compaq in 1996

9
RDMA
10
TCP/IP Packet Overhead
11
Latency Comparison

• Standard Ethernet TCP/IP Driver
• 80 to 100 microseconds latency
• Standard Ethernet Dell NIC with MPICH over TCP/IP

• 65 microseconds latency
• Infiniband 4X with MPI Driver
• 6 microseconds
• Myrinet
• 6 microseconds
• Quadrics
• 3 microseconds

12
Latency Comparison
13
References

• Infiniband Trade Association - www.infinibandta.or
  g
• OpenIB Alliance - www.openib.org
• TopSpin - www.topspin.com
• Wikipedia - www.wikipedia.org
• OReilly - www.oreillynet.com
• Sourceforge - infiniband.sourceforge.net
• Performance Comparison of MPI Implementations
  over InfiniBand, Myrinet and Quadrics. Computer
  and Information Science. Ohio State University.
  - nowlab.cis.ohio-state.edu/p
  rojects/mpi-iba/publication/sc03.pdf
