Numerical Descriptive Techniques

1
Numerical Descriptive Techniques

• Chapter 4

2
4.2 Measures of Central Location

• Usually, we focus our attention on two types of
  measures when describing population
  characteristics
• Central location (e.g. average)
• Variability or spread

The measure of central location reflects the
locations of all the actual data points.
3
4.2 Measures of Central Location

• The measure of central location reflects the
  locations of all the actual data points.
• How?

With two data points, the central location
should fall in the middle between them (in order
to reflect the location of both of them).
But if the third data point appears on the left
hand-side of the midrange, it should pull the
central location to the left.
4
The Arithmetic Mean

• This is the most popular and useful measure of
  central location

5
The Arithmetic Mean
Sample mean
Population mean
Sample size
Population size
6
The Arithmetic Mean
The arithmetic mean

• Example 4.1

The reported time on the Internet of 10 adults
are 0, 7, 12, 5, 33, 14, 8, 0, 9, 22 hours. Find
the mean time on the Internet.
0
7
22
11.0
42.19
38.45
45.77
43.59
7
The Median

• The Median of a set of observations is the value
  that falls in the middle when the observations
  are arranged in order of magnitude.

Odd number of observations
8
0, 0, 5, 7, 8 9, 12, 14, 22
8.5,
0, 0, 5, 7, 8, 9, 12, 14, 22, 33
8
The Mode

• The Mode of a set of observations is the value
  that occurs most frequently.
• Set of data may have one mode (or modal class),
  or two or more modes.

For large data sets the modal class is much more
relevant than a single-value mode.
The modal class
9
The Mode
The Mode
The Mean, Median, Mode

• Example 4.5Find the mode for the data in Example
  4.1. Here are the data again 0, 7, 12, 5, 33,
  14, 8, 0, 9, 22
• Solution
• All observation except 0 occur once. There are
  two 0. Thus, the mode is zero.
• Is this a good measure of central location?
• The value 0 does not reside at the center of
  this set(compare with the mean 11.0 and the
  mode 8.5).

10
Relationship among Mean, Median, and Mode

• If a distribution is symmetrical, the mean,
  median and mode coincide

• If a distribution is asymmetrical, and skewed to
  the left or to the right, the three measures
  differ.

A positively skewed distribution (skewed to the
right)
Mode
Mean
Median
11
Relationship among Mean, Median, and Mode

• If a distribution is symmetrical, the mean,
  median and mode coincide

• If a distribution is non symmetrical, and skewed
  to the left or to the right, the three measures
  differ.

A negatively skewed distribution (skewed to the
left)
A positively skewed distribution (skewed to the
right)
Mean
Mode
Mean
Mode
Median
Median
12
4.3 Measures of variability

• Measures of central location fail to tell the
  whole story about the distribution.
• A question of interest still remains unanswered

How much are the observations spread out around
the mean value?
13
4.3 Measures of variability
Observe two hypothetical data sets
Small variability
The average value provides a good representation
of the observations in the data set.
Larger variability
The same average value does not provide as good
representation of the observations in the data
set as before.
14
The range

• The range of a set of observations is the
  difference between the largest and smallest
  observations.
• Its major advantage is the ease with which it can
  be computed.
• Its major shortcoming is its failure to provide
  information on the dispersion of the observations
  between the two end points.

But, how do all the observations spread out?
The range cannot assist in answering this question
Range
Largest observation
Smallest observation
15
The Variance
16
The Variance
Let us calculate the variance of the two
populations
Why is the variance defined as the average
squared deviation? Why not use the sum of squared
deviations as a measure of variation instead?
After all, the sum of squared deviations
increases in magnitude when the variation of a
data set increases!!
17
The Variance

• Example 4.7
• The following sample consists of the number of
  jobs six students applied for 17, 15, 23, 7, 9,
  13. Finds its mean and variance
• Solution

18
The Variance Shortcut method
19
Standard Deviation

• The standard deviation of a set of observations
  is the square root of the variance .

20
Standard Deviation

• Example 4.8
• To examine the consistency of shots for a new
  innovative golf club, a golfer was asked to hit
  150 shots, 75 with a currently used (7-iron)
  club, and 75 with the new club.
• The distances were recorded.
• Which 7-iron is more consistent?

21
Standard Deviation
The Standard Deviation

• Example 4.8 solution

Excel printout, from the Descriptive
Statistics sub-menu.
The innovation club is more consistent, and
because the means are close, is considered a
better club
22
Interpreting Standard Deviation

• The standard deviation can be used to
• compare the variability of several distributions
• make a statement about the general shape of a
  distribution.
• The empirical rule If a sample of observations
  has a mound-shaped distribution, the interval

23
Interpreting Standard Deviation

• Example 4.9A statistics practitioner wants to
  describe the way returns on investment are
  distributed.
• The mean return 10
• The standard deviation of the return 8
• The histogram is bell shaped.

24
Interpreting Standard Deviation

• Example 4.9 solution
• The empirical rule can be applied (bell shaped
  histogram)
• Describing the return distribution
• Approximately 68 of the returns lie between 2
  and 18 10 1(8), 10
  1(8)
• Approximately 95 of the returns lie between -6
  and 26 10 2(8), 10
  2(8)
• Approximately 99.7 of the returns lie between
  -14 and 34 10
  3(8), 10 3(8)

25
The Coefficient of Variation

• The coefficient of variation of a set of
  measurements is the standard deviation divided by
  the mean value.
• This coefficient provides a proportionate measure
  of variation.

A standard deviation of 10 may be perceived large
when the mean value is 100, but only moderately
large when the mean value is 500
26
4.4 Measures of Relative Standing and Box
Plots

• Percentile
• The pth percentile of a set of measurements is
  the value for which
• p percent of the observations are less than that
  value
• 100(1-p) percent of all the observations are
  greater than that value.
• Example
• Suppose your score is the 60 percentile of a SAT
  test. Then

40
60 of all the scores lie here
27
Quartiles

• Commonly used percentiles
• First (lower)decile 10th percentile
• First (lower) quartile, Q1, 25th percentile
• Second (middle)quartile,Q2, 50th percentile
• Third quartile, Q3, 75th percentile
• Ninth (upper)decile 90th percentile

28
Quartiles

• Example
• Find the quartiles of the following set of
  measurements 7, 8, 12, 17, 29, 18, 4, 27, 30, 2,
  4, 10, 21, 5, 8

29
Quartiles

• Solution
• Sort the observations
• 2, 4, 4, 5, 7, 8, 10, 12, 17, 18, 18, 21, 27, 29,
  30

The first quartile
At most (.25)(15) 3.75 observations should
appear below the first quartile. Check the first
3 observations on the left hand side.
At most (.75)(15)11.25 observations should
appear above the first quartile. Check 11
observations on the right hand side.
CommentIf the number of observations is even,
two observations remain unchecked. In this case
choose the midpoint between these two
observations.
30
Location of Percentiles

• Find the location of any percentile using the
  formula
• Example 4.11
• Calculate the 25th, 50th, and 75th percentile of
  the data in Example 4.1

31
Location of Percentiles

• Example 4.11 solution
• After sorting the data we have 0, 0, 5, 7, 8, 9,
  22, 33.

32
Location of Percentiles

• Example 4.11 solution continued
• The 50th percentile is halfway between the fifth
  and sixth observations (in the middle between 8
  and 9), that is 8.5.

33
Location of Percentiles

• Example 4.11 solution continued
• The 75th percentile is one quarter of the
  distance between the eighth and ninth observation
  that is14.25(22 14) 16.

Eighth observation
Ninth observation
34
Quartiles and Variability

• Quartiles can provide an idea about the shape of
  a histogram

Q1 Q2 Q3
Q1 Q2 Q3
Positively skewed histogram
Negatively skewed histogram
35
Interquartile Range

• This is a measure of the spread of the middle 50
  of the observations
• Large value indicates a large spread of the
  observations

Interquartile range Q3 Q1
36
Box Plot

• This is a pictorial display that provides the
  main descriptive measures of the data set
• L - the largest observation
• Q3 - The upper quartile
• Q2 - The median
• Q1 - The lower quartile
• S - The smallest observation

S
Q1
Q2
Q3
L
37
Box Plot

• Example 4.14 (Xm02-01)

Left hand boundary 9.2751.5(IQR)
-104.226 Right hand boundary84.9425
1.5(IQR)198.4438
0
9.275
198.4438
-104.226
84.9425
119.63
26.905
No outliers are found
38
Box Plot

• Additional Example - GMAT scores
• Create a box plot for the data regarding the
  GMAT scores of 200 applicants (see GMAT.XLS)

537
512
449
575
417.5
669.5
788
5751.5(IQR)
512-1.5(IQR)
39
Box Plot
GMAT - continued
Q1 512
Q2 537
Q3 575
449
669.5
25
50
25

• Interpreting the box plot results
• The scores range from 449 to 788.
• About half the scores are smaller than 537, and
  about half are larger than 537.
• About half the scores lie between 512 and 575.
• About a quarter lies below 512 and a quarter
  above 575.

40
Box Plot
GMAT - continued
The histogram is positively skewed
Q1 512
Q2 537
Q3 575
449
669.5
25
50
25
50
25
25
41
4.5 Measures of Linear Relationship

• The covariance and the coefficient of correlation
  are used to measure the direction and strength of
  the linear relationship between two variables.
• Covariance - is there any pattern to the way two
  variables move together?
• Coefficient of correlation - how strong is the
  linear relationship between two variables

42
Covariance
mx (my) is the population mean of the variable X
(Y). N is the population size.
43
Covariance

• Compare the following three sets

44
Covariance

• If the two variables move in the same direction,
  (both increase or both decrease), the covariance
  is a large positive number.

• If the two variables move in opposite directions,
  (one increases when the other one decreases), the
  covariance is a large negative number.
• If the two variables are unrelated, the
  covariance will be close to zero.

45
The coefficient of correlation

• This coefficient answers the question How strong
  is the association between X and Y.

46
The coefficient of correlation
1 0 -1
Strong positive linear relationship
COV(X,Y)gt0
or
r or r
No linear relationship
COV(X,Y)0
COV(X,Y)lt0
Strong negative linear relationship
47
The coefficient of correlation

• If the two variables are very strongly positively
  related, the coefficient value is close to 1
  (strong positive linear relationship).
• If the two variables are very strongly negatively
  related, the coefficient value is close to -1
  (strong negative linear relationship).
• No straight line relationship is indicated by a
  coefficient close to zero.

48
The coefficient of correlation and the
covariance Example 4.16

• Compute the covariance and the coefficient of
  correlation to measure how GMAT scores and GPA in
  an MBA program are related to one another.
• Solution
• We believe GMAT affects GPA. Thus
• GMAT is labeled X
• GPA is labeled Y

49
The coefficient of correlation and the
covariance Example 4.16 Excel

• Use the Covariance option in Data Analysis
• If your version of Excel returns the population
  covariance and variances, multiply each one by
  n/n-1 to obtain the corresponding sample values.
• Use the Correlation option to produce the
  correlation matrix.

Variance-Covariance Matrix
Population values
Sample values
Population values
Sample values
50
The coefficient of correlation and the
covariance Example 4.16 Excel

• Interpretation
• The covariance (26.16) indicates that GMAT score
  and performance in the MBA program are positively
  related.
• The coefficient of correlation (.5365) indicates
  that there is a moderately strong positive linear
  relationship between GMAT and MBA GPA.

51
The Least Squares Method

• We are seeking a line that best fits the data
  when two variables are (presumably) related to
  one another.
• We define best fit line as a line for which the
  sum of squared differences between it and the
  data points is minimized.

The y value of point i calculated from the
equation
The actual y value of point i
52
The least Squares Method
Y
X
Different lines generate different errors, thus
different sum of squares of errors.
There is a line that minimizes the sum of squared
errors
53
The least Squares Method
The coefficients b0 and b1 of the line that
minimizes the sum of squares of errors are
calculated from the data.
54
The Least Squares Method

• Example 4.17
• Find the least squares line for Example 4.16
  (Xm04-16.xls)
