Class, Friday, Oct 24

1
Class, Friday, Oct 24
2
Announcements

• Homework Ch 8 originally due on Monday, Oct 27
  moved to Wednesday, Oct 29
• Calcium lab due at classtime on Friday, Oct 31
• I am changing the date of exam 2 to Monday, Nov 3
  unless there are problems
• No class on Monday, Oct 27 Prof and Chris will
  be attending the regional American Chemical
  Society meeting where Chris is giving a poster
  presentation. Congratulations to Chris!

3
Chapter 9 Acid-Base Titrations
4
The titration of femtomolar (10-15) quantities of
nitric acid.
5
The titration of a Strong Base with a Strong Acid

• Chemical Reaction net ionic equation
• H OH? ? H2O
• The specific identity of the acid and base is
  not important for this titration.

6
The titration of a Strong Base with a Strong Acid

• The equivalence point is whenever the
• number of moles of the titrant are exactly equal
• to the number of moles of the analyte.
• The end point is that pH when the visual
  indicator
• changes color as discussed in chapter 8. For
• accurate titrations, the end point ought to be
  the
• same as the equivalance point. If it is not, the
• difference is the end-point error.

7
The titration of a Strong Base with a Strong Acid

• The titration curve (plot of pH vs Volume of
  titrant) may be calculated for the SA/SB
  titration by considering 3 unique regions They
  are
• Region before the equivalence point
• The equivalence point
• Region after the equivalence point
• We want to consider each of the above points. We
  can
• calculate the pH values as a function of the
  amount of added
• titrant.

8
The titration of a Strong Base with a Strong Acid

• Region before the equivalence point
• Before the equivalence point the unreacted OH?
  establishes the pH of the reaction mixture. The
  calculations involved determining the number of
  moles of OH- minus the number of moles of H
  added to that point, and dividing by the volume
  of the reaction mixture, generally the initial
  volume plus the volume of the titrant added.

9
The titration of a Strong Base with a Strong Acid

• Region before the equivalence point
• For example, what is the pH after 10.00 mL of
  0.1000 M HCl has been added in the titration of
  50.00 mL of 0.1000 M NaOH?
• Initial mole OH- 50.00 x 0.1000 5 x 10-3 or
  5 mmol
• mole H added 10.00 x 0.1000 1 x 10-3 or 1
  mmol
• moles unreacted OH- 5 1 4 mmol
• Total volume 10.00 50.00 60.00 mL
• OH- 4mmol / 60.00mL 0.06667 mmol/mL
• pOH -log(0.06667) 1.18 pH 12.82
• All other points prior to the equivalence point
  are calculated by like fashion.

10
The titration of a Strong Base with a Strong Acid

• At the equivalence point
• For the SA/SB titration, the pH at the
  equivalence point is always 7.00.
• Often we will need to calculate the volume of
  titrant to reach the equivalence point. At the
  equivalence point the mol of OH- mol H.
• In the previous example, the total mol of base
  were 5 mmol therefore, 5 mmol of acid are
  required to reach the equivalence point. Since V
  x M mol, 5mmol / conc volume of titrant, or
  in this case, 5 / 0.1000 50.00 mL, the volume
  of HCl to reach the equivalence point

11
The titration of a Strong Base with a Strong Acid

• Region after the equivalence point
• The pH of the reaction mixture after the
  equivalence point is established by the
  concentration of the excess amount of titrant
  (here the acid)
• What is the pH of the solution whenever a total
  of 55 mL of HCl has been added?
• The mmol of H in excess (55 50)(0.1000)
• 0.5000 mmol
• The total volume at this point is (50 55)
  105mL
• The H 0.5000 mmol/105 mL 0.00476 M
• pH -log(0.00476) 2.32

12
The titration curve for the titration of a strong
base such as NaOH with a strong acid such as HCl
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
