Theoretical Astrophysics

1
Theoretical Astrophysics
Part 3

• Bram Achterberg
• a.achterberg_at_astro.uu.nl
• http//www.astro.uu.nl/achterb/astrophysics

2
Kelvin-Helmholtz Instability

• An example of a fluid system
• that is not stable against small perturbations

3
Numerical Simulation of the Kelvin-Helmholtz
Instabilityin an astrophysical jet
4
Basic situation two streaming fluidsseparated
by a sharp boundary
z 0
After a small perturbation
5
Applications in Astrophysics
Interaction of the Earths magnetosphere And the
Solar Wind
6
Wiggles in parsec-scale jets of Active Galaxies
7
(No Transcript)
8
General approach perturbation analysis of the
dynamical equations for a fluid
9
A quick and dirty derivation
Equation of motion
Small perturbation
Linearized equation For the perturbed motion
10
Equation of motion for small perturbations
Different equations for the two half-spaces!
11
Incompressible fluctuations no sound waves!
12
Incompressible fluctuations no sound waves!
13
Incompressible fluctuations no sound waves!
Pressure satisfies Poissons equation!
14
Remember two streaming fluidsseparated by a
sharp boundary,situation is uniform in x and y
directions!
z 0
15
Solution for pressure in both fluids
Wave-like solution
Poissons equation
At fluid interface z0 pressure must be the same
on both sides!
16
Solution for pressure in both fluids
Wave-like solution
At fluid interface z0 pressure must be the same
on both sides!
17
Solution for pressure in both fluids
Wave-like solution
At fluid interface z0 pressure must be the same
on both sides!
18
Amplitudes from Equation of Motion
Wave-like solution
Equation of motion in component form for lower
fluid
19
Solution
Amplitude in lower fluid
20
Solution
Amplitude in lower fluid
Upper fluid by analogy!
21
Physical boundary condition at interface
displacement must match!
22
Boundary condition yields dispersion relation
between ? and k !
23
Boundary condition yields dispersion relation
between ? and k !
Always a growing solution the system is unstable!
24
time
25
(No Transcript)
26
Compressible case finite sound speed effects
Simplest possible situation two
counterstreaming but otherwise identical fluids
27
Very symmetric KH Dispersion Relation
Incompressible case recovered for infinite sound
speed
28
The compressible case effect of finite sound
speed
unstable
29
Numerical simulation Of the KH Instability
30
The Rayleigh-Taylor Instability
The inability of a light fluid to support a heavy
fluid against gravity
31

• What will we do??
• Perturb the interface at z0

2. Look for wave-like solutions to the
equation of motion

• Find the frequency ? of the
• perturbations
• 4. Look for solutions with Im(?)gt0

32
Numerical simulation Of RT Instability inside a
SN1A nuclear flame (Bell et al 2004)
g
Hot burned material less dense!
33
Calculation is analogous to KH case
34
Solution for pressure in both fluids
Wave-like solution
35
Conditions at the interface (z0)

• Displacement the same
• on both sides of interface

2. Pressure jump due to gravity and the
density jump
From the equation of motion
36
Explanation of the pressure jump
37
Dirac delta-function
38
(No Transcript)
39
Resulting dispersion relation for the frequency
of the RT Instability
