Predictive State Representations

1
Predictive State Representations
Duke University Machine Learning
Group Discussion Leader Kai Ni September 09, 2005
2
Outline

• Predictive State Representations (PSR) Model
• Constructing a PSR from a POMDP
• Learning parameters for PSR
• Conclusions

3
Two Popular Methods

• There are two dominant approaches in
  controlling/AI area.
• The generative-model approach
• Typified by POMDP, more general, unlimited
  memory
• Strongly dependent on a good model of system.
• The history-based approach
• Typified by k-order Markov methods, simple and
  effective
• Limited by history extension.

4
The Position of PSR
Figure 1 Data flow in a) POMDP and other
recursive updating of state representation, and
b) history-based state representation.

• The predictive state representation (PSR)
  approach
• Like the generative-model approach in that it
  updates the state representation recursively
• Like the history-based approach in that its
  representations are grounded in data

5
What is a PSR

• A PSR looks to the future and represents what
  will happen.
• A PSR is a vector of predictions for a specially
  selected set of action-observation sequences,
  called tests
• One test for a1o1a2o2 after time k means
• A PSR is a set of tests that is sufficient
  information to determine the prediction for all
  possible tests (a sufficient statistic).

6
The System-Dynamics Vector (1)

• Given an ordering over all possible tests t1t2,
  the systems probability distribution over all
  tests, defines an infinite system-dynamics vector
  d.
• The ith elements of d is the prediction of the
  ith test
• The predictions in d have some properties

7
The System-Dynamics Vector (2)
Figure 2 a) Each of ds entries corresponds to
the prediction of the test. b)Properties of the
predictions imply structure in d.
8
System-Dynamics Matrix (1)

• To make the structure explicit, we consider a
  matrix, D, whose columns correspond to tests and
  whose rows correspond to histories.
• Each element is a history-conditional prediction
• The first history is the zero length history,
  thus the system-dynamics vector d is the first
  row of the matrix D.

9
System-Dynamics Matrix (2)
Figure 3 The rows in the system-dynamics matrix
correspond to all possible histories (pasts),
while the columns correspond to all possible
tests (futures). The entries in the matrix are
the probabilities of futures given pasts.

• All the entries of matrix D are uniquely
  determined by the vector d because both the
  numerator and the denominator are elements of d.

10
POMDP and D

• The system-dynamics matrix D is not a model of
  the system but should be viewed as the system
  itself.
• D can be generated from a POMDP model by
  generating each tests prediction as follows
• Theorem A POMDP with k nominal states cannot
  model a dynamical system with dimension greater
  than k.
• The dimension of a dynamic system equal to the
  rank of D

11
The Idea of Linear PSR

• For any D with rank k, there must exist k
  linearly independent columns and rows. We
  consider the set of columns and let the tests
  corresponding to these columns be Q q1 q2
  qk, called core tests.
• For any h, the prediction vector p(Qh)
  p(q1h) p(qkh is a predictive state
  representation. It forms a sufficient statistic
  for the system. All other tests can be calculated
  from the linear dependence
• p(th) p(Qh)Tmt, where mt is the weight
  vector for test t.

12
Update the core tests

• The predictive vector can be update recursively
  after new action-observation pair is added.

Figure 4 An example of system-dynamics matrix.
The set Q t1, t3, t4 forms a set of core
tests. The equations in the ti column show how
any entry on a row can be computed from the
prediction vector of that row.
13
Constructing a PSR from a POMDP

• POMDP updates its belief state by computing
• Define a function u mapping tests to (1 x k)
  vectors by
• u(?) 1 and u(aot) (TaOa,ou(t)T)T. We call
  u(t) the outcome vector for test t.
• A test t is linearly independent of a set of
  tests S if u(t) is linearly independent of the
  set of u(S).

14
Searching Algorithm
Figure 5 Searching algorithm for finding a
linear PSR from a POMDP.

• The cardinality of Q is bounded by k and no test
  in Q is longer than k action-observation pairs.
• All other tests can be computed by

15
An Example of PSR
Figure 6 The float-reset problem

• Any linear PSR of this system has 5 core tests.
  One such PSR has the core tests and the initial
  predictions
• Q r1, f0r1, f0f0r1, f0f0f0r1, f0f0f0f0r1.
• q(Qh) 1, 0.5, 0.5, 0.375, 0.375
• After a float action, the last prediction is
  updated by
• p(f0f0f0f0r1hf0) q(Qh).0625, -.0625, -.75,
  -.75, 1T

16
Learning PSR model

• The parameters we need to learn are weight vector
  mao and weight matrix Mao with the ith column
  equal to maoqi
• Using an Oracle
• Parameters can be computed by
• Build a PSR by querying the oracle for p(QH),
  p(aoH) and p(aoqiH)
• Without an Oracle
• Estimate an entry p(th) in D by performing a
  Bernoulli trial
• Using suffix-history to get around the problem
  without reset

17
TD (temporal difference) Learning

• Update long-term guess based on the next time
  step instead of waiting until the end.
• t a1o1a2o2a3o3 and is the estimation
  of p(th). After takes action a1 and observe
  ok1, TD estimation is
• and model parameters can be updated based on
  error.
• Expand the Q to include all suffixes of the core
  tests, called Y.

18
Result (1)
Table 1. Domain and Core Search Statistics. The
Asymp column denotes the approximate asymptote
for the percent of required core tests found
during the trials for suffix-history (with
parameter 0.1). The Training column denotes the
approximate smallest training size at which the
algorithm achieved the asymptote value.
19
Result (2)

• Average error between prediction and truth.

Figure 7 Comparison of Error vs. training length
for tiger problem
20
Conclusion

• Predictive state representation (PSR) is a new
  way to model the dynamical systems. It is more
  general than both POMDPs and nth-order Markov
  models. PSR is grounded in data flow and is easy
  to learn.
• The system-dynamics matrix provides an
  interesting way of looking at discrete dynamical
  systems.
• The author propose suffix-history and TD
  algorithm for learning PSR without reset. Both of
  them have small prediction error.

21
Reference

• M. L. Littman, R. S. Sutton and S. Singh,
  Predictive Representations of State, NIPS 2002
• S. Singh, M. R. James and M. R. Rudary,
  Predictive State Representations A New Theory
  for Modeling Dynamical Systems, UAI 2004
• B. Wolfe, M. R. James and S. Singh, Learning
  Predictive State Representations in Dynamical
  Systems Without Reset, ICML 2005
