State-wide Communications System for Law
Enforcement and Public Safety

Project Update Dan Brown,
Project Director

3
The Challenges of CoordinationDuring a Critical
Incident
Make it Happen
4
Definition

• Interoperability is the ability of public safety
  service and support providers to communicate with
  each other via voice and/or data
• On demand
• In real time
• When needed
• When authorized

5
More than one way..
VHF
800MHZ
6
Project 25

• The FY05 HSGP guidance "encourages" applicants to
  purchase equipment that meets public safety
  standards, including Project 25. At a minimum,
  public safety land mobile radio equipment
  purchased with Federal homeland security grants
  should support use of the Common Air Interface,
  which is the most mature interface in the
  Project. ICTAP recommends that urban areas make
  efforts to ensure equipment that is procured will
  support the ISSI with minimal upgrades.

7
All Hazards Regional CouncilsStrategic Vision
with Regionalization

• Strategic Plan
• Regional Response and Growth
• Visionary
• Competitive
• Ensures Long range Continuity

Over 100 million
8
Interoperability Techniques Short-Term Solutions
Mutual Aid Repeater System
800 MHz
Repeater
Talkaround
Swap Radios
9
Growing the UASI System
10
LETPP Solution

• Interoperable Communications System that when
  implemented
• Uses existing Radio Frequency infrastructure
• Achieves on demand interoperability through
  overlay additions to the current RF
  infrastructure IP network backbone, IP network
  components and Mobile Communication Units
• Provides flexibility and scalability
• Achieves functionality in area covering 75 of
  state population with fixed communications
  assets functionality in remaining 25 with
  mobile communication assets
• Can be implemented within 8M budget
• Can be completed within two year time frame
• Can be managed effectively with three working
  groups Task Force Requirements Analysis Group,
  Technical Working Group, Operations Working Group

11
Motorola MOTOBridge

• Comprised of 4 basic components
• Operational Management Control (OMC) Server
• Keeps track of network configuration and is used
  to manage entire system
• Two redundant systems (main and backup)
• Session Initiated Protocol (SIP) Server
• Sets up calls on the system
• Two redundant systems (main and backup)
• Radio Gateway Unit (RGU)
• Connects the radio systems into the network
• Resides in every jurisdiction (usually in
  communications center)
• Work Station Gateway Unit (WSGU)
• Gives dispatcher access to the system
• Resides in every jurisdiction (usually in
  communications center)

12
MOTOBridge Technology
System A
System B
MCU
800 MHz
VHF
RGU
RGU
MPLS
VHF
UHF
WSGU
Dispatch
WSGU
911 Dispatch
OMC Server
SIP Server
13
(No Transcript)
14
What can you expect?

• Opportunity
• Plan for Growth and Development
• Mutual Aid Connectivity/Pool resources
• Statewide Gateway Network
• Possible amateur/Public safety connection

15
What Project Will Not Do

• Increase Radio Frequency Coverage
• Increase Channel Capacity
• Allow Radio of One Type to Communicate with
  Transmitter of Different Type
• Eliminate Technology Obsolescence

16
Administrative Model
17
Project Time Lines

• Feasibility Complete 12/01/04
• Project Start 2/14/05
• RFQC Release 4/01/05
• TFRAG Approval of RFP Vendors PSAPs -5/2/05
• RFP Release 5/16/05
• RFP Technical Evaluation Complete 7/20/05
• RFP Price and Final Evaluation Complete 7/29/05
• Vendor Recommendations to TFRAG 8/12/05
• Vender Selected/Contract Negotiated 9/13/05
• Vendor Identification of Project Team
  Background Check 9/15/05
• Pilot (Cobb, Floyd, Glynn, Cores) 12/16/05
• Pilot (Muscogee) 3/16/06
• First MCU Delivery 4/30/06
• Production Deployment Start 7/16/06
• Production Complete 3/30/07

18
(No Transcript)
19
Coverage Map
36
87.7 Population
20
Phase One Status

• PSAPs
• Expected Total Number (Phase 1) 68
• Kickoffs 67
• Workshops 62
• Designs/Proposals Completed 44
• Client Decisions 27
• Installations 10
• MCUs
• Total Number 2
• Acceptance Test 4 plus locals
• Training Sessions
• End Users 2
• System Administrators 1
• System Engineers - 2

21
Investment Summary

• PSAP Equipment
• R-GU, WS-GU, Workstation, VHF Radio System
• Network Connectivity
• Common System Equipment (share)
• OMC Servers, SIP Servers, MCUs
• Network Connectivity (Reoccurring Cost)
• Common Services (share)
• Procurement, Technical, Project Management,
  Training, Support
• Total 132,000

22
Local Government Responsibilities

• Provide Own Radios for Gateway Units
• Obtain Necessary Signatures on MOAs
• Facility Upgrades\Additional Radios
• Support Training and Exercise Programs
• Develop and Support System Operational Procedures

23
State Responsibilities

• Provide Legal and Procurement Assistance
• Secure Funding for Project Success
• Provide Leadership in Establishing System
  Operational Procedures
• Provide Central Fleet Management and Maintenance
  - GSP (administration)
• Overall Project Management

24
Value Proposition for System

• Local Law Enforcement
• Interoperable communications for law enforcement
  and other first responders at local level
• Interoperability with neighboring agencies with
  overlapping radio frequency coverage
• Dispatch back-up capability with other agencies
  for continuity of operations
• Dispatch conferencing with other departments and
  agencies
• Interoperable communications statewide in major
  events
• State Agencies
• Centralized broadcast, remote monitoring
  statewide in major event situations
• Selective dispatch center conferencing statewide
• Dispatch consolidation
• All
• Participate in first statewide interoperable
  communications project
• Help create a model for future state wide
  interoperable communication projects involving
  multiple local and state government agencies
• Project mostly funded by federal money for first
  two years

25
Managing Cost

• Maintenance
• Upgrades
• Network
• Unified Pricing

26
(No Transcript)
27
Success

• On time
• On budget
• Achieved Interoperability by Project Design.
• Satisfied constituents

28
Methodology for PSAP Design
29
Design Related Activities

• Site Walk by GTRI
• Survey current power, data connectivity, space,
  and radio systems in use
• Identify space, power, rack requirements, data
  connectivity and schedule required for LETPP
• Understand operations
• Agencies dispatched
• Determine interfaces for Radio Gateway Unit (RGU)
• Needs driven
• Introduce Agency Interoperability Matrix (AIM)
• PSAP staff internalization of interoperable needs
  through AIM completion

30
R-GU Interoperability
4WTone Remote Control
31
Workshop Process

• Complete the Agency Interoperability Matrix (AIM)
• Identify Interoperability that can be satisfied
  by the WSGU in your Dispatch Center i.e.,
  conferencing, remote dispatch, etc.
• Identify Interoperability that can be satisfied
  by RGU in your Dispatch Center
• Rank in order of needs the interoperability
  satisfied by the RGU in 3.
• Identify the type of radio resource that must be
  interfaced to the RGU to satisfy each need
  identified in 4 (also 3)
• Assign the type of resource to each of the ports
  of the RGU i.e., VHF, 800, iDEN, etc.
• Identify the radio resource for each port i.e.,
  control station, base station, BIM, i90 handset,
  etc.
• Identify the source (provider) of each radio
  resource
• Do a sanity check on the AIM

32
Agency Interoperable Matrix (AIM)
Legend CP - Console Patch XPROG - Cross
Programming EGW - Existing Gateway RS - Radio Swap
DR - Dispatch Relay IDEN iDEN TG - Talk
Groups NR- Not Req'd Other
33
The Cornerstone

• Your
• Plan

34
Inter-Governmental Agreements

• ODP MOU
• Grantee Sub-grantee Agreement
• Documentation of Award

35
Standard Operating Procedures

• Equipment Operation
• Technical Assistance
• Local Use
• Regional Use
• State-wide Use

36

• National Priority Strengthen Interoperable
  Communications Capabilities
• Identify decision-making processes and
  the integration of after-action reports.
• Address interoperable communications
  issues across all elements of the
  interoperability continuum. The DHS Strategy
  Review Board acknowledges that the strategy
  clearly references standard operating procedures
  and technology acquisitions, but recommends that
  the strategy include discussion of governance,
  training/exercises, and usage of interoperable
  communications.

37
Testing Components

• Factory Acceptance
• Pilot Site Acceptance
• Core
• PSAPs
• Pilot System Acceptance
• Mobile Communication Units Acceptance
• Production PSAPs Site Acceptance
• Final System

38
Training and Education

• Vendor Training
• End Users (Train the Trainer and three regional
  meetings)
• System Engineers
• System Administrators
• Application Administrators
• Database Administrators
• LETPP Exercises/
• Local
• Regional
• State-wide

39
Datapath
40
Moto-bridge MCU
41
(No Transcript)
42
(No Transcript)
43
Communications with Public Safety Community

• Newsletter
• Personal Visit
• Chronicle of the Project
• Documents posted on Website
• Training CD
• Site Survey Tools

44
Committed?
45
Finish the Job

• Customer service/Training piece
• 1 site kick-off
• SOP Work
• Training (4)
• Installation
• System Acceptance
• Transition

46
