Cell death

1
Cell death

• Part II Regulation

Eric R. Gauthier, Ph.D. Dept. Chemistry-Biochemist
ry
2
Outline

• Basic regulatory mechanisms
• Turnover
• Compartmentalization
• Alternative splicing
• Changes in protein conformation
• Post-translational modifications
• Protein-protein interactions

3
Core apoptotic machinery

• Major control points
• Death receptor signalling
• Bax activation/translocation
• Initiator caspase activation
• Executioner caspase activation.
• Major regulatory mechanisms
• Cellular compartmentalization
• Modulation of protein turnover ( transcription,
  translation, stability)
• Changes in protein conformation
• Post-translational modifications
  (phosphorylation, nitrosylation, deamidation,
  ubiquitylation)
• Alternative splicing
• Protein-protein interaction.

caspase-8
cFLIP
Adapted from Nature Struct. Biol. 2001. 8 5
4
Death receptor regulation

• Death receptors multiple outcomes
• TNF can lead to cell survival or death
  (apoptosis, necrosis)
• Fas induction of cell death is dependent on the
  cell context (e.g. TCR stimulation)
• TRAIL preferentially induces death in tumor
  cells
• Major regulatory mechanisms
• Inhibition of DISC (Death Inducing Signalling
  Complex) formation
• Expression (transcription) of death receptors
  (p53 and Fas)
• Decoy receptors
• Compartmentalization.

5
Inhibition of DISC formation

• cFlip Inactive homologs of Casp-8 and Casp-10
• cFlipL Mutation of the active site Cys
• cFlipS Contains only two DED
• Binds FADD and dimerizes with pro-Casp-8
  initially thought to act as a dominant-negative
  inhibitor, leading to cell survival
• However recent data indicates that cFlip can
  also trigger cell death by promoting
  Casp-8/Casp-10 dimerization

c-FlipS
6
Inhibition of DISC formation

• Low c-FlipL levels
• Dimerizes with pro-Casp-8 at the DISC
• Contributes to Casp-8 activation c-Flip\Casp-8
  dimers form more efficiently than Casp
  homodimers
• Cell death.
• High c-FlipL
• Incomplete processing of proCasp-8
• Casp-8 activated but remains at the DISC
• Cleave different substrates, leading to
  pro-survival function.

Biochem. J. (2004) 382, e1e3
7
Decoy receptors - TRAIL receptors
Cell Research (2004) 14(5)359-372
8
Death receptor regulationCompartmentalization

• Complex 1
• Formed early after receptor activation
• Comprises TNF-R, TRADD, TRAF2, RIP1
• Leads to NF-kB activation by recruitment of the
  I-kB kinase signalsome (IKK1-IKK2-NEMO)
• Complex 2
• Found at later time points (gt2 hrs), possibly
  after receptor internalization
• Dissociation from TNFR, and recruitment of FADD
  and proCasp-8
• In situations where complex-1 formation trigger
  sufficient NF-kB signalling, c-FLIP and other
  anti-apoptotic proteins (e.g. IAPs) are
  synthesized, leading to inhibition Casp-8
  activation in complex II
• Also localization in lipid rafts seems to
  promote the survival signalling function of TNFR,
  as cholesterol depletion favors complex II
  formation.

Immunity, Vol. 21, 461465, October, 2004
9
Core apoptotic machinery

• Major control points
• Death receptor signalling
• Bax activation/translocation
• Initiator caspase activation
• Executioner caspase activation.
• Major regulatory mechanisms
• Cellular compartmentalization
• Modulation of protein turnover ( transcription,
  translation, stability)
• Changes in protein conformation
• Post-translational modifications
  (phosphorylation, nitrosylation, deamidation,
  ubiquitylation)
• Alternative splicing
• Protein-protein interaction.

caspase-8
cFLIP
Adapted from Nature Struct. Biol. 2001. 8 5
10
Bax modulation

• Because of its central role in the intrinsic
  pathway, several mechanisms have evolved to
  control Bax activation
• Transcription (p53)
• Alternative splicing
• Subcellular localization
• Protein-protein interaction
• Inactivation of anti-apoptotic proteins

11
Bax activation

• Bax exists as an inactive, cytosolic protein
• C-terminal TMD in the BH1/BH2/BH3 hydrophobic
  groove
• Prevents Bax from anchoring into the
  mitochondrial outer membrane (MOM)
• Prevents interaction of regulatory proteins with
  hydrophobic groove.
• Prevents inappropriate aggregation in the
  cytosol
• N-terminal a1 helix not accessible.
• Mitochondrial targeting sequence?
• Bax activation
• Requires the release of the TMD from the BH
  groove
• Results in the exposure of the NH2 terminus
  (detectable by IP with 4G2 antibody)

Biochimica et Biophysica Acta 1644 (2004) 83 94
Helices a2 (BH3) a45 (BH1) a78 (BH2)
12
Bax activation
Biochimica et Biophysica Acta 1644 (2004) 83 94
J Cell Biol. 2004. 164 ( 7) 10211032
13
Bax Activation

• Bax activation can be induced by several
  triggers
• pH alkalinization
• Direct tBid/Bim binding
• Ser 184 dephosphorylation
• Ser 184 PO4 by AKT
• Inactivation of Bcl-2 / Bcl-xL
• PO4 (Bcl-2 Ser 87, Thr 69 - JNK)
• Ubiquitylation (Bcl-2)
• Casp-mediated cleavage
• BH3 protein binding (e.g. Bad, Noxa, Puma)
• Bcl-xL deamidation (Asn 52/66)
• Release of binding by KU70
• Removal of the N-terminal 20 first amino acids
  (calpain-mediated)

SCIENCE. 2002. 298 1346-1347
14
Bax modulationInactivation of Bcl-xL
Cell, Vol. 87, 619628, November 15, 1996
Mol. Cell. 2004. 13 627638
Cell, Vol. 91, 231241, October 17, 1997
15
Core apoptotic machinery

• Major control points
• Death receptor signalling
• Bax activation/translocation
• Initiator caspase activation
• Executioner caspase activation.
• Major regulatory mechanisms
• Cellular compartmentalization
• Modulation of protein turnover ( transcription,
  translation, stability)
• Changes in protein conformation
• Post-translational modifications
  (phosphorylation, nitrosylation, deamidation,
  ubiquitylation)
• Alternative splicing
• Protein-protein interaction.

caspase-8
cFLIP
Adapted from Nature Struct. Biol. 2001. 8 5
16
IAPs

• BIR Baculovirus IAP repeat
• RING ubiquitin ligase (E3) domain
• UBC ubiquitin E2 domain
• CARD caspase recruitment domain
• NACHT putative ATP-binding domain

Nature Reviews Molecular Cell Biology 5, 897-907
(2004)
17
IAPs

• Mammals
• BIR-3 inhibits active Casp-9
• Linker segment between BIR-1/2 inhibits active
  Casp-3/7
• Drosophila
• BIR1 inhibits Drice (Casp-3 homolog)
• BIR2 inhibits Dronc (Casp-9 homolog)

Nature Reviews Molecular Cell Biology 5, 897-907
(2004)
18
XIAP and caspase inhibition
Biochem. J. (2004) 384, 201232
19
XIAP and effector caspase inhibition
TRENDS in Biochemical Sciences Vol.27 No.2
February 2002 94-101
20
XIAP and caspase-9 inhibition

• The BIR-3 domain of XIAP traps Casp-9 in a
  monomeric, inactive conformation
• BIR-3 binds Casp-9 through an interface which is
  required for Casp-9 homodimerization and its
  interaction wiht the apoptosome
• An N-terminal segment of the small subunit of
  Casp-9 (A298-T-P-F301) anchors this interaction
  by binding a conserved groove on BIR-3 (next
  slide).

21
XIAP and caspase-9 inhibition
Biochem. J. (2004) 384, 201232
22
DIAP and Dronc inhibitionRecruitment of E2/E3
enzymes
Cell, Vol. 109, 793796, June 28, 2002 793-796
23
Inhibiting the inhibitorsSMAC/DIABLO
Nature Reviews Molecular Cell Biology 5, 897-907
(2004)
24
DIAP and Dronc inhibitionRecruitment of E2/E3
enzymes
Cell, Vol. 109, 793796, June 28, 2002 793-796
25
Core apoptotic machinery

• Major control points
• Death receptor signalling
• Bax activation/translocation
• Initiator caspase activation
• Executioner caspase activation.
• Major regulatory mechanisms
• Cellular compartmentalization
• Modulation of protein turnover ( transcription,
  translation, stability)
• Changes in protein conformation
• Post-translational modifications
  (phosphorylation, nitrosylation, deamidation,
  ubiquitylation)
• Alternative splicing
• Protein-protein interaction.

caspase-8
cFLIP
Adapted from Nature Struct. Biol. 2001. 8 5
26
DIAP and Dronc inhibitionInvolvement of the
N-end rule pathway
NATURE CELL BIOLOGY VOL 5 MAY 2003 373-376
27
Inhibiting the inhibitorsThe case of Drosophila
NATURE STRUCTURAL BIOLOGY. 2003. 10 (9) 892-898
