Title: Center for Environmental Technology Logical Network Diagram


1
Center for Environmental Technology Logical
Network Diagram
Internet
cetfire
cetwww
cetftp
cetauth
CET Instrument Network Private IPs
192.168.38.0/24
University of Colorado Boulder Campus
Network 128.138.0.0
air1 ground1 mod1 mod2
Asterisk PBX
Promise ISCSI Disk Array
CET IP Phone Network Private IPs 192.168.1.0/24
VoIP 2-line No. 1
VoIP 2-line No. 2
Polycoms, Budgetones, conference phones, and ATAs
CET Public Network Routable IPs
(128.138.248.208-254)
