Chapter 10
C R U S T A L D E F O R M A T I O N
2

• Earths architectural features
• Folds, Faults, Fractures, Joints, etc.
• Structural Geology
• Study of these features

3
Why is it important?

• Oil / Gas Deposits
• Precious Other Metal Deposits
• Hazards Analysis
• Earthquakes, Dams, Nuclear Plants, etc.

4
What is Deformation?

• Change in a rock mass
• Size
• Shape
• Orientation or
• Position

5
Where Does Deformation Occur?

• Anywhere tectonic forces act upon formations
• e.g., Plate margins

6
Deformation in rocks near Lulworth, Doset, England
7
Types of Stress

• Stress
• Confining Pressure (stress uniform in all
  directions)
• Differential Stress (nonuniform stress)
• Compressional Stress
• Tensional Stress
• Shear Stress

8
Undeformed rocks
9
Horizontal compression
10
Horizontal tension
11
Shearing
12
(No Transcript)
13
Strain

• Deformation caused by stress
• - a strained body does not retain its original
  shape during/after deformation

14
Agents of Deformation

• Deformation depends on
• Temperature Confining Pressure
• Brittle Ductile deformation
• Brittle the material breaks
• Ductile solid-state flow change in size and
  shape without breakage

15
(No Transcript)
16

• -Rock Type
• Rock Salt, Gypsum, Shale flow ductilely
• Limestone, marble, schist - intermediate
• Granite, basalt strong and brittle

17

• Fluids
• small amounts of water increase ductility
• Time
• effects of small amounts of stress over time
• (wooden bookshelf loaded with books)

18
Mapping Geological Structures

• Formations
• Strike and dip
• Folds
• Faults

19
Formations

• Mappable rock unit
• Has definite upper lower contacts (boundaries
  with other units)
• Obvious characteristics (i.e., rock type) which
  allows it to be traced from place to place
• Is different from other rock units
• Generally sedimentary rocks
• Named for nearby location/feature main rock (or
  Formation if no single rock type)

20
Named formations in Grand Canyon
21

• Strike
• The compass direction of the line produced by the
  intersection of an inclined rock layer or fault,
  with a horizontal plane
• In northern hemisphere, measured from north
• Example N75E the horizontal line is oriented
  75º east of north

22

• Dip
• The angle of inclination of the surface of a rock
  unit or fault measured from a horizontal plane
• Dip direction direction water would flow if you
  poured some on the surface

23
75
75
24
Folds

• Wave-like undulations of strata
• Most form from compressional stresses
• Microscopic to Macroscopic in scale

25
Parts of a Fold

• Limbs
• The two sides of a fold
• Axial Plane
• - The surface that divides a fold as
  symmetrically as possible
• Hinge
• The line drawn along maximum curvature
• Plunge
• - angle the hinge makes with the horizontal

26
(No Transcript)
27
Types of Folds

• Anticlines Synclines
• Symmetrical Antisymmetrical
• Overturned
• Recumbent (the axial plane is horizontal)

28
(No Transcript)
29
Monocline

• Rocks bent due to a fault in the underlying
  bedrock

30
(No Transcript)
31
Plunging folds
32
Domes Basins

• Doubly-plunging folds
• Domes
• Large scale, circular or elongated upwarped
  folded sedimentary strata
• Basins
• Same, but downwarped

33
(No Transcript)
34
Dome - Black Hills, South Dakota
35
Basin bedrock geology of Michigan
36
Faults

• Faults are fractures in the crust along which
  appreciable displacement has taken place
• Sudden movement along faults are the cause of
  most earthquakes

37
(No Transcript)
38
Some Georgia Faults

• Brevard Fault Zone (Chattahoochee)
• Towaliga Fault / Goat Rock Fault
• Pine Mountain, Warm Springs
• Cartersville Fault
• Rome Fault

39
Categories of Faults

• Dip-slip Faults
• Movement parallel to the dip of the fault surface
• Strike-slip Faults
• Movement parallel to the strike of the fault
  surface

40
Hanging wall footwall
41
Types of Dip-Slip Faults

• Normal Faults
• Reverse Faults
• Thrust Faults

42
Normal fault - Hanging wall moved down (or
footwall up)
43
Horst graben structure
44
Reverse fault - Hanging wall moved up (or
footwall down)
45
Thrust fault - Reverse Fault with an angle of dip
lt45
46
Strike-Slip Faults

• Displacement is horizontal and parallel to the
  strike of the fault surface
• Right-lateral strike slip fault
• Left-lateral strike slip fault

47
Right-lateral strike-slip fault (San Andres
fault, Calif)
48
Joints

• Fractures in rocks where no appreciable movement
  has occurred
• May have two or three intersecting sets
• Mineral deposits may be deposited within joints
• Joints may affect construction projects
  (highways, dams)

49
Columnar jointing Devils Tower, Wyoming
50
Horizontal vertical jointing
