Title: Interactive Series Baseline Correction Algorithm


1
Interactive Series Baseline Correction Algorithm
  • Andrey Bogomolova, Willem Windigb,
  • Susan M. Geerc, Debra B. Blondellc,
  • and Mark J. Robbinsc
  • a ACD/Labs, Russian Chemometrics Society, Moscow,
    Russia
  • b Eigenvector Research Inc., Rochester, NY, USA
  • c Eastman Kodak Company, Rochester, NY, USA

2
Baseline (Background) Problem
  • Baseline is an eternal issue in analytical data
    processing
  • Baseline or background?
  • no clear distinction
  • baseline is associated with a smooth line
    reflecting a physical interference
  • background tends to be used in a more general
    sense to designate ANY unwanted signal including
    noise and chemical components
  • Our preference is given to the term baseline
    because smoothness of the background signal is
    the main assumption of the proposed correction
    algorithm

3
Classical Approach to the Baseline Correction
Problem
  • Classical baseline correction algorithms with
    respect to single curve are almost exhaustively
    elaborated in the literature
  • A baseline to be subtracted is fitted by a linear
    (polynomial) function to the nodes that belong to
    signal-free regions
  • The nodes can be automatically detected by the
    software or manually placed by the user
  • These methods are advantageous for half-automatic
    processing where software-generated results need
    to be revised by a human expert

4
Serial (Batch) Methods
  • Development of two-dimensional spectroscopy and
    hyphenated techniques demanded new methods
    applicable to data matrices
  • Early works in this direction applied automated
    baseline correction algorithms to every
    individual curve in a matrix dataset
  • The main problem with this approach is that it
    neglects internal (inter-spectral) correlations
  • Instead of the expected rank reduction it may
    introduce additional variance into the dataset
  • It is a black-box routine that is difficult to
    control

5
Multivariate Background Correction
  • Multivariate data analysis produced a
    revolutionary impact onto the baseline problem in
    general
  • The paradigmatic shift from hard-
    (knowledge-driven) to soft- or self-
    (data-driven) modeling has opened new horizons
    and introduced new concepts
  • PLS introduces the means to address the
    background without its subtraction in the
    calibration context
  • OSC by S. Wold turns the problem inside out
    eliminating the variance that is irrelevant for
    calibration (orthogonal to Y) from the data (X)
  • A number of other excellent algorithms

6
Our Objectives
  • The researchers are typically concentrated at the
    development of fully automated background
    correction methods
  • Statement fuzzy character of the baseline
    problem in general puts in doubt the feasibility
    of automated (expert-free) baseline correction
    routines
  • In contrast, we present an alternative approach
    that tends to maximize the means of control for a
    human operator
  • simplicity
  • visualization
  • interactive stepwise algorithm

7
The Method
  • The method is applied to a series of curves
    (e.g., spectra or chromatograms)
  • The method consists of two distinct steps
  • First, a prototype baseline is constructed from
    linear segments by selecting a set of nodes
  • To aid in the node selection the mean values are
    calculated to represent the entire series
  • Second, the prototype baseline is used to
    construct individual baselines to be subtracted
    from the series curves by adjusting the nodes
    vertically to the corrected curve

8
HPLC/DAD Sample Data
9
2nd Derivative for Node Selection
10
Baseline Correction for Curve Resolution
  • Baseline correction is an application-specific
    preprocessing technique
  • The present baseline correction algorithm has
    been developed to improve the performance of
    SIMPLISMA (SIMPLe-to-use Interactive
    Self-modeling Mixture Analysis) curve resolution
    technique
  • The algorithm has been used at Eastman Kodak
    Company over 10 years for routine analysis of
    TGA/IR data that represent a challenging case for
    curve resolution
  • a lot of components
  • high degree of overlap
  • intensive background signal

11
TGA/IR Sample Data
Reprinted with permission from Eastman Kodak
Company, 2005
12
Baseline Nature in TGA/IR
  • The most common reasons for TGA/IR baseline
    drift
  • Temperature fluctuations over time
  • Instrument drift
  • Material scattering
  • Impurities
  • Inappropriate background, etc.
  • In the present dataset - miscellaneous reasons
  • Spectral domain is more suitable for series
    baseline correction because of narrow peaks and
    explicit baseline areas

13
TGA/IR Baseline Correction
Reprinted with permission from Eastman Kodak
Company, 2005
14
TGA/IR Corrected Data Map
Reprinted with permission from Eastman Kodak
Company, 2005
15
TGA/IR SIMPLISMA Curve Resolution
Reprinted with permission from Eastman Kodak
Company, 2005
16
IR Library Identification
Reprinted with permission from Eastman Kodak
Company, 2005
17
Conclusions
  • A new interactive approach to the baseline
    correction problem has been suggested
  • It allows for adapting traditional automated
    single-scan baseline correction routines or for
    performing manual correction on matrix data as if
    they were a single curve
  • Advantages of the method include transparency
    of the process and the means for extensive
    operator interaction
  • The method has passed long-term testing in an
    industrial laboratory and was integrated into a
    professional software package
  • In spite of the simplicity of the algorithm, it
    allows for successful elimination of baselines
    even in complex cases such as TGA/IR data

18
Acknowledgements
  • Antony Williams for his friendly support, and
  • Michel Hachey for his help and valuable ideas
