Network Control and Management in the 100x100 Architecture

1
Network Control and Managementin the 100x100
Architecture
2
The Role of Network Control and Management

• Many different network environments
• Data center networks, enterprise/campus
• Access, backbone networks
• Many different technologies
• Longest-prefix routing, label switching,
  switching
• IP, MPLS, ATM, optical circuits
• Many different policies
• Routing, reachability, transit, traffic
  engineering, robustness
• The control plane software binds these elements
  together and defines the network

3
Control Plane The Key Leverage Point

• Great Potential control plane determines the
  behavior of the network
• Reaction to events, reachability, services
• Great Opportunities
• A radical clean-slate control plane can be
  deployed
• Agnostic to packet format IPv4/v6, ethernet
• No changes to end-system software
• Control plane is the nexus of network evolution
• Changing the control plane logic can smooth
  transitions in network technologies and
  architectures

4
100x100 Project Themes
5
A Clean-slate Design

• What are the fundamental causes of outages?
• How to reduce/simplify the software in networks?
• Control logic is software no reason it should
  be hard to update, but how to avoid complexity
  pitfalls
• What functionality needs to be distributed what
  can be centralized?
• What would a RISC router look like?
• Leverage technology trends
• CPU and link-speed growing faster than of
  switches

FIX ME
6
Three Principles forNetwork Control Management

• Network-level Objectives
• Express goals explicitly
• Security policies, QoS, egress point selection
• Do not bury goals in box-specific configuration

Reachability matrix Traffic engineering rules
Management Logic
7
Three Principles forNetwork Control Management

• Network-wide Views
• Design network to provide timely, accurate info
• Topology, traffic, resource limitations
• Give logic the inputs it needs

Reachability matrix Traffic engineering rules
Management Logic
Read state info
8
Three Principles forNetwork Control Management

• Direct Control
• Allow logic to directly set forwarding state
• FIB entries, packet filters, queuing parameters
• Logic computes desired network state, let it
  implement it

Reachability matrix Traffic engineering rules
Write state
Management Logic
Read state info
9
Overview of the 4D Architecture
Network-level objectives
Decision
Dissemination
Direct control
Network-wide views
Discovery
Data

• Decision Plane
• All management logic implemented on centralized
  servers making all decisions
• Decision Elements use views to compute data plane
  state that meets objectives, then directly writes
  this state to routers

10
Overview of the 4D Architecture
Network-level objectives
Decision
Dissemination
Direct control
Network-wide views
Discovery
Data

• Dissemination Plane
• Provides a robust communication channel to each
  router and robustness is the only goal!
• May run over same links as user data, but
  logically separate and independently controlled

11
Overview of the 4D Architecture
Network-level objectives
Decision
Dissemination
Direct control
Network-wide views
Discovery
Data

• Discovery Plane
• Each router discovers its own resources and its
  local environment
• E.g., the identity of its immediate neighbors

12
Overview of the 4D Architecture
Network-level objectives
Decision
Dissemination
Direct control
Network-wide views
Discovery
Data

• Data Plane
• Spatially distributed routers/switches
• Ideally exposes interface to tables in hardware
• Can deploy with todays technology

13
Concerns and Challenges

• How does the 4D simplify the problem?
• How will communication between routers and DEs
  survive failures in the network?
• Can a robust dissemination plane be built?
• Latency means DEs view of network is behind
  reality. Will the control loop be stable?
• What is the overhead to/from the DEs?
• What happens in a network partition?

FIX ME
14
Fundamental Problem Wrong Abstractions
Shell scripts
Traffic Eng

• Management Plane
• Figure out what is happening in network
• Decide how to change it

Planning tools
Databases
Configs
SNMP
netflow
modems
OSPF

• Control Plane
• Multiple routing processes on each router
• Each router with different configuration program
• Huge number of control knobs metrics, ACLs,
  policy

Link metrics
Routing policies
FIB

• Data Plane
• Distributed routers
• Forwarding, filtering, queueing
• Based on FIB or labels

FIB
FIB
Packet filters
15
Good Abstractions Reduce Complexity
Management Plane
Configs
Decision Plane
Control Plane
FIBs, ACLs
FIBs, ACLs
Dissemination
Data Plane
Data Plane

• All decision making logic lifted out of control
  plane
• Eliminates duplicate logic in management plane
• Dissemination plane provides robust communication
  to/from data plane switches

16
4D Separates Distributed Computing Issues from
Networking Issues

• Distributed computing issues ! protocols and
  network architecture
• Overhead
• Resiliency
• Scalability
• Networking issues ! management logic
• Traffic engineering and service provisioning
• Egress point selection
• Reachability control (VPNs)
• Precomputation of backup paths

17
4D Can Leverage Network Structure

• Decision plane logic can be specialized for
  structure of each physical network
• Distributed protocols must be prepared for
  arbitrary topology graphs
• 4D enables network logic specialized differently
  for access and for backbone
• Advantages
• Faster route computations
• Retain flexibility to evolve network as needed
• Support transition to 100x100 architecture

18
The Feasibility of the 4D Architecture

• We designed and built a prototype of the 4D
  Architecture
• 4D Architecture permits many designs prototype
  is a single, simple design point
• Decision plane
• Contains logic to simultaneously compute routes
  and enforce reachability matrix
• Multiple Decision Elements per network, using
  simple election protocol to pick master
• Dissemination plane
• Uses source routes to direct control messages
• Extremely simple, but can route around failed
  data links

19
Evaluation of the 4D Prototype

• Evaluated using Emulab (www.emulab.net)
• Linux PCs used as routers (650 800MHz)
• Tested on 9 enterprise network topologies
  (10-100 routers each)

Example network with 49 switches and 5 DEs
20
Performance of the 4D Prototype

• Trivial prototype has performance comparable to
  well-tuned production networks
• Recovers from single link failure in lt 300 ms
• lt 1 s response considered excellent
• Survives failure of master Decision Element
• New DE takes control within 1 s
• No disruption unless second fault occurs
• Gracefully handles complete network partitions
• Less than 1.5 s of outage

21
Future Work

• Scalability
• Evaluate over 1-10K switches, 10-100K routes
• Networks with backbone-like propagation delays
• Structuring decision logic
• Arbitrate among multiple, potentially competing
  objectives
• Unify control when some logic takes longer than
  others
• Protocol improvements
• Better dissemination and discovery planes
• Deployment in todays networks
• Data center, enterprise, campus, backbone (RCP)

22
Themes of Network Control Management

• Holistic Design
• Many different technologies a few common
  problems
• Find the right abstractions exploit commonality
• Clean Slate
• How much autonomy do routers/switches need?
• New principles for controlling networks
• Eliminate duplicate logic
• Leverage Network Structure
• Many different types of networks exist - each
  with different objectives and topologies
• Separate networking issues from distributed
  system issues

23
Recent Results

• G. Xie, J. Zhan, D. A. Maltz, H. Zhang, A.
  Greenberg, G. Hjalmtysson, J. Rexford, On Static
  Reachability Analysis of IP Networks, IEEE
  INFOCOM 2005, Orlando, FL, March 2005.
• J. Rexford, A. Greenberg, G. Hjalmtysson, D. A.
  Maltz, A. Myers, G. Xie, J. Zhan, H. Zhang,
  Network-Wide Decision Making Toward a
  Wafer-Thin Control Plane, Proceedings of ACM
  HotNets-III, San Diego, CA, November 2004.
• D. A. Maltz, J. Zhan, G. Xie, G. Hjalmtysson, A.
  Greenberg, H. Zhang, Routing Design in
  Operational Networks A Look from the Inside,
  Proceedings of the 2004 Conference on
  Applications, Technologies, Architectures, and
  Protocols for Computer Communications (ACM
  SIGCOMM 2004), Portland, Oregon, 2004.
• D. A. Maltz, J. Zhan, G. Xie, H. Zhang, G.
  Hjalmtysson, A. Greenberg, J. Rexford, Structure
  Preserving Anonymization of Router Configuration
  Data, Proceedings of ACM/Usenix Internet
  Measurement Conference (IMC 2004), Sicily, Italy,
  2004.

24
Questions?
25
Fundamental Problem Wrong Abstractions

• interface Ethernet0
• ip address 6.2.5.14 255.255.255.128
• interface Serial1/0.5 point-to-point
• ip address 6.2.2.85 255.255.255.252
• ip access-group 143 in
• frame-relay interface-dlci 28
• router ospf 64
• redistribute connected subnets
• redistribute bgp 64780 metric 1 subnets
• network 66.251.75.128 0.0.0.127 area 0
• router bgp 64780
• redistribute ospf 64 match route-map
  8aTzlvBrbaW
• neighbor 66.253.160.68 remote-as 12762
• neighbor 66.253.160.68 distribute-list 4 in

access-list 143 deny 1.1.0.0/16 access-list 143
permit any route-map 8aTzlvBrbaW deny 10 match
ip address 4 route-map 8aTzlvBrbaW permit 20
match ip address 7 ip route 10.2.2.1/16 10.2.1.7
26
Fundamental Problem Wrong Abstractions
2000
Size of configuration files in a single
enterprise network (881 routers)
Lines in config file
1000
0
881
0
Router ID (sorted by file size)
27
Fundamental Problem Wrong Abstractions
Shell scripts
Traffic Eng

• Management Plane
• Figure out what is happening in network
• Decide how to change it

Planning tools
Databases
Configs
SNMP
netflow
modems
OSPF

• Control Plane
• Multiple routing processes on each router
• Each router with different configuration program
• Huge number of control knobs metrics, ACLs,
  policy

Link metrics
Routing policies
FIB

• Data Plane
• Distributed routers
• Forwarding, filtering, queueing
• Based on FIB or labels

FIB
FIB
Packet filters
28
Good Abstractions Reduce Complexity
Management Plane
Configs
Decision Plane
Control Plane
FIBs, ACLs
FIBs, ACLs
Dissemination
Data Plane
Data Plane

• All decision making logic lifted out of control
  plane
• Eliminates duplicate logic in management plane
• Dissemination plane provides robust communication
  to/from data plane switches

29
Fundamental Problem Conflating Distributed
Systems Issues with Networking Issues
Routing Process
D left
D
D
Routing Process
Routing Process
D
D
D left
D left

• Distributed Systems Concern resiliency to link
  failures
• Solution multiple paths through routing process
  graph

30
Fundamental Problem Conflating Distributed
Systems Issues with Networking Issues
Routing Process
D right
D
Routing Process
Routing Process
D
D
D left
D left

• Distributed Systems Concern resiliency to link
  failures
• Solution multiple paths through routing process
  graph

31
Fundamental Problem Conflating Distributed
Systems Issues with Networking Issues
Routing Process
D left
D
D
Routing Process
Routing Process
D
D
D left
D left

• Networking Concern implement resource or
  security policy
• Solution restrict flow of routing information,
  filter routes, summarize/aggregate routes

32
4D Separates Distributed Computing Issues from
Networking Issues

• Distributed computing issues ! protocols and
  network architecture
• Overhead
• Resiliency
• Scalability
• Networking issues ! management logic
• Traffic engineering and service provisioning
• Egress point selection
• Reachability control (VPNs)
• Precomputation of backup paths

33
4D Can Leverage Network Structure

• Decision plane logic can be specialized for
  structure of each physical network
• Distributed protocols must be prepared for
  arbitrary topology graphs
• 4D enables network logic specialized differently
  for access and for backbone
• Advantages
• Faster route computations
• Retain flexibility to evolve network as needed
• Support transition to 100x100 architecture

34
Fundamental Problem Computing Configurations is
Intractable

• Computing configuration files that cause control
  plane to compute desired forwarding states is
  intractable
• NP-hard in many cases
• Requires predictive model of control plane
  behavior
• Configurations files form a program that defines
  a set of forwarding states
• Very hard to create program that permits only
  desired states, and doesnt transit through bad
  ones

Forwarding states allowed by configs
Auto-adaptation leads to/thru bad states
Planned responses avoid bad states
35
Direct Control Provides Complete Control

• Zero device-specific configuration
• Supports many models for pushing routes
• Trivial push convergence requires time for all
  updates to be receive and applied same as today
• Synchronized update updates propagated, but not
  applied till agreed time in the future clock
  skew defines convergence time
• Controlled state trajectory DE serializes
  updates to avoid all incorrect transient states

36
4D and Todays Networks

• 4D architecture and principles apply to todays
  networks as well as 100x100
• Enterprise/campus/university networks
• Data center networks
• Access/backbone networks
• Greater expressivity in determining behavior
• Behavior of butterfly graph gadgets under failure
• Selection of traffic egress points

37
4D Supports Network Evolution Expansion

• Decision logic can be upgraded as needed
• No need for update of distributed protocols
  implemented in software distributed on every
  switch
• Decision Elements can be upgraded as needed
• Network expansion requires upgrades only to DEs,
  not every switch

38
Three Key Questions

• Is there any transition path to deploy the 4D
  architecture?
• Is the 4D architecture feasible?
• Does the 4D architecture have more expressive
  power than todays approaches to network control
  and management?

39
Deployment of the 4D Architecture

• Pre-existing industry trend towards separating
  router hardware from software
• IETF FORCES, GSMP, GMPLS
• SoftRouter Lakshman, HotNets04
• Incremental deployment path exists
• Individual networks can upgrade to 4D and gain
  benefits
• Small enterprise networks have most to gain
• No changes to end-systems required

40
Reachability Example
R1
R2
Chicago (chi)
New York (nyc)
Data Center
Front Office
R5
R4
R3

• Two locations, each with data center front
  office
• All routers exchange routes over all links

41
Reachability Example
R1
R2
Chicago (chi)
New York (nyc)
Data Center
Front Office
R5
R4
R3
chi-DC
chi-FO
nyc-DC
nyc-FO
chi-DC
chi-FO
nyc-DC
nyc-FO
42
Reachability Example
Packet filter Drop nyc-FO -gt Permit
R1
R2
chi
Data Center
Front Office
Packet filter Drop chi-FO -gt Permit
R5
nyc
R4
R3
43
Reachability Example
Packet filter Drop nyc-FO -gt Permit
R1
R2
chi
Data Center
Front Office
Packet filter Drop chi-FO -gt Permit
R5
nyc
R4
R3

• A new short-cut link added between data centers
• Intended for backup traffic between centers

44
Reachability Example
Packet filter Drop nyc-FO -gt Permit
R1
R2
chi
Data Center
Front Office
Packet filter Drop chi-FO -gt Permit
R5
nyc
R4
R3

• Oops new link lets packets violate security
  policy!
• Routing changed, but
• Packet filters dont update automatically

45
Prohibiting Packets from chi-FO to nyc-DC
46
Reachability Example
Packet filter Drop nyc-FO -gt Permit
R2
R1
chi
Data Center
Front Office
Packet filter Drop chi-FO -gt Permit
R5
nyc
R4
R3

• Typical response add more packet filters to
  plug the holes in security policy

47
Reachability Example
Drop nyc-FO -gt
R2
R1
chi
Data Center
Front Office
R5
nyc
Drop chi-FO -gt
R4
R3

• Packet filters have surprising consequences
• Consider a link failure
• chi-FO and nyc-FO still connected

48
Reachability Example
Drop nyc-FO -gt
R2
R1
chi
Data Center
Front Office
R5
nyc
Drop chi-FO -gt
R4
R3

• Network has less survivability than topology
  suggests
• chi-FO and nyc-FO still connected
• But packet filter means no data can flow!
• Probing the network wont predict this problem

49
Allowing Packets from chi-FO to nyc-FO
50
(No Transcript)
51
(No Transcript)
52
Packet Filters Implement Policy

• Packet filters used extensively throughout
  networks
• Protect routers from attack
• Implement reachability matrix
• Define which hosts can communicate
• Localize traffic, particularly multicast

53
Mechanisms for Action at a Distance
A
Routing Process
Routing Process
Routing Process
Atag12
Atag12
Tag?
FIB
FIB
FIB
R1
R2
R3

• Policy often implemented by tagging routes on one
  router
• And testing for tag at another router

54
Multiple Interacting Routing Processes
Client
Server
55
The Routing Instance Graph of a 881 Router
Network
56
Reconvergence Time UnderSingle Link Failure
57
Reconvergence Time When Master DE Crashes
58
Reconvergence Time WhenNetwork Partitions
59
Reconvergence Time WhenNetwork Partitions
60
Systems of Systems

• Systems are designed as components to be used in
  larger systems in different contexts, for
  different purposes, interacting with different
  components
• Example OSPF and BGP are complex systems in its
  own right, they are components in a routing
  system of a network, interacting with each other
  and packet filters, interacting with management
  tools
• Complex configuration to enable flexibility
• The glue has tremendous impact on network
  performance
• State of art multiple interactive distributed
  programs written in assembly language
• Lack of intellectual framework to understand
  global behavior

61
Many Implementations Possible
Single redundant decision engine

• Multiple decision engines
• Hot stand-by
• Divide network load share

• Distributed decision engines
• Up to one per router

• Choice can be based on reliability requirements
• Dessim. Plane can be in-band, or leverage OOB
  links
• Less need for distributed solutions (harder to
  reason about)
• More focus on network issues, less on distributed
  protocols

62
Direct Expression Enables New Algorithms
D

• OSPF normally calculates a single path to each
  destination D
• OSPF allows load-balancing only for equal-cost
  paths to avoid loops
• Using ECMP requires careful engineering of link
  weights

D

• Decision Plane with network-wide view can compute
  multiple paths
• Backup paths installed for free!
• Bounded stretch, bounded fan-in

63
Slides under Development
64
Supporting Network Evolution

• Logic for controlling the network needs to change
  over time
• Traffic engineering rules
• Interactions with other networks
• Service characteristics
• Upgrades to field-deployed network equipment must
  be avoided
• Very high cost
• Software upgrades often require hardware upgrades
  (more CPU or memory)

65
Supporting Network EvolutionToday

• Todays Solution
• Vendors stuff their routers with software
  implementing all possible features
• Multiple routing protocols
• Multiple signaling protocols (RSVP, CR-LDP)
• Each feature controlled by parameters set at
  configuration time to achieve late binding
• Feature-creep creates configuration nightmare
• Tremendous complexity for syntax semantics
• Mis-interactions between features is common
• Our Goal Separate decision making logic from the
  field-deployed devices

66
Supporting Network Expansion

• Networks are constantly growing
• New routers/switches/links added
• Old equipment rarely removed
• Adding a new switch can cause old equipment to
  become overloaded
• CPU/Memory demands on each device should not
  scale up with network size

67
Supporting Network ExpansionToday

• Routers run a link-state routing protocol
• Size of link-state database scales with of
  routers
• Expanding network can exceed memory limits of old
  routers
• Todays Solution
• Monitor resources on all routers
• Predict approach of exhaustion and then
• Global upgrade
• Rearchitecture of routing design to add
  summarization, route aggregation, information
  hiding
• Our Goal make demands scale with hardware (e.g.,
  of interfaces)

68
Supporting Remote Devices

• Maintaining communication with all network
  devices is critical for network management
• Diagnosis of problems
• Monitoring status and network health
• Updating configuration or software
• the chicken or the egg.
• Cannot send device configuration/management
  information until it can communicate
• Device cannot communicate until it is correctly
  configured

69
Supporting Remote DevicesToday

• Todays Solution
• Use PSTN as management network of last resort
• Connect console of remote routers to phone modem
• Cant be used for customer premise equipment
  (CPE) DSL/cable modems, integrated access
  devices (IADs)
• In a converged network, PSTN is decommissioned
• Our Goal Preserve management communication to
  any device that is not physically partitioned,
  regardless of configuration state

70
Network Control and Management Today

• State everywhere!
• Dynamic state in FIBs
• Configured state in settings, policies, packet
  filters
• Programmed state in magic constants, timers
• Many dependencies between bits of state
• State updated in uncoordinated, decentralized way!

• Data Plane
• Distributed routers
• Forwarding, filtering, queueing
• Based on FIB or labels

Packet filters
71
Network Control and Management Today

• Logic everywhere!
• Path Computation built into routing protocols
• Routing Policy distributed across the routers
• Packet Filters placed by tools in Mng. Plane
• No way to arbitrate inconsistencies between logic!

• State everywhere!
• Dynamic state in FIBs
• Configured state in settings, policies, packet
  filters
• Programmed state in magic constants, timers
• Many dependencies between bits of state
• State updated in uncoordinated, decentralized way!

• Data Plane
• Distributed routers
• Forwarding, filtering, queueing
• Based on FIB or labels

Packet filters
72
A Study of Operational Production Networks

• How complicated/simple are real control planes?
• What is the structure of the distributed system?
• Use reverse-engineering methodology
• There are few or no documents
• The ones that exist are out-of-date
• Anonymized configuration files for 31 active
  networks (gt8,000 configuration files)
• 6 Tier-1 and Tier-2 Internet backbone networks
• 25 enterprise networks
• Sizes between 10 and 1,200 routers
• 4 enterprise networks significantly larger than
  the backbone networks

73
Learning from Ethernet Evolution Experience
Current Implementations Everything Changed
Except Name and Framing
HUB Switch
Router
WAN

• Switched solution
• Little use for collision domains
• Servers, routers 10 x station speed
• 10/100/1000 Mbps, 10gig coming Copper, Fiber

Ethernet Conc..
Server
74
Ethernet Re-inventing the Wheel

• Becoming as service-rich and complex as IP
• Traffic engineering
• Reachability control and traffic isolation
  (VLANs)
• QoS (802.1q)
• Ethernet networks rediscovering the problems and
  solutions faced by IP networks
• Is there commonality to exploit?
• Switch/routers are all fundamentally table-driven
• Destination addr, MPLS labels, VLANs, Circuit IDs

75
Control/Management Needs of100x100 Network
Architecture

• Control/Management creates logical network from
  physical network
• Supports architecture and end-to-end view of
  100x100 network
• Access Network
• Logical level aggregation tree between CPE and
  Regional Node
• Physical level network with redundant links and
  multiple Regional Nodes
• Backbone Network
• Logical level full mesh of links among Regional
  Nodes
• Physical level sparse graph of fiber routes
  constrained by geography
