Lecture 9 Graph algorithms: BFS and DFS search

1
Lecture 9 Graph algorithmsBFS and DFS search

• COMP 523 Advanced Algorithmic Techniques
• Lecturer Dariusz Kowalski

2
Overview

• Previous lectures
• Greedy algorithms
• Minimum spanning tree - many greedy approaches
  (Prims and Kruskals algorithms)
• Priority Queues
• This lecture
• Representation of graphs
• Breadth-First Search (BFS)
• Depth-First Search (DFS)

3
How to represent graphs?

• Given graph G (V,E) , how to represent it?
• Adjacency matrix ith node is represented as ith
  row and ith column, edge between ith and jth
  nodes is represented as 1 in row i and column j,
  and vice versa (0 if there is no edge between i
  and j)
• Adjacency list nodes are arranged as array/list,
  each node record has the list of its neighbors
  attached

1
2
3
4
1
2
3
4
1
0
1
1
1
1
2
1
3
2
1
0
1
0
3
1
2
4
4
2
3
1
1
0
1
4
1
3
4
1
0
1
0
3
Adjacency matrix
Adjacency list
4
Adjacency matrix

• Advantages
• Check in constant time if an edge belongs to the
  graph
• Disadvantages
• Representation takes memory O(n2) - versus O(m)
• Examining all neighbors of a given node requires
  time O(n) - versus O(m/n) in average
• Disadvantages especially for sparse graphs!

1
2
3
4
1
2
3
4
1
0
1
1
1
1
2
1
3
2
1
0
1
0
3
1
2
4
4
2
3
1
1
0
1
4
1
3
4
1
0
1
0
3
Adjacency matrix
Adjacency list
5
Adjacency list

• Advantages
• Representation takes memory O(mn) - versus O(n2)
• Examining all neighbors of a given node requires
  time O(m/n) in average - versus O(n)
• Disadvantages
• Check if an edge belongs to the graph requires
  time O(m/n) in average - versus O(1)
• Advantages especially for sparse graphs!

1
2
3
4
1
2
3
4
1
0
1
1
1
1
2
1
3
2
1
0
1
0
3
1
2
4
4
2
3
1
1
0
1
4
1
3
4
1
0
1
0
3
Adjacency matrix
Adjacency list
6
Breadth-First Search (BFS)

• Given graph G (V,E) of diameter D and the root
  node
• Goal find a spanning tree such that the
  distances between nodes and the root are the same
  as in graph G
• Idea of the algorithm
• For layers i 0,1,,D
• while there is a node in layer i 1 not added to
  the partial BFS tree add the node and any edge
  connecting it with layer i

root
layer 0
layer 2
layer 1
7
Implementing BFS

• Structures
• Adjacency list
• Lists L0,L1,,LD
• Array Discovered1n
• Algorithm
• Set L0 root
• For layers i 0,1,,D
• Initialize empty list Li1
• For each node v in Li take next edge adjacent to
  v and if its second end w is not marked as
  Discovered then add w to Li1 and v,w to
  partial BFS

root
layer 0
layer 2
layer 1
8
Analysis of BFS

• Correctness
• By induction on layer number each node in layer
  i is in the list Li
• Each none w in layer i has its predecessor on the
  distance path in layer i-1,
• consider the first of such predecessors v in list
  Li-1 w is added to list Li by
• the step where it is considered as the neighbor
  of v
• Complexity
• Time O(mn) - each edge is considered at most
  twice - since it occurs twice in the adjacency
  list
• Memory O(mn) - adjacency list takes O(mn),
  lists L0,L1,,LD have at most 2n elements in
  total, array Discovered has n elements

root
layer 0
layer 2
layer 1
9
Depth-First Search (DFS)

• Given graph G (V,E) of diameter D and the root
  node
• Goal find a spanning tree such that each edge in
  graph G corresponds to the ancestor relation in
  the tree
• Recursive idea of the algorithm
• Repeat until no neighbor of the root is free
• Select a free neighbor v of the root and add the
  edge from root to v to partial DFS
• Recursively find a DFS in graph G restricted to
  free nodes and node v as the root and add it to
  partial DFS

root
root
root
10
Implementing DFS

• Structures
• Adjacency list
• List (stock) S
• Array Discovered1n
• Algorithm
• Set S root
• Consider the top element v in S
• For each neighbor w of node v, if w is not
  Discovered then put w into the stock S and start
  the next iteration for w as the top element
• Otherwise remove v from the stock, add edge v,z
  to partial DFS, where z is the current top
  element, and start the next iteration for z as
  the top element
• Remark after considering the neighbor of node v
  we remove this neighbor from adjacency list to
• avoid considering it many times!

root
root
root
11
Analysis of DFS

• Correctness
• By induction on recursive call
• Consider edge v,w in G let v becomes first
  joint to DFS. Then w is free
• and since it is in connected component with v it
  will be in DFS part with
• root v, so v is the ancestor of w
• Complexity
• Time O(mn) - each edge is considered at most
  twice - while adding or removing from the stock
• Memory O(mn) - adjacency list takes O(mn),
  stock S and array Discovered has at most n
  elements each

root
root
root
12
Conclusions

• Graph representations
• Adjacency array
• Adjacency list
• Searching algorithms BFS and DFS in time and
  memory O(m n)

13
Exercises

• Prove that obtained DFS and BFS are spanning
  trees
