Who is HIFI Works?

1

2
Who is HIFI Works?

• A division of Dana Innovations founded in early
  1980s.
• The Dana Innovations group includes such brands
  as Sonance, iPort, Sound Advance, HIFI Works and
  HomeTech. Founders are best known as the
  inventors of the high fidelity in-wall speaker.
• HIFI Works has been developed with the same core
  requirements as all Dana Innovations products
  ease of install, ease of operation, innovation
  and design. All research, development and
  engineering is done in San Clemente, California.

3

• Dana Innovations
• Corporate Headquarters

• San Clemente, California

4
SLA MACHINE

• Stereo Lithography Apparatus
• Full Scale Modeling Via SolidWorks CADCAM
  Engineering
• Allows for perfecting prototypes and expedites
  concept to market time

5
Anechoic Chamber
6
R D Sound Lab
7
IN CEILING SPEAKERS

Outdoor Speakers
In-Wall In-Ceiling Speakers
Speaker Switchers
Volume Controls
Wire and Accessories
8
HFW5 IN-WALL SPEAKER All purpose in-wall speaker
for use with all types of audio equipment.
Specifications Infinite baffle design

• Woofer 5-1/4" black polypropylene cone with
  rubber surround
• Tweeter 3/4" cloth dome with Ferrofluid cooled
  voice coil
• Frequency Response 60 Hz - 20kHz /- 3dB
• Efficiency 89 dB 1W / 1m
• Power Handling 10 watts minimum to 65 Watts
  maximum
• Impedance 8 ohms nominal
• Grille white aluminum (grilles may be painted)
• Speaker Dimensions 7-1/2" wide x 11" high x 2
  5/16" deep
• Cutout Cutout Dimensions 5-1/4 wide x 9-1/8
  high
• Stock 30001
• MSRP 109.95
• UOM Pair
• Master Carton Qty 2

9
HFW6 IN-WALL SPEAKER A better quality in-wall
speaker for use with all audio and video
equipment genuine home theater quality sound.
Specifications Infinite baffle design

• Woofer 6-1/2" black polypropylene cone with
  rubber surround
• Tweeter 3/4" soft dome with Ferrofluid cooled
  voice coil
• Frequency Response 50 Hz - 20kHz /- 3dB
• Efficiency 90 dB 1W / 1m
• Power Handling 10 watts minimum to 100 Watts
  maximum
• Impedance 8 ohms nominal
• Grille white aluminum (grilles may be painted)
• Speaker Dimensions 8-5/6" wide x 12-1/16" high
  x 2 7/8" deep
• Cutout Cutout Dimensions 6-3/4 wide x 11 high
• Stock 30002
• MSRP 149.95
• UOM Pair
• Master Carton Qty 2

10
HFW8 IN-WALL SPEAKER High quality in-wall speaker
for home theater quality sound.
Specifications Infinite baffle design

• Woofer 8 black polypropylene cone with rubber
  surround
• Tweeter 1" cloth dome with Ferrofluid cooled
  voice coil
• Frequency Response 40 Hz - 20kHz /- 3dB
• Efficiency 89 dB 1W / 1m
• Power Handling 10 watts minimum to 125 Watts
  maximum
• Impedance 8 ohms nominal
• Grille white aluminum (grilles may be painted)
• Speaker Dimensions 10-1/16" wide x 14-1/16"
  high x 3-3/16" deep
• Cutout Cutout Dimensions 8-3/4 wide x 12-3/4
  high
• Stock 30003
• MSRP 199.95
• UOM Pair
• Master Carton Qty 2

11

Created to follow THX Select requirements, the
THX LCR series is an excellent choice for the
Home Theater enthusiast.
HFW THX SELECT LCR SPEAKERS

• Specifications
• Woofer 6-½ magnetically shielded, black
  polypropylene cone with a rubber surround
• Tweeter 1 magnetically shielded cloth dome
• Frequency Response 80Hz 20kHz /- 3db
• Efficiency 89db 1W / 1m
• Power 5 watts minimum to 125 watts maximum
• Impedance 8 ohms nominal
• Grille Aluminum (grilles may be painted)
• Speaker Dimensions 8-1/8 wide x 12-3/16
  tall x 3-7/8 deep
• Cut-out Dimensions 6-3/4 wide x 11 tall
• Stock 30044
• MSRP 109.95
• UMO Each
• Master Carton Qty 4

IR Knockout
IR knockout standard in all rectangle models.
12

HFW THX SELECT SUR SPEAKERS
THX select certified speaker for surround
channels in a THX home theater installation.

• Specifications
• Woofer 6-½ magnetically shielded, black
  polypropylene cone with a rubber surround
• Tweeter Two 3/4 cloth domes
• Frequency Response 80Hz 20kHz /- 3db
• Efficiency 89db 1W / 1m
• Power 5 watts minimum to 125 watts maximum
• Impedance 8 ohms nominal
• Grille Aluminum (grilles may be painted)
• Speaker Dimensions 8-1/8 wide x 12-3/16
  tall x 3-7/8 deep
• Cut-out Dimensions 6-3/4 wide x 11 tall
• Stock 30045
• MSRP 149.95
• UMO Each
• Master Carton Qty 4

13
HFW5R IN-CEILING SPEAKER This in-wall speaker is
ideal for smaller rooms
Specifications Infinite baffle design

• Woofer 5-1/4" black polypropylene cone with
  rubber surround
• Tweeter 3/4" coaxial cloth dome with
  Ferrofluid cooled voice coil
• Frequency Response 60 Hz - 20kHz /- 3dB
• Efficiency 89 dB 1W / 1m
• Power Handling 10 watts minimum to 65 Watts
  maximum
• Impedance 8 ohms nominal
• Grille white aluminum (grilles may be painted)
• Speaker Dimensions (Diax) 7-15/16" x 2 5/8"
  deep
• Cutout Cutout Dimensions 6-3/4
• Stock 30004
• MSRP 109.95
• UOM Pair
• Master Carton Qty 2

14
HFW6R IN-CEILING SPEAKER A better grade speaker
for use with medium-sized rooms and general
in-ceiling audio applications.
Specifications Infinite baffle design

• Woofer 6-1/2" black polypropylene cone with
  rubber surround
• Tweeter 3/4" coaxial cloth dome with
  Ferrofluid cooled voice coil
• Frequency Response 50 Hz - 20kHz /- 3dB
• Efficiency 90 dB 1W / 1m
• Power Handling 10 watts minimum to 100 Watts
  maximum
• Impedance 8 ohms nominal
• Grille white aluminum (grilles may be painted)
• Speaker Dimensions (Diax) 9-3/4" x 3-3/4" deep
• Cutout Cutout Dimensions 8-5/32
• Stock 30005
• MSRP 149.95
• UOM Pair
• Master Carton Qty 2

15
HFW8R IN-WALL SPEAKER A large speaker for use in
large rooms for bass reinforcement and for home
theater.
Specifications Infinite baffle design

• Woofer 8" black polypropylene cone with rubber
  surround
• Tweeter 1" coaxial cloth dome with Ferrofluid
  cooled voice coil
• Frequency Response 40 Hz - 20kHz /- 3dB
• Efficiency 91dB 1W / 1m
• Power Handling 10 watts minimum to 125 Watts
  maximum
• Impedance 8 ohms nominal
• Grille white aluminum (grilles may be painted)
• Speaker Dimensions (Diax) 10-3/4" x 3-7/16"
  deep
• Cutout Cutout Dimensions 9
• Stock 30006
• MSRP 199.95
• UOM Pair
• Master Carton Qty 2

16

HFW IN-CEILING SURROUND SPEAKERS
The In-Ceiling Surround Speakers are specifically
designed to reproduce home theater surround
channels with the spaciousness and envelopment
you hear in a movie theater.

• Specifications
• Woofer 6-1/2 gold aluminum cone with a rubber
  surround
• Tweeter Two - 3/4 gold aluminum domes
• Frequency Response 40Hz 20kHz /- 3db
• Efficiency 91db 1W / 1m
• Power 5 watts minimum to 125 watts maximum
• Impedance 8 ohms nominal
• Grille Aluminum (grilles may be painted)
• Speaker Dimensions 9-3/4 diameter x 3-3/4
  deep
• Cut-out Dimensions 8-5/32 diameter
• Stock 30043
• MSRP 199.95
• UMO Pair
• Master Carton Qty 4

17

This speaker is an excellent choice for home
theater applications when a front wall is not an
option. The position of the angled driver directs
sound from the LCR to the listening area for
in-ceiling home theater installations.
HFW OVAL SPEAKERS

• Specifications
• Woofer 6-1/2 gold aluminum cone with a rubber
  surround
• Tweeter 3/4 gold aluminum pivoting dome
• Frequency Response 50Hz 20kHz /- 3db
• Efficiency 90db 1W / 1m
• Power 5 watts minimum to 100 watts maximum
• Impedance 8 ohms nominal
• Grille Aluminum (grilles may be painted)
• Speaker Dimensions 8-5/8 wide x 12-3/4 tall
  x 4-7/8 deep
• Cut-out Dimensions 6-5/8 x 10-3/4 elliptical
• Stock 30042
• MSRP 119.95
• UMO Each
• Master Carton Qty 4

18
Add-A-Room Audio Kit

• Package includes
• 2 HFW5R In-Ceiling Speakers
• 1 HFW VC Volume Control
• 1 HFW WP-2 Wall Plate
• 1 HFW C50 50 Speaker Cable
• Stock 30033
• MSRP 179.95
• UOM Each
• Master Carton Qty 2

19
HFW OUTDOOR SPEAKER An outdoor speaker for use
under patio covers, under eves, or inside the
garage.
Specifications Weather resistant outdoor
loudspeaker

• Woofer 5-1/4" black polypropylene cone with
  rubber surround
• Tweeter 5/8" polycarbonate dome
• Frequency Response 55 Hz - 20kHz /- 3dB
• Efficiency 90 dB 1W / 1m
• Power Handling 10 watts minimum to 80 Watts
  maximum
• Impedance 8 ohms nominal
• Grille white aluminum (grilles may be painted)
• Speaker Dimensions 7 wide x 10-1/4 high x 7"
  deep
• Mounting Bracket included
• Stock 30019
• MSRP 109.95
• UOM Pair
• Master Carton Qty 2

20

HFW 6.5 OUTDOOR II SPEAKERS
Outdoor II speakers bring high-quality music and
other entertainment to your patio, deck, pool
or spa area. Includes mounting bracket and
hardware.

• Specifications
• Woofer 6-1/2 black polypropylene cone with a
  rubber surround
• Tweeter 1 supronil / polyurethane dome
• Frequency Response 45Hz 20kHz /- 3db
• Efficiency 90db 1W / 1m
• Power 10 watts minimum to150 watts maximum
• Impedance 8 ohms nominal
• Grille White aluminum (grilles mat be painted)
• Speaker Dimensions 7-3/8 wide x 12 tall x
  9-1/4 deep
• Stock 30046
• MSRP 179.95
• UMO Pair
• Master Carton Qty 2

21
HFW ROCK SPEAKER An outdoor loudspeaker disguised
as a rock with a granite finish.
Specifications Weather resistant outdoor
loudspeaker

• Woofer 6-1/2" black polypropylene cone with
  rubber surround
• Tweeter 5/8" polycarbonate dome
• Frequency Response 60 Hz - 20kHz /- 3dB
• Efficiency 89 dB 1W / 1m
• Power Handling 10 watts minimum to 100 Watts
  maximum
• Impedance 8 ohms nominal
• Grille white aluminum (grilles may be painted)
• Speaker Dimensions 8-3/4 wide x 8-3/8 high x
  12-1/4" deep
• Stock 30020
• MSRP 109.95
• UOM Pair
• Master Carton Qty 2

22

HFW CA308 SINGLE SOURCE/4-ZONE AMPLIFIER
Four-zone (8-channel) amplifier that connects to
a single audio source (such as a stereo
receivers Tape Record Outputs), playing it in up
to four different rooms. Four individual Zone
ON/OFF switches and Zone Volume Controls allow
each zone to be controlled independently.
Optional CA308 Remote Controls allow users to
control the CA308 from within each zone.

Specifications ? Number of Channels 8 (four
stereo pairs) ? Output Power (Stereo) 30 Watts
per channel (stereo) _at_ 8 ohms ? Frequency
Response 20Hz - 20kHz /- 1dB ? Total Harmonic
Distortion 0.05 (1kHz) 0.1 (20Hz - 20 kHz) ?
Input Sensitivity 730mV ? Input Impedance 90k
ohms ? Signal to Noise Ratio -95dB ? Maximum
Source Input Voltage 3.5 VAC RMS ? Loop Output
Imedance (Buffered) 100 ohms ? Power
Consumption 600 Watts, maximum 20 Watts
(standby) ? AC Fuse 5A (F5A 250V) ?
Dimensions 16-11/16 x 3-15/16 x 14-3/4 ?
Shipping Weight 25 lbs ? Stock 30050 ? MSRP
720.95 ? UMO Each ? Master Carton Qty 2

23
CA 308 FRONT PANEL
CA308 BACK PANEL
24
HFW308 REMOTE CONTROL
Controls the CA308 Amplifier from within the
listening zone via IR. Features Volume UP/DOWN,
Zone ON/OFF and All Zones ON/OFF functions. Must
be used with the CA308 Keypad Controller.
Specifications ? Functions Volume Up/Down, Zone
On/Off, All Zones On/Off ? Operating Range Up to
30 feet, up to 30º from centerline of the IR
receiver ? Battery Type 1 x CR205 (included) ?
Stock 30052 ? MSRP 34.95 ? UMO Each ?
Master Carton Qty 24

25
HT308 KEYPAD CONTROLLER

In-wall keypad allows users to control the CA308
amplifier from within the listening zone.
Features volume UP/DOWN, zone ON/OFF, and all
zones ON/OFF functions. Built-in IR receiver
works with the CA308 remote control. Installs in
a single J-Box and connects to the CA308
amplifier via CAT-5 wire or 5-conductor control
wire.
Specifications ? Functions Volume Up/Down, Zone
On/Off, All Zones On/Off ? Operating Range Up to
30 feet, up to 30º from centerline of the IR
receiver ? Battery Type 1 x CR205 (included) ?
Stock 30051 ? MSRP 79.95 ? UMO Each ?
Master Carton Qty 24

26
HFWS4 SPEAKER SWITCHER Speaker selector becomes
necessary when user wants to connect more than
two pair (up to four) of speakers to a typical
stereo receiver or amplifier, or when the user
wants on/off speaker control from a single
location.
Specifications Speaker Selector on/off
control up to 4 pairs of speakers

• Switch Type Push-push type, self cleaning
• Frequency Response 20 Hz 20kHz
• Power Handling 120 watts per channel maximum,
  40 watts per channel with
• protection while all speakers are engaged
• Protection Circuit Resistive in-line
• Connections Push-type, connectors accept up to
  12-gauge speaker cable
• Dimensions 8-3/8 wide x 2 high x 6-3/4
  deep
• Stock 30009
• MSRP 109.95
• UMO Each

27

HFWS6 SPEAKER SELECTOR

This speaker selector allows you to connect up to
six pairs of speakers to a typical stereo
receiver or amplifier allowing "on/off" speaker
control from a single location.

• Specifications Speaker selector on/off control
  for up to 6 pair of speakers
• Inputs One stereo source (speaker level from
  receiver or amplifier)
• Outputs Six stereo (speaker level) parallel
  output for additional speaker switches
• Protection Circuit 5 ohm resistor manually
  activated
• Connections Push-type, wire-grabbing connectors
  accept up to 12-gauge speaker cable
• Power Handling 120 watts per channel (40 watts
  per channel with protection engaged)
• Dimensions11-1/4 wide x 2 tall x 7 deep
• Stock 30010
• MSRP 149.95
• UMO Each
• Master Carton Qty 5

28
HFWVC STEREO VOLUME CONTROL Stereo in-wall
mounted volume control that enables user to
control the volume of the speakers from the room
in which they are located packed with mounting
ring, 2 styles of wallplates (standard and
decora), knob, Decora insert, and wire nuts.
Specifications Volume control with 10-position
light touch switch

• Attenuation by step top 6 steps are -3 db per
  step, lowest 4 steps are -6db per step
• the last step is off
• Frequency Response 20 Hz 20kHz
• Mounting and Depth standard single gang
  electrical trim ring under 2 from
• finished wall
• Stock 30010
• MSRP 49.99
• UOM Each
• Master Carton Qty 6

29
HFW WP-1 SPEAKER WALL PLATE A wall mount wire
connection for one speaker.
Specifications Single speaker wall
plate

• Clean wire connection
• In-wall speaker to amplifier connection
• Attractive Decora style wall plate
• Gold Plated, color coded terminals
• Stock 30021
• MSRP 12.99
• UOM Each
• Master Carton Qty 10

30

• HFW AUDIO INPUT WALL PLATE
• Designed for the knowledgeable end user or
  installer offering a simple homerun terminal
  point for up to six pair of speakers. Mounts
  within a standard double J-Box enclosure or
  P-ring. Must use impedance matching volume
  controls.

• Specifications
• Speaker Connectors Gold 5-way binding posts
• Plate Size Standard Decora style 2 gang plate
• Dimensions (WxHxD) 3-3/8 x 4-1/8 x 1-1/4
• Box Dimensions (WxHxD) - 4-7/8 x 4-7/8 x 2
• Stock 30049
• MSRP 99.99
• UOM Each
• Master Carton Qty 5

31
HFW WP-2 STEREO SPEAKER WALL PLATE A wall mount
wire connection for pair of speakers.
Specifications connection for a pair of
speakers

• Clean wire connection
• In-wall speaker to amplifier connection
• Attractive Decora style wall plate
• Gold Plated, color coded terminals
• Stock 30022
• MSRP 19.99
• UOM Each
• Master Carton Qty 10

32
HFW 5.1 HOME THEATER WALL PLATE Designed for the
knowledgeable end user or installer offering
in-wall connection capabilities for audiophile
quality home theater speaker systems. Mount
within a double J-Box enclosure or P-ring.
Specifications 5.1 speaker wall plate

• Speaker Connections Gold 5-way binding posts
• Plate Size Standard Decora style 2 gang plate
• Dimensions (WxHxD) 3-3/8 x 4-1/8 x 1-1/4
• Clamshell Dimensions (WxHxD) 6-11/16 x
  8-1/8 x 1-1/2
• Stock 30048
• MSRP 49.99
• UMO Each
• Master Carton Qty 5

33
HFW VE2 EMITTER Dual, lowoutput emitter assembly
that can be placed directly over the IR senor on
components.
Specifications IR Emitter

• Design Dual visible IR emitter
• Lead Termination Emitters are wired in series
  and terminated with a 3.5mm mono-mini
• plug
• Wire Length 7 to junction, 3 to each emitter
• Shipping Weight 1.2oz (0.034kg)
• Stock 30053
• MSRP 24.95
• UOM Each
• Master Carton Qty 1

34
HFWVC ODVC KIT A weather resistant outdoor volume
control housing that controls your outdoor
speaker volume.
Specifications Outdoor volume control housing

• Attenuation by step top 6 steps are -3 db per
  step, lowest 4 steps are -6db per step
• the last step is off
• Weather Resistant
• Use with HFW VC 30010
• Pole or surface mount
• Stock 30024
• MSRP 19.99
• UOM Each
• Master Carton Qty 5

35
HFWBC50 SPEAKER WIRE A 50 foot length of stereo
speaker cable for use with HiFi Works Rock
speakers and outdoor speakers.
Specifications 16 Gauge 4 conductor speaker
cable

• Oxygen-free stranded copper (19 strands per
  conductor)
• NEC Rating CL3 low voltage
• Extra-thick skin to protect buried cable from
  the elements
• Use with HFW VC 30010
• Individually color-coded insulation
• Stock 30031
• MSRP 79.95
• UOM Each
• Master Carton Qty 5

36
HFWC100 SPEAKER WIRE A 100 foot length of stereo
speaker cable UL and NEC rated for class 2 or 3
low voltage wiring (speaker-level) inside walls.
Specifications 16 Gauge 4 conductor speaker
cable

• Oxygen-free stranded copper (19 strands per
  conductor)
• NEC Rating CL3 low voltage
• Use with HFW VC 30010
• Individually color-coded insulation
• Stock 30011
• MSRP 79.95
• UOM Each
• Master Carton Qty 5

37
Customer Service Support
HIFI Works CSR Contact Josh Wright (888)
484-6782 [phone] joshw_at_sonance.com

• Place Product Orders
• Order Marketing Collateral
• Returns Service

Tech Support [phone] Web Site
www.hifiworks.com
