Estimation of Distribution Algorithms EDA

1
Estimation of Distribution Algorithms (EDA)

• Siddhartha K. Shakya
• School of Computing.
• The Robert Gordon University
• Aberdeen, UK
• ss_at_comp.rgu.ac.uk

2
EDAs

• A novel paradigm in Evolutionary Algorithm
• Also known as Probabilistic model building
  Genetic Algorithms or Iterated density
• A probabilistic model based heuristic
• Motivated from the GA evolution
• More explicit evolution than the GA

3
Basic Concept of Solution and Fitness
Graph colouring Problem An Example
Given a set of colours, GCP is to try and assign
Colour to each nodes in such the way that
neighbouring nodes will not have same colour
4
Basic concept of a solution and Fitness
Given 2 colour Black 0 White 1
Representation of a solution as a chromosome
Solution
5
Chromosome and Fitness in GCP

• Chromosome is a set of colours assigned to the
  nodes of graph. (there are other way of
  representing GCP in GA, such as order based
  representation).
• Fitness is the number of correctly coloured
  nodes.

6
GA Iteration

• Initialisation of a parent population
• Evaluation
• Crossover
• Mutation
• Replace parent with child population and go to
  step 2 until termination criteria satisfies

7
GA Iteration
Initialization
Evaluation
After Crossover
8
GA evolution

• Selection drives evolution towards better
  solutions by giving a high pressure to the
  selection of high-quality solutions
• Crossover and mutation (Variation operator)
  together ensures the exploration of the possible
  space of the promising solutions. Maintains the
  variation in the population.

9
Variation in GA Evolution

• Has its limitation
• Can recombine fit solution to produce more fit
  solution
• Also can disrupt good solution and converge in
  local optimum

10
Estimation of Distribution Algorithm (EDA)

• To overcome the negative effective of the
  crossover and mutation approach of variation, a
  probabilistic approach of variation has been
  proposed.
• Algorithm using such approach is known as EDA (or
  PMBGA)

11
GA to EDA
Initial Population
Evaluation
Selection
Probabilistic Model Building
Sampling Child Population
EDA framework
12
General Notation

• EDA represents a solution as a set of value taken
  by a set of random variable.

is a conditional distribution
is a joint probability distribution
13
Estimation of Probability distribution
14
Simple Univariate Estimation of Distribution
Algorithm
Initial Population
Evaluation
Selection
Calculate univariate marginal probability and
sample Child Population
15
Simple univariate EDA (UMDA)
Initialization
Evaluation
Selection
Repeat iteration
Build model
Estimation of Distribution
Calculate Distribution
Sampling
16
Note

• It is not guaranteed that the above algorithm
  will give optimum solution for the graph
  colouring problem.
• The reason is obvious.
• The chromosome representation of GCP has
  dependency. i.e. node 1 taking black colour
  depends upon the colour of node 2.
• But univariate EDAs do not assume any dependency
  so it may fail.
• However, one could try

17
Complex Models

• To tackle problems where there is dependency
  between variables we need to consider more
  complex models.
• The extra model building step will be added to
  univariate EDA.
• Different algorithms has been purposed using
  different models
• They are categorised into three groups
• Univariate EDA
• Bivariate EDA
• Multivariate EDA

18
Univariate EDA Model
x2
x1
x3
x5
x4
x7
x6
Graphical representation of probability model
assuming no dependency among variables. (UMDA,
PBIL, cGA)
19
Bivariate EDA Model
a. Chain model (MMIC)
b. Tree model (COMIT)
c. Forest model (BMDA)
Graphical representation of probability model
assuming dependency of order two among variables.
20
Multivariate EDA Model
21
Finding a probabilistic model

• Task of finding a good probabilistic model
  (finding the relationship between variable) is a
  optimization problem in itself.
• Most of the algorithm use Bayesian network to
  represent the probabilistic relationship.
• Two metric to measure the goodness of Bayesian
  Network.
• Bayesian Information Criterion (BIC) metric
• Bayesian-Dirichlet (BD) metric
• Use greedy heuristic to find a good model.

22
Summary

• EDA is an active area of research for GA
  community
• EDAs are reported to solve GA hard problems, and
  also hard optimization optimisation problems like
  MAX SAT.
• Success and failure of EDAs depends upon the
  accuracy of the used Probabilistic model.

23
Links

• http//cswww.essex.ac.uk/staff/zhang/MoldeBasedWeb
  /RGroup.htm (Research Groups working on EDAs)
• http//www.sc.ehu.es/ccwbayes/main.html (EDA
  homepage maintained by Intelligent system group).


Books

• Larrañaga P., and Lozano J. A. (2001) Estimation
  of Distribution Algorithms A New Tool for
  Evolutionary Computation. Kluwer Academic
  Publishers, 2001.
• Pelikan, M., (2002). Bayesian optimization
  algorithm From single level to hierarchy. Ph.D.
  thesis, University of Illinois at
  Urbana-Champaign, Urbana, IL. Also IlliGAL Report
  No. 2002023.
