Production Design Presentation

1
Production Design Presentation

• By
• Mr Dalton

2
Car Project

• Key Points
• Sketching
• Create Features
• Constraints
• 2D and 3D Drawings
• Creating Balloon Part Lists
• Creating Presentations

3
Weight Machine Project

• Team 1
• Craig
• Eric
• Ryan
• Key Points of Project
• Teaming
• Link and Sharing

4
Weight machine continued

• What I learned
• Project Geometry
• Mirror Feature
• Circular Pattern
• Bolted Connection
• Section Views
• Sharing Files

5
Injection Molding Machine

• What I learned
• Circular Array
• Emboss
• Rim and tire
• Materials
• Stress Analysis

6
Tips and Tech Notes

• In the next few slides are some of the tools and
  tips I discovered while completing my projects
  that were time saving and powerful.

7
Creating Ribs and Webs

• Create an active sketch in the location you will
  place the rib or web
• Sketch an open profile that defines the basic
  shape or one edge of the rib or web.
• Add constraints and dimensions to the sketch as
  needed
• Click the rib tool located on the Part Features
  Panel Bar

8
Ribs and Webs Continued

• Specify the direction of the rib or web. Click
  the direction button in the Rib Dialog box.
  Position the cursor around the open profile to
  specify whether the rip or web will extend
  parallel or perpendicular.
• Enter the value for the rib or web in the
  Thickness edit box
• Use the Flip buttons to choose which side of the
  profile to apply the thickness value

9
Ribs and Webs continued

• Specify the depth of the profile by clicking
  either the To Next or Finite buttons in the
  Extents area of the Rib Dialog box.
• If you use the Finite option, enter an offset
  distance and click Extend Profile if the
  endpoints are to be extended to the next
  available face.
• To complete the operation, click the OK button.

10
Create the 2nd and 3rd tip and tech notes.

• Key points
• No more than 5 points on any slide
• Continue to next slide for additional points.
• Last slide should have key points of the class.
  What was your favorite project and why.
