Combustion Air Pre-heater Design Review Presentation

1
Combustion Air Pre-heater Design Review
Presentation

• ME 486
• 3/13/03

2
Purina Boiler Efficiency Team

• Members and Roles
• Ryan Cook
• Documenter and Secretary
• Kofi Cobbinah
• Team Leader and Website Manager
• Carl Vance
• Communicator and Historian
• Matt Bishop
• Financial Officer and Mediator

3
Summary

• Client Introduction
• Project Description
• Our Design
• Mathematical Model
• Schedule
• Budget
• Conclusion

4
Our Client Nestlé Purina

• Client contact is John Cain
• Manager of Engineering at the Flagstaff Plant.
• Purina as a company
• Flagstaff Plant opened in 1975
• Employs 180 people
• Purina is now a division of Nestlé Foods

5
Purina Steam System

• The boiler produces approximately 500,000 lbm
  of steam per day.
• 40 cooking products.
• 50 drying products.
• 10 miscellaneous areas air and water
  heating systems.
• Steam production is 2/3 of the plant's total
  energy use.

6
Project Description

• Problem Definition
• Nestlé Purina has requested a proposal for a
  combustion air pre-heater. The goal of the
  project is to provide savings for the plant by
  reducing energy costs and improving efficiency in
  the steam system.
• Justification for the project is cost reduction
  and fuel conservation through higher efficiency.

7
Project Description

• Clients Needs Statement
• Design of a combustion air preheater must be
• Efficient
• Economically Feasible
• Minimize Modifications to Existing Systems

8
Our Design Philosophy

• Finish Design and Construction Under Budget.
• Satisfy the Clients Requirements.
• Design for Safety.
• Act with Integrity.

9
What is a Combustion Air Preheater

• Device or system that heats the boiler intake
  air.
• Uses recaptured waste heat to that would normally
  leave the boiler to the atmosphere.

10
Design Choice

• Final Design Choice
• Concentric Duct Design
• Air enters into a duct that surrounds the stack.
• The stack transfers heat to the air by convection
  and radiation.
• The air enters into the boiler at a higher
  temperature.

11
Preheater Design Basics
12
Design Benefits

• Concentric Duct Design Will Provide
• Relatively Low Installation Cost
• Low Material Costs
• Low Impact on Existing Systems
• High Payback on Investment
• Low Maintenance Costs

13
Specifications to date

• The stack height is 4.3 meters, which fixes our
  duct height and will provide our surface area for
  heat transfer.
• Duct diameter will be 1.15 meters to optimize
  forced convection.

14
Proposed Design
15
Forced Convection Model
16
Heat Exchanger Model
17
Radiation Model
18
Project Monetary Savings
Convection Savings
Forced Convection
Radiation
19
Accomplishments to Date

• Proposal Document has been accepted by client
• Mathematical Analysis of the design has been
  accepted by the client.

20
Problems Encountered

• CAD model is taking more time than estimated.

21
Future Design Tasks

• Final Design will include
• Finalizing Mathematical Models
• Finishing CAD Models
• Design Results
• Bill of Materials
• Construction Methods

22
Project Schedule

• CAD Models ------------- March 24,
  2003Final Design-------------- April 20,
  2003Capstone Presentation- April 25, 2003Final
  Report ------------- May 2, 2003

23
Budget

• Printing Cost
• Proposal Document ----------------- 15
• Mathematical Models Document - 15
• Total--------------------------------------- 30

24
Team Time Log
25
Conclusion

• We are on schedule to finish all deliverables
  and have a completed design as planned.
• We will provide the client with a design that is
  both efficient and feasible to implement.

26
Questions?
