ATS All Terrain Stretcher

1
ATS (All Terrain Stretcher)

• Chris Arnold
• Beth Pavlik
• Mike Rushia
• Scott Sanson

2
Assumptions

• User 1 or 2 Search and Rescue team members
• Market SR, Military, Ski Patrol
• Need Inexpensive, compact, lightweight device
  for wilderness rescue operations
• Environment Densely forested mountainside with
  or without snow

3
Limits

• Inexpensive Cannot use much high end material
  (total less than 400)
• Lightweight Compact Maximum victim height of 7
  ft, weight of 300 lbs, empty weight less than 40
  lbs
• Easy Assembly Must be fast to assemble (less
  than 10 min)
• Manageable Terrain Trees must be at least 2.5 ft
  apart

4
Final Design Step 1
5
Final Design Step 2
6
Final Design Step 3
7
Final Design Side View
8
Final Design Shocks Springs

• Ideal shock Leaf spring
• Realistic shock Spring/ski
• Pawls for telescoping parts

9
Final Design - Clamps

• Folding bike hinge
• Hinge/clamp system for rigidity
• Modular clamp
• Ski ? Wheel

10
Frame BOM
.058 Chromoly
11
Final Design - Nonframe

• Backpack style shoulder straps
• Ball joint
• Handles on 2 ends for 2 person rescue team
• Braking system
• Lever lowers

12
Defense of Design (concepts)

• Crumple Frame
• Inflatable High material cost (60-100 per m2,
  about 300 min)
• Solid Frame
• Low material cost
• Wide range of materials

13
Solid Frame Ideas

• Piece frame
• Good compactability
• Slow/Unclear assembly
• Accordion style hinged frame
• Good compactability, easy assembly
• Messy overlap, potential for bending

14
Questions
