Title: Introduction to Matlab 7 Lesson IV


1
Introduction to Matlab 7Lesson IV
  • Marco Lattuada
  • Swiss Federal Institute of Technology - ETH
  • Institut für Chemie und Bioingenieurwissenschaften
  • ETH Hönggerberg/ HCI F135 Zürich (Switzerland)
  • E-mail lattuada_at_chem.ethz.ch
  • http//www.morbidelli-group.ethz.ch/education/inde
    x

2
Example of Function
  • The M-File the "mysum" function (saved in
    mysum.m)

3
Exercise
  • Create a new function called 'my_second_function'
  • Scope of the function
  • Compute the function f(x) 2x2-exp(x)3
  • Parameters of the function
  • Input a generic array x with n components
  • Output an array n?1 with the values of the
    function in x
  • Evaluate the function for 40 x values ranging
    from -5 to 5
  • Plot f(x) versus x

4
Exercise
  • Create the function 'bisection_root' that
  • Computes the zero of a function f(x) by the
    'Bisection' method
  • The objective function is f(x) 2x2-exp(x)3
  • The interval within the search for the zero is
    carried out is given to the function as input
    parameter (xmin, xmax)
  • The function returns as output the zero (x0) and
    the corresponding value of the function (f(x0))
  • Iterate the search for the zero until the search
    interval is less than 10-4
  • Provide to the function the desired precision e
  • Add a preliminary check on the supplied
    uncertainty interval
  • If f(xmin)f(xmax) gt 0 return an error (use the
    command error)
  • Compute x0
  • Compute f(x0)
  • Change the interval x1, x2
  • Iterate 1-gt3 until (x2-x1) lt e

5
How to Pass a Function to a Function
How can I use the function 'bisection_root' to
compute the root of a generic function fobj(x)?
6
Simulation of a Batch Reactor
  • Hp T const V const
  • Variables CA, CB , CC
  • Equations

R1 A ? 2B with R1 k1A R2 B ? C with R2 k2B
  • Create the function 'batch_reactor' which
  • Receives the time t and the column vector C with
    the concentration of the three components
  • Returns a vector dCdt with the derivatives dCi/dt
  • k1 and k2 are fixed values in the function

7
Integration of Systems of ODEs
  • Function call
  • t, dydt ode15s (_at_fcn_dydt, t_grid, y_init)
  • The function ' fcn_dydt' must have the following
    header
  • function dydt fcn_dydt (t, y)

Let us use the built in Matlab function ode15s
8
Simulation of a Batch Reactor
  • Hp T const V const
  • Variables CA, CB , CC
  • Equations

R1 A ? 2B with R1 k1A R2 B ? C with R2 k2B
  • Modify the function 'batch_reactor' so that
  • It receives the time t and the column vector C of
    the concentration of the three components
  • It returns a vector dCdt with the derivatives
    dCi/dt
  • It receives k1 and k2 as input parameters

9
Integration of Systems of ODEs
The new function header does not correspond to
that required for the subroutine ode15s function
dydt fcn_dydt (t, y)
Alternative call 1 t_out,C ode15s(_at_(t,
C) batch_reactor(t, C, k),t_in,C_init)
Alternative call 2 t_out,C
ode15s(_at_batch_reactor,t_in,C_init,,k)
Alternative call 3 global k t_out,C
ode15s(_at_batch_reactor2,t_in,C_init)
batch_reactor_an _at_(t, C) batch_reactor(t, C, k)
The value of k becomes part of the "body" of
batch_reactor_an
Function "handle"
10
Anonymous Functions
11
Input-output functions
  • To enter date from the keyboard during the
    execution of a program, use the command input
  • Variable_nameinput(Message)
  • Stops the execution of the program until
    something is typed in. The value that is typed in
    is stored in the variable variable-name
  • To retrieve data from a file, there are different
    possibilities
  • Load loads vectors and matrices from a binary
    file
  • Dataload(file_name.ext)
  • Will store the values in the file file_name.ext
    in Data. Remember the values in the file need to
    be stored in matrix form (some number of rows and
    columns everywhere) and the file has to be ASCII

12
Read from - and write to - a file
  • fidfopen(filename.ext,w) creates a file
    named filename.ext
  • or it overwrites it if already existing.
  • Instread of w, the permission can be
    r(read), ora (append)
  • A fread(fid) similar to load, reads data
    and stores them in A
  • A fscanf(fid, format) reads formatted data
    (specified by format) and stores it in A
  • tl fgetl(fid) reads one line from the file and
    stores it in tl
  • fwrite(fid, A, precision) writes matrix A as a
    column vector with specified precision
  • fprintf(fid,14.10e\n,a(1,1)) writes a(1,1) in
    the file with specified format (in this case,
    exponential notation)
  • Fclose(fid) closes file

File identifier
Permission
13
Exercise
  • Create the function 'my_derivative' that
  • Computes sin(x) in x
  • Computes the derivative of sin(x) in x
  • Uses a step Dx 1e-8 to compute the derivative
  • Compare the result produced by the function with
    the analytical solution of the derivative
  • Provide the step Dx as an input parameter
  • Select a value of Dx and run the function for x
    00.1pi
  • Select x 1 and run the function of decreasing
    Dx
  • Compare previous result with the analytical
    solution
  • For which Dx the derivative is best approximated?
  • Repeat points 5 to 7 for the function F(x) a
    exp(-b x) c x2 where (a, b, c) (2, 3, -4)

14
My Derivative
