Hybrid Vehicles

1

_____ _______
2
Whats a Hybrid Vehicle?

• Small gasoline engine
• Electric motor
• High Voltage (HV) battery pack

3
(No Transcript)
4
(No Transcript)
5
HV DISCONNECT FEATURES

• Inertia switches for fuel and voltage
• Switches located front and rear
• HV with the ignition switch
• Removal of HV Service Disconnect Switch
• HV battery is fused for short circuits
• 140 F sensor in battery
• HV connectors have disconnect sensors

6
What emergency procedures should be taken at a
fire involving a hybrid vehicle?
7
Follow normal vehicle firefighting procedures

• SCBA
• Adequate water flow rate
• A safe position of approach
• Wheels chocked

8
Fire Situations in a Hybrid Present Unique
Concerns

• Direct flame impingement on the HV battery pack
• A fire in the battery pack
• An electrical fire within the HV system

9
Ni-MH Battery Pack
If the HV battery case is ruptured hose the area
down with lots of water
10
Ford Escape
11
Ford Escape

• Rear inertia switch
• HV service disconnect switch
• HV battery 300 volts
• HV wiring
• 12 volt battery
• ECVT Electronically Controlled Transmission
• DC DC Converter
• Front inertia switch

12
Ford Escape
13
Ford Escape
14
APPROACHING A DAMAGED VEHICLE

• Disable the HV electrical system
• Put the shift lever into Park
• Remove the ignition key
• Disconnect the negative cable from the 12-volt
  battery

15
APPROACHING A DAMAGED VEHICLE

• Block the wheels
• Remove HV Service Disconnect Switch
• If exposed cables do not touch
• Treat severed lines as HV
• If in water do not touch HV components
• Do not remove till HV battery is discharged

16
Removing the High Voltage Service Disconnect
Switch disconnects high voltage from the
vehicle. The individual cells inside the battery
pack will still be charged. Do not cut into the
high voltage battery case or penetrate the
batteries in any way
WARNING
17
Honda Civic
18
Honda Civic
19
Honda Civic
20
Honda Civic
21
Honda Civic
22
Honda Civic
Extrication equipment cut zones
23
Turning off Battery Switch

• Remove rear seat
• Unscrew bolts
• Remove cover
• Replace cover

24
Airbags and Seat Belts

• Airbags front and sides
• Pyrotechnic seat belt tensioners
• 3 point seat belts
• Disconnect 12 v. battery for 3 minutes
