Installing Oracle9i RAC Release 2 on HP OpenVMS Systems

1
Installing Oracle9i RAC Release 2 on HP OpenVMS
Systems
2
Installation notes

• Oracle Real Application Cluster will be installed
  on two nodes using a single disk that is shared
  cluster wide.
• The node names are Path1 and Path2.
• The RAC cluster interconnect will be the through
  the Ethernet devices in each node using TCP/IP as
  the transport.

3
Specifications (1 of 3)

• Installation example demonstrates install and
  build of an Oracle9i RAC Release 2 database on an
  OpenVMS Cluster.
• Hardware used is a PC running Xcursion and a 4
  Processor ES40 configured as a 2-node Galaxy.
• We booted on disk DKA0 on each node.
• Oracle account is on a cluster shared disk
  DKA100.
• Oracle and the database will be installed on
  DKA100.
• Install disk MUST be ODS-5.
• Installation uses the 9.2 kit that was obtained
  from the Oracle website. It comes in a Java JAR
  file.

4
Specifications (2 of 3)

• Oracle ships a JRE with its product. However, you
  will have to install Java on OpenVMS so you can
  unpack the 9.2 JAR file that comes from the
  Oracle website.
• Unpack the JAR file as described on the Oracle
  website. This creates two .BCK files.
• Follow the instructions in the VMS_9202_README.txt
  file to restore the two backup save sets.
• When the two backup saves sets files are
  restored, you will have two directories
• disk1 directory
• disk2 directory
• These directories will be in the root of a disk.
  In this example they are in the root of DKA100.

5
Specifications (3 of 3)

• OUI requires X-Windows. If the Alpha system that
  you are using for installation does not have a
  graphic head, you can use a PC with an X-Windows
  terminal emulator such as Xcursion.
• Installation instructions tell you to run
  _at_DKA100disk1runinstaller. However
  RUNINSTALLER.COM file is not in the root of
  DKA100disk1.
• You must first copy it from the
  dka100disk1.000000 directory into
  dka100disk1
• Copy dka100disk1.000000runinstaller.com
  dka100disk1
• Execute _at_DKA100disk1runinstaller from a
  terminal window.

6
Oracle Universal Installer

• Oracle Installer starts.

7
Welcome window

• Click Next to start installation.

8
Assign name and directory structure

• Assign a name for your Oracle home.
• Assign the directory structure for the home. For
  example
• Ora_home
• Dka100oracle.oracle9
• This is where the OUI will install Oracle.
• OUI will create the directories as necessary.

9
Select product to install

• Select database.
• Click Next.

10
Select installation type

• Select Enterprise Edition.
• Click Next.

11
Enable RAC

• Select Yes. This will be a member of a RAC.
• Click Next.

12
View product summary

• OUI displays a list of products that will be
  installed
• Click Install.

13
Installation begins

• Installation begins.
• Installation time varies from 45 minutes to an
  hour.

14
Installation ends

• Installation finishes.
• Click Exit.

15
Database Configuration Assistant

• Oracle is now installed.
• In the example it was installed in
  DKA100oracle.oracle9.
• To create the first database, you must first set
  up Oracle logicals.
• To do this use a terminal and execute
  _at_.oracle9orauser.
• Tool to create and manage databases is DBCA.
• On the terminal type DBCA to launch the Database
  Assistant.

16
Welcome to Database Configuration Assistant

• Database Configuration Assistant starts.
• Click Next.

17
Create a database

• Select Create a database.
• Click Next.

18
Select a template

• Select New Database.
• Click Next.

19
Specify database information

• Enter the Database name and Oracle System
  Identifier (SID).
• In this example, database name is DB9I and the
  SID is DB9I1.
• Click Next.

20
Select database features

• Select which demo databases are installed. In the
  example we selected all of the possible
  databases.
• Click Next

21
Select default mode

• In the example we selected Shared Server.
• Click Next.

22
Select installation parameters

• We left this screen at the default.
• Click Next.

23
Specify storage parameters

• Select the device and directory. Use UNIX device
  syntax
• DKA100oracle.oracle9.database would be
• /DKA100/oracle/oracle9/database/
• We accepted default settings in the example.
• Click Next.

24
Create a template

• Creating a template can save time the next time
  you create a database.
• Click Finish.

25
Template example

• Accept template to be used to create database.
• Click OK.

26
Database builds

• Database built from template.
• If it completes successfully, click Exit.
• If it does not build successfully, build it
  again.

27
View database

• Type show system to see the Oracle database up
  and running.
• Set up some files to start and stop the database.

28
Example of a start file

• Example sets the logicals to manage the database.
• Next line starts the Listener (needed for client
  connects).
• Final lines start the database.

29
Stopping the database

• Example of how to stop the database.

30
Test database server

• Use Enterprise Manager Console to test database
  server.

31
Oracle Enterprise Manager

• Enter the address of the server and SID.
• Enter a name.
• Click OK.

32
Enter database connect information

• Enter the system account and password.
• Change the connection box to read AS SYSDBA.
• Click OK.

33
View database information

• Database is opened and information displayed.

34
Listener .ora file (1 of 2)

• Listener.ora file is not necessary unless you
  have some special information to provide to the
  TNS listener.
• You should delete the Listener.ora file.
• The Listener will automatically pick up the SID
  from the database.
• Start the Listener before the database and the
  SID will show up right away in the listener.
• If you start the database before the Listener,
  the SID may not immediately display.

35
Listener .ora file (2 of 2)

• To see if the SID is registered in the Listener
  type
• lsnrctl stat
• The SID appears as shown in the example.

36
Unlock a username

• To unlock a username, type
• ORACLE_MARV1gtgtsqlplus "/as sysdba"
• SQLgt alter user oe identified by oe account
  unlock
• User altered.
• SQLgt exit
• Preferred method is to use the Enterprise Manager
  Console.

37
Configuring second node in cluster (1 of 6)

• In UNIX, LINUX, and Windows this is done with the
  DBCA.
• In OpenVMS however, you must configure the second
  node by hand.
• Remember
• Two nodes in this example are Path1 and Path2.
• Their TCPIP addresses are 10.2.3.1 ( Path1) and
  10.2.3.2 (Path2).

38
Configuring second node in cluster (2 of 6)

• Log in to the Oracle account on PATH1 and
  execute
• _at_.oracle9orauser db9i1
• In the example Oracle was installed in a
  directory .oracle9 and the SID assigned was
  db9i1.
• The com file executed in the example will set up
  the logicals needed to manage the newly created
  database.
• Next, create and modify some files to include the
  second cluster node PATH2.
• The SID for the second node will be assigned
  DB9I2.

39
Configuring second node in cluster (3 of 6)

• Set default ora_rootnetwork.
• Create a file using a command procedure.

40
Configuring second node in cluster (4 of 6)

• Create another file using a command procedure.

41
Configuring second node in cluster (5 of 6)

• Next, type
• Set def ora_rootdbs
• Copy DB9I1password file to DB9I2 password file
• Copy orapwdb9i1 orapwdb9i2
• Create a copy of the instance specific Init.ora
  file
• copy initdb9i1.ora initdb9i2.ora
• Create a copy of the property file
• copy sid_db9i1.properties sid_db9i2.properties

42
Configuring second node in cluster (6 of 6)

• These are the items that need to be modified in
  the INITSIDB.ORA file
• Delete the undo file reference at the bottom of
  the file.
• Place the new lines anywhere in the file.

cluster_database true
undo_tablespace UNDOTBS1 or UNDOTBS2
service_names sidA or sidB
instance_name sidA or sidB
instance_number 1 or 2
thread 1 or 2
cluster_interconnects 10.2.3.1
remote_login_passwordfile SHARED
43
Create redo files
44
appendix node 1 (1 of 3)

• The following steps are provided with the
  assumption that
• Instance on node1 is sidA.
• Instance on node2 is sidB.
• Set up your environment
• _at_orauser sidA
• set default ora_rootnetwork
• Create the DCL script needed for bequeath
  connections
• _at_create_orasrv_beq ltora_dbgt ltsidBgt ltdb_namegt
• And
• _at_create_orasrv_netv2 ltora_dbgt ltsidBgt ltdb_namegt
• For example
• _at_create_orasrv_beq DISKDISK1Oracle.oracel9.OR
  ADATA.DB9I - _ sidB DB9I
• And
• _at_create_orasrv_netv2 DISKDISK1Oracle.oracel9.
  ORADATA.DB9I - _ sidB DB9I
• set default ora_rootdbs

45
appendix node 1 (2 of 3)

• Create a copy of the Password file
• copy orapwsidA. orapwsidB.
• Create a copy of the instance specific parameter
  file
• copy initsidA.ora initsidB.ora
• The new file must be modified.
• Create a copy of the properties file
• copy sid_sidA.properties sid_sidB.properties
• The new file must be modified.
• Edit the files that were created in Step 4 and
  Step 5. (Before starting the instance, refer to
  the "List Of Parameters" following these numbered
  steps.)
• Ensure that parameter remote_login_passwordfile
  is set to SHARED (default EXCLUSIVE).

46
appendix node 1 (3 of 3)
47
appendix node 2

• Set up your environment
• _at_orauser sidB
• SQLgt connect / as sysdba
• SQLgt startup
• Define list of parameters before starting an
  instance that will participate in RAC

cluster_database true
undo_tablespace UNDOTBS1 or UNDOTBS2
service_names sidA or sidB
instance_name sidA or sidB
instance_number 1 or 2
thread 1 or 2
cluster_interconnects 10.2.3.1
remote_login_passwordfile SHARED
cluster_database_instances 4 optional
