ND GIS Users Conference

1
Introduction to ArcPad Mobile GIS

• Gregory Vandeberg, Ph.D.
• Department of Geography

2
Outline

• Introduction
• What is ArcPad?
• What can you do with ArcPad?
• What do you need to run it?
• Using ArcPad
• Main components and menu
• Creating and editing data
• GPS
• Forms
• Field Exercise

3
Introduction What is ArcPad?

• Mobile GIS Program
• ESRI, Redlands, CA
• 7.01 current release (10/2006)
• Interfaces with ArcGIS
• Handheld portability
• GPS interface possible
• ArcPad Application Builder
• Extensions such as GPS Correct

Image Trimble
4
What Can ArcPad Do?

• Use existing GIS data
• Capture data in field
• Query data
• Measure distances
• Navigate with GPS
• Edit data in field

5
Use Existing Data in Field

• GIS data files transferred from ArcGIS
• Multiple layers
• Symbolism
• Data types
• Shapefile
• ArcPad graphics
• ArcPad Photos
• MrSID MG2 and MG3
• JPEG and JPEG2000
• TIFF
• GIF
• PNG
• Windows bitmap
• CADRG
• ArcIMS Images Services

6
Query Data

• Query layer or layers to find item or location

7
Capture Data in Field

• GPS
• Imagery (digital camera)
• Range Finder

Image ESRI ArcGIS ArcPad, p. 4
8
Edit Data or Create New Features
9
Quick Forms

• When creating new layer, quickform helps to fill
  in data

10
Application BuilderExample Form Tree Inventory
Source ESRI Arcscript by Robert ODonnell,
Denver Tree Inventory, 2004
11
Running ESRI ArcPad

• Equipment
• Desktop PC
• PDA (e.g. HP IPAQ, Trimble Recon)
• Tablet PC
• Memory
• 64 mb RAM for Mobile PC
• Software
• Desktop (Windows 2000 or XP)
• Windows Mobile (Windows Mobile 2003 5.0, Windows
  CE 4.2, 5.0)
• Microsoft XML 4.0 Service Pack 2
• Microsoft ActiveSync 3.8 or higher

Source www.shopping.hp.com
Source Trimble
12
ArcPad with GPS Capabilities

• Supported protocols
• National Marine Electronics Association. (NMEA)
  0183, version 2.0
• Trimble Standard Interface Protocol (TSIP)
• Rockwell PLGR Protocol
• Delorme Earthmate
• Examples
• Flash card GPS
• Trimble Recon GPS Recon XC
• External GPS
• Bluetooth wireless connection
• Cable connection

Source Trimble
13
ArcPad Extensions for GPS

• Trimble Software Extensions
• Terrasync
• GPS Pathfinder Office
• Post processing
• GPS Correct Extension
• Used for realtime corrections
• Post processing with Pathfinder or GPS Analyst
• GPS Analyst for ArcGIS

14
Using ArcPad

• Menu Items
• Main toolbar
• Browse toolbar
• Edit toolbar
• Command Bar

15
Main Toolbar Open Map

• Map is main document in ArcPad

16
Main ToolbarAdd Layer and Table of Contents

• Data must be in supported format
• Data must be in same projection
• Must have enough memory

17
Main ToolbarGPS Position Window and

• Turn on GPS
• Set Preferences
• Turn on GPS extensions

18
Main Toolbar Tools and Help

• Add toolbars
• Set path options

19
Navigation and Command Toolbars

• Navigation
• Move about map
• Rotate
• Information
• Query data
• Start Editor
• Command
• Unlock and lock
• Toggle on editor pen

20
Edit Toolbar

• Select editable layers in Table of Contents
• Activation of Edit Toolbar turns on command bar

21
Getting Data into ArcPad

• Microsoft ActiveSync used to move data between
  devices
• Mobile device is not visible in ArcCatalog

22
ArcPad Tools in ArcGIS

• ArcPad 7.0 tools in ArcGIS will create map
  document, and transfer files
• Sets extent

23
Creating and Editing Data

• Data can be created by editing existing
  shapefile, form, graphics layer or photo layer
• Data can be created by making new form, graphics
  layer or photo layer

24
GPS Tool

• GPS connected via serial cable, flash card,
  Bluetooth, etc.
• GPS tool is activated from main toolbar
• Preferences must be set for particular GPS unit

25
GPS Position Window and Options
Source ESRI 2004, Using ArcPad. p. 180
Source ESRI 2004, Using ArcPad. p. 180
26
GPS and ArcPad Navigation

• Position shows up on map
• Can mark point to travel to
• Can also use GPS to create shapefiles and tracks

Source ESRI 2004, Using ArcPad. p. 193
27
GPS and Editing

• Create point with current GPS location
• Create line
• vertices
• streaming
• Create polygon
• vertices
• streaming

Source ESRI 2004, Using ArcPad. p. 324
28
Forms

• Allows for creation of forms for filling in field
  data
• Can be applied to previous shapefiles
• Can also use templates from ESRI ArcScripts
• Use ESRI Applications Builder for more advanced
  forms

29
Field Exercise

• Load ArcPad Map
• Create new point shapefile
• Trees around hotel
• Create new line shapefile
• Sidewalks near hotel
• Create new polygon shape file
• Hotel parking lot
• Use GPS to edit new shapfiles

30
References and Resources

• ESRI, 2005. ArcGIS 9 Using ArcPad. Redlands, CA
  ESRI Corporation.
• Free Online Workshop from ESRI
• http//training.esri.com/acb2000/showdetl.cfm?DID
  6Product_ID858
