ECE 552 Image Toolbox Implementation

• Team BLUE
• Dilip Patlolla
• Praneeth Parla
• Abhimanyu Sulakhe
• Prachya Mruetusatorn

2
Overview

• Implement various Image Processing methods in
  FPGA hardware
• Application
• Simulate the techniques using MATLAB compiler on
  the image.

3
Enhancement Techniques

• Contrast Enhancement Method
• Deblurring using Weiner Filter
• Smoothing of an Image.
• Negative to Positive Conversion

4
Contrast Enhancement Method

• An Image is taken and its contrast is
  increased or decreased as per the enhancement
  requirements of the Image.
• The required contrast enhancement is achieved
  applying the Histogram Stretching of the Image.

5
Original Histogram
6
After Contrast Enhancement
7
(No Transcript)
8
Smoothing

• A noisy Image is taken and the noise removal
  is done by applying a smoothing technique.
• The noise removal is achieved by using a mask
  which enables neighborhood pixel processing.

Original Image Smoothened
9
Brighten an Image
Brightened Image developed from original image by
increasing every pixel with a constant
Original Image
Brightened Image
10
Original Image Histogram
Brightened Image Histogram
11
Darken an Image
Darkened Image developed from original image by
decreasing every pixel with a constant
Original Image
Darkened Image
12
Original Image Histogram
Darkened Image Histogram
13
Deblurring using Weiner Filter
Original Image
Deblurred Image
14
Implementation

• The main design will be implemented on Amirix
  board with VirtexIIPro FPGA
• ModelSim will be used to simulate and capture
  waveforms
• Implement the design following the Design for
  Test strategies
• Project will be designed such that it can be a
  reusable IP block

15
