Introduction to VV Techniques and Principles
Software Testing and Verification Lecture 2

• Prepared by
• Stephen M. Thebaut, Ph.D.
• University of Florida

2
Verification and Validation

• at the unit/component-level of system
  development, is what this course is mostly about.
• Adds value...by improving product quality and
  reducing risks.
• Three approaches
• Human-based testing
• Formal correctness proofs
• Machine-based testing

3
Human-Based Testing

• Desk Checking, Walkthroughs, Reviews /
  Inspections
• Applicable to requirements / specifications,
  design, code, proof of correctness arguments,
  test plans / designs / cases, maintenance plans,
  etc.
• Can be extremely effective...

4
Formal Correctness Proofs
pre-condition

• X2
• SP2 4
• while SP2 lt X
• SP2 SP2 2
• end_while
• (? i ? SP2 2i gt X ? 2(i-1) ? X) ? (X
  X)

loop invariant
(? i ? SP2 2i ? 2(i-1) ? X) ? (X X)
post-condition
5
Formal Correctness Proofs (contd)

• Require formal specifications and appropriate
  proof methods.
• Do not eliminate the need for testing.

6
Machine-Based Testing

• Execution of (crafted) test cases
• Actual and expected results (i.e., program
  behaviors) are compared.

7
Definitions of TESTING

• Hetzel Any activity aimed at evaluating an
  attribute or capability of a program or system.
  It is the measurement of software quality.
• Beizer The act of executing tests. Tests are
  designed and then executed to demonstrate the
  correspondence between an element and its
  specification.

8
Definitions of TESTING (contd)

• Myers The process of executing a program with
  the intent of finding errors.
• IEEE The process of exercising or evaluating a
  system or system component by manual or automated
  means to verify that it satisfies specified
  requirements or to identify differences between
  expected and actual results.

9
Definitions of TESTING (contd)

• Testing undertaken to demonstrate that a system
  performs correctly is sometimes referred to as
  validation testing.
• Testing undertaken to expose defects is sometimes
  referred to as defect testing.

10
Evolving Attitudes About Testing

• 1950s
• Machine languages used
• Testing is debugging
• 1960s
• Compilers developed
• Testing is separate from debugging

11
Evolving Attitudes About Testing (contd)

• 1970s
• Software engineering concepts introduced
• Testing begins to evolve as a technical
  discipline
• 1980s
• CASE tools developed
• Testing expands to Verification and Validation
  (VV)

12
Evolving Attitudes About Testing (contd)

• 1990s
• Increased focus on shorter development cycles
• Quality focus increases
• Testing skills and knowledge in greater demand
• Increased acceptance of testing as a discipline

13
Evolving Attitudes About Testing (contd)

• 2000s
• More focus on shorter development cycles
• Increased use of Agile methods Test-First /
  Test-Driven Development, customer involvement in
  testing, and the use of automated testing
  frameworks (e.g., JUnit)
• Better integration of testing / verification /
  reliability ideas
• Growing interest in software safety, protection,
  and security

14
Lets Pause for a Moment

• Imagine that its summertime and that a 3-day
  weekend is just starting Wouldnt it be great
  to just grab a fishin pole and head on out to
  the lake!

15
Fishermans Dilemma

• You have 3 days for fishing and 2 lakes from
  which to choose. Day 1 at lake X nets 8 fish. Day
  2 at lake Y nets 32 fish. Which lake do you
  return to for day 3?
• Does your answer depend on any assumptions?

16
Di Lemma

• In general, the probability of the existence of
  more errors in a section of a program is directly
  related to the number of errors already found in
  that section.

17
Invalid and Unexpected Inputs

• Test cases must be written for INVALID and
  UNEXPECTED, as well as valid and expected, input
  conditions.
• In many systems, MOST of the code is concerned
  with input error checking and handling.

18
Anatomy of a Test Case

• What are the parts of a test case?
• a description of input condition(s)
• a description of expected results
• Where do expected results come from?

19
Who Should Test Your Program?

• Most people are inclined to defend what they
  produce not find fault with it.
• Thus, programmers should in principle avoid
  testing their own programs.
• But what if this is not possible or appropriate?

20
Testing Techniques

• Black-Box Testing based solely on analysis of
  requirements (unit/component specification, user
  documentation, etc.). Also know as functional
  testing.
• White-Box Testing based on analysis of internal
  logic (design, code, etc.). (But expected results
  still come from requirements.) Also known as
  structural testing.

21
Levels or Phases of Testing

• Unit testing of the smallest programmer work
  assignments that can reasonably be planned and
  tracked (e.g., function, procedure, module,
  object class, etc.)
• Component testing a collection of units that
  make up a component (e.g., program, package,
  task, interacting object classes, etc.)

22
Levels or Phases of Testing (contd)

• Product testing a collection of components that
  make up a product (e.g., subsystem, application,
  etc.)
• System testing a collection of products that
  make up a deliverable system

23
Levels or Phases of Testing (contd)

• Testing usually
• begins with functional (black-box) tests,
• is supplemented by structural (white-box) tests,
  and
• progresses from the unit level toward the system
  level with one or more integration steps.

24
Other Types of Testing

• Integration testing which takes place as
  sub-elements are combined (i.e., integrated) to
  form higher-level elements
• Regression re-testing to detect problems caused
  by the adverse effects of program change
• Acceptance formal testing conducted to enable
  the customer to determine whether or not to
  accept the system (acceptance criteria may be
  defined in a contract)

25
Other Types of Testing (contd)

• Alpha actual end-user testing performed within
  the development environment
• Beta end-user testing performed within the user
  environment prior to general release
• System Test Acceptance testing conducted to
  ensure that a system is ready for the
  system-level test phase

26
Other Types of Testing (contd)

• Soak testing a system version over a significant
  period of time to discover latent errors or
  performance problems (due to memory leaks,
  buffer/file overflow, etc.)
• Smoke (build verification) the first test after
  a software build to detect catastrophic failure
  (Term comes from hardware testing)
• Lights out testing conducted without human
  intervention e.g., after normal working hours

27
Testing in Plan-Driven Software Development
28
Plan-Based Testing Process Activities

• Test Planning
• Test Design
• Test Implementation
• Test Execution
• Execution Analysis
• Result Documentation
• Final Reporting

29
Testing in Incremental (E.G., Agile) Software
Development
30
Test-Driven Development (TDD)

• TDD was introduced in support of agile methods
  such as Extreme Programming. However, it can also
  be used in plan-driven development processes.
• Code is developed incrementally, along with a
  test for that increment. You dont move on to the
  next increment until the code that you have
  developed passes its test.
• TDD is taken to be synonymous with Test-FIRST
  Development (TFD) by
• some. Others use the terms differently. See
  below.

31
Test-Driven Development (TDD)
32
TDD Process Activities

• Identify the next required increment of
  functionality.
• Write a test for this functionality and implement
  the test as a program.
• Run the test, along with all other tests that
  have been implemented. (The new test will fail
  since you have not yet implemented the
  functionality.)
• REPEAT Implement the functionality, refactor,
  and re-run the test(s) UNTIL all tests pass.
• Go back to step 1.

33
Rationale for TDD

• When you test first, you capture your intent
  in an automatable and executable form. You focus
  on what you are about to write in a way that
  works to prevent defects rather than create them.
  The tests you write serve as a persistent
  reinforcement of that intent going forward. In
  addition to helping you do the thing right, it
  helps you to do the right thing.
• - Stephen Vance, in Quality Code, 2014

34
TDD versus TFD

• A distinction is sometimes drawn between
  Test-Driven and Test-First Development...
• For some, Test-driven simply means that a
  programs design is influenced by testing, for
  example by refactoring the code to make it easier
  to test. Test-first would further imply that
  test cases are written and run before features
  are implemented.
• Others use the terms synonymously...

35
What Doe Teting Cot?

• About 50 of the total life-cycle effort is spent
  on testing.
• About 50 of the total life-cycle time is spent
  on testing.

36
When Might Testing Guarantee an Error-Free
Program?

1. When branch, condition, and loop coverage are
   achieved
2. When dataflow testing is utilized
3. When path and compound condition coverage are
   achieved
4. When all combinations of all possible input and
   state variable values are covered
5. (None of the above.)

37
Exhaustive Testing is Exhausting

• Situation
• A module has 2 input parameters.
• Word size is 32 bits.
• Testing is completely automated 100 nanoseconds
  are required for each test case.
• Question How long would it take to test this
  module exhaustively, i.e., covering every
  possible combination of input values?

38
Exhaustive Testing is Exhausting (contd)

• Short Answer
• Long Answer

39
Electronic throttle testing

• Feb. 3, 2010 (Bloomberg) Electronic
• throttle systems are under review by
• safety officials as a possible cause of
• sudden acceleration in Toyota Motor
• Corp. vehicles, as alleged in at least seven
  lawsuits.
• Toyota has said it ruled out electronics as a
  cause of sudden acceleration that has resulted in
  recalls of millions of its cars and trucks.
• In terms of electronics of the vehicle, weve
  done exhaustive testing and weve found no issues
  with the electronics, Toyotas Lentz said on a
  conference call with reporters Feb. 1.

40
The ECONOMICS of Testing

• In general, we cant test everything (i.e., test
  exhaustively).
• We need to weigh COST and RISK.
• When is it not cost effective to continue
  testing?
• Conventional wisdom VV should continue until
  there is confidence that the software is fit for
  purpose.
• The level of confidence required depends on at
  least three factors...

41
Factors affecting level of confidence required

• Software function/purpose Safety-critical
  systems, for example, require a much higher level
  of confidence than demonstration-of-concept
  prototypes.
• User expectations Users may have low
  expectations or may tolerate shortcomings when
  the benefits of use are high.
• Market environment Getting a product to market
  early may be more important than finding
  additional defects.

42
Ken Johnstons Minimum Viable Quality (MVQ)
testing model

• Builds on premise that some companies test their
  web-based software services too much before
  releasing them to production
• You need to be comfortable with testing less and
  knowingly shipping buggier software faster than
  ever before. Speed of release is the vital
  competitive advantage in the world of connected
  services and devices.
• Ken Johnston is a former Director of Test
  Excellence at
• Microsoft Corp.

43
(No Transcript)
44
MVQ testing model (contd)

• ...new code is pushed to a subset of users if
  its too buggy, a quick fail back to last known
  good takes the code out of use with minimum
  negative user impact.
• ...you start to get data about how the code is
  functioning in production with real users more
  quickly.
• The key aspect is to balance...the feature set
  and (their) quality... If it is too low, then you
  wont discover and learn the harder to find bugs
  because the code won't be exercised.

45
MVQ testing model (contd)

• See Ken Johnstons Guest Lecture from Spring 14
  on the CEN 4072/6070 E-Learning website (via the
  Course Video Lecture tab)
• CEN6070_Supplement_01-hh.mp4
• The lecture is entitled, The Future of Testing
  is EaaSy, and describes his MVQ model in a more
  general context.
• Note that Exam 1 will include questions based on
  Kens recorded lecture.

46
Costs of Errors Over Life Cycle

• The sooner an error can be found and corrected,
  the lower the cost.
• Costs can increase exponentially with time
  between injection and discovery.

COST
TIME
47
Costs of Errors Over Life Cycle (contd)

• An industry survey showed that it is 75 times
  more expensive to correct errors discovered
  during installation than during analysis.
• One organization reported an average cost of 91
  per defect found during inspections versus
  25,000 per defect found after product delivery.

48
VV for Software Engineers

• VV techniques have evolved considerably and
  require specialized knowledge, disciplined
  creativity, and ingenuity.
• Software engineers should be familiar with all
  VV techniques, and should be able to employ (and
  assess the effectiveness of) those techniques
  appropriate to their responsibilities.

49
Vehicles for Continuous Process Improvement

• Post-Test Analysis reviewing the results of a
  testing activity with the intent to improve its
  effectiveness
• Causal Analysis identifying the causes of errors
  and approaches to eliminate future occurrences
• Benchmarking general practice of recording and
  comparing indices of performance, quality, cost,
  etc., to help identify best practices

50
Introduction to VV Techniques and Principles
Software Testing and Verification Lecture 2

• Prepared by
• Stephen M. Thebaut, Ph.D.
• University of Florida
