Computing Resource Review Board Project Status

1
CERN-RRB-2007-102
Computing Resource Review Board Project
Status CERN 23 October 2007
2
Grid Activity

• Continuing increase in usage of the EGEE and OSG
  grids
• All sites reporting accounting data (CERN,
  Tier-1, -2, -3)
• Increase in past 17 months 5 X number of jobs
  - 3.5 X
  cpu usage

3
Tier-2 Sites September 2007

• Of the 45 federations reporting - 10 account
  for 50 of the cpu usage, 24 for 90
• Total usage equivalent to 48 of the commitment
  of the 53 federations in the WLCG MoU
• Only 16 federations have usage exceeding 70 of
  the commitment

4
September 2007 - CPU UsageCERN, Tier-1s, Tier-2s

• gt 80 of CPU Usage is external to CERN

5
Baseline Services
The Basic Baseline Services from the TDR (2005)

• Storage Element
• Castor, dCache, DPM (with SRM 1.1)
• Storm added in 2007
• SRM 2.2 spec. agreed May 2006 -- being
  deployed now
• Basic transfer tools Gridftp, ..
• File Transfer Service (FTS)
• LCG File Catalog (LFC)
• LCG data mgt tools - lcg-utils
• Posix I/O
• Grid File Access Library (GFAL)
• Synchronised databases T0??T1s
• 3D project

• Information System
• Compute Elements
• Globus/Condor-C
• web services (CREAM)
• gLite Workload Management
• in production at CERN
• VO Management System (VOMS)
• VO Boxes
• Application software installation
• Job Monitoring Tools

... continuing evolution reliability,
performance, functionality, requirements
6
CERN data export 2007

• Data distribution from CERN to Tier-1 sites
• The target rate was achieved last year under test
  conditions
• This year under more realistic experiment
  testing, reaching 70 of the target peak rate

7
CERN data export 2007
8
(No Transcript)
9
(No Transcript)
10
Data Storage Services

• Signalled as a major concern at the last meeting
• Good progress with experiment testing (see
  previous slides)
• dCache (DESY, FNAL)
• New version being deployed now with all
  functionality needed for startup (including SRM
  2.2)
• CASTOR (CERN)
• Performance problems at CERN resolved full
  performance demonstrated with ATLAS
• New version (SRM 2.2-ready) deployed at all
  Castor sites over past few months
• Upgrades with all functionality needed for
  startup being deployed now
• DPM (CERN), STORM (INFN)
• simpler disk-only systems
• Being introduced in production

11
Castor during CMS Export Tests
CMS t0 export pool(330TB across 60 servers)

• Red Data into the pool
• 100MB/s from tape
• occasionally up to 100MB/s data import
• Rest is data written by CSA07 (preparation)
  application.

• Green Data out of the pool
• 280MB/s to tape
• occasionally up to 100MB/s data export
• Rest is data read by CSA07 (preparation)
  application.

CSA 07 starts

• Several concurrent activities with aggregate
  I/O corresponding to nominal CMS speed at
  100 efficiency.
• Up to 900,000 file operations/day (10/s)
• Good stability

Tony Cass cern/it 5 october 07
12
SRM 2.2 Current Schedule

• Schedule has slipped again
• New implementations installed at test sites, but
  test programme stalled due to availability of
  experts
• Subject of workshop at beginning of September
  ? more realistic schedule agreed
• Beta testing
• September ATLAS testing (BNL, FZK, IN2P3, NDGF)
• October LHCb testing (CERN, CNAF, FZK, IN2P3,
  NIKHEF)
• End of October (after CSA07) CMS testing
• November
• dCache 1.8 in production at FZK
• SRM 2.2 production services at Castor sites
• February 2008 SRM 2.2 in production at all key
  sites
• DPM, STORM already available for production use

13
Site Reliability
14
Combined Computing Readiness Challenge - CCRC

• A combined challenge by all Experiments Sites
• validate the readiness of the WLCG computing
  infrastructure
• before start of data taking
• at a scale comparable to that need for data
  taking in 2008
• Should be done well in advance of the start of
  data taking
• to identify flaws, bottlenecks
• and allow time to fix them
• Wide battery of tests simultaneously all
  experiments
• Driven from DAQ with full Tier-0 processing
• Site-site data transfers, storage system to
  storage system
• Required functionality and performance
• Data access patterns similar to 2008 processing
• CPU and data loads simulated as required to reach
  2008 scale
• Coordination team in place
• Two test periods February, May

15
Ramp-up Needed for Startup
16
Summary

• Applications support in good shape
• WLCG service
• Baseline services in production with the
  exception of SRM 2.2
• Continuously increasing capacity and workload
• General site reliability is improving
• Data and storage remain the weak points
• Experiment testing progressing
• involving most sites, approaching full dress
  rehearsals
• Sites experiments working well together to
  tackle the problems
• Major Combined Computing Readiness Challenge next
  year before the machine starts
• Steep ramp-up ahead to delivering the capacity
  needed for 2008 run
