Process Modeling DFD
Chao-Hsien Chu, Ph.D. School of Information
Sciences and Technology The Pennsylvania State
University
IDEF
DFD
2
Enterprise Modeling
Organization Modeling
Network Modeling
Requirement Analysis
Data Modeling
Process Modeling
Normalization
Process Analysis
Data Management
3
Building Blocks of Process
4
What is DFD?

• DFD, stands for data flow diagram, is a graphical
  technique that depicts information flow and the
  transforms that are applied as data moves from
  input to output.
• DFD is also known as data flow graph or a bubble
  chart.
• A DFD can be seen as a method of organizing data
  from its raw state.

5
Characteristics of DFD

• Graphic
• Partitioned
• Hierarchic
• Multidimensional
• Emphasize flow of data
• Viewpoint of data and process

6
Facts About DFDs

• Not all models use control information in their
  DFD.
• Some models describe manual as well as computer
  activities in their DFD.
• DFDs go from left to right, up and down or other
  directions.
• Notations (symbols) in DFDs differ heavily.
• A minimum or a lot of explaining text around the
  symbols in a DFD.

7
Symbols for DFD
Yourdon- Constantine
Game- Sarson
External Interactor
External Entity Source or destination of
data Process Action on data Data Store Storage
of data Data Flow Data Transfer
Process name
8
(No Transcript)
9
Data Flow Diagram Example

• An employment system
• An applicant submits an application form, which
  is reviewed by the personnel section and filed. A
  request for reference letter is sent to the
  references named by the applicant. After one-week
  a summary of reference reports received is
  prepared and a decision is made whether or not to
  interview. Unsuccessful applicants are sent a
  standard rejection letter. An interview is
  scheduled with likely applicants, and references
  are stored with the applicant details. Applicants
  are interviewed and a decision is made on who to
  hire. Unsuccessful interviewees are sent a
  commiseration letter, while the successful
  applicant is sent an employment contract

10
Data Flow Diagram Example
An applicant submits an application form, which
is reviewed by the personnel section and filed. A
request for reference letter is sent to the
references named by the applicant.
Job Applications
Application Form
Receive Review Application
Applicant
Referees
Request for reference
11
Data Flow Diagram Example
After one-week a summary of reference reports
received is prepared and a decision is made
whether or not to interview. Unsuccessful
applicants are sent a standard rejection letter.
Job Applications
Check References Summarise
Referees
reference data
Rejection or Interview Advice
Applicant
12
External Entity

• External entity represents the sources and
  destination of data created by the system.
• External entity represents the immediate
  interface of the system with the external world.
• When an external source of data is also a
  destination for data, a loop or occurrence number
  may be used.
• In case the destination or use of data created by
  the process are not known, the flow simply points
  outside the system. Similarly, data flows may
  originate from nowhere.

13
Process Boxes

• Each processes box in a DFD describes an action
  on data.
• The Identifier. A number indicating the sequence
  of the process.
• The Action. A verb specifying the action on which
  it is performed on the data.
• The Actor or Place. A noun indicating who
  performs the action or where it is performed.

14
Data Flow Arrows

• Data flow arrows link all the process boxes and
  data stores in DFDs.
• Data flows should be labeled, except in case the
  data flows into and out of simple files.
• DFDs show only the flow of data, not materials.
• A DFD depicts information flow without explicit
  representation of procedural logic (e.g.,
  conditions or loops).

15
Data Store Rectangles

• Data stores can be manual files or computer
  files. The type of file is not indicated.
• Only in case the data store is altered the flow
  is not indicated. A simple access is not
  indicated.
• A data store is never the direct recipient of
  unprocessed data from external sources or from
  other data stores nor is data from a data store
  ever directly delivered to an external sources.
  There must be a process step in between.

16
Examples of Data Stores
A data item stored in the data store is read
by a process
Read
Read/ Write
W rite
A data item is created or deleted or updated in
the data store by a process
17
Rules for Constructing DFDs

• Overall
• Know the purpose of the DFD. It determines the
  level of detail to be included in the diagram.
• Organize the DFD so that the main sequence of
  actions reads left to right and top to down.
• Very complex or detailed DFDs should be leveled.
• Processes
• Identify all manual and computer processes.
• Label each process symbol with an active verb and
  the data involved.
• A process is required for all data
  transformations and transfers.
• Do not indicate hardware or where a process is
  manual or computerized.

18
Rules for Constructing DFDs

• Data Flows
• Identify all data flows for each process, except
  simple record retrievals.
• Label data flows on each arrow.
• Data Stores
• Data not indicate file types for data stores.
• Draw data flows into data stores only if the data
  store will be changed.
• External Entities
• Indicate external sources and destination of data
  when known.
• Number each occurrence of repeated external
  entities.
• Do not indicate actors or places as entity
  squares when the process is internal to the
  system.

19
DFD Not Allowed Flows
20
DFD Not Allowed Flows
If part of our system
If not part of our flow ignore
21
Data Flows

• Only one direction of flow between processes

22
Data Flows

• Joins forks allowed only if exactly the same
  data

23
Data Flows

• Cannot go directly back to the process it leaves

24
Data Flows

• Data which moves together should be shown in a
  single data flow

invoice payment
itemised calls
Pay Invoice
Telephone Company
invoice
invoice payment
Pay Invoice
Telephone Company
itemised calls And invoice
25
DFD Rules
Incorrect
Correct
26
DFD Rules
Correct
Incorrect
27
DFD Rules
Incorrect
Correct
28
Naming

• Use process name as a qualifier

Edited Invoice
Edit Invoice
Verify Invoice
Invoice
Verified Invoice
29
Naming

• To avoid clutter external agents can be
  duplicated indicated by a corner line

30
Modeling Procedure

• Determine requirements/purposes.
• Divide activities.
• Model separate activities
• Construct preliminary context diagram.
• Construct preliminary level 0 diagrams.
• Deepen into preliminary level n diagrams

31
Creating a Data Flow Diagram

• The level 0 should depict the software/system as
  a single bubble
• Primary input and output should be carefully
  noted
• Refinement should begin by isolating candidate
  processes, data items and stores to be
  represented at the next level

32
Creating a Data Flow Diagram

• All arrows and bubbles should be labelled with
  meaningful names
• Information flow continuity must be maintained
  from level to level
• One bubble at a time should be refined

33
Producing DFDs

• Pretend you are looking at the system from above
• Record where you go and what happens to you as
  you sit on each data flow in turn, record each
  process as you as the data flow is being
  transformed
• Start with an high-level summary
• Build on this detail
• Do not try and draw the final
• product first time round
• refine and redraw
• Check it

34
Hierarchical DFDs

• DFDs are hierarchically structured
• The top-level is referred to as the context
  diagram (or fundamental system model or the level
  zero design)
• the purpose of the context diagram is to define
  external to the system interfaces and identify
  system boundaries

35
Hierarchical DFDs

• The system of interest is usually contained in a
  single process bubble
• Subsequent DFD levels will show increasing
  system detail
• label clearly all DFD symbols
• Stop when
• each process is a single decision or operation
• each data store has data for a single entity
• when every data flow does not need to be split to
  handle different flows

36
Decomposition Conventions

• Ensure no information is lost
• balancing
• hierarchical numbering
• add data stores at lower levels, if they are
  internal to the higher level process, not at
  context diagram
• external agents are introduced at level-0 never
  at owner levels

37
Level 0 DFD
Origin 1
Destination 1
a
z
System
b
Origin 2
Destination 2
r
c
38
Level 1 DFD
a
1.1
1.3
d
z
b
e
1.5
g
h
r
i
1.2
1.4
f
c
39
Level 2 DFD
f
2.3
2.2
2.1
c
40
Usages of DFDs

• Requirements Analysis. DFDs has been used to
  transform users requirements to processes,
  entities, and data stores.
• Process Modeling.
• Systems Implementation.
• Understanding
• Communication
• Improvement

41
(No Transcript)
42
Thank You? Any Question?
43
(No Transcript)
44
Balancing

• The conservation of input and output flows
  through different levels

A
A
C
D
B
B
E
C
45
Data-flow models

• Show the processing steps as data flows through
  a system
• Intrinsic part of many analysis methods
• Simple and intuitive notation that customers can
  understand
• Show end-to-end processing of data

46
Data-flow diagrams

• may be used to show processing at different
  levels of abstraction from fairly abstract to
  fairly detailed
• May also be used for architectural description
  showing data interchange between the sub-systems
  making up the system
• Not a good way to describe system interfaces

47
Data Flow Diagrams

• They show the overall data flow through a system
  and they do NOT show
• control
• order
• time
• errors
• It is primarily a systems analysis tool used to
  draw the basic procedural components and the data
  that pass among them

48
DFDs

• Physical
• describes operations of existing system, however
  badly the existing system is performing.
• This is essential in the fact finding stage of
  the life cycle
• Logical
• shows the essential processes and data
  interfaces, without reference to design or
  implementation
• Can be Current and NEW
• current physical or logical
• new logical

49
DFD Elements

• Sources and sinks (or external entities or
  terminators)
• a producer or consumer of information that
  resides outside the bounds of the system to be
  modelled
• can be a person, another system, a program,
  hardware,
• usually a singular noun is used to name the
  source or sink

50
DFD Elements

• Processes (or functions or data transformations)
• a transformer of information that resides within
  the bounds of the system to be modelled
• it receives the data and changes it in some way
• if not decomposed usually a verb and noun
  together describe the activity
• if decomposed then a verb is used to name the
  process

51
DFD Elements

• Data flows (directional)
• represent the flow of data item of a collection
  of data items from one node to another
• a node can be a process, a source, or a data
  store
• can be input or output information
• the arrowhead indicates the direction of data
  flow
• all arrows should be labelled (a data flow into
  or out of a data store may be nameless in which
  case it is assumed to carry the entire contents
  of one record in the store)
• usually with a singular noun

52
DFD Elements

• Data stores
• a repository of data that is to be stored for use
  by one or more processes
• usually named using a plural noun (the singular
  describes the individual data items in the store)

53
Naming
Receive Data
Store
Needed data
information

• Too general
• process names should define a specific action
• data stores should store only a single structure
