Lecture 22: More Inheritance, Searching

1
Lecture 22More Inheritance, Searching
2
More on Inheritance

• Lets do one more example
• Well redo Laundry with Interfaces
• This time using Inheritance
• Weve done lots of Laundry
• TShirts, Pants
• We modified the Laundry Sorter program so that it
  could sort all different kinds
• via Laundry Interface, which TShirt and Pants
  implemented

3
Laundry Interface
public interface Laundry // Move the
laundry relative to its current position //
Parameter // xOffset - distance to move
horizontally // yOffset - distance to move
vertically public void move( double xOffset,
double yOffset ) // Move the laundry to
a new position // Parameter // x -
new x-coordinate // y - new y-coordinate
public void moveTo( double x, double y )
// Remove the laundry from the display
public void removeFromCanvas () //
Return true if the point is in the laundry //
Parameters // pt - the point to test for
containment public boolean contains( Location
pt) // Return the Color of the laundry
item. public Color getColor( ) //
Return the Color of the laundry item. public
void setColor( Color newColor )

• Heres the Laundry interface we used before
• We wrote the bodies of all these methods in
  TShirt and Pants
• Bodies for all these methods were very similar
• Could we factor the common parts out somehow?

4
TShirt, Pants move()
// move the pants by specified offsets. public
void move(double xOffset, double yOffset)
hips.move(xOffset,yOffset)
leftLeg.move(xOffset,yOffset)
rightLeg.move(xOffset,yOffset)
hipTrim.move(xOffset,yOffset)
leftLegTrim.move(xOffset,yOffset)
rightLegTrim.move(xOffset,yOffset)
// move the t-shirt by specified offsets.
public void move(double xOffset, double yOffset )
body.move(xOffset,yOffset)
neck.move(xOffset,yOffset)
sleeves.move(xOffset,yOffset)
bodyTrim.move(xOffset,yOffset)
sleeveTrim.move(xOffset,yOffset)
neckTrim.move(xOffset,yOffset)

• Only difference here is the pieces we move
• Different instance variables per object, but
  notice that theyre all Drawable objects in
  objectdraw

5
TShirt, Pants hide()
//hide the pants public void hide()
hips.hide() leftLeg.hide()
rightLeg.hide() hipTrim.hide()
leftLegTrim.hide() rightLegTrim.hide()
// hide the t-shirt from sight. public void
hide() body.hide() neck.hide()
sleeves.hide() bodyTrim.hide()
sleeveTrim.hide() neckTrim.hide()

• This is almost the same as move()
• Simply delegates to its instance variables

6
TShirt, Pants moveTo()
// move the t-shirt to a new upper-left
coordinate position public void moveTo(double
x, double y) move( x - sleeves.getX(), y -
neck.getY())
// move the pants to a specific position.
public void moveTo(double x, double y)
move( x - hips.getX(), y - hips.getY() )

• Only difference here is which shape is used to
  determine the upper left corner of the Laundry

7
TShirt, Pants contains()
// returns true if the t-shirt contains the
point // false otherwise public boolean
contains(Location pt) return
body.contains(pt) sleeves.contains(pt)
neck.contains(pt)
// returns true if the pants contains the
point //false otherwise public boolean
contains(Location pt) return
hips.contains(pt) leftLeg.contains(pt)
rightLeg.contains(pt)

• Much like the others, these are the same but for
  the pieces being compared.
• In this case we just test whether some of the
  shapes contain the point

8
TShirt, Pants getColor(), setColor()
// set color for the shirt public void
setColor(Color newHue) hue newHue
body.setColor(hue) sleeves.setColor(hue)
neck.setColor(hue) // get the sum of the
components // of the shirt's color public
Color getColor() return hue
// set color for the pants public void
setColor(Color newHue) hue newHue
hips.setColor(hue) leftLeg.setColor(hue)
rightLeg.setColor(hue) // get the sum of
the components // of the pant's color public
Color getColor() return hue

• Again, only difference is the pieces of the
  object were setting the color on.
• Note that getColor() is exactly the same for both
  classes.

9
What to do?

• We really want to combine this functionality into
  one common superclass
• Problem
• They have different types of instance variables
• They have different numbers of instance variables
• So what we need is
• Some way to talk to different types variables the
  same way
• Some way to talk to potentially changing numbers
  of such variables
• What do we know of that could solve these
  problems?

10
What to do?

• We know that we can use interfaces to talk to
  different types of objects the same way
• So we could use DrawableInterface to refer to all
  these instance variables
• Theyre all drawable objectdraw objects, so they
  all implement DrawableInterface
• And we know that we can use arrays to hold
  varying numbers of objects
• We can keep track of how many objects are
  actually in the array
• When we need to talk to them, we can use a for
  loop to send each a similar message

11
Putting it all together

• Ill define AbstractLaundry, a generic superclass
  for all of our Laundry items, like this
• Note that its declared abstract
• This just means it cant be instantiated on its
  own
• AbstractLaundry can only be used as a superclass
• You can only extend it and construct subclasses

public abstract class AbstractLaundry implements
Laundry
12
AbstractLaundry
// The shapes that make up the laundry
private DrawableInterface parts //
max number of parts of laundry private int
maxParts // current number of parts of
laundry private int numParts //
Coordinates of upper-left corner of laundry
private double upperX, upperY // Color of
laundry - black initially private Color hue
new Color(0, 0, 0) // basis for all laundry
constructions // protected so can only be
called by extensions protected
AbstractLaundry( double x, double y, int
maxLaundryParts ) upperX x
upperY y maxParts
maxLaundryParts numParts 0
parts new DrawableInterfacemaxParts

• The constructor and instance variables for
  AbstractLaundry are at left
• Note that we have an array for all our components
• Constructor remembers
• Upper left corner
• max number of parts

13
AbstractLaundry addComponent()
// add a component to laundry item protected
void addComponent(DrawableInterface newPart)
if (numParts lt maxParts)
partsnumParts newPart
numParts

• This method is declared protected so only
  subclasses can use it
• It allows the subclass to add shapes to the
  AbstractLaundry whatever shapes they want
• All are stored in the array and managed together
  by AbstractLaundry.

14
Using AbstractLaundry

• Lets try to make a TShirt class now
• Hopefully its easier than before
• We shouldnt have to write nearly as many methods
• Declare like this
• Now what do we do?

public class TShirt extends AbstractLaundry
15
TShirt constructor

• Implementing different kinds of laundry is simple
  now
• we can just add all the pieces in the subclass
  constructor
• Heres a TShirt (without constants shown)
• Hey, this isnt so bad. We no longer have to
  write a bunch of tedious methods theyre managed
  for us! All we do is put in the shapes.

//Create a new shirt at the specified
location. public Tshirt( double x, double y,
DrawingCanvas canvas ) super (x, y,
numTShirtParts) // Construct background
trim addComponent(new FramedRect( x, y
SIZE, SLEEVE_WIDTH, SLEEVE_HEIGHT, canvas ))
addComponent(new FramedRect( x BODY_INSET, y
SIZE, BODY_WIDTH, BODY_HEIGHT, canvas ))
// construct interior (except neck)
addComponent(new FilledRect( x1, ySIZE1,
SLEEVE_WIDTH-1, SLEEVE_HEIGHT-1, canvas ))
addComponent(new FilledRect( xBODY_INSET1,
ySIZE1, BODY_WIDTH-1, BODY_HEIGHT-1, canvas
)) // add neck and neck trim
addComponent(new FilledOval( x NECK_INSET, y,
NECK_WIDTH, NECK_HEIGHT, canvas ))
addComponent(new FramedOval( x NECK_INSET, y,
NECK_WIDTH, NECK_HEIGHT, canvas ))
16
AbstractLaundry Final Words

• You can probably imagine how to implement Pants
• Take a look at how its done, along with the
  AbstractLaundry methods, in the
  InheritanceLaundry example program on the web
  site
• What did we just do?
• We used all the tools for abstraction that weve
  learned about this semester to make a really
  general class
• AbstractLaundry can describe almost any kind of
  movable shape
• Does so using power of interfaces, arrays, and
  inheritance
• Lots to think about here! Be sure its straight
  in your head how this is working

17
AbstractLaundry Final Words

• You can think of abstract superclasses like
  AbstractLaundry as code that you write for
  programmers
• By writing AbstractLaundry, weve made our own
  lives easier by
• reducing the task of creating new graphical
  objects to an almost declarative process
• We just declare shapes we want to combine in
  the constructor by calling their constructors and
  calling addComponent()
• The imperative part, or the how of moving,
  hiding, contains(), etc, is left up to the
  computer!
• This is a pretty powerful technique, in that you
  can express a great variety of objects with not a
  lot of code

18
Searching

• New Topic Searching
• Searching is, simply, looking for something
• When do you search in real life?
• Search for phone numbers?
• Search through your address book?
• What about on a computer?

19
Searching on a Computer

• Some examples
• Finding a particular number in an array
• Finding a scribble that contains the point where
  the mouse is
• Youve done this already!
• Finding your SSN in a database
• Searching for the String Fred in your Word
  documents
• Finding Amino Acid sequences in strands of DNA
• Searching the web

20
Finding scribbles

• Weve done some searching this semester
• We searched recursively through a list of
  scribbles for one that contained a particular
  point
• Remember the contains method?

public boolean contains(Location point) if
(first.contains(point)) return true
if (!rest.isEmpty()) return
rest.contains(point) return false
21
Searching for a Scribble
Does this scribble contain the point?

• Run through the list and test each element to see
  if it contains the point
• Return an element if it does contain the point.

22
Searching for a Scribble
Does this scribble contain the point?

• Run through the list and test each element to see
  if it contains the point
• Return an element if it does contain the point.

23
Searching for a Scribble
Does this scribble contain the point?

• Run through the list and test each element to see
  if it contains the point
• Return an element if it does contain the point.

24
Searching for a Scribble
Does this scribble contain the point?

• Run through the list and test each element to see
  if it contains the point
• Return an element if it does contain the point.

25
Searching for a Scribble
Does this scribble contain the point?

• Run through the list and test each element to see
  if it contains the point
• Return an element if it does contain the point.

26
How much work did that take?

• Well estimate the amount of work that a search
  takes by figuring out
• how many places did we have to look?
• We say that n is the total number in the list or
  data set that were searching
• Well express the amount of work (the number of
  places we need to look) in terms of n

27
How much work did that take?

• In the case of the list of scribbles, we had a
  total of 4 scribbles in our data set, so n 4.
• Calling contains() is what we do to check a
  scribble, or to look in a particular place
• If we assume that a scribble that contains the
  point were looking for has an equal chance of
  being at any position in the list
• Then the search takes n/2 calls to contains() on
  average, when it is successful
• If its unsuccessful, it takes n calls to
  contains()
• So this is, in the worst case, n steps

28
Disadvantage of Lists

• Lists dont allow fast arbitrary access to
  elements
• If we want to get at one, weve got to step
  through the list one element at a time
• You cant jump right to the end, or to any place
  in the middle without traveling over all the
  preceding elements
• This is inefficient, because it takes a lot of
  work to iterate over all the elements
• So were going to switch to arrays, as we can
  access them wherever we want, and fast!
• From here on, Ill talk about searching in arrays

29
Searching an array of ints
5
3
4
9
0
2
1
7
8
6
0
1
2
3
4
5
6
7
8
9

• Suppose Ive got an array of integers and I want
  to find one in it.
• Ill define a method like this
• What should the body look like?

public int search(int array, int num)
30
Searching an array of ints
5
3
4
9
0
2
1
7
8
6
0
1
2
3
4
5
6
7
8
9

• Suppose Ive got an array of integers and I want
  to find a number, call it num, in the array.
• Ill define a method like this

public int search(int array, int num)
for (int index 0 index lt array.length
index) if (arrayindex num)
return index
return -1
31
Searching an array of ints
public int search(int array, int num)
for (int index 0 index lt array.length
index) if (arrayindex num)
return index
return -1

• Suppose that num is 0
• Well search for it, starting at element 0
• is array0 0?

32
Searching an array of ints
public int search(int array, int num)
for (int index 0 index lt array.length
index) if (arrayindex num)
return index
return -1

• Suppose that num is 0
• Well search for it, starting at element 0
• is array1 0?

33
Searching an array of ints
public int search(int array, int num)
for (int index 0 index lt array.length
index) if (arrayindex num)
return index
return -1

• Suppose that num is 0
• Well search for it, starting at element 0
• is array2 0?

34
Searching an array of ints
public int search(int array, int num)
for (int index 0 index lt array.length
index) if (arrayindex num)
return index
return -1

• Suppose that num is 0
• Well search for it, starting at element 0
• is array3 0?

35
Searching an array of ints
public int search(int array, int num)
for (int index 0 index lt array.length
index) if (arrayindex num)
return index
return -1

• Suppose that num is 0
• Well search for it, starting at element 0
• is array4 0?
• YES! Well return 4, to tell whoever called us
  where the number we were looking for was found.

36
Searching an array of ints
public int search(int array, int num)
for (int index 0 index lt array.length
index) if (arrayindex num)
return index
return -1

• If we went all the way to the end, wed stop when
  we fell off the end
• Returning -1 indicates that we didnt find
  anything in the array

37
Recursive search
public int recSearch(int array, int num, int
start) if (start gt array.length)
return -1 else if (arraystart num)
return start else return
recSearch(array, num, start 1)

• We can write the search that we used before
  recursively, instead of using a for loop
• Makes the various cases clearer
• Can you see how this does exactly the same thing?

38
Searching an ordered array

• Suppose our array looks like the one above, in
  that all of its elements are in order
• And suppose we search for 11
• What happens?

39
Searching an ordered array

• Suppose our array looks like the one above, in
  that all of its elements are in order
• And suppose we search for 11
• What happens?
• The search goes all the way to the end, but finds
  nothing. It returns -1.

40
Searching an ordered array

• What do we know when we reach 12, though?
• Well, we searched for 11
• 12 is greater than 11
• And the elements of the array are in order
• We know during the search that if the current
  number is greater than what were looking for,
  that the search will fail
• we wont find num, well just return -1

41
Searching an ordered array

• We can thus rewrite search like this, if we know
  were searching an ordered array
• This new condition bails out and returns -1 when
  weve passed where num should be

public int recSearch(int array, int num, int
start) if (start gt array.length)
return -1 else if (arraystart num)
return start else if (arraystart gt
num) return -1 // num will not appear
in rest of array since it is sorted. else
return recSearch(array, num, start 1)

42
How much work?

• If we assume that the numbers well search for
  are evenly distributed around the median of the
  array, then
• It should take, on average, n/2 steps of work for
  both successful and unsuccessful searches
• In the worst case, though, we search for
  something thats at or past the end of the array
• Still worst case n steps of work

43
Linear Search

• These searches are called linear searches
• This is because the number of steps it takes to
  solve them is a linear function of the number of
  elements in the list youre searching
• That is
• number of steps a n b
• for some constants a and b
• n number of elements in the list
• In our case, were pretty much talking about when
  the amount of work for n elements is either n or
  n/2 steps.
• Can we do less work than this?

44
Can we do better than this?

• How do you search for names in a phonebook?
• You know theyre in order
• Where do you start?
• Do you start at the beginning, then look at every
  page until youve either found or passed the name
  youre looking for?
• Probably not
• You probably start somewhere in the middle, then
  skip around

45
Guessing numbers

• Well play a guessing game
• Ill think of a number between 1 and 100
• You try to guess it, and Ill say either
• Too High or
• Too Low
• Well see how many guesses it takes
• Essentially youre searching for a number between
  1 and 100
• Depending on how good you are at this, it could
  take a while.
• Dont worry, well stop before you end up missing
  the rest of lecture.

46
Guessing numbers

• What did you do?
• If youre good at this, you probably tried to
  eliminate as many numbers as you could each turn
• To do this, youd start in the middle
• What number am I thinking of?
• 50?
• too low.
• 75?
• too high.
• 62?
• too low.
• 68?
• Yes.

47
Process of elimination

• If you know the array is sorted and you start in
  the middle, then you know you can eliminate half
  of the items on the first check
• If Im looking for 4 above, and I discover that
  10 is in the middle of the array
• I can eliminate the whole right-hand side,
  because I know 4 cant possible be there
• Then can act like Im just searching the left
  half of the array
• Do the same thing to the left half! Start in its
  middle

48
Process of elimination
0
3
4
7
10
12
89
105
106
200
0
1
2
3
4
5
6
7
8
9

• Now we operate on the left half of the array
• Check the middle of it
• Remember, were trying to see if the array
  contains 4
• Is 3 less than or greater to 4?
• Less than!
• We can now eliminate half of whats remaining,
  just like before
• This time eliminate the left-hand side of the
  remaining array from consideration

49
Process of elimination
0
3
4
7
10
12
89
105
106
200
0
1
2
3
4
5
6
7
8
9

• Now weve reduced our search to two squares, and
  this is only the 3rd step!
• Now what?
• Were looking for 4, and we found 4 at index 2.
• We return 2, to let the caller know where we
  found 4.
• Done!

50
Binary search

• The process we just went through is called binary
  search
• Its called a divide conquer algorithm because
  it divides the problem in half at each step
• First step is whole array, next is 1/2 of it,
  next is 1/4 of that, next is 1/8 of that, etc.b
• This makes time to solution MUCH faster!
• Heres Binary Search in Java

public int binarySearch(int array, int num, int
low, int high) if (low gt high)
return -1 else int mid (low
high) / 2 if (arraymid num)
// num is same as middle number return
mid else if (num lt arraymid)
// num is smaller than middle number
return binarySearch(array, num, low, mid - 1)
else // num is larger than middle
number return binarySearch(array, num,
mid 1, high)
51
Wrapping Binary Search

• Binary search, as written, is inconvenient
• We have to provide a low and a high value when we
  call it
• but usually these are going to be 0 and
  array.length - 1
• Can solve this by providing a helpful search()
  method with two parameters that just calls the
  binarySearch() method with low and high set
  appropriately

public int binarySearch(int array, int num, int
low, int high)
public int search(int array, int num)
return binarySearch(array, num, 0, array.length -
1)
52
How much work is it?

• Each step, we cut the portion we need to search
  in half.
• How many times can divide number in half before
  you get to 1?
• If you start with n, you divide to get n/2 then
  n/4, n/8, ... and eventually get 1.
• Let's suppose that n2k, then divide to 2k-1,
  2k-2, 2k-3, ..., 20 1 divide k times by 2.
• In general, you can divide n by 2 at most k times
  to get to 1, where k log2(n).
• So this is, in the worst case, log2(n) steps of
  work

53
Compare to linear search

• Its not so significant at first, but as the
  number of elements gets larger, youre doing much
  less work
• For 1 million elements, linear search could have
  to check all 1,000,000
• Binary Search only has to check 20!
• Caveat remember that binary search only works if
  your numbers are sorted!
• Well learn how to be sure they are put that way
  next time.
