Molecular phylogeny of the Arcellinida

• Enrique LARA, Thierry J. HEGER, Flemming EKELUND,
  Mariusz LAMENTOWICZ, Edward A. D. MITCHELL

2
Outline

• Introduction
• Why study the molecular phylogeny of testate
  amoebae?
• Characteristics of the Arcellinida and open
  questions
• Methods
• Results
• Conclusions and perspectives

3
Why work on the phylogeny of testate amoebae in
RECIPE?

• Initial plan to study the diversity of protists
  using molecular methods
• Focus on testate amoebae, the dominant group of
  heterotrophic protists in peatlands
• Problem almost no molecular data (DNA sequences)
  on testate amoebae
• gt Need for baseline data sequencing dominant
  species and establishing the phylogeny based on
  molecular data

4
General characteristics of testate amoebae

• Size 10-300 µm
• Produce a shell (proteinaceous material or
  agglutinated mineral particles)
• Feed on bacteria, fungi, micro-algae, rotifers,
  etc.
• Often narrow ecological tolerance gt useful for
  ecology and paleoecology

5
The Arcellinida
Testate amoebae are polyphyletic
The Euglyphida
Filose pseudopodia
Lobose pseudopodia
(1) Adl, S.M. (2005), J. of Eukaryotic Microbiol.
6
Family Hyalospheniidae (sensu Schultze, 1877)

• Includes 6 genera among them Nebela (sensu lato),
  Hyalosphenia and Heleopera
• Are especially abundant and diverse in peatlands

7
Current challenges in the phylogeny and taxonomy
of testate amoebae

• Current classification is based on morphology
• The phylogenetic value of the morphological
  characters is uncertain.
• Phenotypic plasticity demonstrated for some
  species (1)
• Many taxa have uncertain value
• (1) Wanner M., Meisterfeld, R. (1994), Europ.
  J. Protistol. 30 (191-195)

8
Ecological and palaeoecological implications of
taxonomic uncertainties

• Ecological studies require sound taxonomy to
  maximize the indicator value of the amoebae (2)
• gt Taxonomic uncertainties undermine the use of
  testate amoebae in ecology and paleoecology
• gt Need for a molecular phylogeny
• (2) Bobrov, A. A., Charman, D. J., Warner, B.
  G. (2002) Biology Bulletin29 605617

9
Ecological and palaeoecological implications of
taxonomic uncertainties

• Similar morphology
• similar ecological
  tolerance?

Nebela tincta var. major
Nebela flabellulum
10
Methods

• Isolation of 10-20 living amoebae from each
  species under inverted microscope
• DNA extraction
• PCR with newly designed Arcellinida and
  Hyalospheniidae specific primers
• Sequencing of SSU rRNA gene

11
11 studied species from 4 genera

• Genus Nebela
• N. carinata
• (2 geographical origins)
• N. penardiana
• N. tubulosa
• N. tincta tincta
• N. tincta major
• (2 geographical origins)
• N. flabellulum
• N. lageniformis

• Genus Hyalosphenia
• H. elegans
• H. papilio
• Genus Apodera
• A. vas
• Genus Heleopera
• H. rosea

12
Results

• All species are clearly genetically distinct
• Paraphyly of genera Nebela and Hyalosphenia

ML tree, 100 bootstraps, ln(L)-2646, 918 sites
13
A hard to sequence insertion yields precious
phylogenetic information

• An insertion of about 450 bp is present in the
  SSU rRNA gene of the Hyalospheniidae.
• By aligning the sequences with the insertion, it
  is possible to resolve the phylogenetic position
  of closely related taxa.

ML tree, 500 bootstraps, ln(L)-2621, 1406 sites
14
Evaluation of the identification criteria used
for Hyalospheniidae taxa
CONCLUSIONS

• All morphospecies have so far proven to be
  genetically distinct.
• Even subspecies are distinct!
• gt what is the true diversity of testate amoebae?
• No evidence for geographical genetic variation
• at least in the SSU rRNA gene

15
Perspectives

• Ecology and paleoecology
• Further work on the phylogeny with other genera
  and speciesgt resolve remaining taxonomic
  uncertainties
• Biogeography and evolution
• Variable genetic markers are needed to infer the
  dispersal potential of testate amoebaegt
  cosmopolitanism versus endemism of protists?

16
Acknowledgements

• Colleagues from Copenhagen University
• Colleagues from EPFL (Switzerland) Pierre Rossi,
  Christof Holliger and Andy Siegenthaler
• Funding EU project RECIPE, University of
  Copenhagen
• Many thanks also to the people who brought mosses
  samples from all over the world (from Machu Pichu
  to Northern Sweden and Marion Island!!!) and made
  this work possible

17
Position of the Hyalosphaeniidae inside the
Arcellinida
ML tree, 100 bootstraps, ln(L)-2744, 542 sites
18
CCA plotting the different Sphagnum species
against environmental data in peat bogs
19
Ecological preferences of some Hyalospheniidae
in Sphagnum peatlands
The Hyalosphaeniidae as bioindicators
Axis 2
Nebela militaris
Heleopera rosea
Nebela tincta tincta
Nebela flabellulum
Axis 1
Nebela bohemica
Hyalosphenia papilio
Hyalosphenia elegans
Nebela lageniformis
Lamentowicz Mitchell Microbial Ecology, 2005
Nebela carinata
CCA analysis
20
Palaeoecology

• Palaeoecological diagram and reconstruction of
  water table depth pH (Mitchell et al. 2001
  Holocene)

21
Organisation of the SSU rRNA gene
v4
Saccharomyces
Nebela
Insertion of 450 bp

• An insertion of about 450 bp is present in the
  SSU rRNA gene of the Hyalospheniidae.
• This insertion is located at position 1200 in
  Saccharomyces pombe SSU rRNA sequence (X58056)
• Also present at least in Bullinularia indica,
  probably in other species as well
• Highly variable, therefore informative among
  closely related species...
• Is extremely difficult to sequence, probably
  because of a complex secondary structure

22
Phylogenetic relationships within Hyalosphaeniidae

• - Large species
• Rounded test base
• Nebela carinata, N. penardiana

Core Nebelas
-Large species -Pointed test base Nebela
tubulosa, N. marginata
Small, rounded species Nebela tincta tincta, N.
tincta major, N. flabellulum
Mixotrophic, proteinaceous test Hyalosphenia
papilio
Symbiotic Chlorella-like algae
Phagotrophic, proteinaceous test Hyalosphenia
elegans
Elongated neck, more or less constricted Nebela
lageniformis, Apodera vas
Outgroup Heleopera rosea
23
CONCLUSIONSEvaluation of the identification
criteria used for Hyalospheniidae taxa

• Shell shape most reliable for classification into
  major groups
• but shell composition is NOT sufficient for
  defining a genus (here genus Hyalosphenia)
• The presence of a carenated ridge is a criterion
  which could separate very closely related species

• ... if this is not a case of phenotypic
  plasticity (ex N. marginata/N. tubulosa)
• Parallel example the spines of the cercozoan
  testate amoebae from the genus Euglypha.
