Advanced Algorithms

1
Advanced Algorithms
(Feodor F. Dragan) Department of Computer Science
Kent State University
2
Textbook Thomas Cormen, Charles Leisterson,
Ronald Rivest, and Cliff Stein,
Introduction to Algorithms,
McGraw Hill Publishing Company
and MIT Press, 2001 (2nd
Edition).

• Grading
• Homework 40
• Midterm Exam 30
• Final Exam 30

All the course slides will be available
at http//www.cs.kent.edu/dragan/CS6-76101-AdvAlg
.html
3

• Course Outline
• We will cover the following topics (the
  topics and order listed are tentative and
• subject to change some topics may only be
  quickly surveyed to add breadth,
• while others will be covered in reasonable
  depth).
• Dynamic Programming
• Optimal greedy algorithms
• Amortized analysis
• Parallel and circuit algorithms
• Network flow algorithms
• Randomized algorithms
• Number theoretic cryptographic algorithms
• String matching algorithms
• Computational geometry algorithms
• Algorithms for NP-hard and NP-complete problems
• Approximation algorithms
• Online algorithms
• Linear programming algorithms

4
What is a computer program exactly?
Input
Output
Some mysterious processing
Programs Data Structures Algorithms
5
CHAPTER 15Dynamic Programming

• We begin discussion of an important algorithm
  design technique, called dynamic programming (or
  DP for short).
• It is not a particular algorithm, it is a
  metatechnique.
• Programming tableau method, not writing a
  code.
• The technique is among the most powerful for
  designing algorithms for optimization problems.
  This is true for two reasons.
• Dynamic programming solutions are based on a few
  common elements.
• Dynamic programming problems are typical
  optimization problems (find the minimum or
  maximum cost solution, subject to various
  constraints.
• The technique is related to divideandconquer,
  in the sense that it breaks problems down into
  smaller problems that it solves recursively.
  However, because of the somewhat different nature
  of dynamic programming problems, standard
  divideandconquer solutions are not usually
  efficient.

6
The basic elements that characterize a dynamic
programming algorithm are

• Substructure Decompose your problem into
  smaller (and hopefully simpler) subproblems.
  Express the solution of the original problem in
  terms of solutions for smaller problems. (Unlike
  divideandconquer problems, it is not usually
  sufficient to consider one decomposition, but
  many different ones.)
• Tablestructure Store the answers to the
  subproblems in a table. This is done because
  (typically) subproblem solutions are reused many
  times, and we do not want to repeatedly solve the
  same problem.
• Bottomup computation Combine solutions on
  smaller subproblems to solve larger subproblems,
  and eventually to arrive at a solution to the
  complete problem. (Our text also discusses a
  topdown alternative, called memoization.)

7

• The most important question in designing a DP
  solution to a problem is how to set up the
  subproblem structure. This is called the
  formulation of the problem.
• Dynamic programming is not applicable to all
  optimization problems.

There are two important elements that a problem
must have in order for DP to be applicable.

• Optimal substructure Optimal solution to the
  problem contains within it optimal solutions to
  subproblems. This is sometimes called the
  principle of optimality. It states that for the
  global problem to be solved optimally, each
  subproblem should be solved optimally.
• Polynomially many subproblems An important
  aspect to the efficiency of DP is that the total
  number of distinct subproblems to be solved
  should be at most a polynomial number.

8
Strings

• One important area of algorithm design is the
  study of algorithms for character strings.
• There are a number of important problems here.
  Among the most important has to do with
  efficiently searching for a substring or
  generally a pattern in large piece of text. (This
  is what text editors do when you perform a
  search.)
• In many instances you do not want to find a
  piece of text exactly, but rather something that
  is similar. This arises for example in genetics
  research. Genetic codes are stored as long DNA
  molecules. The DNA strands consists of a string
  of molecules of four basic types C, G, T, A.
  Exact matches rarely occur in biology because of
  small changes in DNA replication. For this
  reason, it is of interest to compute similarities
  between strings that do not match exactly.
• One common method of measuring the degree of
  similarity between two strings is to compute
  their longest common subsequence.

9
Longest Common Subsequence
10
Dynamic Programming Approach
11
Dynamic Programming Approach (cont.)
12
Implementing the Rule
13
Extracting the Actual Sequence
14
Time and Space Bounds and an Example

• The running time of the algorithm LCS is clearly
  O(mn) since there are two nested loops with m and
  n iterations, respectively. The running time of
  the algorithm getLCS is O(mn). Both algorithms
  use O(mn) space.

Y 0 1 2 3 4 n
Y 0 1 2 3 4 n
B D C B
B D C B
XBACDB YBDCB LCSBCB
0 1 2 3 4 5
BACDB
0 1 2 3 4 5
BACDB
X
m
m
LCS Length Table
with back pointers included
Longest common subsequence example.
READ Ch. 15.4 in CLRS.
15
Chain Matrix Multiplication

• This problem involves the question of
  determining the optimal sequence for performing a
  series of operations.
• This general class of problem is important in
  compiler design for code optimization and in
  databases for query optimization.
• We will study the problem in a very restricted
  instance, where the dynamic programming issues
  are easiest to see.
• Suppose that we wish to multiply a series of
  matrices
• Matrix multiplication is an associative but not
  a commutative operation. This means that we are
  free to parenthesize the above multiplication
  however we like, but we are not free to rearrange
  the order of the matrices.
• Also recall that when two (non-square) matrices
  are being multiplied, there are restrictions on
  the dimensions. A matrix has p rows and
  q columns. You can multiply a matrix
  A times a matrix B, and the result will
  be a matrix C. The number of
  columns of A must equal the number of rows of B.
• In particular, for and
• There are total entries in C and each

  takes O(q) time to compute, thus the
  total time
  (e.g. number of multiplications) to
  multiply these two matrices is

A B C
q
p
p
r
r
q
16
Problem Formulation
17
Naive Algorithm
18
Dynamic Programming Approach
19
Dynamic Programming Formulation
20
Implementing the Rule
21
Extracting Optimum Sequence
22
Chain Matrix Multiplication Example
23
Recursive Implementation
24
Recursive Implementation (cont.)
25
Memoization
26
Memoization (cont.)
27
Polygons and Triangulations
Polygon
28
Triangulations (cont.)
29
Minimum-Weight Convex Polygon Triangulation
30
Correspondence to Binary Trees
31
Correspondence to Binary Trees (cont.)
32
Dynamic Programming Solution
33
Dynamic Programming Solution (cont.)

• This subdivides the polygon into the
  subpolygons and
  whose minimum weight are already known to
  us as ti,k and tk1,j.
• In addition we should consider the weight of
  newly added triangle
• Thus, we have the following recursive rule

• Note that this has exactly the same structure
  as the recursive definition used in the
  chain-matrix multiplication algorithms.
• The same algorithm can be applied
  with only minor changes.

READ Ch. 15.3 in CLRS and again all slides about
triangulations (this part was taken from the
first edition of the book (Ch. 16.4), you will
not find this in the second edition).
Homework 1 See on the class web-page.
