CS 728 Advanced Database Systems Chapter 15

1
CS 728 Advanced Database Systems Chapter 15

• Database Design Theory Normalization Algorithms

2
Chapter Outline

• 0. Designing a Set of Relations
• 1. Properties of Relational Decompositions
• 2. Algorithms for Relational Database Schema
• 3. Multivalued Dependencies and 4th Normal Form
• 4. Join Dependencies and 5th Normal Form
• 5. Inclusion Dependencies
• 6. Other Dependencies and Normal Forms

3
Designing a Set of Relations (1)

• The 1st approach is (Chapter 14) a Top-Down
  Design (Relational Design by Analysis)
• 1. Designing a conceptual schema in a high-level
  data model, such as the EER model
• 2. Mapping the conceptual schema into a set of
  relations using mapping procedures.
• 3. Each of the relations is analyzed based on the
  functional dependencies and assigned primary
  keys, by applying the normalization procedure to
  remove partial and transitive dependencies if any
  remain.

4
Designing a Set of Relations (2)

• The 2nd approach is (Chapter 15) a Bottom-Up
  Design (Relational Design by Synthesis -
  ???????)
• 1. First constructs a minimal set of FDs
• Assumes that all possible functional dependencies
  are known.
• 2. a normalization algorithm is applied to
  construct a target set of 3NF or BCNF relations.
• start by one large relation schema, called the
  universal relation, which includes all the
  database attributes.
• then repeatedly perform decomposition until it is
  no longer feasible or no longer desirable, based
  on the functional and other dependencies
  specified by the database designer.

5
Designing a Set of Relations (3)

• Additional criteria may be needed to ensure the
  set of relations in a relational database are
  satisfactory.
• Two desirable properties of decompositions
• The dependency preservation property and
• The lossless (or nonadditive) join property

6
Designing a Set of Relations (4)

• When we decompose a relation schema R with a set
  of functional dependencies F into R1, R2, , Rn
  we want
• Dependency preservation
• Otherwise, checking updates for violation of
  functional dependencies may require computing
  joins, which is expensive.
• Nonadditive (Lossless) join decomposition
• Otherwise decomposition would result in
  information loss.
• No redundancy
• The relations Ri preferably should be in either
  Boyce-Codd Normal Form or 3NF.

7
Designing a Set of Relations (5)

• Example R (A, B, C) F A?B, B?C
• Can be decomposed in two different ways
• R1 (A, B), R2 (B, C)
• Lossless-join decomposition
• R1 ? R2 B and B ? BC
• Dependency preserving
• R1 (A, B), R2 (A, C)
• Lossless-join decomposition
• R1 ? R2 A and A ? AB
• Not dependency preserving
• cannot check B ? C without computing R1 R2

8
Properties of Relational Decompositions (1)

• Relation Decomposition and Insufficiency of
  Normal Forms
• Universal Relation Schema
• a relation schema R A1, A2, , An that
  includes all the attributes of the database.
• Universal relation assumption
• every attribute name is unique.
• Decomposition
• The process of decomposing the universal relation
  schema R into a set of relation schemas
• D R1, R2, , Rm that will become the
  relational database schema by using the
  functional dependencies.

9
Properties of Relational Decompositions (2)

• Relation Decomposition and Insufficiency of
  Normal Forms
• Attribute preservation condition
• Each attribute in R will appear in at least one
  relation schema Ri in the decomposition so that
  no attributes are lost.
• Another goal of decomposition is to have each
  individual relation Ri in the decomposition D be
  in BCNF or 3NF.
• Additional properties of decomposition are
  needed to prevent from generating spurious
  (???????) tuples.

10
Properties of Relational Decompositions (3)

• Example of spurious tuples.
• Decomposition of R (A, B)
• R1 (A) R2 (B)

A
B
A
B
? ? ?
1 2 1
? ?
1 2
?B(r)
?A(r)
r
A
B
?A(r) ?B(r)
? ? ? ?
1 2 1 2
11
Properties of Relational Decompositions (4)

• Dependency Preservation Property of a
  Decomposition
• It would be useful if each functional dependency
  X ? Y specified in F either
• appeared directly in one of the relation schemas
  in the decomposition D or
• could be inferred from the dependencies that
  appear in some Ri .
• Informally, this is the
• dependency preservation condition.

12
Properties of Relational Decompositions (5)

• Dependency Preservation Property of a
  Decomposition
• We want to preserve the dependencies because each
  dependency in F represents a constraint on the
  database.
• If one of the dependencies is not represented in
  some individual relation of the decomposition, we
  cannot enforce this constraint by dealing with an
  individual relation instead,
• we have to join two or more of the relations in
  the decomposition and then check that the
  functional dependency holds in the result of the
  join operation.
• This is clearly an inefficient and impractical
  procedure.

13
Properties of Relational Decompositions (6)

• Dependency Preservation Property of a
  Decomposition
• It is not necessary that the exact dependencies
  specified in F appear themselves in individual
  relations of the decomposition D.
• It is sufficient that the union of the
  dependencies that hold on the individual
  relations in D be equivalent to F.
• We now define these concepts more formally.

14
Properties of Relational Decompositions (7)

• Dependency Preservation Property of a
  Decomposition
• Definition
• Given a set of dependencies F on R, the
  projection of F on Ri, denoted by ?Ri(F) where Ri
  is a subset of R, is the set of dependencies X ?
  Y in F such that the attributes in X ? Y are all
  contained in Ri.
• Hence, the projection of F on each relation
  schema Ri in the decomposition D is the set of
  functional dependencies in F, the closure of F,
  such that all their left- and right-hand-side
  attributes are in Ri.

15
Properties of Relational Decompositions (8)

• Dependency Preservation Property of a
  Decomposition
• A decomposition D R1, R2, ..., Rm of R is
  dependency-preserving with respect to F if the
  union of the projections of F on each Ri in D is
  equivalent to F that is,
• ((?R1(F)) ? ? (?Rm(F))) F
• Claim 1 It is always possible to find a
  dependency-preserving decomposition D with
  respect to F such that each relation Ri in D is
  in 3NF.

16
Properties of Relational Decompositions (9)

• Consider a decomposition of R (R, F) into

• R1 (R1, F1) and R2 (R2, F2)
• How to compute the projections F1 and F2?
• Fi is the projection of FDs in F over Ri
• Example RABC and F A?B, B?C, C?A
• Let R1AB and R2BC
• Not enough to let F1 A?B and F2 B?C
• Consider FDs in F B?A and C?B
• So F1 A?B, B?A and F2 B?C, C?B
• Now F and F1 ? F2 are equivalent

17
Properties of Relational Decompositions (10)

• Lossless (Non-additive) Join Property of a
  Decomposition
• This property ensures that no spurious tuples are
  generated when a NATURAL JOIN operation is
  applied to the relations in the decomposition.
• Lossless join property a decomposition D R1,
  R2, ..., Rm of R has the lossless (nonadditive)
  join property with respect to the set of
  dependencies F on R if, for every relation state
  r of R that satisfies F, the following holds,
  where is the natural join of all the relations
  in D
• (?R1(r), ..., ?Rm(r)) r
• r ? r1 r2 rm and
• r1 r2 rm ? r

18
Properties of Relational Decompositions (11)

• Consider
• What happens if we decompose on
• (Id, Name, Address) and
• (C, Description, Grade)?
• Spurious tuples will be generated

19
Properties of Relational Decompositions (12)

• Lossy Decomposition
• Problem Name is not a key

SSN Name Address SSN Name Name
Address 1111 Joe 1 Pine 1111 Joe
Joe 1 Pine 2222 Alice 2 Oak
2222 Alice Alice 2 Oak 3333 Alice
3 Pine 3333 Alice Alice 3 Pine
?
r1
r2
r
20
Properties of Relational Decompositions (13)

• Lossless (Non-additive) Join Property of a
  Decomposition
• Note The word loss in lossless refers to loss of
  information, not to loss of tuples. In fact, for
  loss of information a better term is addition
  of spurious information.
• Algorithm 15.3 Testing for Lossless Join
  Property
• Input A universal relation R, a decomposition D
  R1, R2, ..., Rm of R, and a set F of
  functional dependencies.

21
Properties of Relational Decompositions (14)

• 1. Create an initial matrix S with one row i for
  each relation Ri in D, and one column j for each
  attribute Aj in R.
• 2. Set S(i, j) bij for all matrix entries.
• // each bij is a symbol associated with indices
  (i, j)
• 3. For each row i representing relation schema Ri
• For each column j representing attribute Aj
• if (relation Ri includes attribute Aj) then
  S(i, j) aj
• // each aj is a symbol associated with
  index j

22
Properties of Relational Decompositions (15)

• 4. Repeat until a complete loop execution results
  in no changes to S
•       for each functional dependency X ?Y in F
• for all rows in S which have the same symbols
  in the
• columns corresponding to attributes
  in X
• make the symbols in each column that
  correspond
• to an attribute in Y be the same
  in all these rows as
• follows
• If any of the rows has an a symbol
  for the
• column, set the other rows to that
  same a
• symbol in the column.

23
Properties of Relational Decompositions (16)

• If no a symbol exists for the attribute in
  any of the rows, choose one of the b symbols
  that appear in one of the rows for the
  attribute and set the other rows to that same
  b symbol in the column
• 5. If a row is made up entirely of a symbols,
  then the decomposition has the lossless join
  property otherwise it does not.

24
Properties of Relational Decompositions (17)

• Lossless (non-additive) join test for n-ary
  decompositions.
• (a) Case 1 Decomposition of EMP_PROJ into
  EMP_PROJ1 and EMP_LOCS fails test.
• (b) A decomposition of EMP_PROJ that has the
  lossless join property.
• (c) Case 2 Decomposition of EMP_PROJ into EMP,
  PROJECT, and WORKS_ON satisfies test.

25
Properties of Relational Decompositions (18)
26
Properties of Relational Decompositions (19)
27
Properties of Relational Decompositions (20)

• Binary Decomposition
• decomposition of a relation R into two relations.

• Non-additive (Lossless) Join Test for Binary
  decompositions (NJB)
• A decomposition D R1, R2 of R has the
  lossless join property with respect to a set of
  functional dependencies F on R if and only if
  either
• The FD ((R1 n R2) ? (R1- R2)) is in F, or
• The FD ((R1 n R2) ? (R2 - R1)) is in F.

28
Properties of Relational Decompositions (21)

• Intuition for Test for Losslessness
• Suppose R1 ? R2 ? R2. Then a row of r1 can
  combine with exactly one row of r2 in the
  natural join (since in r2 a particular set of
  values for the shared attributes defines a unique
  row), i.e.,
• R1 ? R2 is a superkey of R2

R1?R2 R1?R2 . a
a ... a b
. b c .
c r1 r2
29
Properties of Relational Decompositions (22)

• Schema (R, F) where
• R SSN, Name, Address, Hobby
• F SSN ? Name, Address
• can be decomposed into
• R1 SSN, Name, Address
• F1 SSN ? Name, Address
• and
• R2 SSN, Hobby
• F2
• Since R1 ? R2 SSN and
• SSN ? R1- R2
• SSN ? Name, Address is in F, then
• the decomposition is lossless

30
Properties of Relational Decompositions (23)

• Example WRT the FD set
• Id ? Name, Address
• C ? Description
• Id, C ? Grade
• Is
• (Id, Name, Address) and
• (Id, C, Description, Grade)
• a lossless decomposition?

31
Properties of Relational Decompositions (24)

• A relation scheme
• Sname, Sadd, City, Zip, Item, Price
• The FD set
• Sname ? Sadd, City
• Sadd, City ? Zip
• Sname, Item ? Price
• Consider the decomposition
• Sname, Sadd, City, Zip and
• Sname, Item, Price
• Is it lossless?
• Is it dependency preserving?
• What if we replaced the first FD by
• Sname, Sadd ? City?

32
Properties of Relational Decompositions (25)

• The scheme
• Student, Teacher, Subject
• The FD set
• Teacher ? Subject
• Student, Subject ? Teacher
• The decomposition
• Student, Teacher and
• Teacher, Subject
• Is it lossless?
• Is it dependency preserving?

33
Properties of Relational Decompositions (26)

• Claim 2 (Preservation of non-additivity in
  successive decompositions)
• If a decomposition D R1, R2, ..., Rm of R has
  the lossless (non-additive) join property with
  respect to a set of functional dependencies F on
  R, and
• if a decomposition Di Q1, Q2, ..., Qk of Ri
  has the lossless (non-additive) join property
  with respect to the projection of F on Ri,
• then the decomposition D2 R1, R2, ..., Ri-1,
  Q1, Q2, ..., Qk, Ri1, ..., Rm of R has the
  lossless (non-additive) join property with
  respect to F.

34
Algorithms for RDB Schema Design (1)

• Algorithm 15.4 Relational Synthesis into 3NF
  with Dependency Preservation
• Input A universal relation R and a set of
  functional dependencies F on the attributes of R.
• Find a minimal cover G for F
• For each left-hand-side X of a functional
  dependency that appears in G, create a relation
  schema in D with attributes X ? A1 ? A2 ...
  ? Ak, where X ? A1, X ? A2, ..., X ? Ak are
  the only dependencies in G with X as
  left-hand-side (X is the key of this relation)
• Place any remaining attributes (that have not
  been placed in any relation) in a single relation
  schema to ensure the attribute preservation
  property.

35
Algorithms for RDB Schema Design (2)

• A set of FDs F is minimal if it satisfies the
  following conditions
• Every FD in F is of the form X?A, where A is a
  single attribute,
• We cannot remove any dependency from F and have a
  set of dependencies that is equivalent to F.
• For no X?A in F is F-X?A equivalent to F.
• We cannot replace any dependency X?A in F with a
  dependency Y?A, where Y is a proper-subset of X
  (Y subset-of X) and still have a set of
  dependencies that is equivalent to F.
• For no X?A in F and Y?X is F-X?A?Y?A
  equivalent to F.

36
Algorithms for RDB Schema Design (3)

• Examples
• A?C, A?B is a minimal cover for AB?C, A?B
• What about AB?C, B ? AB, D?BC?
• Every set of FDs has an equivalent minimal set
• There can be several equivalent minimal sets
• There is no simple algorithm for computing a
  minimal set of FDs that is equivalent to a set F
  of FDs
• To synthesize a set of relations, we assume that
  we start with a set of dependencies that is a
  minimal set.

37
Algorithms for RDB Schema Design (4)

• Two sets of FDs F and G are equivalent if
• Every FD in F can be inferred from G, and
• Every FD in G can be inferred from F
• Hence, F and G are equivalent if F G
• Definition (Covers)
• F covers G if every FD in G can be inferred from
  F
• (i.e., if G is subset-of F)
• F and G are equivalent if F covers G and G covers
  F
• There is an algorithm for checking equivalence of
  sets of FDs

38
Algorithms for RDB Schema Design (5)

• Algorithm 15.2  Finding a minimal cover G for F
• 1. Set G F.
• 2. Replace each FD X?A1, A2, ..., Ak in G by
  the n functional dependencies X?A1, X?A2 , ,
  X?Ak.
• 3. For each FD X?A in G
• For each attribute B that is an element of X
• if ((G -X?A) ? (X-B)?A) is equivalent to G,

• then replace X?A with (X-B)?A in G.
• 4. For each remaining FD X?A in G,
• if (G-X?A) is equivalent to G, then remove X?A
  from G.

39
Algorithms for RDB Schema Design (6)

• Example
• A?B, ABCD?E, EF?GH, ACDF?EG
• Make RHS a single attribute
• A?B, ABCD?E, EF?G, EF?H, ACDF?E, ACDF?G
• Minimize LHS ACD?E instead of ABCD?E
• Eliminate redundant FDs
• Can ACDF?G be removed?
• Can ACDF?E be removed?
• Final answer A?B, ACD?E, EF?G, EF?H

40
Algorithms for RDB Schema Design (7)

• Minimal Cover Exercise
• Compute the minimal cover of the following set of
  functional dependencies
• ABC ? DE, BD ? DE, E ? CF, EG ? F
• ABC ? D
• ABC ? E //
• BD ? D // reflexive
• BD ? E
• E ? C
• E ? F
• EG ? F // augmentation
• The minimal cover is
• ABC ? D, BD ? E, E ? C, E ? F

41
Algorithms for RDB Schema Design (8)

• Example of Algorithm 15.4 (3NF Decomposition)
• Consider
• the relation R CSJDPQV
• FDs F C?CSJDPQV, SD?P, JP?C,J?S
• Find minimal cover
• C?J, C?D, C?Q, C?V, SD?P, JP?C, J?S
• New relations
• R1CJDQV, R2JPC,
• R3JS, R4SDP

42
Algorithms for RDB Schema Design (9)

• Algorithm 15.5 Relational Decomposition into
  BCNF with Lossless (non-additive) join property
• Input A universal relation R and a set of
  functional dependencies F on the attributes of R.
• Set D R
• While there is a relation schema Q in D that is
  not in BCNF
• do
• choose a relation schema Q in D that is not in
  BCNF
•           find a FD X?Y in Q that violates
  BCNF
•         replace Q in D by two relation
  schemas (Q-Y) (X?Y)

43
Algorithms for RDB Schema Design (10)

• Example of Algorithm 15.5 (BCNF Decomposition)
• R (branch-name, branch-city, assets,
  customer-name, loan-number, amount)
• F branch-name ? branch-city, assets
• loan-number ? branch-name, amount
• Key loan-number, customer-name
• Decomposition
• R1 (branch-name, branch-city, assets)
• R2 (branch-name, customer-name, loan-number,
  amount)
• R3 (loan-number, branch-name, amount)
• R4 (loan-number, customer-name)
• Final decomposition R1, R3, R4

44
Algorithms for RDB Schema Design (11)

• Example of Algorithm 15.5 (BCNF Decomposition)
• R (A, B, C)F A ? B, B ? CKey A
• R is not in BCNF
• Decomposition R1 (A, B), R2 (B, C)
• R1 and R2 in BCNF
• Lossless-join decomposition
• Dependency preserving

45
Algorithms for RDB Schema Design (12)

• Algorithm 15.6 Relational Synthesis into 3NF with
  Dependency Preservation and Lossless
  (Non-Additive) Join Property
• Input A universal relation R and a set of
  functional dependencies F on the attributes of R.
• Find a minimal cover G for F (Use Algorithm
  15.2).
• For each left-hand-side X of a functional
  dependency that appears in G, create a relation
  schema in D with attributes X?A1?A2...?
  Ak, where X?A1, X?A2, ..., X?Ak are the only
  dependencies in G with X as left-hand-side (X is
  the key of this relation).
• If none of the relation schemas in D contains a
  key of R, then create one more relation schema in
  D that contains attributes that form a key of R.
• Eliminate redundant relations from the resulting
  set of relations. A relation T is considered
  redundant if T is a projection of another
  relation S.

46
Algorithms for RDB Schema Design (13)

• Algorithm 15.2a Finding a Key K for R Given a set
  F of Functional Dependencies
• Input A universal relation R and a set of
  functional dependencies F on the attributes of R.
• Set K R
• For each attribute A in K
•            compute (K - A) with respect to F
• If (K - A) contains all the attributes in R,
• then set K K - A

47
Algorithms for RDB Schema Design (14)

• Discussion of Normalization Algorithms
• Problems
• The database designer must first specify all the
  relevant functional dependencies among the
  database attributes.
• These algorithms are not deterministic in
  general.
• It is not always possible to find a decomposition
  into relation schemas that preserves dependencies
  and allows each relation schema in the
  decomposition to be in BCNF (instead of 3NF).

48
Algorithms for RDB Schema Design (15)
Table 15.1 Summary of some of the algorithms
discussed
49
Multivalued Dependencies and 4th Normal Form (1)

• Beyond BCNF
• CustService (State, SalesPerson, Delivery)

Is this BCNF?
50
Multivalued Dependencies and 4th Normal Form (2)

• Everything is in the key -- must be BCNF
• Still problems with duplication
• Multivalued Dependencies

51
Multivalued Dependencies and 4th Normal Form (3)

• At least three attributes (A, B, C)
• A B and A C
• B and C are independent of each other (they
  really shouldnt be in the same table)

52
Multivalued Dependency and 4NF

• Multivalued dependency (MVD)
• Consequence of first normal form (1NF)

53
Multivalued Dependency and 4NF

• Relations containing nontrivial MVDs
• All-key relations
• Fourth normal form (4NF)
• Violated when a relation has undesirable
  multivalued dependencies

54
Multivalued Dependencies and 4th Normal Form (4)

• Definition
• A multivalued dependency (MVD) X gtgt Y specified
  on relation schema R, where X and Y are both
  subsets of R, specifies the following constraint
  on any relation state r of R
• If two tuples t1 and t2 exist in r such that
  t1X t2X, then two tuples t3 and t4 should
  also exist in r with the following properties,
  where we use Z to denote (R - (X ? Y))
• t3X t4X t1X t2X
• t3Y t1Y and t4Y t2Y.
• t3Z t2Z and t4Z t1Z.
• An MVD X gtgt Y in R is called a trivial MVD if
• (a) Y is a subset of X, or
• (b) X ? Y R

55
Multivalued Dependencies and 4th Normal Form (5)

• 4th Normal Form
• BCNF with no multivalued dependencies
• Create separate tables for each separate
  functional dependency

56
Multivalued Dependencies and 4th Normal Form (6)

• (a) The EMP relation with two MVDs ENAME gtgt
  PNAME and ENAME gtgt DNAME. (b) Decomposing the
  EMP relation into two 4NF relations EMP_PROJECTS
  and EMP_DEPENDENTS.

57
Multivalued Dependencies and 4th Normal Form (7)
SalesForce (State, SalesPerson) Delivery
(State, Delivery)
58
Multivalued Dependencies and 4th Normal Form (8)

• Inference Rules for Functional and Multivalued
  Dependencies
• IR1 (reflexive rule for FDs)
• If X ? Y, then X gt Y.
• IR2 (augmentation rule for FDs)
• X gt Y ?? XZ gt YZ.
• IR3 (transitive rule for FDs)
• X gt Y, Y gtZ ?? X gt Z.
• IR4 (complementation rule for MVDs)
• X gtgt Y ?? X gtgt (R (X ? Y)).
• IR5 (augmentation rule for MVDs)
• If X gtgt Y and W ? Z then WX gtgt YZ.
• IR6 (transitive rule for MVDs)
• X gtgt Y, Y gtgt Z ?? X gtgt (Z - Y).
• IR7 (replication rule for FD to MVD)
• X gt Y ?? X gtgt Y.
• IR8 (coalescence (???????) rule for FDs and
  MVDs)
• If X gtgt Y and there exists W with the properties
  that (a) W ? Y is empty, (b) W gt Z, and (c) Y ?
  Z, then X gt Z.

59
Multivalued Dependencies and 4th Normal Form (9)

• A relation schema R is in 4NF with respect to a
  set of dependencies F (that includes functional
  dependencies and multivalued dependencies), at
  least one of the following hold
• X gtgt Y is trivial (i.e., Y ? X or X ? Y R)
• X is a superkey for schema R
• If a relation is in 4NF it is in BCNF

60
Multivalued Dependencies and 4NF (10)

• Decomposing a relation state of EMP that is not
  in 4NF. (a) EMP relation with additional tuples.
  (b) Two corresponding 4NF relations EMP_PROJECTS
  and EMP_DEPENDENTS.

61
Multivalued Dependencies and 4NF (11)

• Algorithm 15.7 Relational decomposition into 4NF
  relations with non-additive join property
• Input A universal relation R and a set of
  functional and multivalued dependencies F.
• Set D R
• While there is a relation schema Q in D that is
  not in 4NF do
• choose a relation schema Q in D that is not in
  4NF
• find a nontrivial MVD X gtgt Y in Q that
  violates 4NF
• replace Q in D by two relation schemas (Q - Y)
  and (X ? Y)

62
Multivalued Dependencies and 4NF (12)

• R (A, B, C, G, H, I)
• F A gtgt B, B gtgt HI, CG gtgt H
• R is not in 4NF since A gtgt B and A is not a
  superkey for R
• Decomposition
• R1 (A, B) (R1 is in 4NF)
• R2 (A, C, G, H, I) (R2 is not in 4NF)
• R3 (C, G, H) (R3 is in 4NF)
• R4 (A, C, G, I) (R4 is not in 4NF)
• Since A gtgt B and B gtgt HI, A gtgt HI, A gtgt I
• R5 (A, I) (R5 is in 4NF)
• R6 (A, C, G) (R6 is in 4NF)
