Alternative B

1
Alternative B

• Steven Halcomb
• Binh Nguyen
• Charles Balzarini
• Mat Mollenkopf
• Ryan Redick
• Mila Umanskaya
• Mitch Mork

2
10 Path Layout
3
20 Path Layout
4
Centerline Profile
5
Path Cross Section
6
Path Detail
7
Path Vision
8
Path Material

• Material
• 1600 yds3 concrete
• 315 yds3 D1
• 945 yds3 Type IIA gravel (Non frost susceptible
  soil)
• Cut Fill
• Min Cut 15 yds3
• Max Cut 2050 yds3
• Min Fill 25 yds3
• Max Fill 450 yds3

9
Bridge Concepts
10
Challenges

• Refine retaining wall and footing design
• Calculate minimum path thickness
• Utility access beneath the bridge (maintenance)
• Can the utilities be accessed without moving the
  bridge?
• 7-8 vertical clearance
• Approximately 9 wide.
• Lighting
• Landscaping
• Connect utilities to the building

11
Questions?
