Reliability and Availability

1

• Reliability and Availability
• Analysis

2
Learning Objectives

• Define availability and reliability in the
  context of computer and communications systems.
• Provide a quantitative approach to understand and
  compute availability and reliability metrics.

3
A Motivating Availability Example

• Consider a simple example of an online brokerage
  which is in the process of designing its site and
  selecting the components that will be used in its
  design.
• The main consideration here is the site
  availability, which has to be at least 99.99
  (four 9s) according to management decision.

4

• The site is used by users to get quotes on stocks
  and mutual funds, manage portfolios, conduct risk
  analysis, and to place orders to trade stocks and
  mutual funds.
• Consider in the security trading business, Web
  service availability is a key QoS metric.
• If customers are denied access to the trading
  services, they may incur financial losses and the
  trading company may be liable for these loses.

5
Trading site architecture
Internet
Load Balancer
Web Server
Database Server
R router
6

• The trading site architecture is composed of a
  load balancer that distributes the incoming
  requests to one of nWS Web servers.
• The servers are all implemented using the same
  type of hardware and software.
• At the back-end, nDS database server are used to
  store all the persistent data needed to support
  customer trading transactions.
• The database is fully replicated at each of the
  nDS database servers to increase availability and
  distribute the load.

7

• The company is considering two types of boxes
  highly reliable, expensive, high-end servers with
  hot-swappable CPU boards and disks, as well as
  less expensive, less reliable, low-end servers.
• Management wants to answer the following
  questions
• What is the least expensive configuration that
  meets the 99.99 availability requirement?
• All low-end servers, all high-end servers, or a
  mix of low-end and high-end servers?

8
Reasons of System Failure

• To categorize different types of failure three
  dimensions are considered
• Duration, Effect, and Scope

9

• Duration of the failures
• Permanent failures
• A system stops working and there is no
  possibility of repairing or replacing it. (e.g.,
  unmanned space ship)
• Recoverable failures
• The system is placed back in operation after a
  fault is recovered. (e.g., Web site
  inaccessibility due to its connection to the
  internet being down)
• Transient failures
• Characterized by having a very short duration and
  may not require major recovery actions. (e.g.,
  problems that can be solved by resetting network
  routers or rebooting servers.)

10

• Effect of the failures
• Functional failures
• The system does not operate according to its
  functional specifications. (e.g., an online
  bookstore failing to display information about a
  book even though it is in the catalog)
• Performance failures
• Even though the system may be executing the
  requested functions correctly, they are not
  executed in a timely fashion. (e.g., A search
  engine that presents very accurate results to
  requests for search but takes more than a minute
  on average to process each request)

11

• Scope of the failure
• Partial failures
• Some of the services provided by the computer
  system becomes unavailable, while others can
  still be used. (e.g., The services that allow
  customers to bid in an online auction site may
  become unavailable due to the failure of the
  servers that process these types of requests,
  while customers may still be able to see existing
  bids)
• Total failures
• Characterized by a complete disruption of all
  services offered by the computer system. (e.g.,
  power outages could cause a Web site to go down
  completely)

12
Reliability and Availability Basics

• Reliability
• The reliability of a system or component is the
  probability that it is functioning properly and
  constantly over a fixed period of time.
• Availability
• The fraction of time that a component (or system)
  is operational.

13

• Consider the notion that a component (or system)
  alternates through periods in which it is
  operational the up periods and periods in
  which it is down the down periods.
• Mean Time To Failure (MTTF)
• The average time it takes for a system to fail.

14

• Mean Time To Recover (MTTR)
• The average time it takes for the system to
  recover.
• Mean Time Between Failures (MTBF)
• The average time between failures can be written
  as,
• MTBF MTTF MTTR

15
Relationship between MTTF, MTTR, and MTBF
MTTF
MTTF
MTTR
up
down
up
MTBF
n-th failure
(n1)-th failure
16
Summary
Computer systems tend to be labeled by the number
of 9s in the availability. For example a
five-9s system has an availability of 99.999.
Computer system classification according to their
availability is shown below
17
Expression for the availability of a system

• The following state transition diagram can be
  used to show that the system can be in one of two
  states up and down
• The system fails, i.e., goes from up to down,
  with a rate ?
• It gets repaired, i.e., goes from down to up,
  with a rate ?

18

• Writing these rates in term of the MTTF and MTTR
  we get,
• Using the flow-in-flow-out principle, we can
  write,
• Here pup and pdown are the probability that the
  system is up and down, respectively.
• Thus,

19

• The availability A of a system is simply pup
• We also know that pup pdown 1
• Therefore,

20

• Therefore,
• And, the system un-availability is simply

21

• In most systems of interest, it takes
  significantly longer time for the system to fail
  than to be repaired
• MTTFgtgtMTTR
• Thus, the unavailability can be approximated as
• U ? MTTR/MTTF

22

• Consider a Web site composed of two Web servers,
  one application server, and one database server.
  Suppose that historical data shows that the
  application server machine is rebooted every
  twenty days on average. Assuming that the system
  administrator takes 10 minutes to reboot the
  machine, what is the application server
  availability?
• Here the MTTF is 20 days or (20?24?6028,800
  minutes) and
• The MTTR is 10 minutes
• Therefore the availability is given by,
• AMTTF/(MTTFMTTR)28,800/(28,80010)99.965

23

• If the system administrator were able to cut the
  reboot time to 20
• The availability would be A 28,800/(28,800
  10?0.2) 99.972
• To achieve the same availability (99.972) with
  the original MTTR of 10 minutes, the MTTF would
  have to be increased to 35,704 minutes, I.e., a
  24 increase
• This indicates the importance of reducing the
  time to recovery to improve the availability of a
  system

24
The Reliability of Systems of Components

• Q. What is the reliability of the system as a
  function of the reliability of the components
  used to build the system?
• Well consider two cases,
• Components connected in series
• Components connected in parallel
• Example of a serial system is when a Web site has
  a Web server connected to an application server
  which is then connected to a database server,
  each on its own dedicated machine,

25

• Inside each box in the diagram are the
  reliabilities r1,rn of the n components.
• To compute the reliability, Rs, of the series
  system we need,
• To know the probability that the entire system is
  operational when needed.
• All n components must be operational for the
  system to be operational.

26

• Assuming that the n components fail in an
  independent way (failure of one component does
  not affect any other component).
• Using the probability theory that says that the
  probability of an event expressed as the
  intersection of independent events (all n
  components are operational) is the product of the
  probabilities of the independent events. Thus,
• ImplicationsSince each reliability value, ri, is
  a probability and therefore, ri?1
• Therefore as more components are added in series
  the system reliability will decrease.

27

• A Web site has a Web server (WS), an application
  server (AS), and a database server (DS) in
  series. Let rWS, rAS, and rDB be the
  reliabilities of these components and assume
  their values are rWS0.9, rAS0.95, and rDB0.99.
• Management wants to replace the database server
  with a highly reliable and expensive model that
  is advertised as having a 0.999 reliability. Is
  it a wise decision?
• The reliability of the site with the current
  database server is
• Rsite rWS ? rAS ? rDB 0.9 ? 0.95 ? 0.99
  0.84645
• The reliability of the site with the new database
  server is
• RnewDBsite rWS ? rAS ? rnewDB 0.9 ? 0.95 ?
  0.999 0.85415

28

• If instead of the database server, the web server
  (the most unreliable component of the system) is
  replaced by a new one with r 0.95. The
  reliability of the site now will be,
• RnewWSsite rWSWS ? rAS ? rDB 0.95 ? 0.95 ?
  0.99 0.89348
• Thus it is evident that replacing the most
  unreliable component has a more pronounced effect
  in terms of improving overall system reliability.

29
Reliability block diagram for a parallel system

• Using components in parallel is one of the most
  common way to use redundancy.
• The reliability of the parallel system, Rp, is
  the probability that it is in operation when
  needed
• This probability is equal to one minus the
  probability that the system is not in operation.

30

• For this to happen, all n components must be
  down.
• The probability that component i is down is
  simply (1-ri).
• So, assuming independence of failures between
  components, we get,
• The special case when all components have the
  same reliability r. We get,

31

• Thus as we increase the number of components,
  system reliability grows very fast.
• As shown

32

• A search engine site wants to achieve a site
  reliability of 99.999 using a cluster of very
  cheap and unreliable Web servers. A cluster is a
  parallel combination of a number of servers. Each
  has a reliability of 85. How many servers should
  be used in the cluster?
• From the eq. we know that,
• 0.99999 1 (1-8.85)n 1 0.15 n
• So,
• 0.15n 1 0.99999 0.00001
• If we apply logarithms to both sides of the above
  equation and we take into consideration that n
  must be an integer, we get that
• n ?ln 0.00001/ ln 0.15? ?6.069? 7
• Thus, seven unreliable Web servers can provide a
  high-level of reliability when used in parallel,
