Rendezvous

1
Rendezvous a DIY VPN(profiting from mobile
access to the enterprise)
Rendezvous Server
2
AppGate

• AppGate Network Security specialises in providing
  extremely secure network solutions, such as
  application VPNs, personal firewalls and
  application access control systems.
• AppGate Network Security ties together all the
  pieces of security technology in one easy-to-use
  system. AppGate solutions work in both fixed and
  wireless network environments, with a broad range
  of client systems. It scales from small
  organisations up to enterprise-level customers,
  supporting thousands of users.
•
• That is why AppGate Network Security has
  customers among the largest and most prestigious
  corporations in the world.

3
Zühlke Engineering

• Genuine Breadth and Depth in IT Technology
  Consultancy
• Bespoke Systems Developments
• Coaching and Mentoring
• Project Resources
• Consulting
• Training
• Iterative Development Methods
• System Architecture Design Realisation
• Enterprise Application Integration (EAI)
• Web Services
• Mobile Computing
• Information Security
• Technical Reviews
• Software Audits
• Evaluation of Methods, Tools and Components

Services
Disciplines
4
ObjectValue Ltd.

• One-man wireless and IT consultancy
• Worked as a partner of AppGate to develop and
  test the Rendezvous concept
• Company still exists, but staff working full-time
  for Zühlke
• http//www.objectvalue.com/

5
The Problem

• Hypothesis equipping knowledge workers with
  mobile access to enterprise applications leads to
  better productivity
• E-mail
• Scheduling
• Contacts
• Intranet Web servers
• ERP
• CRM
• Custom applications etc.
• People need proof a user trial lasting at least
  a few weeks provides the clearest evidence of
  Return on Investment (ROI)
• Technology trailblazers depend on expensive
  infrastructure upgrades to connect their mobile
  devices to the company network
• How can users be empowered to try the technology
  without having to justify the business case in
  advance and wait for the IT dept.?

6
Rendezvous concept

• Using an AppGate, companies can already give
  their mobile workers secure, always-on, remote
  access to services such as corporate email, CRM
  systems, etc.
• The Rendezvous concept takes a standard AppGate
  server and re-uses it in a new way to give
  smaller companies/teams the same benefits, but
  without the need to invest in an AppGate server
  themselves.
• The rendezvous software has been developed by one
  of AppGates partners, ObjectValue Ltd., and
  supports the same range of platforms as the
  AppGate client (Windows, MacOS, Linux, etc.)

7
AppGate Rendezvous Server

• Hosted outside a companys firewall, the
  Rendezvous Server gives individual users working
  outside the office secure access to chosen
  services within the office.

Rendezvous Server
appGATE server
Data
Application servers
Protected Network
GPRS
Remote Worker
Secured connection
Secured connection
8
AppGate Rendezvous Server

• Typical office user connected to office services
  (such as email server)

Data
xxxx
Application servers
Protected Network
9
AppGate Rendezvous Server

• User opens connection to AppGate using the normal
  client (via proxy if required), selected ports
  are forwarded and the Rendezvous client is
  started automatically

appGATE server
Data
xxxx
Application servers
Protected Network
10
AppGate Rendezvous Server

• Ports in the range 2xxxx on the client are
  forwarded to the same port number on the AppGate
  itself. This is the port number on which the
  Rendezvous Server listens for connections from
  its office client.

Rendezvous Server
appGATE server
Data
xxxx
Application servers
Protected Network
11
AppGate Rendezvous Server

• Rendezvous Server and client together act as a
  virtual firewall router, relaying connection
  requests from the mobile device to office
  services (such as the email server)

Rendezvous Server
appGATE server
Data
xxxx
Application servers
Protected Network
12
AppGate Rendezvous Server

• Leaving the office client running, the user later
  connects to AppGate from a remote location with
  the same ID, and so establishes the second of a
  pair of connections
• Ports in the range xxxx on the client are
  forwarded to 1xxxx on the AppGate itself so for
  sending mail via SMTP, local port 25 on the
  mobile device would be forwarded to port 10025 on
  the AppGate

appGATE server
GPRS
Remote Worker
13
AppGate Rendezvous Server

• The Rendezvous Server associates the
  corresponding 1xxxx and 2xxxx ports internally
  based on the user ID, establishing a fully
  secured end-to-end tunnel from the mobile user
  via the PC in the office to the application
  server.

Rendezvous Server
appGATE server
Data
xxxx
xxxx
Application servers
1xxxx
2xxxx
Protected Network
GPRS
Remote Worker
14
Demonstration
If you cannot see the movie above, make sure you
have the free QuickTime player installed (see
www.apple.com) and then click here.
15
Working at the application layer

• AppGate client opens just one secure tunnel
  through the firewall to the server on port 22
  (normally)
• The connections for each service are multiplexed
  through this tunnel by default 5 connections
  are allowed
• Each connection simply lets the client see a
  remote port on the AppGate server The AppGate
  server can not look back into the network
• The AppGate client can link only the 5 default
  connections to the AppGate server, e.g. 20025 to
  20025, 20110 to 20110 etc.
• Using the Rendezvous client, users choose which
  of the default connections they need

Application tunneling
pop3
smtp
Port 22
intranet
16
Accessing intranet Web servers

• To resolve intranet URLs, DNS lookups must be
  made within the office network, so a proxy server
  is used.
• The mobile browser is configured to use
  localhost8080 as its proxy. Rendezvous relays
  HTTP requests to the real proxy server in the
  office.

Rendezvous Server
8080
Proxy server
appGATE server
8080
80
Web servers
18080
28080
Protected Network
GPRS
Remote Worker
17
Sharing a Rendezvous Client

• Where it is not desirable to leave the office PC
  switched on, the Rendezvous Client and Appgate
  Client can be set up to run on an office server
  (e.g. NT, Linux)
• Multiple mobile users from the same office can
  connect to the same Rendezvous Server and hence
  Rendezvous client using the same AppGate user ID
• All will access the same set of services, but
  because they will sign in with different network
  user IDs they will not receive identical
  information or gain unauthorised access to data
• Users sharing a single instance of the Rendezvous
  client can connect consecutively or at the same
  time without interfering with each other

18
Security wherever your business needs it

• AppGate Network Security AB
• www.appgate.com
• jamie_at_appgate.com
