DESIGN PATTERNS

1
DESIGN PATTERNS Redesigning Applications And
Design Patterns in Object Oriented Designs.
Presented by Anita PatankarKeith Wright
2

• Design Patterns
• What are Design Patterns?
• Overview of Design Patterns
• Design Problems and Use of Patterns
• Causes of Redesign and Use of Patterns
• Factory Method Pattern
• Illustration

3
Design Patterns
For
Design déjà vu
What is a Design Pattern? Each pattern
describes a problem which occurs over and over
again in our environment, and then describes the
core of the solution to that problem, in such a
way that you can use this solution a million
times over, without ever doing it the same way
twice says Christopher Alexander.
4

• Overview
• These are the design solutions in the form of
  classes, objects and interfaces.
• Patterns are descriptions of communicating
  objects and classes that are customized to solve
  a particular object oriented design problem.
• It is a way to record good experience in object
  oriented design
• Using patterns also helps in documentation and
  maintenance as it gives explicit classification
  of classes and objects
• It can also be said that design pattern of one
  person can be a building block of the design of
  other person.

5
Classification of Patterns
Scope
Purpose
Structural
Behavioural
Static
Dynamic
Creational
(Applies to object)
(Classes Object Composition)
(Ways in which classes/ objects interact)
(Applies to class)
(Object creation)
6
Classification of Design Patterns
Purpose Purpose Purpose
Creational Structural Behavioral
Scope Class Factory Method Adapter (class) Interpreter Template Method
Scope Object Abstract Factory Builder Prototype Singleton Adapter(Object) Bridge Composite Decorator Façade Flyweight Proxy Chain of Responsibility Command Iterator Mediator Memento Observer State Strategy Visitor
7
Design Problems and Use of Patterns
1. Finding Appropriate Objects - Decomposing
a system into OBJECTS due to factors such as
encapsulation, granularity, dependency,
flexibility, performance, evolution, reusability
etc.. - Design methodologies help create
classes that often lack the abstraction. Design
Patterns help to identify less obvious
abstractions and objects to capture them.Eg
State Pattern Represents each state of entity
as object. 2. Determining Object
Granularity - Objects vary in size and number,
representing everything form hardware to the
entire application. - How do we decide what
should be an object. Design patterns help to
identify objects and their structure.Eg Façade
Pattern shows how to represent complete
subsystems as objects.
8
3. Specifying Object Interfaces- Signature
is the method declaration with its name,
parameters and return data type.- Interface or
type defines a set of signatures defined by an
objects operations and object is known through
these interfaces Design Patterns help to define
interfaces, to identify their key elements and
how the data is sent across an interface. Eg
Momento Pattern Encapsulates internal state of
object so that object can be restored to that
state. 4. Specifying Object
Implementations- The class defines the
objects internal data, data representations and
the operations the object can perform- Object is
an instance of a class so the storage allocates
memory for internal data. Design Patterns like
Abstract Factory, Builder etc facilitate
Abstraction, object Creation and Interface
Association.
9
5. Class Vs Interface Inheritance- An
objects class defines its implementation,
internal state and operations in contrast to its
type which only refers to its interfaces (set of
requests it can respond to). - Class inheritance
defines an object's implementation in terms of
another object's implementation while interface
inheritance describes when an object can be used
in place of another. Many design Patterns depend
on this distinction. Eg COMPOSITE pattern
Defines a common type (interface) with class
implementation.Whereas COMMAND, OBSERVER,
STATE, STRATEGY patterns Implemented using
abstract classes with pure interfaces 6.
Programming to an interface not an
implementation- Clients know only the
interfaces and the abstract classes but are
unaware of the other classes.Design Patterns
ensure that system is in terms of interfaces and
not implementation. Eg Abstract Factory helps
to instantiate by abstraction of object creation
10

• 7. Putting reuse mechanisms to work-
  WHITE-BOX reuse refers to visibility when
  implementing one class in terms of another using
  inheritance where the internals of the parent
  class are visible.
• BLACK-BOX reuse refers to composition
  (assembling objects with well defined interfaces)
  to get added functionality while the hiding the
  internal details of the objects.- Object
  composition is dynamic and has fewer
  implementation dependencies.- Composition keeps
  classes encapsulated and task oriented, focusing
  on interfaces and relationships and thus reduce
  the hierarchy levels.
• 8. Delegation Makes Composition as reusable
  as inheritance by involving 2 objects- Receiving
  object and delegate object.

RectangleWidth, Height Area()
WindowArea()
Eg of Design PatternStrategy
Return Rectangle-gtarea()
11
Causes of Redesign and Use of Patterns

• 1. Creating an object by specifying a class
  explicitly Commits you to an implementation
  instead of an interface.
• Solution its better to create objects directly.
• - Design patterns Abstract Factory, Factory
  Method, Prototype.
• 2. Dependence on specific operations
  Specifying an operation commits you to only one
  way of satisfying a request.
• Solution Avoid hardcoded requests and make it
  easy to change the way request gets satisfied at
  compile time and run time.
• - Design patterns Chain Of Responsibility,
  Command.
• Dependence on hardware and software platform
  Operating systems and API's differ between
  platforms and software depending on a specific
  system needs to consider this aspect while
  redesigning.
• Solution Design the system to limit its platform
  dependencies.
• - Design patterns Abstract Factory, Bridge.
• 4. Dependence on object representations or
  implementations Clients knowing how objects are
  represented will probably need modification if
  the object changes. Solution Hide information
  from clients.
• - Design patterns Abstract Factory, Bridge,
  Memento, Proxy.

12
Causes of Redesign and Use of Patterns (cont.)
5. Algorithmic dependencies Algorithms change
and objects that are made dependent on the
algorithms will require change. Solutions
Isolate the algorithms that are likely to
change.- Design patterns Builder, Iterator,
Strategy, Template Method, Visitor. 6. Tight
coupling Classes tightly coupled are hard to
reuse in isolation due to dependence. Solution
Loosely coupled systems.- Design patterns
Abstract Factory, Bridge, Chain Of
Responsibility, Command, Façade, Mediator,
Observer. 7. Extending functionality by
subclassing Subclassing requires in-depth
understanding of parent classes and overriding
operations may require an unmanageable number of
subclasses. Solution Using composition.- Design
patterns Bridge, Chain Of Responsibility,
Composite, Decorator, Observer, Strategy. 8.
Inability to alter classes conveniently
Altering classes may affect many subclasses or
may be difficult if the source code is lost.-
Design patterns Adapter, Decorator, Visitor.
13
Illustration using Factoy Method Pattern

• Factory Method (Also known as visual
  constructor)
• - In this method, an interface for creating an
  object, is defined and the subclasses decide
  which class to instantiate.
• Thus factory method lets the class defer
  instantiation to subclasses.
• Frameworks Use abstract classes to define and
  maintain relationships between objects. They are
  also responsible for creating these objects.
• Example Framework for applications that can
  present multiple documents to the user.
• 2 key abstractions for this framework are 2
  classes Application Class- Responsible for
  managing and creating documents Document
  Class-useful To manage a specific document
• Both are abstract so the clients need to subclass
  them for their application-specific
  implementation.To Create a Drawing Application
  for example We need 2 subclasses DrawingApplicat
  ion DrawingDocumentProblems - When a subclass
  of document (which is application specific), when
  created, Application class can not know what it
  contains or can not relate to it.- Framework has
  to instantiate classes but has only abstract
  classes which can not be instantiated.

14
Problem
ApplicationCreateDocument()NewDocument() OpenDoc
ument()
DocumentOpen()Close() Save()
MyDocument
DocumentOpen()Close() Save()
ApplicationCreateDocument()NewDocument() OpenDoc
ument()
DrawingDocumentOpen()Close() Save()
DrawingApplicationCreateDocument()NewDocument()
OpenDocument()
Solution Without Using Pattern
15
Problem
ApplicationCreateDocument()NewDocument() OpenDoc
ument()
DocumentOpen()Close() Save()
MyDocument
ApplicationCreateDocument()NewDocument() OpenDoc
ument()
DocumentdocCreateDocument()docs.Add(doc)doc-
gtopen()
DocumentOpen()Close() Save()
MyApplicationCreateDocument()
MyDocument
return new MyDocument
Solution Using a Pattern
16
How factory method helps to solve the problem

• Factory Method encapsulates the knowledge of
  which document subclass to create and moves the
  knowledge of it, out of framework.
• Application subclasses redefine an abstract
  CreateDocument operation on application and
  returns appropriate document subclass.
• Once an application specific class is
  instantiated, it can instantiate application
  specific documents without knowing the class.
• CreateDocument() method is called Factory method
  as it manufactures the object of Subclass of
  document.
• It also illustrates the principle of delegation,
  already discussed.
• - This method is used when a class cant
  anticipate the class of object, it must create
  and wants a subclass to specify objects it
  creates.

17

• Points for discussion
• What are the conditions/ circumstances to use
  patterns?
• How do patterns relate to design requirements
• Are patterns same as components?
• How design Patterns are created?

18
How to select a design pattern

• Consider how design pattern solves a problem.
• Scan intent sections from all patterns
• Study how patterns interrelate
• Study patterns of like purpose
• Examine cause of redesign and look for a
  suitable pattern
• Consider what should be variable in design. (
  that can be changed without redesign)- Define a
  variable for encapsulation.

19
How to use a design pattern

• Read the pattern for an overview
• Study the structure, participants and
  collaborations
• See the sample code in the examples
• Choose names for pattern participants that are
  meaningful in application.
• Define classes, interfaces and their
  relationships
• Define operations in the system
• Implementation of the pattern
