Title: Project: Seat Sensor System


1
(No Transcript)
2
Project Seat Sensor System
  • Implemented in
  • Dinosaur Disneys Animal Kingdom
  • Indiana Jones Adventure Disneyland
  • Indoors
  • Action-adventure ride!

3
Presentation outline
  • Objective and specifications
  • Review original design
  • Construction and functional testing
  • Design changes
  • Performance and reliability testing
  • Conclusions

4
Objectives
  • Detect presence of person and state of seatbelt
  • Display output via LED
  • State 1 Unlatched and Unoccupied
  • State 2 Latched and Occupied
  • State 3 Unlatched and Occupied
  • State 4 Fault

5
Benefits
  • Enhance safety features
  • Automatically verifies seat occupancy
  • Automatically verifies seatbelt state
  • Increase hourly ride capacity
  • Eliminates need for manual seat check
  • Designed around existing ride equipment

6
Product Features
  • LED indicator
  • Counter to keep track of amount of guests
  • Affordable safety enhancement
  • No additional operators are needed
  • Potential for system expansion
  • Detect presence of person and state of seatbelt
    while ride is in motion

7
Performance Requirements
  • Indicates 4 states correctly
  • 99.99 reliability
  • Implemented with minimal equipment
  • Accommodate various weights
  • Waterproof and durable

8
Original Design
  • Block diagram

Vehicle Control System
Control Logic and PLC
Seat Sensors
Guest
Operator LED Display
PLC Display
Seatbelt Sensors
Power Supply
9
Design Considerations
  • Power conversion 24VDC to 5VDC and back
  • Electrode design
  • QT310 parameter settings
  • Seat belt sensor design
  • PLC hardware and software

10
Original Design Seat Sensor
11
Construction Seat Sensors
  • Seat sensors
  • Evaluation Board testing
  • Circuit construction with custom electrode
  • Electrode selection and testing
  • Parameter alteration
  • Integration

12
Power Conversions
Transistor 4.87V to 17V
LM317 28V to 4.87V
13
Transistor Output VoltageChoosing the Resistance
14
Construction Seat Belt Sensors
  • Seat belt sensors
  • Hall-effect sensor
  • 300 Gauss activation
  • Rated 4.75 24V input voltage
  • Magnet selection
  • Field strength testing

15
Programmable Logic Controller (PLC) Signals
  • Inputs 24V logic
  • 4 inputs for each seat
  • QT310 seat sensor
  • Seat belt sensor
  • Fault
  • Reset
  • x 2 seats 8 inputs
  • Outputs 24V logic
  • 4 states for each seat
  • Occupied, Latched
  • Occupied, Unlatched
  • Unoccupied, Unlatched
  • Fault
  • x 2 seats 8 outputs

16
Construction PLC
  • Read the manual
  • PLC 600 pages
  • PLC programming software 300 pages
  • DV-1000 Display 200 pages
  • Wiring, programming and compilation
  • I/O and state testing
  • Debug and revise
  • Repeat

17
PLC Program
  • Ladder logic
  • Control relays
  • Timers
  • Counters
  • Implements
  • State decoder
  • Fault detection
  • Seat counters

18
Construction Integration
  • Interface sensors and PLC
  • Physical system construction
  • Seats and seat belts
  • Functionality testing and debugging
  • PCB and packaging

19
(No Transcript)
20
Design Changes Fault
  • Original XOR two sensors
  • BAD!
  • New utilize heartbeat signal
  • 15us float superimposed on QT310 output, 20ms
    between beats

21
Design Changes Fault
  • PLC scan time 20ms.
  • Fault signal period 40ms.
  • PLC Code
  • Timer resets with Fault input.
  • If you can count up to 5 fault.
  • PCB power outage, fried IC will trigger fault.

22
Design Changes
  • Electrode
  • 24V supply outputs 28V!
  • Seatbelt sensors not rated for 28V
  • Re-calculation of power conversions
  • Counting display
  • Added counter for each seat
  • Interface with DV-1000 display

23
Testing
  • Electrode
  • Range small enough so as not to detect other
    seats
  • Range large enough to accommodate for human
    movement

24
Testing
  • Seat sensor
  • Various weights of humans tested (45kg, 55kg,
    90kg) 50 times each
  • Output independent of weight
  • 100 reliability
  • Various theme park specific objects tested
  • Book , backpack, jacket, stuffed animal, water
    bottle, camera, I-Pod, snow globe
  • Sensor not activated

25
Seat Belt Sensor
  • Reliability Testing
  • Seat belt outputs 16.7VDC when triggered
  • Data over period of 50 trials per seat belt
    yields 100 reliable
  • Fulfills performance requirement of triggering at
    least 99.9 of time

26
Magnet data
(w,l,t)
27
Seat belt Sensor
  • Magnet Placement

28
Testing Water Tolerance
  • 0ml-1000ml in 100ml increments
  • Soaked cotton and placed it directly on the seat.
  • Up to 3L of water.
  • With tub, up to 5L.
  • Pass!

29
Design Challenges
  • PLC programming
  • Electrode selection
  • Component casualties
  • 1 voltage regulator
  • 3 QT310 chips
  • 1 latch
  • 1 resistor
  • 1 PLC output module

30
Successes
  • Met all performance requirements!
  • Indicates 4 states correctly
  • 99.99 reliability
  • Implemented with minimal equipment
  • Accommodate various weights
  • Waterproof and durable
  • Passed all performance tests!

31
Recommendations
  • Detect seat and state of seat belt while ride is
    in motion
  • Transmit outputs wirelessly
  • Display outputs on a computer screen instead of
    via LEDs
  • Automatic dispatch

32
Conclusion
  • It works!
  • Thanks Mo!
  • Thanks Disney!
  • Next step
  • Present design to Walt Disney Imagineering
  • You could be sitting on this one day
