HEATING expands the mind

1
HEATINGexpands the mind

• EISCAT training course

2
The past G. Marconi (1874 -1937) Nobel Prize 1909
There had to be a reflecting layer in order to
explain his trans-Atlantic radio wave connection.
Reflecting layer at 100-200 km altitude (the
ionosphere)
Radio Sender
Earth
Receiver
3
The past N. Tesla (1856-1943)
Tesla developed high-frequency high-power
generators
4
The past At the same time as Marconi, Tesla
wanted to transmit energy as well as information
using wireless radio waves. He built a
transmission tower for this pupose. However, his
work had little to do with modern ionospheric
research.
5
The past Geometry of the Luxembourg effect
(Tellegen, 1933)
6
EISCAT consists of much more than just radars. It
possesses the worlds largest high-frequency (HF)
ionospheric modifi-cation facility, called
HEATING or simply the HEATER. Built by the
Max-Planck-Society in the late 1970s, it passed
to EISCAT in 1993.
EISCAT mainland
7
A geographic overview of the EISCAT radar,
HEATING SPEAR HF facilities and CUTLASS
coherent scatter radars
8
The Heating facility at Tromsø
Control
Antenna 1
Transmitter
Antenna 2
Antenna 3
9
Tromsø HEATING facility layout
10
HEATER control house with EISCAT radars in the
background
11
A single HEATING antenna
12
An antenna array
13
Transmitters during construction 6 of 12
14
Coax
Only 50 km of home-made aluminium RF coaxial
transmission lines with mechanical switches
15
Thermal expansion One of many detours
16
2 Antennas give a broad beam
Beam forming
4 Antennas give a narrower beam with more power
in the forward direction and less power in
all other directions.
Effective Radiated Power Radiated power ?
Antenna gain At Heating 300 MW 1.1 MW ? 270
for low gain antennas 1.2 GW 1200 MW 1.1 MW ?
1100 for high gain antenna
17

• 1970 Platteville, Colorado
• 1975 SURA (Nizhni Novgorod), Russia
• 1980 Arecibo (Puerto Rico),
• Tromsø (Norway), HIPAS (Alaska)
• 1995 HAARP (Alaska)
• 2003 SPEAR (Svalbard)

World overview
18
A comparison
HEATING SPEAR HAARP (final) Power
(MW) 1.1 0.192 3.3 Antenna 24 and 30 16
22 30Gain (dB) ERP (MW) 300 1200 7.6
30 3600 Freq. (MHZ) 3.9-5.4 5.4-8 2-3 4-6
2.8-10 Polarisation O X O X O
X Beam only north-south any anySteering relati
vely slow fast fast Diagnostics KST ESR ?
CUTLASS CUTLASS KODIAK Dynasonde ? Digisonde
19
The ionosphere
Fc 8.98sqrt(Ne) for O-mode Fc
8.98sqrt(Ne) 0.5Be/m for X-mode
20
A comparison of frequency range and effective
radiated power of different facilities
1GW
100 MW
SPEAR
10 MW
21

• Why do we need the HEATING facility?
• Why? HF facilities are the only true active
  experiments in the ionosphere because the plasma
  may be temporarily modified under user control.
• Operations 200 hours per year (1 year8760
  hours), mostly in user-defined campaign mode.
• Experiments can be divided into 2 groups
• Plasma physics investigations the ionosphere
  is used as a laboratory to study wave-plasma
  turbulence and instabilities.
• Geophysical investigations ionospheric,
  atmospheric or magnetospheric research
• is undertaken.

22
The Incoherent Scatter Radar Spectra with Ion and
Plasma lines corresponding to ion-acoustic waves
and Langmuir waves
Langmuir turbulence, the parametric decay
instability e/m pump(?0 ,0) ? Langmuir(?0 -
?ia,-k) IonAcoustic(?ia ,k) Langmuir(?0 -
?ia,-k) ? Langmuir(?0 - 2?ia,k) IonAcoustic
(?ia,-2k) The component of the pump electric
field parallel to the Earth's magnetic field is
what matters.
Thermal resonance instability e/m pump
field-aligned electron density striation ?
electrostatic wave (UH) Upper hybrid (UH)
resonance condition ?02 ?p2 ?e2 The
component of the pump electric field
perpendicular to the Earth's magnetic field is
what matters.
23
PLASMA TURBULENCE
12 Nov 2001 5.423 MHz ERP 830 MW O-mode
UHF ion line spectra
HF on
HF off
24
PLASMA TURBULENCE
The UHF radar observes HF pump-induced plasma
turbulence 5.423 MHz ERP 1.1 GW O-mode
25
PLASMA TURBULENCE
Z-mode penetration of the ionosphere
26
HF pump-induced magnetic field-aligned electron
density irregularities (up to 5) causes
coherent radar reflections and anomalous
absorption (by scattering) of probing signals.
Striations
27
HF induced F-region CUTLASS radar backscatter
28
Striations
Amplitude of radio waves received from the
satellite
29
Striations
After HF pump off, the irregularities decay
with time
30
HF induced E-region STARE backscatter (144 MHz)
Tromsø
31
Artificially raised electron temperatures 16
Feb 1999 4.04 MHz ERP 75 MW O-mode
?Heater on
32
HF pump-induced artificial optical emissions 16
Feb 1999 4.04 MHz ERP 75 MW O-mode
1740 HF on
1744 HF off
33
HEATER and UHF beam swinging
UHF zenith angle
7 Oct 1999 4.954 MHz ERP 100 MW O-mode
34
ARTIFICIAL AURORA shifted onto magnetic field
line
Heater beam (vertical)
Spitze direction
Field aligned
21 Feb 1999 630 nm Start time 17.07.50 UT
Step480 sec 4.04 MHz ERP 75 MW O-mode
35
SEE
36
Stimulated Electromagnetic Emissions
are weak radio waves produced in the ionosphere
by HF pumping. They were originally discovered
at HEATING.
HF transmit frequency
Gyroharmonic ? 1.38 MHz in F-layer
37
GYRO-HARMONIC
Special effects appear for HF frequencies close
to an electron gyro-harmonic. (1.38 MHz in
F-layer)
38
GYROHARMONIC
3 Nov 2000 ERP 70 MW O-mode
UHF
Cutlass
Artificial aurora 630 nm
39
VHF
PMSE
Artificial HF modulation of Polar Mesospheric
Summer Echoes. VHF backscatter power reduces by
gt40 dB. 10 July 1999 5.423 MHz ERP 630
MW X-mode
HF off
HF on
40
Satellite in the magnetosphere
ULF ELF VLF waves
Ionosphere
DC current
Conductivity modulation causes electrojet
modulation, which acts as a huge natural antenna
100 km altitude 30 km diameter
superimposed ac current
0.001-1 W ULF/ELF/VLF waves are radiated from
the ionosphere
Heating Tx 0.2-1 GW HF waveis amplitude
modulated and radiated
VLF receiver
41
Very Low Frequency waves (kHz)
Natural (lightning) and artificial (HEATING)
ducted VLF waves resonate with trapped particles
in the magnetosphere causing pitch angle
scattering and precipitation.
42
Ultra Low Frequency waves (3 Hz)
Field line tagging
43
Artificial Periodic Irregularities (API)
The API technique was discovered at SURA and
allows any HF pump and ionosonde to probe the
ionosphere. API are formed by a standing wave due
to interference between the upward radiated wave
and its own reflection from the
ionosphere. Measured parameters include N(n),
N(e), N(O-), vertical V(i), T(n), T(i) T(e)
44
Further information
EISCAT/HEATING www.eiscat.uit.no/heater.html HAARP
www.haarp.alaska.edu HIPAS www.hipas.alaska.edu
ARECIBO www.naic.edu SURA www.nirfi.sci-nnov.
ru/english/index2e.html SPEAR www.ion.le.ac.uk/sp
ear/
