First Nations Presentation

1
NEPTUNE CanadaRegional Cabled Ocean
Observatory Transforming Ocean Science
Mairi Best Ph.D., Associate Director Science,
NEPTUNE Canada
2
Major issues facing the oceans/planet
Environmental degradation Mass consumption of
fossil fuels Global warming and climate
change Acidification of the oceans, bleaching of
coral reefs, ocean hypoxia Over-fishing fishing
down through the food web Extinctions and loss of
biodiversity Human attitudes and political
expediency
3
Transforming our study of the oceans
The last century of oceanography is marked most
by the degree of undersampling Walter Munk
(2001)?

• In contrast, cabled ocean observatories will
  have
• 24/7/365/25 presence, variety of sensors,
  selected locations
• Sampling frequencies of subseconds for most
  parameters
• Real-time multidisciplinary, interactive
  experiments
• All this is possible with
• Abundant power (up to 9kW) and high bandwidth (up
  to 4 Gb)
• Remote control of observatory network and
  instruments
• Real-time high data/imagery return
• A vast interactive data archive

4
Partnerships
5
Scientific involvement
Builders Bridge-builders Data analysts Knowledge
Beneficiaries
6
NEPTUNE Development

• Workshops
• Victoria May 3-5, 2004
• Victoria September 27-29, 2004
• Halifax November 22-23, 2004
• Proposals Due January 18, 2005
• External Review Committee Executive Committee
  review relative to facility scope
• 11 million available for observing systems
• Decisions July 2005
• 17 group proposals received 5 successful

7
Science research themes

• Plate tectonic processes and earthquake dynamics
• Dynamic processes of fluid fluxes and gas
  hydrates in the sea bed
• Regional oceanic/climate dynamics and effects on
  the marine biota
• Deep-sea ecosystem dynamics
• Engineering and computational research

8
Plate-scale science - NEPTUNE Canada
9
Earthquakes in western Canada
10
(No Transcript)
11
Broadband seismometer
12
Pacific tsunamis
13
Earth-ocean processes and systems
14
(No Transcript)
15
Tracking marine mammals

• Receivers will identify and track whales and
  dolphins
• Record migration, abundance, and communication
  behaviour
• Examine ship interactions

16
Coccolithophorid algal bloom NASA photo June 16,
2006
17
(No Transcript)
18
(No Transcript)
19
Gas hydrates
20
Recent tests of Wally in hydrate terrain of
Barkley Canyon
Jacobs University of Bremen, Germany
21
Earth-ocean processes and systems
22
Seafloor volcanism
Over 80 of Earths volcanism is on ocean
ridges Juan de Fuca Ridge had 3 major eruptions
in 15 years
23
(No Transcript)
24
TEMPO-mini
Designed by Frances Ifremer An instrument
module designed for study of hydrothermal vent
communities Video, temperature, oxygen, and iron
sensors Coordinated antifouling system
25
Acoustic imaging of hydrothermal plumes

• Multibeam sonar acoustics plus visualization and
  quantification methods to image and measure
  smoker-type plumes in 3D and to map diffuse flow
  in 2D

Russ Light, Peter Rona, Karen Bemis Funded by the
US National Science Foundation
26
Complexity of the integrated system
27
Networks
seismic
tsunami
chemical
fluid dynamics
visual
audio
130 instruments (gt40 types)? gt300 sensors
28
Alcatel-Lucent Node deployment1 July-17 August
Cable Ship Lodbrog Alcatel-Lucent
Research Vessel Atlantis Woods Hole
Oceanographic Institution
29
Nodes
30
Power and internet to the deep sea
31
Seaproofs armoured cable being loaded onto
transport Bodo, Norway to Victoria, Canada
32
Instrument deployment19 August-20 Sept.
Research Vessel Thomas G. ThompsonUniversity
of Washington
33
ROPOS ROV and the Remotely Operated Cable Laying
System (ROCLS)

• Collaborative development with NEPTUNE Canada
• In addition to the 800km backbone cable, the
  initial NEPTUNE Canada network includes 94
  secondary cables of over 60km total length

34
Test deployment Sept 2008-Feb 2009, on VENUS
Saanich Inlet

• acoustic current meter (Nortek)
• acoustic Doppler current profiler (RDI)
• bottom pressure recorder (NRCAN)
• hydrophone (Naxys)
• rotary sonar (Kongsberg Mesotech)
• TEMPO-mini (IFREMER)

35
(No Transcript)
36
Junction boxes manufactured and one deployed in
Saanich test
37
Data Management and Archiving System (DMAS)?
38
New website
39
Developing Oceans 2.0
40
Cabled observatories developing around the world
41
NEPTUNE Canada - Status

• Secured a further 20M for installation in fall
  2006 (total 80Min kind)?
• Scope of observatory expanded from 2 to 5 nodes,
  increased the instruments by 250
• DMAS operating for VENUS since 2006
• Cable, repeaters and branching units laid in Fall
  2007
• Node development and testing and manufacture
  through 2008/2009
• Most instruments are now procured or built, and
  are currently undergoing testing
• Test deployment on VENUS at end September 2008
• Nodes to be installed early summer 2009
• Instruments, extensions, junction boxes to be
  installed in late summer 2009
• Initial operating funds secured from NSERC/CFI/BC

42
Transformative Science
Shelf to Deep Sea Cross-plate Remotely
Operated Continuous, Real-Time Data Four
Dimensional Multi-disciplinary Linkages Integrativ
e Coordinated Datasets -gt Geoinformatics
43
Join us!

• neptunecanada.ca
