Signal and Design Integrity April 2002

1
Signal and Design IntegrityApril 2002
2
Technical issues in Deep Sub-Micron Design

• Manufacturability (Chip cant be built)
• Antenna rules
• Minimum area rules for stacked vias
• CMP (Chemical Mechanical Polishing) area fill
  rules
• Signal Integrity (failure to meet Performance
  targets)
• Crosstalk induced errors
• Timing dependence on crosstalk
• IR Drop on power supplies
• Substrate coupled noise
• Design Integrity (reliability failures in the
  field)
• Electromigration on power supplies
• Hot electron effects on devices
• Wire self heat effects on clocks and signals

3
Why now?

• These effects have always existed, but become
  worse at deep sub-micron sizes because of
• Finer geometries
• Greater wire and via resistance
• Higher electric fields (if supply voltage not
  scaled)
• More metal layers
• Higher ratio of cross coupling to grounded
  capacitance
• Lower supply voltages
• More current for a given power
• Lower device thresholds
• Smaller noise margins
• Good news Same solutions that work at 150 nm and
  130 nm will work for next few technology
  generations until ltlt 100 nm

4
Crosstalk induced errors

• Transition on an adjoining signal causes
  unintended logic transition
• Symptom - chip fails (repeatably) on certain
  logic operations

Aggressor net
Coupling C
Victim net
Wire R
Drive R
Grounded C
Input Noise Tolerance
5
Timing Dependence on Crosstalk

• Timing depends on behavior of adjoining signals
• Symptom - Timing predictions inaccurate compared
  to silicon. Effect can be large 31 on
  individual nets.

Delay here
and here depends on the behavior of other nets
Wire R
Grounded C
Coupling C (multiplied by Miller effect)
Other logic net(s)
6
Effect of Crosstalk on Delay
Thresholds
min
nom
max
nominal
friendly
unfriendly
7
Electromigration

• Power supply lines fail due to excessive current
• Symptom Chip eventually fails in the field when
  the wire breaks

Currents depend on driver type, loads, and how
often cell is switched
Currents depend on currents of other cells
Power supply network consists of wires of
varying sizes they must be big enough, but too
big wastes area
Pad
Current limit depends on wire size
8
IR Drop

• Voltage drop in supply lines from currents drawn
  by cells
• Symptom chip malfunctions on certain vectors
• Biggest problem - whats the worst case vector?

Currents depend on driver type, loads, and how
often cell is switched
Voltages depend on currents of other cells
Allowable voltage drop at pin
Power supply network consists of wires of
varying sizes they must be big enough, but too
big wastes area
Pad
9
Hot Electron Effects

• May also be called short channel effect
• Caused by extremely high electric fields in the
  channel
• Occurs when voltages are not scaled as fast as
  dimensions
• Effect becomes worse as devices are turned on
  harder
• Symptom Thresholds shift over time until chip
  fails

Oxide and/or interface is damaged here
Gate


N diffusion
Electrons pick up speed in channel hot
electrons are the fastest of a statistically fast
bunch
Impact ionization occurs here
10
Hot Electron Effect (cont)
Contours of constant hot electron flux

• Depends on how hard device is driven (input slew
  rate)
• And on the size of the load

Vgs
Trajectory with large C, fast Tin
Trajectory with small C, slow Tin
Vds
11
Wire Self Heat

• May also be called signal wire electromigration
• Wire heats above oxide temperature as pulses go
  through
• Symptom Chip eventually fails when wire breaks
• Depends on metal composition, signal frequency,
  wire sizes, slew rates, and amount of capacitance
  driven
• Requires different data/formulas from power
  supply EM

Oxide
Metal
12
Substrate Noise

• Currents injected by high speed switching of
  digital devices
• Supply currents injected via substrate contacts

13
Analog Noise in Custom Digital ICs
Propagated Noise
Overshoot (TDDB)
CLK
Undershoot (TDDB)
14
What can tools do about these problems?

• Accurate Analysis
• Make sure real problems are caught
• Avoid fixing problems that arent really there
• For analog issues, such as substrate noise, this
  is about all we can do. The user must decide how
  to fix the problem
• Tools can try to prevent or avoid errors
• Tools can try to fix errors once they have been
  found
• Can view two ways
• For a given problem (ie. crosstalk) what can each
  tool do?
• For a given tool (ie. synthesis), which problems
  can be alleviated?
• Following slides have a mixture of these analyses.

15
Signal Integrity Flow- Full Chip Design
Floor Planning
Place Route
Chip Assembly
All Tools
Verification
Design global wiring
Build Blocks
Re-verify
Do global routing
Re-verify Sign-off
-Signal nets correct by construction -Push
budgets into blocks
-implement wiring strategy -Route with
variable width, spacing, shielding
-Place blocks -Place cells with Optimization -
Re-check loads, drives, timing
-Re-extract routing parasitics -Re-check
loads, drives, timing
-Re-extract routing parasitics - Re-check
loads, drives, timing

• Signal Integrity Correction and Checking
• Early and Often throughout the design flow
• Fewer Signal Integrity issues at the end of the
  design flow

16
Signal Integrity Flow- Block Design

• Signal Integrity issues fixed at each step in the
  Design Flow

• Post-Route
• Crosstalk
• Fixing

17
Controlling crosstalk

• Use timing windows
• Use a sensitivity-based noise check to minimize
  false failures
• Need fast analysis with SPICE-like distributed
  models
• Based on reduced order models
• Automatically fix functional noise failures via
  ECOs to PR
• Support mixed flat and hierarchical analysis
• Special commands for fixing post-route crosstalk
• Needed for good flow convergence

18
Timing Windows for Crosstalk

• Only consider signals that can change at the same
  time
• Data comes from static timing analysis

One clock cycle
B
D
STA Timing Windows
A
C
Crosstalk Magnitudes
Worst case occurs here, does not include signals
A or D.
19
Glitch Rejection

• Calculates the sensitivity of each receiver to
  noise at its input
• Accounts for the inherent glitch rejection of
  each receiver
• Depends on input waveform, input circuitry, and
  output load

Noise sensitivity is dependent on input waveform
shape and output loading
20
DC Noise Peak Vs Noise Immunity

• Using Sensitivity analysis (such as CeltIC)
  implies less rework!

21
Crosstalk Analysis Accuracy Measurement

• Can reduced order models give accurate results?
• Worked through this with customers its very
  difficult
• To determine error budget, need to understand
  each portion separately
• Need to get LEF, TLF, and SPICE to exactly agree
• Need to run, and measure, SPICE simulations
• Slopes, normally a second order effect, are first
  order for crosstalk checking
• Even SPICE analysis has ambiguities
• Simultaneous Switching (SS) vs. Worst Case
  Alignment (WCA)

22
Simultaneous switching is not worst delay
Thresholds
min
nom
max
nominal
friendly
unfriendly
23
Crosstalk results lumped vs distributed

• Glitch Noise
• Lumped analysis was about (-10, 70) for noise
  peak.
• CeltIC (distributed analysis) was (-9, 4) for
  noise peak
• Since most signals fail by only a few millivolts,
  using distributed analysis results in many fewer
  reported errors.

24
Glitch size with lumped model
25
Celtic (distributed) Noise Errors (note scale
change)
26
Better prevention helps flow convergence

• Crosstalk prevention in synthesis
• Upgrade drivers of slow transition signals even
  if not needed for timing
• Global slew limits
• Clock tree generator should include EM prevention
  for clocks
• Crosstalk prevention in routing
• Long parallel line avoidance
• Longer term, track assignment does even better
• Takes advantage of free shielding by power
  supply grid
• Crosstalk timing prevention in synthesis (forward
  prediction)

27
Fixing errors after routing

• Fixing crosstalk errors after routing requires
  care
• Rip-up-and-reroute may change neighbors
• Making victims stronger makes them better
  aggressors
• Specific post-route heuristics are required for
  best convergence
• Insert/change components with minimal routing
  changes
• Change some marginal components preemptively to
  avoid iterations
• These commands are also useful for other post
  route changes
• ECOs

28
Strategy for Crosstalk Fixing

• From Post Route Analysis
• Create repair files for Post Route Crosstalk
  Fixing
• Apply repair file
• Buffer insertion
• Wide Space Routing
• Shielded Routing

Wide Space Routing
Buffer Insertion
Shielded Routing
29
Timing Convergence

• Extremely few timing problems from crosstalk
  glitch fixing (none in 20-30 large examples at
  0.15 and 0.13 micron)
• If flow is timing driven, critical path has
  strong drivers, short nets and good slopes -gt few
  crosstalk problems
• Conversely, nets with problems tend to be long
  nets with weak drivers, and buffer insertion
  helps these.
• Wire fixes (extra spacing/shielding) increase
  performance if anything

30
Handling Timing Impact of Crosstalk

• Correct treatment of coupling has an effect even
  if there is no noise!
• Need accurate analysis of effect
• Lumped models have large errors
• Distributed analysis is needed
• Reduced order models give good results
• Would like to avoid the need to iterate around
  timing windows

31
Even without noise, coupling is important
What existing timing verifiers see.
Real circuit on silicon
Logic 0
Solid 0
victim
in
True timing is about 15 faster
32
Crosstalk results lumped vs distributed

• Analysis of crosstalk induced delay
• Lumped analysis was about (-20, 450) on delay
• Spice has simultaneous switching Lumped analysis
  used Worst Case Alignment
• The delay measurement was interconnect delay
  not stage delay
• A distributed analysis with reduced order models
  (CeltIC) was (-16, 10) for delay

33
Lumped crosstalk delay
34
Distributed (CeltIC) Delay Errors
35
Noise Aware-Timing

• Internal iteration

CeltIC
Noise Aware Timer
STA
36
Noise Aware Timing
Static Timing Analysis

• Avoids iteration between tools

Detailed Crosstalk Delay Calculation
37
Signal Integrity (SI) in Synthesis

• Synthesis with placement can help SI issues
• Crosstalk and EM prevention in placement/sizing
• Interface to detailed crosstalk analysis
• Generate timing windows, constraints, and clocks
• Generate maximum frequency for reliability checks
• Wire self heat and hot electron
• Post routing crosstalk correction
• Add buffers
• Size drivers
• Decision based on routing and cell congestion
• Includes post route timing corrections
• Integrated clock tree generation supports EM
  prevention

38
Signal Integrity Avoidance in Synthesis

• Other possible prevention options
• Global slew limit (can limit length as a function
  of driver size)
• Global length limits (per layer).
• Some customers have requested this for
  manufacturability, but it can also be used for
  SI.
• Better correction options
• Decide bigger driver, inserted buffer, or extra
  spacing on a net by net basis after routing.

39
Controlling Wire Self Heat (also called Signal
Line Electromigration or Joule Heating)

• Need a maximum frequency for each net
• Timing analysis and/or synthesis can provide this
• Generated by propagating clocks forward to data
  signals
• Maximum frequency, times load, gives maximum
  possible current
• Clock nets are a particular concern
• Highest frequency operation, long wires, big
  loads
• Worst spot on net may not be at driver
• Vias may have tighter limits
• Specialized clock drivers may only have pins on
  the high metal layers, leading to a good initial
  clock route, but.
• Router may change layers during rip-up and
  re-route
• Nets must be tapered (to reach pins), but only at
  input pins

40

• All wiring segments, vias, and cell I/O pins must
  be checked
• Frequency dependent Cload and/or Slew are
  calculated and checked.
• EM current density change on a wire path are
  measured and checked.

OK
4M
No Good
Buffer
Buffer
OK
41
Signal Line Electromigration

• New Placement and Routing features
• Router must taper correctly (No taper at driver)
• Analysis must check correctly
• Tapered (input) pins are not checked
• All segments on net are checked
• All vias on the net are checked.
• Layers and vias that are in the routing rule, but
  not used, are not checked.

42
Extract Improvements Needed for SI

• Accuracy for cross coupling
• Capacity
• Coupling capacitance reduction

43
Extraction for Cross Coupling

• Fully distributed coupling reflects physical
  reality
• Files are huge (3GB for 100K instances) -gt 300GB
  for 10M cells
• Need a reduction that reduces network size with
  an acceptable degradation of accuracy.
• We believe a good compromise is possible here.
• When combined with delay calculation, can
  potentially regain 15 timing margin associated
  with assuming coupling Cs are truly grounded.

44
Intelligent Network Reduction
A very small example
6 shapes
9 inter-shape couplings
SPICE/DSPF require even more components No native
element for distributed RC 12 Rs, 9 Cs for T
model, 6 Rs, 16Cs for Pi model Net result huge
files
45
Network Reduction (continued)

• Reduce number of components
• Preserve important properties
• Preserve moments (Elmore delay and higher order)
• Preserve cross-coupling properties

46
Hot Electron Degradation

• Most customers are designing their libraries such
  that the CAD tools dont need to check this.
• If needed, can be fixed by a combination of
  timing analysis and placement, and
  pre-characterization of cells
• Timing analyzer computes input slope and max
  frequency
• Placement tool computes output load, then
  consults pre-characterized table
• If load is too high for specified chip lifetime,
  upsizes driver or inserts isolation buffer

47
Power Supply Analysis

• IR drop analysis
• Static (uses average current)
• Dynamic (worst case stimulus)
• Most users use static analysis since worst case
  vectors are unknown.
• This is an active research problem
• Important to do this early in the flow since
  widening the power supplies later causes huge
  routing problems.

48
Power Calculation Flow
Average
Design -LEF, DEF
Power Characterization Supply Voltages RSPF
parasitics VCD file or freq activity
Triplet
Power Calc
Vectors
PWL
Power Spec File
49
Rail Analysis Flow
Design LEF, DEF

• Extract Power network
• Calculate IR Drop and EM through wire segments
• Display on physical design

SEDSM
Rail Analysis
Wire Seg File Cell Seg File
50
Rail Analysis
51
Power supply analysis improvements

• Improve existing features
• Multi-Vcc -gt Map to cell supply voltage
• Peak IR drop try to make easier to use
• Hierarchical analysis
• Top down, enter estimates for uncompleted blocks
• Bottom up, analyze block and it builds a model
  for top analysis.
• Model has a current source per pin, and a matrix
  of pin interconnection Rs.
• Similar to paper of Blaauw in DAC 2000.
• Better run times and higher capacity
• New matrix size reduction techniques can help

52
Model for Cell Power Supply Network

• Model is exact for a linear system works for
  transient response too

1
3
Z13
Z14
Z12
Z34
Z23
4
2
Z24
53
Flow analysis/testing

• There are many interactions within a place and
  route flow
• Must verify (for example) that fixing one
  violation does not cause others (at least on the
  average)
• Crosstalk (for example) can be fixed in many
  places
• Aggressive sizing in synthesis/placement
• Post track assignment analysis
• Post detail routing analysis
• Which of these has minimum impact on chip
  performance and/or time to market?

54
90nm and Beyond Subwavelength Effects
What you draw is not what you Image!

• Widths and spacings affected by neighboring
  geometries
• OPC (Optical Proximity Correction) tries to fix
  this, but will not succeed completely at small
  process sizes.
• Eventually will impact manufacturability and
  routing, and possibly placement

User draws
Without OPC
Mask w/OPC
Silicon fabbed
55
90nm and Beyond Inductance

• Inductance is required in some cases
• Package models, PC boards, MCMs, Flip-chip
  packages
• For on-chip wires, it is sometimes (rarely)
  required
• Short wires (compared to their rise time) are
  equipotential
• Long wires have an R that dominates their L
• In both these cases L is not needed. Most nets
  meet one of these rules
• A physical prototype allows our analysis to
  determine on a net by net basis whether L is
  needed. If not, we dont extract it.
• For the remaining nets the extraction and timing
  infrastructure must support inductance
• Result accurate analysis without a serious time
  penalty

Figures of Merit to Characterize the
Importance of On-Chip Inductance, by
Ismail, Friedman, and Neves, IEEE Transactions on
VLSI Systems, December 1999
56
Summary

• Lots of activity in the area of Signal Integrity!
• Better analysis of all kinds of effects
• SI prevention features in synthesis
• Improvements to extraction
• Improved SI prevention in placement and routing
• Improved power supply analysis
• New problems coming at 90 nm and below!
• Will provide job security for years to come!
