Title: CSE 8383 - Advanced Computer Architecture


1
CSE 8383 - Advanced Computer Architecture
  • Week-13
  • April 15, 2004
  • engr.smu.edu/rewini/8383

2
Contents
  • Warm up
  • Big Picture
  • Clusters
  • Scheduling
  • Mobile IP
  • Reliability issues in Mobile IP

3
Group Work
Lets test your network background
4
What?
LAN
LAN
Internet
5
Explain
Application
Telnet
ftp
Mail
Presentation
Transmission Control Protocol (TCP)
Session
Transport
Network
Internet Protocol (IP)
Data Link
Token ring
Ethernet
Physical
6
Big Picture
7
Leopolds View of the Field
Numerous Application Programs
High
Hiding Details
Low
Concrete Architectures
8
Parallel and Distributed Architecture (Leopold,
2001)
SIMD
SMP
CC-NUMA
DMPC
Cluster
Grid
SIMD
MIMD
Shared Memory
Distributed Memory
Degree of Coupling
tight
loose
Supported Grain Sizes
coarse
fine
Communication Speed
slow
fast
9
Clusters (Commodity Off The Shelf)
10
What is a Cluster?
  • A Collection of interconnected stand-alone
    computers working working together as a single
    integrated computing resource
  • Cluster nod3es may exist in a single cabinet or
    be physically separated and connected via a LAN

11
Clusters
Programming Environment
Middleware
Interconnection Network
12
Clusters offer these features
  • High Performance
  • Expandability and Scalability
  • High Throughput
  • High Availability

13
High Performance Clusters
  • Tuned to derive maximum performance
  • Share processing load
  • Needs software customization
  • E.g. Beowulf

14
Cluster Components
  • Homogeneous Clusters
  • All nodes have same configuration
  • Heterogeneous Clusters
  • Nodes with different configurations e.g.
    different OSs

15
Cluster Architecture and OS
  • Cluster of PCs
  • Cluster of Workstations
  • Cluster of SMPs (Symmetric Multiprocessors)
  • Linux clusters (Beowulf)
  • Solaris clusters (NOW)
  • NT clusters

16
Cluster Size
  • Group clusters 2-99 nodes
  • Departmental clusters 99-999 nodes
  • Organizational clusters many 100s
  • Global clusters 1000s
  • Internet wide

17
Typical Cluster Environment
User Application
PVM/MPI
  • Middleware

OS/Hardware
18
PVM MPI
  • PVM (Parallel Virtual Machine)
  • Allows heterogeneous collection of computers
    linked by a network to be used as a single large
    parallel computer
  • MPI (Message Passing Interface)
  • Library specification for message passing
  • Free and vendor supplied implementations available

19
PVM Introduction
  • http//www.netlib.org/pvm3/
  • http//www.epm.ornl.gov/pvm/
  • Started as a research project in 1989
  • Developed at Oak Ridge National Lab University
    of Tennessee
  • It makes it possible to develop applications on a
    set of heterogeneous computers connected by a
    network that appears logically to user as a
    single parallel computer

20
PVM Environment
  • Virtual machine
  • Dynamic set of heterogeneous computer systems
    connected via a network and managed as a single
    parallel computer
  • Computer nodes ? hosts
  • Hosts are uniprocessors or multiprocessors
    running PVM software

21
PVM Software
  • Two Components
  • Library of PVM routines
  • Daemon
  • Should reside on all hosts in the virtual machine
  • Before running an application, the user must
    start up PVM and configure a virtual machine

22
PVM Application
  • A number of sequential programs, each of which
    will correspond to one or more processes in a
    parallel program
  • These programs are compiled individually for each
    host in the virtual machine
  • Object files are placed in locations accessible
    from other hosts

23
PVM Application (Cont.)
  • One of these sequential programs, which is called
    the initiation task, has to be started manually
    on one of the hosts
  • Tasks on other hosts are started automatically by
    the initiation task
  • Tasks comprising a PVM application can be
    identical (SPMD) common in most applications or
    can be different (pipeline input processing,
    output)

24
Application Structure
  • Start graph
  • Middle node is call supervisor or master
  • Supervisor-workers or Master-slaves
  • Tree
  • Root is the top supervisor
  • Hierarchy

25
Task Creation
  • A task in PVM can be started manually or can be
    spawned from another task
  • The function pvm_spawn() is used for dynamic task
    creation.
  • The task that calls the function pvm_spawn() is
    referred to as the parent
  • The newly created tasks are called children.

26
To Create a child, you must specify
  1. The machine on which the child will be started
  2. A path to the executable file on the specified
    machine
  3. The number of copies of the child to be created
  4. An array of arguments to the child tasks

27
Task ID
  • All PVM tasks are identified by an integer task
    identifier
  • When a task is created it is assigned a unique
    identifier (TID)
  • Task identifiers can be used to identify senders
    and receivers during communication. It can also
    be used to assign functions to different tasks
    based on their TIDs

28
Task ID Retrieval
  • Tasks TID ? pvm_mytid()
  • Mytid pvm_mytid
  • Childs TID ? pvm_spawn()
  • pvm_spawn(,,,,, tid)
  • Parents TID ? pvm_parent()
  • my_parent_tid pvm_parent()
  • Daemons TID ? pvm_tidtohost()
  • daemon_tid pvm_tidtohost(id)

29
Scheduling
30
Scheduling
31
Scheduling
  • Introduction
  • Model
  • Program tasks
  • Machine
  • Schedule
  • Execution and communication time
  • Problem Complexity

32
Introduction to Scheduling
  • This problem has been described in a number of
    different ways in different fields
  • Classical problem of job sequencing in production
    management has influenced most of the solutions
  • Set of resources and set of consumers

33
Scheduling System
Consumers
Resources
Scheduler
Policy
34
Program Tasks
  • (T, lt, D, A)
  • T ? set of tasks
  • lt ? partial order on T
  • D ? Communication Data
  • A ? amount of computation

35
Task Graph
A
10
5
5
5
8
7
D
E
F
B
C
15
10
20
15
10
5
5
5
4
4
G
H
15
15
20
5
10
I
30
36
Machine
  • m heterogeneous processors
  • Connected via an arbitrary interconnection
    network (network graph)
  • Associated with each processor Pi is its speed Si
  • Associated with each edge (i,j) is the transfer
    rate Rij

37
Examples of Network Graphs
Ring
Linear Array
Fully Connected
Mesh
38
Task Schedule
  • Gantt Chart
  • Mapping (f) of tasks to a processing element and
    a starting time
  • Formally
  • f T ? 1,2,3, , m x 0,infinity
  • f(v) (i,t) ? task v is scheduled to be
    processed by processor i starting at time t

39
Gantt Chart
40
Execution and Communication Times
  • If task ti is executed on pj
  • Execution time Ai/Sj
  • The communication delay between ti and tj, when
    executed on adjacent processing elements pk and
    pl is
  • Dij/Rkl

41
Complexity
  • Computationally intractable in general
  • Small number of polynomial optimal algorithms in
    restricted cases
  • A large number of heuristics in more general
    cases
  • Quality of the schedule vs. Quality of the
    scheduler

42
Mobile Computing
43
What is Driving Mobile Computing
  • Advances in Wireless Communication Technology
  • Advances in Portable Computing Technology
  • Reliance on Network Computing
  • Mobile Workforce

44
Mobile Computing
  • Using small size portable computers, hand-helds,
    and other small wearable devices,
  • To run applications and access information
    resources via wireless connections
  • By mobile and nomadic users

45
Mobility versus Nomadicity
  • Mobile Node
  • The node is able to change its point of
    attachment from one subnet to another while
    maintaining all existing communication.
  • Nomadic Node
  • The node must terminate all existing
    communication before changing its point of
    attachment.

46
Main Components
  • Mobile Hosts
  • Backbone Network
  • Wired
  • Wireless Multi-hop
  • Hybrid

47
Wired Backbone
48
Wireless Multi-hop Backbone
49
Hybrid backbone
50
IETF Mobile IP
  • System Components
  • Mobile host
  • Home address
  • Home agent
  • Foreign agent (NOT in V6)
  • Care of address

51
Mobile IP (Cont.)
  • Mobile IP Functionality
  • Agent Discovery
  • Registration
  • Tunneling
  • Optimization
  • Binding Caches
  • Foreign Agent Smooth Handoff

52
Mobile IP (Cont.)
Foreign Agent
Foreign subnet
Home Agent
Arbitrary Topology of Routers and Links
Home subnet
Mobile Host visiting A foreign subnet
Foreign subnet
Mobile Host at Home
Foreign Agent
53
Update in Mobile IP
Mobile Host at Home
54
Two-Tier Update
  • Can we reduce the cost of update?
  • The use of Proxy Agents
  • Neighborhood (Location Area)

55
Tradeoff Between Update and Search
Mobile Host at Home
Location area
