Title: Operating Systems: Introduction

1
Operating Systems Introduction

Joonwon Lee

2
Introduction

Why DO We Study OS?
1. to make a better OS
2. to understand computer systems better.
- We are all computer users !!
3. the capstone of all the computer science
principles
languages, hardware, data structures,
algorithms. ,,,
What Do We Study?
1. Abstraction
OS gives us an illusion that there are infinite
number of CPUs, infinite memory, single world
wide computing, ....
2. System Design
tradeoffs between performance and simplicity
functionality either by hardware or by software
3. How computers work
let's look inside of computers
4. OS Research

3
What this course is about

OS Principles - You've learned a lot from a
textbook
OS research literature
history of OS
current trends in OS research
understand where these trends come from
identify interesting research topics
relate current work to the past
Conducting OS research
learn to produce quality research
identify problem
design an experimental setup
building, measuring, analyzing
practice conducting research (final project)

4
What is OS Research?

Identification of a problem/phenomenon
physical memories are small
CPU is getting faster but IO is NOT that much
applications change often but OS does NOT
personal computing is popular
Hypothesize a solution
Evaluate the hypothesis
Measure
Measure
Measure again
Use real system if possible
gather trace data
instrument existing systems
simulation
analytical investigation
isolate small components

Draw conclusion
use result to suggest new hypotheses
compare results against other's results
Toughest things
there are not necessarily any right answers
no one can tell you with certainty that you are
right
you are never done
large system is difficult to understand

6
Writing a Research Paper

Abstract
introduce area (1 sentence)
state problem/area (1-2 sentences)
summarize conclusions (be quantitative)
Introduction
complete description of problem
state more detailed results
short summary of what's have been done
road map of the paper
Motivation
why is this work important
what horrible things will happen if this work is
not done
what good things will happen if this work is done
why is now the right time to be doing this work

Previous Work
do a thorough literature search (from 60's)
neither more nor less list of references
relate your work to existing work
demonstrate how your work fits in to the grand
scheme of things
What you did
describe your research
be thorough, but concise
The Results
describe experiment setup
explain expected results, reasons for such
expectation
explain surprising difference
visual presentation of data
Conclusions
state results again
state significance of results
tell people what they should have learned

Future Work
what questions still remain
what new questions have arisen
how can your work be extended
General Tips
spell-check very important
grammar-check very difficult for us
style check passive voice, plular, he/she, ...
let the paper sit for a few days before proof
reading
as research is going on, starts writing
write early
write often very important

9
OS Overview

What is an OS
all the code that you didn't write
the code that manages physical (hardware)
resources
provides users with "logical" well-behaved
environment
OS defines a set of logical resources and a set
of well-defined operations on those objects
(interfaces)
provides mechanisms and policies for the control
of objets/resources
controls how different users and programs
interact
Resources managed by an OS
CPU
memory
disk
networks
keyboard, mouse
various IO devices printers, speakers, cameras.
...

10
OS Overview

Major Issues in OS's
structure how is an OS organized?
sharing how are resources shared among users?
naming how are resources named by users or
programs
protection how is one user/program protected
from another
security how to restrict the flow of information
performance why is it so slow?
reliability and fault tolerance when something
goes wrong
extensibility how do we add new features?
communication how and with whom can we
communicate (exchange information)
concurrency how are parallel activities created
and controlled?
scale and growth what happens as demands or
resources increase?
persistency how to make data last longer than
programs
compatibility can we ever do anything new?
distribution accessing the world of information
accounting who pays the bill?

11
OS Overview

Multiprogramming OS
keeps multiple runnable programs loaded in the
memory
overlaps IO processing of a job with computing of
another
benefits from asynchronous IO devices
needs mechanism of interrupts and DMA
tries to optimizes throughput, not response time
Timesharing
each user feels as if she has the entire machine
timesharing tries to optimize response time, not
throughput
needs mechanism of of time-slicing of CPU
timer clock
scheduler
users are permitted to control of the execution
of process
Multics(MIT) was the first large timesharing OS

12
OS Overview

Real Time OS
used for specialized applications
subway systems, flight control, factory
automation, nuclear power plant, and multimedia
basic idea OS guarantees response to physical
events in a fixed time interval
problem how to schedule all the activities in
order to meet all of their critical requirements
with the advent of multimedia applications, all
the OS's will soon see real time needs
Distributed OS
controls facilities distributed geographically
supports communication between parts of jobs or
different jobs
controls sharing of resources
permits parallel processing, but speedup is not
the issue

Parallel OS
runs on various multiprocessor systems
supports parallel applications wishing to get
speedup
needs mechanism to control parallelism
how to divide one task into multiple tasks that
can run in parallel
how to support communications between those
subtasks
how to synchronize the activities of those
subtasks
have to cope with variety in hardware
technologies
inter-processor communication
routing chips or interconnection network
shared memory or message passing

14
Architectural Support for OS

OS and Architecture
the functionality of an OS is limited by
architecture features
the structure of an OS can be simplified by
architectural support
DOS is so primitive due to the lack of hardware
support when it was first designed
Most proprietary OS's were developed with the
architecture
Architectural features for modern OS
timer operation
atomic synchronization operations
memory protection, fast address translation (TLB)
IO control and operations (DMA, IOP)
interrupts and exceptions
OS protection (kernel/user mode)
protected instructions
system calls
partial completion of an instruction

15
System Protection

Protected Instructions
users should not be allowed direct access to
IO devices such as disks, printers, ...
use privileged instructions or memory mapping
memory management states
page table updates,
page table pointers
TLB loads, flush, ...
setting special mode bits
halt instruction (why do we need this?)
OS Protection
how do we know if we can execute a protected
instruction?
architecture must support at least two modes of
operations kernel and user
mode is indicated by a status bit in a protected
processor register
user program executes in used mode the OS
executes in kernel mode
protected instructions can only be executed in
kernel mode.

16
Crossing Protection Boundaries syscall

users have to ask OS to do something privileged
in behalf of them
how does a user program call a kernel mode
service?
system call
system call instructions should be available to
users
required features of a system call
stop what is going on exceptions
specifies the kind of service asked interrupt
vector
specifies the exact contents of the action
parameter passing
saves the status of what is going on so it can be
restored when the service is done
there must be a way to return to user mode

user program
user mode
system call
kernel mode
trap to kernel mode
trap handler
system service routine
OS kernel
17
Memory Protection

OS must protect user programs from each other
must protect OS from user programs
may or may not protect user programs from OS
a simple protection
base and limit registers are loaded by the OS
before the starting of a program
paged virtual memory system or segmented memory
system adopt similar scheme.

prog A
base register
prog C
limit register
prog B
18
Exception

hardware must detect special conditions
page fault, write to read-only page, overflow,
...
must transfer control to OS immediately
hardware must save state of the running process,
so that the faulting process can be restarted
afterwards
what if there is no hardware support
OS should keep checking the condition at a very
high cost

19
Synchronization

interrupts cause potential problem because an
interrupt can occur at any time
non-deterministic race condition
concurrent processes may interfere with each
other
needs an atomic operation at various level
primitive one (test and set) by hardware
software can do this at a high cost
some by programming languages
then, why do we study this in OS courses
OS contains lots of concurrency in itself
synchronization sometimes involves process
management

20
IO Control
device interrupts

IO Control
IO issues
how to start IO operation
IO completion interrupts
interrupts and asynchronous IO

CPU stops current operation, switches to kernel
mode, and saves current PC and other states on
kernel stack
CPU fetches proper vector from vector table and
b ranches to that address (to interrupt handler)
interrupt routine examines device database
and performs actions required by the interrupt
handler completes operation, restores saved
(interrupted) state and returns to user mode (or
calls scheduler to switch to another program)
21
Timer

how does OS prevent infinite loops?
a timer is set to generates an interrupt in a
given time
before a user process begins, OS loads the timer
with a time to interrupt (more primitive hardware
generates interrupts periodically independent of
OS)
when the time arrives, the timer issues an
interrupt, and thus the user program stops and OS
regains control

22
OS Structure and Components

Process Management
a process
execution entity
includes an execution context
an instance of a program in execution (program is
only a file on the disk that is potentially
runnable)
many processes exists
user programs
batch jobs
print spooler, name server, network listener
OS schedules these processes

code stack PC registers
page tables resource counts .......
23
OS Structure and Components

Memory Management
primary memory is the space that is directly
accessible from CPU
program should be in memory to execute
OS must
allocate space for programs to run
deallocates space when needed
mapping virtual to real address (when virtual
memory is used)
decides how much space to allocate to a process,
and when a process should be removed from memory
IO Management
much of OS kernel is concerned with IO
OS provides a standard interface between devices
and programs (user or OS)
need a device driver for each device type
device driver encapsulates device-specific
knowledge, i.e., device commands, device status,
data format, errors, ..

24
OS Structure and Components

Disk Management
disk is the persistent memory, i.e., it endures
system failures (we wish)
OS does
scheduling of disk requests
disk arm movement
error handling
the line between this and the file system is very
fuzzy
File System
raw disk is too crude to be used by user programs
(even for OS)
the file system provides logical objects and
logical operations on those objects
a file is the basic long-term storage entity a
file is a named collection of persistent
information that can be read or written
needs a way to locate information about a file
efficiently
a directory may be itself a file
file system provides standard file operations
the file system also provides general services,
e.g.
backup
maintaining mapping information
accounting and quotas

25
OS Structure and Components

Protection System
when many processes may rub concurrently, all
resource objects need protection
memory
processes
files
devices
protection mechanism helps to detect errors as
well as to prevent malicious destruction
Command Interpreter
interprets user command issued from a keyboard
some systems have it as a standard part of OS
other systems it is just a user program
(replaceable)
others do not have such thing they have iconic
interface
Accounting System
keep track of resource usage
used for enforce quotas, or to generate bills

26
OS Structure

So far, you have seen components of an OS
the issues are
how to organize all of them
what are the entities and where are they
how do these entities cooperate
in reality,
interaction between these components is very
complex
boundaries between them are very fuzzy
but, we have to build an OS that is
working
efficient (performance)
reliable
extensible

27
Traditional Structure

everything in one process monolithic kernel
why monolithic?
that's the way we lived
fast interaction between components (procedure
call)
easy sharing no protection between OS components
why not monolithic?
hard to understand
hard to modify
unreliable a bug in anywhere causes an entire
system crash
hard to maintain

28
Layered Structure

it has been used in structuring many complex
systems
a layer is a virtual machine to the layer above
it
a layer should not be aware of a layer above it
THE (Dijkstra)
why layering?
easy to focus on a small task
easy to build a large system step by step
why not layering?
real systems are more complex than a simple
hierarchy
not flexible
poor performance sue to layer crossing
In real world, systems are often modelled as
layered structures but not built that way

29
Microkernel architecture

a structure in vogue
minimize that goes in the kernel
implement the remaining things of OS as
user-level processes
what for?
better reliability (focus on small part)
ease of extension and customization
any problem? poor performance
interaction between OS components is not
procedure call anymore, it is inter-process
communication
Examples
Hydra (CMU, 1970)
MINIX (Tannenbaum)
CMU March IBM Workplace, OSF/1. ...
Chorus
Microsoft Windows/NT (in a way)

30
Processes

Related OS functions
Coordinator
allow several things to work together in
efficient and fair ways (examples concurrency,
memory protection, file systems, ..)
Standard devices
provide standard facilities that everyone needs
(examples standard libraries, windowing
systems, ..)
Concurrency
OS has to coordinates all the activities on a
machine multiple users, IO activities, etc.
How can it keep all these thing straight?
Answer
Decompose hard problems into simpler ones.
Instead of dealing with everything going on at
once, separate them so that we can deal with one
at a time.
What is a Process?
OS abstraction to represent what is needed to run
a single program (UNIX definition)
A sequential stream of execution in its own
address space (formal definition)

31
Processes

Issues
what are the units of execution?
how are those units of execution represented in
the OS?
how is the work scheduled on the CPU?
what are possible execution states, and how does
the system move from one to another?
What's in a process?
the code for the running program
the data for the running program
an execution stack (for procedure calls)
the program counter indicating the location in
code to execute
a set of registers with current values
a set of OS resources that the process uses
open files, connections to other programs, ..
Process and Programs
There may be many processes running the same
program (Examples vi, cc, ...)
There may be many programs run by a single
process
(Examples cc runs several programs such as cpp,
cc1, cc2, ..)

32
Processes

Process State
Each process has an execution state that
indicates what it's currently doing
ready waiting for CPU allocation
running execution instructions on the CPU
waiting waiting for an event such as IO
completion
As a program executes, the process moves from
state to state
Actions that trigger transition of states
system calls (by itself)
OS rescheduling (by timer interrupt)
interrupts (by external events)

created
scheduler
ready
running
sys call
blocked
terminated
33
Processes

Data Structure for a Process
represents the state of a process
stored in Process Control Block and other area
(u-, u. area)
PCB is accessed by kernel
PCB contains information for OS to manage this
process
process state
process number
hardware context (PC, registers, SP)
memory management information
list of open files
queue pointers to state queues
scheduling information (priority, real -time QOS,
..)
accounting information
IO states, IO in progress
.....etc

some information is in u-area
mapped to the virtual address space of the
process
u-area may be swapped out
u-area may be readable in user mode
difficult for OS to locate information in u-area
u., u-area contains information for executing
this process
user/kernel mode state
state related to system calls
descriptor table
the per-process execution stack for the kernel
resource control (of those that do not need OS
coordination)

35
Processes

Context Switching
happens on timer interrupt, IO request, ..
saves the hardware context in the running PCB
finds a process to run next
loads the values in PCB onto the hardware
registers
time quantum 1 10 ms
State queues
the OS maintains a collection of queues that
represent the state of all processes in the
system.
there is typically one queue for each state
ready, blocked for IO, sleep, wait for signal,
....
there may be many wait queues, one for each type
of wait

ready Q
PCB A
PCB Z
PCB G
sleep Q
PCB C
PCB B
IO Q
PCB R
PCB M
PCB N
36
Processes

PCBs and state queues
PCB is a data structure allocated by OS
PCB is allocated when a process is created
PCB moves from one state queue to another state
queue as the computation goes on
when a process terminates, the PCB is deallocated
Creating a Process
one process can create other processes. These are
child processes and the creator is the parent
the parent usually donates resources and
privileges for its children
a parent may proceeds with its child in parallel
fork()
the child inherits everything from the parent
except for a return code
needs exec() to execute a new program

37
Address Space

What is it?
a range of addresses a thread can access
consists of code, data, heap, stack
How large is it?
the larger the better
with 32 address bits, total 4.3 giga bytes
do we really need all this space?
single address space
OS partitions the total space into many smaller
ones, and allocates each partition to a process
each process uses unique range
need protection mechanism
multiple address spaces
OS maintains multiple spaces of the same range,
e.g., each process is allocated the same
04.3giga space
each process needs a unique mapping from the
address space to real storage

38
Threads

A Full Process includes
an address space defining all the code and data
pages
OS resource and accounting information
a thread of control which defines where the
process is currently executing (PC and registers)
Creating a process is expensive due to all of the
structures (e.g., page tables) that must be
allocated
Communicating between processes is costly,
because most communication goes through the OS
(remember the steps needed to cross protection
boundaries)
Needs for a large number of processes
parallel processing (per parallelism)
large server (per requests)
constructing a large complex system

39
ThreadsThe Thread Model (1)

(a) Three processes each with one thread
(b) One process with three threads

40
The Thread Model (2)

Items shared by all threads in a process
Items private to each thread

41
The Thread Model (3)

Each thread has its own stack

42
Thread Usage (2)

A multithreaded Web server

43
Thread Usage (3)

(a) Dispatcher thread
(b) Worker thread

44
Thread Usage (4)

Three ways to construct a server

45
Implementing Threads in User Space

A user-level threads package

46
User Level Thread

User-Level Threads
to run faster, threads must be in user-level
a user-level thread is managed entirely by the
run-time system
each thread is represented by ..... that is in
user space
all the services related to threads are executed
in user level without kernel involvement
Performance Comparisons
in microseconds
measured on old 3 MIPS hardware

Ultrix
Topaz
FastThreads
fork()
11320
1208
39
signal/wait
1846
229
52
47
User Level Thread 2

User-Level Threads
much faster than kernel threads
lacks in integration with OS
running a process that has no work to do
block a process even when there is a thread ready
to run
remove a process whose thread holds a lock
Solution communication between the kernel and
the user-level thread package
Threads in Solaris 2.x

user thread
kernel thread
CPU
CPU
CPU
48
Implementing Threads in the Kernel

A threads package managed by the kernel

49
Kernel Threads

kernel is aware of the existence of threads
kernel manages threads like processes
slow, because of
a thread operation still requires a kernel call
kernel threads are overly general, in order to
support all the user needs
the kernel does not trust the user, so there must
be lots of checking on kernel calls.

50
How different OSs support threads
address space
thread
Unix
MS/DOS
Xerox/Pilot
Mach, Chorus, NT Solaris, HP/UX
51
Threads - Summary

Why NOT Kernel Threads?
semantic inflexibility
users want different notion of threads - run
time behavior, scheduling, number of threads
poor performance
Why NOT User-Level Threads
blocking system call
lack of coordination between synchronization and
scheduling
lack of convention for sharing among thread
packages

52
Memory Management

What to manage
size illusion of infinite memory
protection protect program and OS
sharing let programs share code, data
Protection
address space
all the addresses a program can touch
all the state that a program affect or be
affected by
MMU translates address generated from CPU
restrict what a program can touch
Dual mode
in kernel mode, can do anything (untranslated)
in user mode, can touch only its own address
space (translated)
how a control transfers from kernel to user

53
Address Translation

Address translation without HW support
uniprogramming (DOS)
OS resides in a fixed location (high memory)
load user program in a fixed location (low
memory)
user program can touch anywhere even an OS
multiprogramming can multiple programs run
without HW support?
yes, by relocating addresses used by load,
store, jump
this is done by linker-loader
still no protection
Hardware Translation

Translation Box (MMU)
real address
Physical Memory
virtual address
CPU
untranslated
54
Base and Bounds

base and bounds
each program is loaded into contiguous region of
physical memory but with protection (Cray-1)
program has illusion that it has its own machine
address from CPU is added with base to form a
real address
address from CPU is checked to see if it is
within bound
only OS can change the base and bounds
hardware cost
2 registers
adder and comparator
performance loss
time to add/compare on every memory reference
cons
difficult to share
hard to grow address space
complex memory allocation (first fit, best fit,
buddy system)

55
Segmentation

Solutions to the above 3 problems of base
bounds
segmentation sharing and resizing
paging sharing and memory allocation
paged segmentation all of them
Segmentation
a table of base and bounds
virtual address table
physical
there are holes in virtual addresses
correct program would not touch that holes
if it does, trap to kernel. OS will take care of
it
pros and cons
efficient for sparse spaces

code
stack
data
data
stack
code
56
Paging

Paging
eases memory allocation problem
virtual memory and physical memory are divided
into many chunks of the same size page
page table maps virtual page number into physical
page number
what if the size of page is very large
internal fragmentation
what if the reverse
lots of space for page table
pros and cons
simple memory allocation
easy to share
- big page table if the address space is sparse

Multi-Level Translation
use tree of tables
segmentation paging
virtual address consists of ltseg , page,
offsetgt
seg indexes into the seg table to find the
address of page table
page indexes into the page table to find the
physical page number
pure multilevel paging
same
Where is the page table
in virtual address space (I said it may be LARGE)
how to translate the address for the page table
(recursion)
keep the page tables for the page tables in
memory
in seg paging, seg tables contains virtual
address for some segments and real address for
some others (HP, MIPS)

58
TLB

address translation needs three memory references
system page table
user page table
for real data
solution use cache
Cache
copy that can accessed more quickly than original
idea make frequent case efficient since
infrequent paths do not matter as much
generic issues in caching
hithow do you know if it is a hit?
miss how do you choose what to replace to make a
room?
consistency

59
TLB

Cacheing in Address Translation
cache recent address translation
TLB (Translation Lookaside Buffer)
hardware table
ltvirtual page number, real page number, control
datagt
how do we know if it is a hit
direct mapped
set-associative
fully-associative
TLB is usually fully associative since it is
small
why is it smaller than memory caches even when it
is referenced at the same frequency?
What to replace?
random since hardware is dumb
LRU if traps to OS (OS is slow)

Consistency
context switch
invalidate all the TLB entries
tag process id
when translation information changes
by paging
invalidate corresponding TLB entry
multiprocessor
each node has its own TLB
problem sources
process migrates back and forth
threads share a TLB even when they run on
different processors
processes share some pages
shoot-down algorithm (Mach)
stall processors to invalidate all the TLBs
with some hardware, selective invalidation is
possible (ask Intel)

61
Issues with 64-bit Address Spaces

Problems
page table is huge for 64-bit address space
inverted page table is not a solution due to
increased physical memory size
most programs use the address space sparsely
Multi-level page tables
PTEs are structured into an n-ary tree
reduces significantly PTEs for unused address
space
when the height of the tree is large
too many memory reference to find a PTE
when it is too small
lose the benefit of multi-level

Hashed page tables
hash function maps a VPN to a bucket
a bucket is a linked list of elements which
consist of
PTE (PPN, attribute, valid bit,..)
VPN (almost 8 bytes)
next pointer (8 bytes)
space overhead 16 bytes per PTE
next pointer can be eliminated by allocating a
fixed number of elements for each bucket
overflow problem remains
Clustered page table
each element of the linked list maps multiple
pages
VPN
next pointer
n PTEs
a memory object (in virtual address) usually
occupies multiple pages
space overhead of the hashed page table is
amortized
more efficient than linear table for sparse space

63
Demand Paging

90-10 rule
Programs spend 90 of their time in 10 of their
code
use main memory as a cache for disk
some pages are in memory
some are on disk
Transparency
user programs should not know paging
restartability hardware must help out by saving
faulting instruction
processor state
problems
side effects of CICS
delayed branches filled with previous instruction
1234(br to X)56 gt 34(br to X)1256
if page faults after br, the saved return address
will be X, and instructions 1,2 will remain
unexecuted
delayed loads
what if fault occurs while previous loads are
still in progress
MVL

Replacement Policies
Optimal
random
FIFO
LRU (least recently used)
LFU (least frequently used)
use Huffman code
Belady's anomaly with FIFO policy, larger
memory sometimes entails more page faults

65
Demand Paging

Implementing LRU
Perfect
keep ordered list of all the pages
clock algorithm
pages form a circle and a hand points a page
use bit of a page is set on each reference
on page fault, OS advances hand
if the use bit is set, clear the use bit (loop
until a page with the use bit clear is found)
replace this page (whose use bit is not set)
partitions pages into young and old
why not k partitions? how?
read undergraduate textbook for more algorithms
