CPSC 441 Computer Graphics: Keyframe AnimationSmooth Curves

1
CPSC 441 Computer Graphics Keyframe
Animation/Smooth Curves

• Jinxiang Chai

2
Outline

• Keyframe interpolation
• Curve representation and interpolation
• - natural cubic curves
• - Hermite curves
• - Bezier curves
• Required readings HB 8-8,8-9, 8-10

3
Computer animation

• Animation
• - making objects moving
• Compute animation
• - the production of consecutive images, which,
  when displayed, convey a feeling of motion.

4
Animation topics

• Rigid body simulation
• - bouncing ball
• - millions of chairs falling down

5
Animation topics

• Rigid body simulation
• - bouncing ball
• - millions of chairs falling down
• Natural phenomenon
• - water, fire, smoke, mud, etc.

6
Animation topics

• Rigid body simulation
• - bouncing ball
• - millions of chairs falling down
• Natural phenomenon
• - water, fire, smoke, mud, etc.
• Character animation
• - articulated motion, e.g. full-body animation
• - deformation, e.g. face

7
Animation topics

• Rigid body simulation
• - bouncing ball
• - millions of chairs falling down
• Natural phenomenon
• - water, fire, smoke, mud, etc.
• Character animation
• - articulated motion, e.g. full-body animation
• - deformation, e.g. face
• Cartoon animation

8
Animation criterion

• Physically correct
• - rigid body-simulation
• - natural phenomenon
• Natural
• - character animation
• Expressive
• - cartoon animation

9
Animation criterion

• Physically correct
• - rigid body-simulation
• - natural phenomenon
• Natural
• - character animation
• Expressive
• - cartoon animation

10
Keyframe animation
11
Outline

• Process of keyframing
• Key frame interpolation
• Hermite and bezier curve
• Splines
• Speed control

12
Oldest keyframe animation

• Two conditions to make moving images in 19th
  century
• at least 10 frames per second
• a period of blackness between images

13
2D Animation

• Highly skilled animators draw the key frames
• Less skilled (lower paid) animators draw the
  in-between frames
• Time consuming process
• Difficult to create physically realistic
  animation

14
3D Animation

• Animators specify important key frames in 3D
• Computers generates the in-between frames
• Some dynamic motion can be done by computers
  (hair, clothes, etc)
• Still time consuming Pixar spent four years to
  produce Toy Story

15
The Process of Keyframing

• Specify the keyframes
• Specify the type of interpolation
• - linear, cubic, parametric curves
• Specify the speed profile of the interpolation
• - constant velocity, ease-in-ease-out, etc
• Computer generates the in-between frames

16
A Keyframe

• In 2D animation, a keyframe is usually a single
• In 3D animation, each keyframe is defined by a
  set of parameters

17
Keyframe parameters

• What are the parameters?
• position and orientation
• body deformation
• facial features
• hair and clothing
• lights and cameras

18
Outline

• Process of keyframing
• Key frame interpolation
• Hermite and bezier curve
• Splines
• Speed control

19
Inbetween frames

• Linear interpolation
• Cubic curve interpolation

20
Linear interpolation

• Linearly interpolate the parameters between
  keyframes

21
Cubic curve interpolation

• We can use three cubic functions to represent a
  3D curve
• Each function is defined with the range 0 lt t
  lt1

22
Compact representation
23
Compact representation
24
Smooth Curves

• Controlling the shape of the curve

25
Smooth Curves

• Controlling the shape of the curve

26
Smooth Curves

• Controlling the shape of the curve

27
Smooth Curves

• Controlling the shape of the curve

28
Smooth Curves

• Controlling the shape of the curve

29
Smooth Curves

• Controlling the shape of the curve

30
Constraints on the cubics

• How many constraints do we need to determine a
  cubic curve?

31
Constraints on the cubics

• How many constraints do we need to determine a
  cubic curve?

32
Constraints on the cubic functions

• How many constraints do we need to determine a
  cubic curve?

33
Constrains on the cubic functions

• How many constraints do we need to determine a
  cubic curve?

34
Constrains on the cubic functions

• How many constraints do we need to determine a
  cubic curve? 4

35
Natural cubic curves
36
Interpolation

• Find a polynomial that passes through specified
  values

37
Interpolation

• Find a polynomial that passes through specified
  values

38
Interpolation

• Find a polynomial that passes through specified
  values

39
Interpolation

• Find a polynomial that passes through specified
  values

40
Interpolation

• Find a polynomial that passes through specified
  values

41
Interpolation

• Perform interpolation for each component
  separately
• Combine result to obtain parametric curve

42
Interpolation

• Perform interpolation for each component
  separately
• Combine result to obtain parametric curve

43
Interpolation

• Perform interpolation for each component
  separately
• Combine result to obtain parametric curve

44
Constraints on the cubic curves

• How many constraints do we need to determine a
  cubic curve? 4
• - does not provide local control of the curve

45
Constraints on the cubic curves

• How many constraints do we need to determine a
  cubic curve? 4
• - does not provide local control of the curve
• Redefine C as a product of the basis matrix M and
  the control vector G C MG

46
Constraints on the cubic curves

• How many constraints do we need to determine a
  cubic curve? 4
• - does not provide local control of the curve
• Redefine C as a product of the basis matrix M and
  the control vector G C MG

MG
47
Constraints on the cubic curves

• How many constraints do we need to determine a
  cubic curve? 4
• - does not provide local control of the curve
• Redefine C as a product of the basis matrix M and
  the control vector G C MG

M
G
48
Constraints on the cubic curves

• How many constraints do we need to determine a
  cubic curve? 4
• - does not provide local control of the curve
• Redefine C as a product of the basis matrix M and
  the control vector G C MG

M?
G?
49
Outline

• Process of keyframing
• Key frame interpolation
• Hermite and bezier curve
• Splines
• Speed control

50
Hermite curve

• A Hermite curve is determined by
• - endpoints P1 and P4
• - tangent vectors R1 and R4 at the
  endpoints

R1
P4
R4
P1
51
Hermite curve

• A Hermite curve is determined by
• - endpoints P1 and P4
• - tangent vectors R1 and R4 at the
  endpoints
• Use these elements to control the curve, i.e.
  construct control vector

R1
P4
R4
P1
Mh
Gh
52
Hermite basis matrix

• Given desired constraints
• - endpoints meet P1 and P4
• Q(0) 0 0 0 1 Mh Gh P1
• Q(1) 1 1 1 1 Mh Gh P4
• - tangent vectors meet R1 and R4

53
Tangent vectors
54
Tangent vectors
55
Hermite basis matrix

• Given desired constraints
• - endpoints meet P1 and P4
• Q(0) 0 0 0 1 Mh Gh P1
• Q(1) 1 1 1 1 Mh Gh P4
• - tangent vectors meet R1 and R4
• Q(0) 0 0 1 0 Mh Gh R1
• Q(1) 3 2 1 0 Mh Gh R4

56
Hermite basis matrix

• Given desired constraints
• - endpoints meet P1 and P4
• Q(0) 0 0 0 1 Mh Gh P1
• Q(1) 1 1 1 1 Mh Gh P4
• - tangent vectors meet R1 and R4
• Q(0) 0 0 1 0 Mh Gh R1
• Q(1) 3 2 1 0 Mh Gh R4

So how to compute the basis matrix Mh?
57
Hermite basis matrix

• We can solve for basis matrix Mh

Mh
58
Hermite basis matrix

• We can solve for basis matrix Mh

Mh
59
Hermite basis matrix
60
Hermite basis function

• Lets define B as a product of T and M
• Bh(t) indicates the weight of each element in Gh

61
Bezier curve

• Indirectly specify tangent vectors by specifying
  two intermediate points

R1
P2
P3
P4
P1
R2
62
Bezier curve

• Indirectly specify tangent vectors by specifying
  two intermediate points

R1
P2
P3
P4
P1
R4
63
Bezier curve

• Indirectly specify tangent vectors by specifying
  two intermediate points

R1
P2
P3
P4
P1
R4
How to compute the basis matrix Mb?
64
Bezier basis matrix

• Establish the relation between Hermite and Bezier
  control vectors

65
Bezier basis matrix

• Establish the relation between Hermite and Bezier
  control vectors

66
Bezier basis matrix

• Establish the relation between Hermite and Bezier
  control vectors

Mhb
Gb
67
Bezier basis matrix

• For Hermite curves, we have
• For Bezier curves, we have

68
Bezier basis matrix

• For Hermite curves, we have
• For Bezier curves, we have

69
Bezier basis matrix
P2
P1
P4
P3
70
Hermite basis function

• Lets define B as a product of T and M
• Bh(t) indicates the weight of each element in Gh

71
Hermite basis function

• Lets define B as a product of T and M
• Bh(t) indicates the weight of each element in Gh

Whats function of this red curve?
72
Hermite basis function

• Lets define B as a product of T and M
• Bh(t) indicates the weight of each element in Gh

Whats function of this red curve? 2t3-3t21
73
Bezier basis functions

• Bezier blending functions are also called
  Bernstein polynomials

74
Bezier basis functions

• Bezier blending functions are also called
  Bernstein polynomials

Whats function of this red curve?
75
Bezier basis functions

• Bezier blending functions are also called
  Bernstein polynomials

Whats function of this red curve? -t33t2-3t1
76
Bezier basis functions

• Bezier blending functions are also called
  Bernstein polynomials

Whats function of this red curve? -t33t2-3t1
77
How to interpolate a 3D curve
y
x
o
z
78
How to interpolate a 3D curve
y
x
o
z
Bezier curve
79
Bezier java applet

• Try this online at
• - Move the interpolation point, see how the
  others (and the point on curve) move
• - Control points (can even make loops)

http//www.cse.unsw.edu.au/lambert/splines/
80
Different basis functions

• Cubic curves
• Hermite curves
• Bezier curves

81
Complex curves

• Suppose we want to draw a more complex curve

82
Complex curves

• Suppose we want to draw a more complex curve

How can we represent this curve?
83
Complex curves

• Suppose we want to draw a more complex curve
• Why not use a high-order Bézier?
• - Wiggly curves
• - No local control

84
Complex curves

• Suppose we want to draw a more complex curve
• Why not use a high-order Bézier?
• - Wiggly curves
• - No local control

• Instead, well splice together a curve from
  individual segments that are cubic Béziers

85
Complex curves

• Suppose we want to draw a more complex curve
• Why not use a high-order Bézier?
• - Wiggly curves
• - No local control

• Instead, well splice together a curve from
  individual segments that are cubic Béziers

86
Complex curves

• Suppose we want to draw a more complex curve
• Why not use a high-order Bézier?
• - Wiggly curves
• - No local control

• Instead, well splice together a curve from
  individual segments that are cubic Béziers

87
Complex curves

• Suppose we want to draw a more complex curve
• Why not use a high-order Bézier?
• - Wiggly curves
• - No local control

• Instead, well splice together a curve from
  individual segments that are cubic Béziers
• Why cubic?
• - Lowest dimension with control for the
  second derivative
• - Lowest dimension for non-planar
  polynomial curves

88
Next lecture

• Spline curve and more key frame interpolation
